Cp* as a removable protecting group: low valent Zn(I)
compounds by reductive elimination, protolytic and
oxidative cleavage of Zn–Cp*†
Cite this: Dalton Trans., 2013, 42, 10540
Kerstin Freitag,a Hung Banh,a Chelladurai Ganesamoorthy,a Christian Gemel,a
Rüdiger W. Seidelb and Roland A. Fischer*a
Zn–Cp* bond cleavage reactions leading to novel monovalent cationic zinc species are presented (Cp* =
F
pentamethylcyclopentadienyl). The treatment of [Zn2Cp*2] with two equiv. of [H(Et2O)2][BAr4F] (BAr4
=
B{C6H3(CF3)2}4) yields the triple-decker complex [Cp*3Zn4(Et2O)2][BAr4F] (1) via protolytic removal of a
Cp* ligand as Cp*H, whereas the reaction with an equimolar amount of [FeCp2][BAr4F] (Cp = cyclopenta-
dienyl) results in the formation of [Cp*Zn2(Et2O)3][BAr4F] (2) under oxidative cleavage of a Cp* ring
giving decamethylfulvalene, (Cp*)2, and [FeCp2] as by-products. The molecular structures of compounds
1 and 2 are established by single-crystal X-ray diffraction studies. A new synthetic pathway for the for-
mation of [Zn2Cp*2] based on the reductive elimination of Cp*H from in situ formed Cp*ZnH is
presented.
Received 10th May 2013,
Accepted 29th May 2013
DOI: 10.1039/c3dt51230d
www.rsc.org/dalton
compounds, the knowledge on related cationic species is still
rather limited. The existence of [Zn2]2+ was first evidenced in
1. Introduction
Although [Zn2Cp*2] (Cp* = pentamethylcyclopentadienyl) was 1967 in a zinc solution of fused ZnCl2,19 but up to now, only
discovered nearly a decade ago by Carmona et al.,1 a possible the dimethylaminopyridine stabilized [Zn2]2+ dication
reaction mechanism for the formation of this remarkable ZnI– [Zn2(dmap)6][Al{OC(CF3)3}4]2 (dmap = 4-dimethylaminopyri-
ZnI bonded species has not yet been fully elucidated. First pos- dine) has been isolated and characterized.15 These results
tulations have been made by Schnepf and Himmel in 2005 suggest that a selective removal of the stabilizing/protecting
where the authors discussed the involvement of active zinc, Cp* moieties from [Zn2Cp*2] is feasible in general and the syn-
formed in disproportionation steps during the reaction, which thetic success will depend on finding the right reaction con-
reduces ZnCp*2.2 This possibility has been ruled out by ditions and sufficiently stabilizing ligand settings for the
Carmona et al. as Rieke-zinc was not strong enough to achieve resulting [Zn2]2+ species. As for the smooth removal of Cp*
reduction and conversion into [Zn2Cp*2].3 Until now, the groups from related GaCp* species we were able to demon-
F
F
favoured perception of the reaction scheme is based on radical strate the suitability of [H(Et2O)2][BAr4
]
(BAr4
=
F
mechanisms in which [Zn2Cp*2] is formed by dimerization of B{C6H3(CF3)2}4) and [FeCp2][BAr4 ] (Cp = cyclopentadienyl). The
the monovalent, radical fragments [Cp*Zn˙].4 The first reports first reagent allows the abstraction by protolytic splitting of
on [Zn2Cp*2] were mostly dealing with the structure and Cp*H, the latter one yields selective oxidation of the Cp*
bonding situation of the Cp* stabilized Zn2 molecule itself, moiety forming decamethylfulvalene as a by-product. Thus,
F
F
recent studies also focus on the synthesis of new Zn2 contain- the reaction of GaCp* with [H(Et2O)2][BAr4
]
(BAr4
=
ing derivatives [Zn2R2] (R ≠ Cp*)4–17 as well as the reactivity of B{C6H3(CF3)2}4) results in the formation of the cation
[Zn2Cp*2] towards aryl or alkyl alcohols in the presence of [Ga2(C5Me5)]+.20 Accordingly, Braun et al. synthesized the
stabilizing nitrogen donors.18 In contrast to neutral organo ZnI triple-decker complex [Zn2Cp*3][BAr4F], emerging from the
reaction of [ZnCp*2] with [H(Et2O)2][BAr4F].21 In addition, we
succeeded in the oxidative cleavage of Ga–Cp* bonds with
[FeCp2][BAr4F] in [M(GaCp*)4] (M = Ni, Pd, Pt) yielding [GaNi-
(GaCp*4)]+ and [(µ2-Ga)nM3(GaCp*)6]n+ (n = 2 for M = Pd and
n = 1 for M = Pt).22 Herein, we report on selective Zn–Cp* clea-
vage reactions of [Zn2Cp*2] leading to cationic species with an
intact ZnI–ZnI bond: [Cp*3Zn4(Et2O)2][BAr4F] is accessible by
protonation of [Zn2Cp*2] with [H(Et2O)2][BAr4F], while
aInorganic Chemistry II, Faculty of Chemistry and Biochemistry, Ruhr-University Bochum,
Universitätsstraße 150, 44780 Bochum, Germany. E-mail: roland.fischer@rub.de
bAnalytical Chemistry, Faculty of Chemistry and Biochemistry, Ruhr-University Bochum,
Universitätsstraße 150, 44780 Bochum, Germany
†Electronic supplementary information (ESI) available. CCDC 928866 and
928867. For ESI and crystallographic data in CIF or other electronic format see
DOI: 10.1039/c3dt51230d
10540 | Dalton Trans., 2013, 42, 10540–10544
This journal is © The Royal Society of Chemistry 2013

View Article Online
Dalton Transactions
Paper
oxidation with [FeCp2][BAr4F] selectively leads to semi-depro- be assigned to [M − (Et2O)2]+ (see the ESI†). Two more signals
tected [Cp*Zn2(Et2O)3][BAr4F]. These studies of selective Cp* at m/z = 602 and 536 indicate the loss of one and two zinc
removal from [Zn2Cp*2] lead us to a new and reliable synthetic atoms, respectively (see the ESI†).
route for the preparation of [Zn2Cp*2] based on a Cp*H reduc-
tive elimination reaction from the precursors [ZnCp*2] and 2.3. Molecular structure of [Cp*3Zn4(Et2O)2][BAr4F] (1)
ZnH2(s) most likely involving in situ formed [Cp*ZnH].
Compound 1·2C6H5F crystallizes in the monoclinic space
group P21/c with four molecules in the unit cell. While Zn1
and Zn4 are η5 bound to terminal Cp* rings, two more Zn
atoms (Zn2 and Zn3) are η3 bound to one bridging Cp* ring
resulting in a “bent” triple-decker sandwich structure (Fig. 1).
The bridging Cp* ligand and the terminal one bound to Zn1
are each disordered over two sites. The Zn–Zn distances are
almost identical with values of 2.310(1) Å for Zn1–Zn2 and
2.307(1) Å for Zn3–Zn4. These bond distances are virtually the
same as the one found in [Zn2Cp*2] (2.305(3) Å) or other Zn2R2
compounds, e.g. [Zn2TpMe22] (Tp = tris(3,5-dimethylpyrazolyl)
hydridoborate).1,14 The approximate Zn–Cp*centroid distances
for the terminal ligands (Zn1–Cp*centroid 1.93 Å, Zn4–Cp*centroid
1.89 Å) are slightly shortened as compared to the mother
compound [Zn2Cp*2] (2.04 Å) or other Zn2R2 compounds like
[{Zn2(η5-C5Me5)(µ-OC5Me5)-(pyr-py)}2] (2.004 Å) or [Cp*2ZnZn-
(dmap)2] (2.033 Å) (dmap = 4-dimethylaminopyridine).1,18,27
However, these ZnCp*centroid distances are all slightly
elongated in comparison to the recently published triple-
decker complex of ZnII, [Zn2Cp*3][BAr4F] (Zn–Cp*centroid 1.828
and 1.830 Å).21 The Zn2–CCp* and Zn3–CCp* distances in 1
2. Results and discussion
2.1. Protolytic cleavage of Zn–Cp* – synthesis of
[Cp*3Zn4(Et2O)2][BAr4F] (1)
The reaction of [H(Et2O)2][BAr4F] with two equivalents of
[Zn2Cp*2] at −25 °C in fluorobenzene leads to the novel double
sandwich complex [Cp*3Zn4(Et2O)2][BAr4F] (1) as a white
powder in yields around 70% (Scheme 1). Colourless crystals
of 1·2C6H5F suitable for single crystal X-ray diffraction were
obtained by slow diffusion of n-hexane into a saturated fluoro-
benzene solution of 1 at −30 °C. The pure solid of 1 is stable
under an inert gas atmosphere at −30 °C but decomposes
rapidly in the solid state at room temperature under formation
of a metallic precipitate.
2.2. Spectroscopic features of [Cp*3Zn4(Et2O)2][BAr4F] (1)
The 1H NMR spectrum of 1 in CD2Cl2 at room temperature
F −
shows the expected set of signals for one [BAr4
] anion (δ =
7.57 (s, 4H) and 7.73 (s, 8H) ppm) and two coordinated diethyl
ether solvent molecules (δ = 1.22 (m, 12H) and 3.63 (m, 8H
ppm)) as well as one signal for the Cp* groups at δ = 2.06 (s,
45H) ppm. Low temperature 1H NMR measurements at −60 °C
show no splitting of the signal which indicates a fast fluxional
process interchanging the terminal and bridging Cp* units.
strongly vary between 2.256(3)–2.451(3) (Zn2–CCp*
) and
2.316(4)–2.572(3) (Zn3–CCp*), due to the η3 binding mode of
the central Cp* ring. This can also be observed in the related
[Zn2Cp*3]+, where the respective distances vary between 2.060(3)
and 2.049(3) Å and 2.396(3) and 2.050(3) Å caused by an η1
binding mode.21 Both Zn–O bonds (Zn2–O2 2.204(4) Å, Zn3–
O1 2.234(4)) are elongated as compared to literature known
The 19F NMR spectrum exhibits one signal at δ = 62.9 ppm for
F −
the CF3 groups of the [BAr4
] anion, as expected. Owing to
the instability of 1 in solution, no 13C NMR spectrum could be
obtained. The FTIR spectrum of 1 shows absorption bands
typical of the Cp* units at 2955, 2887 and 2844 cm−1 and a
band at 1260 cm−1 ascribed to the C–F vibration. Both absorp-
tion bands are well comparable to literature known
examples.23–26
Liquid injection field desorption ionization mass spec-
trometry (LIFDI-MS) displays a signal at m/z = 668, which can
Fig. 1 Molecular structure of the cation [Zn4Cp*3(Et2O)2]+ in the crystal of
1·2C6H5F. Displacement ellipsoids are drawn at the 30% probability level. For
the sake of clarity, disorder of the Cp* ligands and hydrogen atoms are omitted.
Selected interatomic distances (Å) and angles (°): Zn1–Zn2 2.310(1), Zn3–Zn4
2.307(1), Zn2–O2 2.204(4), Zn3–O1 2.234(4), Zn2–C31 2.442(3), Zn2–C32
2.256(4), Zn2–C33 2.402(3), Zn3–C33 2.572(3), Zn3–C43 2.316(4), Zn3–C35
2.412(4), Zn1–Cp*centroid 1.935, Zn4–Cp*centroid 1.899; Cp*centroid–Zn1–Zn2 165.86,
Cp*centroid–Zn3–Zn4 170.92.
Scheme 1 Synthesis of [Zn2Cp*2] by reductive elimination of Cp*H and for-
mation of the cations [Cp*3Zn4(Et2O)2]+ and [Cp*Zn2(Et2O)3]+ from [Zn2Cp*2] by
selective protolysis or oxidative cleavage.
This journal is © The Royal Society of Chemistry 2013
Dalton Trans., 2013, 42, 10540–10544 | 10541

View Article Online
Paper
Dalton Transactions
Zn–OEt2 bond distances, which range from 1.997 Å in
[Ph2SiO]8[AlO(OH)]2[AlO2]2[Zn(OH)]2·2(OEt2) to 2.163 Å in [(R,R)-
(N,N′-bis(3,5-di-tert-butylsalicylidene)-1,2-diphenylethylene-
diamino)(diethyl ether)zinc(II)], indicating a rather weak Zn–
OEt2 interaction in 1.28,29 The angles Zn–Zn–Cp*centroid exhibit
values of 165.86(4)° (Zn2–Zn1–Cp*centroid) and 170.92(4)° (Zn3–
Zn4–Cp*centroid), respectively, which results in a significant
deviation from linearity, possibly due to steric reasons. This
deviation can also be observed in similar compounds with
additional coordinated donor ligands to the ZnZnCp* unit, e.g.
[Zn2Cp*(OArMes)(pyr-py)2] (175.6°) or [Zn2Cp*(µ-OC5Me5)(pyr-py)]2
(167.2°).18
2.4. Oxidative cleavage of Zn–Cp* – synthesis of
semi-protected [Cp*Zn2(Et2O)3][BAr4F] (2)
Treatment of [Zn2Cp*2] with an equimolar amount of [FeCp2]-
[BAr4F] at room temperature in diethyl ether leads to an oxi-
Fig. 2 Hydrogen atoms and the disorder of the complex are omitted for clarity.
Selected interatomic distances (Å) and angles (°): Zn1–Zn2 = 2.324(2), ca. Zn2–
Cp*centroid = 1.92, Zn1–O1 = 2.117(4), Zn1–O2 = 2.096(4), Zn1–O3 = 2.076(4);
dative cleavage of
a
Cp* moiety and formation of
[Cp*Zn2(Et2O)3][BAr4F] (2) as a grey powder with a yield of 71%
(Scheme 1). Ferrocene and decamethylfulvalene (Cp*)2 can
both be observed as stoichiometric by-products by in situ 1H
NMR spectroscopy. Although the compound is stable as a
microcrystalline powder at −30 °C under an inert gas atmos-
phere, it gradually decomposes at room temperature in the
solid state and more rapidly in solutions of fluorobenzene,
diethyl ether or dichloromethane under precipitation of
metallic particles.
Cp*centroid–Zn2–Zn1
= 174.47, Zn2–Zn1–O1 = 121.99(15), Zn2–Zn1–O2 =
120.54(12), Zn2–Zn1–O3 = 121.71(14).
ligand from the parent compound [Zn2Cp*2] is replaced by
three Et2O molecules, while the second Zn atom is still co-
ordinated by an η5-Cp* moiety. In the crystal, the entire
complex is disordered over two sites. Compared to [Zn2Cp*2]
(2.305(3) Å) the Zn–Zn bond of 2 is slightly elongated (2.324(2)
Å).1 However this value is in the range of other reported ZnI–
ZnI bond lengths, such as [Zn2(dpp-bian)2] (dpp-bian = 1,2-bis-
[(2,6-diisopropylphenyl)imino]acenaphthene) (2.332(2) Å).7
The Zn2–Cp*centroid distance of approximately 1.92 Å is com-
parable with the Zn1–Cp*centroid and Zn4–Cp*centroid distances
of compound 1 and accordingly distinctly shorter than in
[Zn2Cp*2] (2.04 Å).1 Compound 2 shows a deviation of the
angle Zn1–Zn2–Cp*centroid (170.31°) from linearity, similar to
other ZnI–ZnI compounds with coordinated donor ligands
([Zn2(η5-C5Me5)(OArMes)(pyr-py)2] (175.6°), [Zn2(η5-C5Me5)-
(µ-OC5Me5)(pyr-py)]2 (167.2°) or [Zn2Cp*2(dmpa)2] (159.6°)).18,27
The Zn1–O1, Zn1–O2 and Zn1–O3 distances are 2.117(4), 2.096(4)
and 2.076(4) Å, respectively, which are very close to those of
other Zn–Et2O complexes such as [EtZn(OEt2)3][B(C6F5)4]
(2.110(2), 2.072(2) and 2.031(2) Å).30 There is a major differ-
ence between the Zn–Zn–O angles of compound 1 with
109.66(11) and 110.2(1)° and compound 2 whose values range
from 120.54(12) to 121.99(15)°.
2.5. Spectroscopic features of [Cp*Zn2(Et2O)3][BAr4F] (2)
The 1H NMR spectrum of 2 in CD2Cl2 at room temperature
exhibits two signals for the [BAr4 ]
F − anion (δ = 7.56 (s, 4H) and
7.71 (s, 8H)), two resonances corresponding to the coordinated
Et2O molecules (δ = 1.25 (t, 18H) and 3.69 (q, 12H) ppm) and
one peak for the Cp* moiety (δ = 2.08 (s, 15H) ppm). At room
temperature additional signals are observed due to decompo-
sition of the compound: at 8.24 and 8.02 ppm (BArF) in a ratio
of 1 : 2.
The coordinated Et2O molecules in 2 can be exchanged by
1
THF molecules at room temperature: the H NMR spectrum of
1 in THF-d8 at room temperature shows signals for non-
coordinated Et2O at δ = 3.39 (q) and 1.12 (t) ppm as well as two
F −
resonances for the [BAr4
] anion (δ = 7.58 (s, 4H) and 7.79 (s,
8H)) and one peak for the Cp* unit at δ = 2.07 (s, 15H) ppm.
Solutions of 1 in THF are apparently less temperature sensitive
than solutions in other solvents like fluorobenzene, CH2Cl2 or
Et2O. The FTIR spectrum of 2 reveals typical bands for the Cp*
ring at 2963, 2889 and 2845 cm−1 as well as a signal due to the
2.7. Mechanism of the [Zn2Cp*2] formation via elimination
of Cp*H
C–F vibration at 1265 cm−1
2.6. Molecular structure of [Cp*Zn2(Et2O)3][BAr4F] (2)
.
The convenient and high-yield elimination of Cp*H from
[Zn2Cp*2] by addition of an external proton source (intermole-
Colourless crystals appropriate for single crystal X-ray diffrac- cular attack on Zn–Cp*) prompted us to study the Cp*H elimi-
tion were obtained by slow diffusion of n-hexane into a fluoro- nation reaction also in systems with an internal hydrogen
benzene solution of 2 at −30 °C. Compound 2 crystallizes in source, i.e. zinc-hydride moiety. Notably, such a very selective,
the orthorhombic space group Pbca. Note that the cation is intramolecular reductive elimination reaction in main group
fully disordered. The coordination geometry of the Cp*Zn2O3 organometallic chemistry has recently been reported for the
unit resembles an “elongated” piano stool (Fig. 2). One Cp* aluminium complexes [Cp*AlH2] and [Cp*2AlH]: heating a
10542 | Dalton Trans., 2013, 42, 10540–10544
This journal is © The Royal Society of Chemistry 2013

View Article Online
Dalton Transactions
Paper
(CF3)3}4]2,15 contain weakly coordinating anions, indicating
the need of such components for a successful isolation of the
di-zinc species. The selective Cp*H elimination turned out as
the key step in the formation of [Zn2Cp*2] from ZnH2 and
ZnCp*2 whereby [ZnCp*H] is suggested to be the crucial inter-
mediate and a new, reliable synthesis of [Zn2Cp*2] was develo-
ped. Apparently, efficient nucleophilic reaction mechanisms,
i.e. intramolecular hydride migration, are possible at the Zn
centre and allow selective Zn–Cp* bond splitting to yield the
desired ZnI compound. From these data it can be expected
that the lability of the Zn–Cp* bond towards both, electrophilic
(protonation) and nucleophilic (hydride) attack and as well
single electron oxidation allow new approaches to other cat-
ionic ZnI products. Moreover it is reasonable to assume that
the reported chemistry may offer valuable precursors and reac-
tion concepts for the formation of intermetallic Zn-rich
clusters.32
Scheme 2 Formation of [Zn2Cp*2] from [ZnCp*2] and ZnH2.
solution of [Cp*AlH2] leads quantitatively to metallic alu-
minium, Cp*H (and presumably H2). Accordingly, reductive
elimination of Cp*H from [Cp*2AlH] represents a new high
yield access to AlCp*.31 Indeed, the reaction of [ZnCp*2] and
ZnH2 in a 3 : 1 molar ratio in THF affords [Zn2Cp*2] and Cp*H
1
in yields around 65%. As shown by H NMR spectroscopy, the
only observed species are the reaction products [Zn2Cp*2] and
Cp*H as well as the starting compound [ZnCp*2]. The yield of
the products depends only on the molar ratio of starting com-
pounds. The reaction proceeds quantitatively, however, the
product [Zn2Cp*2] itself is reactive towards ZnH2 leading to
metallic Zn and Cp*H. By suitable adjustment of reactant con-
centration and molar ratios this undesired decomposition can
be slowed down very considerably and isolated yields of
[Zn2Cp*2] up to 65% (based on Zn) can be obtained. The com-
parison with [Cp*2AlH] suggests that the reaction mechanism
is likely to involve a soluble, unstable intermediate, presum-
ably [Cp*ZnH], which is formed via a heterogeneous reaction
of pure, insoluble ZnH2(s) and soluble [ZnCp*2]. This inter-
mediate [Cp*ZnH] spontaneously reacts with another equi-
valent of [ZnCp*2] to give [Zn2Cp*2] via reductive elimination
of Cp*H (Scheme 2). Preliminary kinetic studies are in agree-
ment with that reasoning (Fig. S8†), however, a more detailed
analysis of this reaction is needed and currently ongoing. The
results will be published elsewhere together with theoretical
calculations, similar to the related [Cp*2AlH] case.30
It should be noted that the possible pathway for [Zn2Cp*2]
formation suggested herein agrees well with the literature: an
appropriate mixture of [ZnCp*2], ZnCl2 and KH most likely gives
a similar distribution of intermediates and products as the com-
bination of [ZnCp*2] with pure, preformed ZnH2. However, the
reaction of [ZnCp*2] with ZnR2 (R = Et, Ph) at low temperature,
which is the second (and low yield) route to [Zn2Cp*2] known in
the literature, cannot be explained by a similar (intra/inter-
molecular) reductive Cp*H elimination mechanism.3
Acknowledgements
This work was funded by the German Research Foundation
(Fi-502/23-2). K.F. is grateful for a Ph.D. scholarship provided
by the German Chemical Industry Fund (https://www.vci.de/
fonds) and for the support of the Ruhr University Research
School (http://www.research-school.rub.de). We thank the
Linden CMS GmbH for support in mass spectrometry.
Notes and references
1 I. Resa, E. Carmona, E. Gutierrez-Puebla and A. Monge,
Science, 2004, 305, 1136–1138.
2 A. Schnepf and H. J. Himmel, Angew. Chem., Int. Ed., 2005,
44, 3006–3008.
3 D. del Rio, A. Galindo, I. Resa and E. Carmona, Angew.
Chem., Int. Ed., 2005, 44, 1244–1247.
4 A. Grirrane, I. Resa, A. Rodriguez, E. Carmona, E. Alvarez,
E. Gutierrez-Puebla, A. Monge, A. Galindo, R. D. Del and
R. A. Andersen, J. Am. Chem. Soc., 2007, 129, 693–703.
5 Y. Wang, B. Quillian, P. Wei, H. Wang, X.-J. Yang, Y. Xie,
R. B. King, P. V. R. Schleyer, H. F. Schaefer III and
G. H. Robinson, J. Am. Chem. Soc., 2005, 127, 11944–11945.
6 Z. Zhu, R. J. Wright, M. M. Olmstead, E. Rivard, M. Brynda
and P. P. Power, Angew. Chem., Int. Ed., 2006, 45, 5807–5810.
7 I. L. Fedushkin, A. A. Skatova, S. Y. Ketkov, O. V. Eremenko,
A. V. Piskunov and G. K. Fukin, Angew. Chem., Int. Ed.,
2007, 46, 4302–4305.
3. Conclusions
In this contribution we presented two routes to unusual cat-
ionic low valent zinc species based on the selective cleavage of
a Cp* ligand from [Zn2Cp*2]. Protonation with [H(Et2O)2]-
[BAr4F] yields the triple-decker complex [Cp*3Zn4(Et2O)2]+ and
oxidation with [FeCp2][BAr4F] leads to the formation of semi-
8 Y. C. Tsai, D. Y. Lu, Y. M. Lin, J. K. Hwang and J. S. Yu,
Chem. Commun., 2007, 4125–4127.
9 X.-J. Yang, J. Yu, Y. Liu, Y. Xie, H. F. Schaefer, Y. Liang and
B. Wu, Chem. Commun., 2007, 2363.
protected [Cp*Zn2(Et2O)3]+. Both cations exhibit intact ZnI–ZnI 10 J. Yu, X.-J. Yang, Y. Liu, Z. Pu, Q.-S. Li, Y. Xie, H. F. Schaefer
units, which are stabilized by substitution labile solvent mole-
and B. Wu, Organometallics, 2008, 27, 5800–5805.
(1) and 11 Y. Liu, S. Li, X.-J. Yang, P. Yang, J. Gao, Y. Xia and B. Wu,
] (2) as well as [Zn2(dmap)6][Al{OC- Organometallics, 2009, 28, 5270–5272.
F
cules. Note that the [Cp*3Zn4(Et2O)2][BAr4
[Cp*Zn2(Et2O)3][BAr4
]
F
This journal is © The Royal Society of Chemistry 2013
Dalton Trans., 2013, 42, 10540–10544 | 10543

View Article Online
Paper
Dalton Transactions
12 P. Yang, X. J. Yang, J. Yu, Y. Liu, C. Zhang, Y. H. Deng and 23 D. del Rio, I. Resa, A. Rodriguez, L. Sánchez, R. Köppe,
B. Wu, Dalton Trans., 2009, 5773–5779.
A. J. Downs, C. Y. Tang and E. Carmona, J. Phys. Chem. A,
2008, 112, 10516–10525.
24 P. Jutzi, B. Neumann, L. O. Schebaum, A. Stammler and
H.-G. Stammler, Organometallics, 1999, 18, 4462–4464.
25 T. Bollermann, K. Freitag, C. Gemel, R. W. Seidel and
R. A. Fischer, Organometallics, 2011, 30, 4123–4127.
13 H. P. Nayek, A. Luehl, S. Schulz, R. Koeppe and
P. W. Roesky, Chem.–Eur. J., 2011, 17, 1773–1777.
14 S. Gondzik, D. Blaser, C. Wolper and S. Schulz, Chem.–Eur.
J., 2010, 16, 13599–13602.
15 S. Schulz, D. Schuchmann, I. Krossing, D. Himmel,
D. Blaser and R. Boese, Angew. Chem., Int. Ed., 2009, 48, 26 T. Bollermann, T. Cadenbach, C. Gemel, K. Freitag,
5748–5751.
M. Molon, V. Gwildies and R. A. Fischer, Inorg. Chem.,
2011, 50, 5808–5814.
27 D. Schuchmann, U. Westphal, S. Schulz, U. Florke,
D. Blaser and R. Boese, Angew. Chem., Int. Ed., 2009, 48,
807–810.
28 M. Veith, H. Hreleva-Carparrotti and V. Huch, J. Organomet.
Chem., 2007, 692, 2784–2788.
29 N. Meyer and P. W. Roesky, Z. Anorg. Allg. Chem., 2007, 633,
2292–2295.
30 D. A. Walker, T. J. Woodman, D. L. Hughes and
M. Bochmann, Organometallics, 2001, 20, 3772–3776.
31 C. Ganesamoorthy, S. Loerke, C. Gemel, P. Jerabek,
M. Winter, G. Frenking and R. Fischer, Chem. Commun.,
2013, 49, 2858–2860.
16 S. Schulz, D. Schuchmann, U. Westphal and M. Bolte, Orga-
nometallics, 2009, 28, 1590–1592.
17 S. Schulz, S. Gondzik, D. Schuchmann, U. Westphal,
L. Dobrzycki, R. Boese and S. Harder, Chem. Commun.,
2010, 46, 7757–7759.
18 M. Carrasco, R. Peloso, A. Rodriguez, E. Alvarez, C. Maya
and E. Carmona, Chem.–Eur. J., 2010, 16, 9754–9757.
19 D. H. Kerridge and S. A. Tariq, J. Chem. Soc. A, 1967, 1122–
1125.
20 B. Buchin, C. Gemel, T. Cadenbach, R. Schmid and
R. A. Fischer, Angew. Chem., Int. Ed., 2006, 45, 1074–1076.
21 M. A. Chilleck, T. Braun and B. Braun, Chem.–Eur. J., 2011,
17, 12902–12905.
22 M. Halbherr, T. Bollermann, C. Gemel and R. A. Fischer, 32 T. Bollermann, C. Gemel and R. A. Fischer, Coord. Chem.
Angew. Chem., Int. Ed., 2010, 49, 1878–1881.
Rev., 2012, 256, 537–555.
10544 | Dalton Trans., 2013, 42, 10540–10544
This journal is © The Royal Society of Chemistry 2013
