Design and Studies on Supramolecular Ferrocene-Porphyrin-Fullerene Constructs for
Generating Long-Lived Charge Separated States
Francis D’Souza,*,† Raghu Chitta,† Suresh Gadde,† D.-M. Shafiqul Islam,‡
Amy L. Schumacher,† Melvin E. Zandler,† Yasuyuki Araki,‡ and Osamu Ito*,‡
Department of Chemistry, Wichita State UniVersity, 1845 Fairmount, Wichita, Kansas 67260-0051, and
Institute of Multidisciplinary Research for AdVanced Materials, Tohoku UniVersity,
Katahira, Sendai 980-8577, Japan
ReceiVed: July 16, 2006; In Final Form: August 7, 2006
Supramolecular ferrocene-porphyrin-fullerene constructs, in which covalently linked ferrocene-porphyrin-
crown ether compounds were self-assembled with alkylammonium cation functionalized fullerenes, have been
designed to achieve stepwise electron transfer and hole shift to generate long-lived charge separated states.
The adopted crown ether-alkylammonium cation binding strategy resulted in stable conjugates as revealed
by computational studies performed by the DFT B3LYP/3-21G(*) method in addition to the binding constants
obtained from fluorescence quenching studies. The free-energy changes for charge-separation and charge-
recombination were varied by the choice of different metal ions in the porphyrin cavity. Free-energy calculations
suggested that the light-induced electron-transfer processes from the singlet excited state of porphyrins to be
exothermic in all of the investigated supramolecular dyads and triads. Photoinduced charge-separation and
charge-recombination processes have been confirmed by the combination of the time-resolved fluorescence
and nanosecond transient absorption spectral measurements. In case of the triads, the charge-recombination
processes of the radical anion of the fullerene moiety take place in two steps, viz., a direct charge recombination
from the porphyrin cation radical and a slower step involving distant charge recombination from the ferrocene
cation moiety. The rates of charge recombination for the second route were found to be an order of magnitude
slower than the former route, thus fulfilling the condition for charge migration to generate long-lived charge-
separated states in supramolecular systems.
Introduction
Although substantial amount of progress in terms of charge
stabilization has been accomplished on covalently linked
polyads,1-6,9-10 achieving similar results on self-assembled
supramolecular polyads has been challenging because of the
occurrence of multiple equilibrium processes and the inferior
stability of the adopted self-assembly approaches in solution,
especially in polar solvents.10 Recently, we addressed the
stability issue by employing multiple modes of binding and
formed structurally well-defined, stable supramolecular systems.10g
An alternate supramolecular approach was also developed, in
which the covalently linked dyads were allowed to self-assemble
with either a donor or an acceptor with a well-defined binding
mechanism to form the triads.10g In the present study, we have
further explored the latter approach where covalently linked
ferrocene-porphyrin-crown ether compounds (Fc-MP-crown
ether) were self-assembled with alkylammonium cation func-
tionalized fullerenes (NH3+-C60) (Scheme 1). As demonstrated
here, upon excitation of the donor porphyrin, efficient forward
electron transfer to the fullerene entity self-assembled via crown
ether-alkylammonium cation complexation occurs followed by
Studies on photoinduced electron transfer in molecular and
supramolecular donor-acceptor polyads (triads, tetrads, etc.)
have undergone rapid growth in recent years mainly to develop
artificial photosynthetic systems capable of stabilizing charge-
separated states,1-6 which is eventually also useful for the
development of molecular optoelectronic devices.7,8 In the
construction of such polyads, porphyrins and fullerenes have
been employed as primary electron donor and acceptor,
respectively, whereas ferrocene, carotene, or tetrathiafulvalene
has often been utilized as terminal electron donors.9,10 In contrast
with the traditionally used two-dimensional aromatic electron
acceptors, fullerenes in donor-acceptor dyads and polyads
accelerate forward electron transfer (kCS) and slow backward
electron transfer (kCR) due to their small reorganization energy
in electron-transfer reactions.11 This property of fullerenes
combined with the adopted electron migration strategy of
polyads has resulted in the generation of distinctly separated
donor-acceptor radical ion pairs upon initial electron transfer
by charge migration reactions along the well-tuned redox
gradients.12-15 In a few systems, energy funneling antenna
molecules have been elegantly connected to the donor-acceptor
systems to probe sequential energy/electron-transfer processes,
thus mimicking the “antenna-reaction center” functionality of
photosynthesis.16
a hole transfer from the MP•+ to the ferrocene entity to generate
the final charge-separated states, Fc+-MP-crown:NH3+-C60
.
•-
As a consequence of the sequential electron-transfer events, the
charge-recombination reaction is slowed in these supramolecular
triads (see Supporting Information).
Results and Discussion
* To whom correspondence should be addressed. E-mail:
Francis.DSouza@wichita.edu (F.D); ito@tagen.tohoku.ac.jp (O.I.).
† Wichita State University.
The structures of the newly synthesized compounds are shown
in Scheme 1. Porphyrins, 1a-c (MP ) H2P, ZnP, and MgP,
‡ Tohoku University.
10.1021/jp064504g CCC: $33.50 © 2006 American Chemical Society
Published on Web 09/23/2006

Ferrocene-Porphyrin-Fullerene Constructs
J. Phys. Chem. B, Vol. 110, No. 50, 2006 25241
SCHEME 1: Structures of the Crown Ether Appended Porphyrins, Ferrocene-Porphyrins Dyads, and Fullerene
