Tetrahedron
Letters
Tetrahedron Letters 45 (2004) 7095–7097
Synthesis of (+)-(1S,2R) and
(À)-(1R,2S)-2-aminocyclobutane-1-carboxylic acids
Christine Gauzy, Elisabeth Pereira, Sophie Faure and David J. Aitken*
´
´
Laboratoire SEESIB-CNRS, Departement de Chimie, Universite Blaise Pascal, Clermont-Ferrand II,
`
24 Avenue des Landais, 63177 Aubiere cedex, France
Received 8 May 2004; revised 19 July 2004; accepted 24 July 2004
Available online 13 August 2004
Abstract—(+)-(1S,2R) and (À)-(1R,2S)-2-aminocyclobutane-1-carboxylic acids have been prepared in >97% ee and in 33% and 20%
overall yields starting from a single, chiral, bicyclic compound perceived as a chiral uracil equivalent. Construction of the cyclo-
butane ring is achieved via a [2+2] photocycloaddition reaction of this chiral precursor with ethylene.
ꢀ 2004 Elsevier Ltd. All rights reserved.
The incorporation of conformationally constrained b-
amino acids into peptides can dramatically influence
their secondary and tertiary structures and biological
activities.1 In consequence, interest for the synthesis
and study of alicyclic b-amino acids has rapidly in-
creased.2 Most efforts are devoted to cyclohexane,3
cyclopentane4 and cyclopropane5 derivatives. Indeed,
oligopeptide chains containing trans-2-aminocyclohex-
anecarboxylic acid have been shown to adopt 14-helical
structures while those containing trans-2-aminocyclo-
pentanecarboxylic acid prefer 12-helices.3b cis-Cyclopro-
pane derivatives, too, give highly stable helical
conformations in peptides.5c Moreover, some alicyclic
b-amino acid derivatives display antifungal, antibiotic
or analgesic activities.2,6 Despite the clear potential of
cyclobutane b-amino acid building blocks in this con-
text, and some positive indications of their ability to im-
pose secondary structure from preliminary studies,7,8a
there are currently very few means of access to these
compounds.
the first case and alkaloid-mediated opening of the
anhydride in the second. Subsequent transformations
led to the (À)-(1R,2S) antipode in each case. We present
here an alternative strategy allowing rapid access to
both enantiomers using simple and easily accessible
materials.
We previously described the synthesis of racemic 2-
aminocyclobutane-1-carboxylic acid ( )-4.10 The strat-
egy was based on a photochemical reaction of ethylene
(1) with uracil (2) to give the cyclobutane adduct ( )-
3, followed by controlled degradation of the heterocyclic
ring. The target amino acid ( )-4 was obtained with an
overall yield of 52% (Scheme 1).
Our aim was to develop an enantioselective version of
this synthesis. To this end, we decided to introduce a
chiral auxiliary on the uracil ring in order to induce dia-
stereochemical discrimination of cyclobutane adducts.
There was also the possibility for diastereofacial selec-
tion during the photochemical [2+2] reaction,11
although results with ethylene as one of the reaction
components are highly variable.12 We selected to use
Only two enantioselective syntheses of cis-2-aminocyclo-
butane-1-carboxylic acid have been described so far: first
8
9
´
`
by Martın-Vila et al. and then recently by Bolm et al.
Both procedures are based on an enantioselective meso-
cyclobutane-1,2-dicarboxylic acid desymmetrization
strategy, involving enzymatic hydrolysis of a diester in
O
O
H
H
H
CO2H
NH2
hν
NH
O
NH
O
N
H
N
H
H
Keywords: b-Amino acid; Cyclobutane; Stereoselective synthesis; [2+2]
Photocycloaddition reaction.
( ) -
1
4
2
( ) -
3
*
Corresponding author. Tel.: +33 4 73 40 71 84; fax: +33 4 73 40 77
17; e-mail: aitken@chimie.univ-bpclermont.fr
Scheme 1.
0040-4039/$ - see front matter ꢀ 2004 Elsevier Ltd. All rights reserved.
doi:10.1016/j.tetlet.2004.07.110

7096
C. Gauzy et al. / Tetrahedron Letters 45 (2004) 7095–7097
the N1-substituted uracil mimic (R)-5. This bicyclic
compound was easily obtained in enantiomerically pure
form in two steps from commercial (R)-phenylglycinol,
essentially as described by Agami et al. for the S-
enantiomer.13
column chromatography on silica gel, giving both (À)-
6 and (À)-7 in stereochemically pure form in 49% and
31% yield, respectively. Subsequent transformations
were carried out under identical conditions for each pure
compound.
Compound (R)-5 was submitted to [2+2] photocyclo-
addition reaction conditions (Scheme 2). Ethylene (1)
was bubbled through a solution of (R)-5 in acetone at
room temperature, which was irradiated with a 400W
medium-pressure mercury lamp fitted with a Pyrex filter
during 2h. In the event, the desired cyclobutane adduct
was obtained as a mixture of two diastereoisomers. In
conformity with our previous study involving uracil 2
(Scheme 1),10 cyclobutane compounds (À)-6 and (À)-7
each had a cis configuration; a de of 14% was deter-
mined by integration of 1H NMR data obtained on
the crude material. Separation was easily achieved by
Selective opening of the five-membered rings of (À)-6
and (À)-7 was achieved by catalytic hydrogenation in
the presence of palladium on charcoal, as described by
Agami et al. for related heterocyclic structures.13 Single
diastereoisomers (À)-8 and (À)-9 were thus obtained in
effectively quantitative yield.
Next, the a-methylbenzyl group was removed cleanly
and efficiently with refluxing formic acid.14 We thus ob-
tained enantiomers (+)-3 and (À)-3 whose spectroscopic
data were identical with those of our previous sample of
( )-3.10 The two-step transformation of the heterocyclic
ring––involving mild base hydrolysis followed by diazo-
tization with 1equiv of sodium nitrite in acidic med-
ium––followed by purification on ion exchange resin
proceeded in good yield without trace of epimerization
and led to the target b-amino acids (+)-4 and (À)-4 in
zwitterionic form (Scheme 2). NMR spectroscopic
data15 were comparable with those for racemic mate-
rial10 and with those reported by Bolm et al.9 for (À)-4.
O
N
+
N
O
1
Ph
(R)-5
hν, pyrex
acetone, r.t.
The overall yields following this short sequence were
33% and 20% for (+)-4 and (À)-4, respectively, from
(R)-5. Their respective optical rotations were +71 (c
0.88, H2O) and À70 (c 1.03, H2O). We determined an
enantiomeric excess of >97% for each enantiomer (+)-
4 and (À)-4 by HPLC on chiral column.16 Since the ee
31 %
49 %
separation of diastereomers
O
N
O
N
H
H
H
N
N
1
of (R)-5 was 98%, as determined by H NMR with the
O
O
chiral shift reagent Eu(hcf)3, we can conclude that there
was no loss of stereochemical fidelity during the
synthesis.
H
Ph
Ph
(-)-6
(-)-7
H2, Pd-C 10 %
EtOH, r.t.
99 %
100 %
The attribution of the 1R,2S absolute configuration
of the b-amino acid (À)-4 was made by correlation with
O
N
O
N
H
H
8
´
`
the previous observations made by Martın-Vila et al.
and Bolm et al.9 The absolute configuration of (+)-4 is
therefore 1S,2R.
NH
O
NH
O
H
Ph
H
Ph
(-)-9
(-)-8
In summary, we have succeeded in synthesizing both
(+)-(1S,2R) and (À)-(1R,2S)-2-aminocyclobutane-1-
carboxylic acid 4 in five steps from (R)-5. Previous
desymmetrization based stereoselective syntheses started
with derivatives of cis-cyclobutane-1,2-dicarboxylic
acid, which, although commercially available, is rather
expensive. Our synthesis represents a useful complemen-
tary strategy and provides the first described access to
the (+) antipode.17 Millimolar-range quantities of the
title b-amino acids are routinely accessible in this way
and their incorporation into peptides is currently under
study.
HCO2H
reflux
83 %
H
77 %
O
O
H
NH
NH
N
H
(-)-3
O
N
H
(+)-3
O
H
H
1) NaOH, r.t.
2) NaNO2, HCl, r.t.
3) ion exchange resin
83 %
85 %
H
H
H
COOH
NH2
COOH
NH2
Acknowledgements
H
(-)-4
We are grateful to the MENRT for a grant (to C.G.)
and the CNRS for ÔJeune EquipeÕ (AIP) funding. We
also thank undergraduate students E. Rossignol (Cler-
(+)-4
Scheme 2.

C. Gauzy et al. / Tetrahedron Letters 45 (2004) 7095–7097
7097
Ortun˜o, R. M. Tetrahedron: Asymmetry 2000, 11,
mont-Ferrand) and P. Ferchaud (Poitiers) for carrying
out some initial experiments competently.
´
`
´
3569–3584; (b) Martın-Vila, M.; Minguillon, C.; Ortun˜o,
R. M. Tetrahedron: Asymmetry 1998, 9, 4291–4294.
9. Bolm, C.; Schiffers, I.; Atodiresei, I.; Hackenberger, C. P.
R. Tetrahedron: Asymmetry 2003, 14, 3455–3467.
10. Aitken, D. J.; Gauzy, C.; Pereira, E. Tetrahedron Lett.
2002, 43, 6177–6179.
References and notes
1. (a) North, M. J. Pept. Sci. 2000, 6, 301–313; (b) Cheng, R.
P.; Gellman, S. H.; DeGrado, W. F. Chem. Rev. 2001, 101,
3219–3232.
11. Bach, T. Synthesis 1998, 683–703.
12. (a) Meyers, A. I.; Fleming, S. A. J. Am. Chem. Soc. 1986,
´
108, 306–307; (b) Alibes, R.; Bourdelande, J. L.; Font, J.;
2. Fulo¨p, F. Chem. Rev. 2001, 101, 2181–2204.
¨
Gregori, A.; Parella, T. Tetrahedron 1996, 52, 1267–1278;
(c) Tsujishima, H.; Nakatani, K.; Shimamato, K.; Shigeri,
Y.; Yumoto, N.; Ohfune, Y. Tetrahedron Lett. 1998, 39,
1193–1196; (d) de March, P.; Figuerdo, M.; Font, J.;
Raya, J. Tetrahedron Lett. 1999, 40, 2205–2208.
3. (a) Appella, D. H.; Christianson, L. A.; Karle, I. L.;
Powell, D. R.; Gellman, S. H. J. Am. Chem. Soc. 1999,
121, 6206–6212; (b) Barechi, J. J., Jr.; Huang, X.; Appalla,
D. H.; Christianson, L.; Durell, S. R.; Gellman, S. H. J.
Am. Chem. Soc. 2000, 122, 2711–2718; (c) Raguse, T. L.;
Porter, E. A.; Weisblum, B.; Gellman, S. H. J. Am. Chem.
Soc. 2002, 124, 12774–12785.
13. (a) Agami, C.; Dechoux, L.; Melaimi, M. Org. Lett. 2000,
2, 633–634; (b) Agami, C.; Cheramy, S.; Dechoux, L.;
Melaimi, M. Tetrahedron 2001, 57, 195–200.
4. (a) Appella, D. H.; Christianson, L. A.; Klein, D. A.;
Huang, X.; Barchi, J. J.; Powell, D. R.; Gellman, S. H.
Nature (London) 1997, 387, 381–384; (b) Appella, D. H.;
Christianson, L. A.; Klein, D. A.; Richards, M. R.;
Powell, D. R.; Gellman, S. H. J. Am. Chem. Soc. 1999,
´
14. (a) Semple, J. E.; Wang, P. C.; Lysenko, Z.; Joullie, M. J.
Am. Chem. Soc. 1980, 102, 7505–7510; (b) Davies, S. G.;
Fenwick, D. R.; Ichihara, O. Tetrahedron: Asymmetry
1997, 8, 3387–3391; (c) Magnus, N. A.; Confalone, P. N.;
Storace, L. Tetrahedron Lett. 2000, 41, 3015–3019.
15. Compounds (+)-4 and (À)-4: 1H NMR (400MHz,
D2O, calibration on 1,4-dioxane at dH 3.75ppm) d 1.75
(m, 1H), 1.95 (m, 2H), 2.03 (m, 1H), 2.92 (m, 1H), 3.61
(q, 1H, J = 6.8Hz); 13C NMR (100MHz, D2O, calibration
on 1,4-dioxane at dC 67.2ppm) d 21.2, 25.0, 41.3, 45.5,
181.0.
16. HPLC analysis was performed using a Waters 590
apparatus equipped with a Waters 484 UV detector and
a Crownpak CR(+) column (0.4 · 15cm) with the follow-
ing conditions: perchloric acid solution (pH = 1) as mobile
phase; T = 4ꢁC; k = 220nm; flow rate = 0.2mL/min.
Retention times: (+)-4: 12.20min; (À)-4: 19.48min.
17. It is also worth noting that this route incurs no difficulties
related to the facile ring-opening propensity of the final
products; see: Aitken, D. J.; Gauzy, C.; Pereira, E.
Tetrahedron Lett. 2004, 45, 2359–2361.
121, 7574–7581; (c) Fulo¨p, F. Stud. Nat. Prod. Chem.
2000, 22, 273–306.
¨
5. (a) Hibbs, D. E.; Hursthouse, M. B.; Jones, I. G.; Jones,
W.; Abdul Malik, K. M.; North, M. Tetrahedron 1997, 53,
17417–17424; (b) Gnad, F.; Reiser, O. Chem. Rev. 2003,
103, 1603–1623; (c) De Pol, S.; Zorn, C.; Klein, C. D.;
Zerbe, O.; Reiser, O. Angew. Chem., Int. Ed. 2004, 43,
511–514.
6. Mittendorf, J.; Kunisch, F.; Matzke, M.; Militzer, H.-C.;
Schmidt, A.; Scho¨nfeld, W. Bioorg. Med. Chem. Lett.
2003, 13, 433–436.
´
`
7. Izquierdo, S.; Martın-Vila, M.; Moglioni, A. G.; Brancha-
dell, V.; Ortun˜o, R. M. Tetrahedron: Asymmetry 2002, 13,
2403–2405.
´
8. (a) Martın-Vila, M.; Muray, E.; Aguado, G. P.; Alvarez-
Larena, A.; Branchadell, V.; Minguillon, C.; Giralt, E.;
`
´
