1940
Organometallics 2000, 19, 1940-1949
Rea ction of Bu tyltin Hyd r oxid e Oxid e w ith
p-Tolu en esu lfon ic Acid : Syn th esis, X-r a y Cr ysta l
An a lysis, a n d Mu ltin u clea r NMR Ch a r a cter iza tion of
{(Bu Sn )12O14(OH)6}(4-CH3C6H4SO3)2
Christophe Eychenne-Baron, Franc¸ois Ribot,* Nathalie Steunou, and
Cle´ment Sanchez
Laboratoire de Chimie de la Matie`re Condense´e, UMR CNRS 7574, Tour 54, 5e e´tage,
Universite´ Pierre et Marie Curie, 4 Place J ussieu, F-75252 Paris Cedex 05, France
Franck Fayon
Centre de Recherche sur les Mate´riaux a` Haute Tempe´rature, UPR CNRS 4212, 1D avenue de
la Recherche Scientifique, F-45071 Orle´ans Cedex 2, France
Monique Biesemans, J ose´ C. Martins, and Rudolph Willem
High-Resolution NMR Center (HNMR), Free University of Brussels (VUB), Pleinlaan 2,
B-1050 Brussels, Belgium
Received November 2, 1999
The reaction of butyltin hydroxide oxide, BuSnO(OH), with p-toluenesulfonic acid,
4-CH3C6H4SO3H, yields the butyltin oxo cluster {(BuSn)12(µ3-O)14(µ2-OH)6}2+ mixed with a
soluble ill-defined butyltin oxo polymer, the presence of which was established by solid-
state and quantitative solution 119Sn NMR. The reaction conditions were varied in order to
optimize the yield of oxo cluster, which can be quantitatively isolated by crystallization as
{(BuSn)12O14(OH)6}(4-CH3C6H4SO3)2‚C4H8O2 (1‚diox). The structure of the latter compound
was determined by X-ray diffraction. 1‚diox and {(BuSn)12O14(OH)6}(4-CH3C6H4SO3)2 (1) were
1
also characterized by solid-state 119Sn MAS NMR and solution 119Sn, H, and 13C NMR. In
1‚diox, the existence of weak Lewis interactions, taking place in the crystal between five-
coordinate tin atoms and dioxane molecules, was evidenced by solid-state 119Sn NMR.
1
2D H-1H NOESY and ROESY experiments, along with ionic conductivity measurements,
-
have proved that the ionic dissociation between {(BuSn)12O14(OH)6}2+ and 4-CH3C6H4SO3
(PTS-) does not take place in dichloromethane, while it does in the more polar and
dissociating dimethyl sulfoxide. Using the H-119Sn J -HMQC NMR technique, the weak
1
2J (1H-O-119Sn) coupling constant between the µ2-OH and the six-coordinate tin nuclei was
determined and shown to depend on the solvent.
In tr od u ction
starting Sn/acid ratio and the nature of the acid control
the outcome of these syntheses. Other monorganotin
oxo clusters, without complexing ligands bound to tin
Several structures of monoorganotin oxo clusters have
been shown to be versatile nanobuilding blocks for the
design of tin-based hybrid organic-inorganic materials.1
Many of these oxo clusters contain strongly complexing
ligands such as carboxylates (i.e., [PhSnO(O2CC6H11)]6),2
phosphinates (i.e., {[BuSn(OH)(O2PPh2)]3O}(O2PPh2)),3
and phosphates (i.e., [BuSnO(O2P(OPh)2)]6),4 which
cover the oxo cores and generally allow hexacoordination
for tin. They are usually synthesized from organo-
stannonic acids and the corresponding carboxylic- or
phosphorus-based acids in a nonpolar solvent.5 The
6
(i.e., (PriSn)9O8(OH)6Cl5 or {(PriSn)12O14(OH)6}Cl2),7
are also known. All of these have been prepared, some-
times with very low yields, by hydrolysis-condensation
of molecular monoorganotin compounds (RSnCl3,6-8
RSn(OR′)3,9 or RSn(CtCR′)310). However, we have
recently shown that the reaction of sulfonic acid with
butylstannonic acid, BuSnO(OH), is a cheap and easy
alternative to prepare the macrocation {(BuSn)12O14-
(OH)6}2+ 11
.
(5) Holmes, R. R. Acc. Chem. Res. 1989, 22, 190.
(6) Puff, H.; Reuter, H. J . Organomet. Chem. 1989, 368, 173.
(7) Puff, H.; Reuter, H. J . Organomet. Chem. 1989, 373, 173.
(8) Dakternieks, D.; Zhu, H.; Tiekink, E. R. T.; Colton, R. J . J .
Organomet. Chem. 1994, 476, 33.
(9) Banse, F.; Ribot, F.; Tole´dano, P.; Maquet, J .; Sanchez, C. Inorg.
Chem. 1995, 34, 6371.
* To whom correspondence should be addressed. E-mail: fri@
ccr.jussieu.fr.
(1) Ribot, F.; Eychenne-Baron, C.; Sanchez, C. Phosphorus, Sulfur
Silicon Relat. Elem. 1999, 150-151, 41.
(2) Chandrasekhar, V.; Day, R. O.; Holmes, R. R. Inorg. Chem. 1985,
24, 1970.
(3) Day, R. O.; Holmes, J . M.; Chandrasekhar, V.; Holmes, R. R. J .
Am. Chem. Soc. 1987, 109, 940.
(4) Day, R. O.; Chandrasekhar, V.; Kumara Swamy, K. C.; Holmes,
J . M.; Burton, S. D.; Holmes, R. R. Inorg. Chem. 1988, 27, 2887.
(10) J aumier, P.; J ousseaume, B.; Lahcini, M.; Ribot, F.; Sanchez,
C. J . Chem. Soc., Chem. Commun. 1998, 369.
(11) Eychenne-Baron, C.; Ribot, F.; Sanchez, C. J . Organomet. Chem.
1998, 567, 137.
10.1021/om990877a CCC: $19.00 © 2000 American Chemical Society
Publication on Web 04/14/2000

Tin-Based Organic-Inorganic Materials
Organometallics, Vol. 19, No. 10, 2000 1941
F igu r e 2. Packing diagram for {(BuSn)12O14(OH)6}(4-
CH3C6H4SO3)2‚C4H8O2 (1‚diox), showing the “cation-
anion” chains (parallel to [100]) and their arrangement into
planes (parallel to [110]).
metric counterparts). Six hydroxy groups bridge the six-
coordinate tin atoms pairwise and define the cage poles.
Two p-toluenesulfonate counteranions interact with
the cage poles. A framework of hydrogen bonds, char-
acterized by an average O-O distance of 2.74 Å, links
the oxo clusters into chains parallel to the a axis of the
structure (Figure 2). This framework involves one-to-
one contacts between the three oxygen atoms of both
sulfonate anions (O45X, O46X, O56X, and their sym-
metric counterparts) and all six µ2-OH bridges. The
formation of chains due to counteranions bridging two
macrocations is common for the {(BuSn)12O14(OH)6}2+
cluster, yet 1‚diox is the first where all the bridging
hydroxy groups are in contact with the anions.8,9 This
feature is in line with the almost identical environments
of the six-coordinate tin atoms (Table 1), in contrast with
the other structures, where two main six-coordinate
environments are identified.8,9
The oxygen atoms of a 1,4-dioxane molecule (O1, C1A,
C1B, and their symmetric counterparts) form weak
donor-acceptor interactions (d(Sn-O) ≈ 3.3 Å) with
four five-coordinate tin atoms (Sn2, Sn3, and their
symmetric counterparts). These contacts cause a small
displacement of the R-carbons (C20, C30, and their
symmetric counterparts), as evidenced by the O-Sn-C
angles (Table 1), and connect “cation-anion” chains into
planes parallel to the a and b axes (Figure 2). This type
of interaction is unreported, since in all structures
described so far, the solvating molecules (DMF,7 H2O,8
HOPri 9) were always hydrogen-bound to bridging hy-
droxy groups not interacting with the anions.
F igu r e 1. CAMERON31 drawing of {(BuSn)12O14(OH)6}-
(4-CH3C6H4SO3)2‚C4H8O2 (1‚diox), showing 20% displace-
ment ellipsoids (two dioxane molecules have been repre-
sented, but only the R-carbon of the butyl chains has been
drawn for clarity).
This paper reports on the reaction between BuSnO-
(OH) and 4-CH3C6H4SO3H (HPTS), with different nomi-
nal tin-to-sulfur ratios (Sn/S varying from 12/2 to
12/8). The crystallographic structure of {(BuSn)12O14-
(OH)6}(4-CH3C6H4SO3)2‚C4H8O2 (1‚diox; diox ) diox-
ane), as determined from single-crystal X-ray diffrac-
tion, as well as solid- and solution-state multinuclear
NMR charaterizations of 1 and 1‚diox, are presented.
The interactions between {(BuSn)12O14(OH)6}2+ and
4-CH3C6H4SO3 (PTS-) in solution were investigated.
-
Resu lts a n d Discu ssion
X-r a y Diffr a ction Str u ctu r e of 1‚d iox. The molec-
ular structure and a packing diagram of 1‚diox are pre-
sented in Figures 1 and 2, respectively. Selected inter-
atomic distances and bond angles are given in Table 1.
The main component of this centrosymmetric compound
is the {(RSn)12(µ3-O)14(µ2-OH)6}2+ macrocation.7-9
As previously reported,7-9 it is composed of twelve tin
atoms bound to one butyl group and linked by µ3-O
(O125, O126, O134, O135, O234, O236, O456, and their
symmetric counterparts) and µ2-OH bridges (O45, O46,
O56, and their symmetric counterparts). The six five-
coordinate tin atoms exhibit a square-pyramidal envi-
ronment (Sn1, Sn2, Sn3 and their symmetric), while the
other six tin atoms exhibit a six-coordinate distorted-
octahedral geometry (Sn4, Sn5, Sn6, and their sym-
Th er m a l Beh a vior of 1‚d iox. The thermogravi-
metric and differential thermal analyses of 1‚diox
(Figure 3) reveal four weight losses between 20 and 1000
°C. The final product corresponds to SnO2 (cassiterite),12
as revealed by X-ray powder diffraction, and the total
weight loss indicates a dioxane-deficient composition
close to {(BuSn)12O14(OH)6}(PTS)2(C4H8O2)0.4 (exptl,
35.7%; calcd, 35.7%). The first weight loss (85 °C; weakly
endothermic) corresponds to leaving dioxane and agrees
well with the lack of dioxane (exptl, 1.2%; calcd, 1.2%).
(12) McCarthy, G.; Welton, J . Powder Diffr. 1989, 4, 156.
