Synthesis of p-tert-butylcalix[6]-1,4-2,5-bis-crowns
Yuanyin Chen,∗ Fafu Yang and Xueran Lu
Department of Chemistry, Wuhan University, Wuhan 430072, People’s Republic of China
Received 1 September 1999; accepted 16 December 1999
Abstract
The synthesis and complexation properties of the first example of p-tert-butylcalix[6]-1,4-2,5-bis-crowns are re-
ported. Their complexation abilities and selectivities are different from that of analogous calix[6]crown. Compound
+
2b exhibits high complexation selectivity towards n-PrNH3 . © 2000 Elsevier Science Ltd. All rights reserved.
Calixcrowns are a family of macropolycyclic molecules in which the subunits of calixarene and crown
ethers are combined through the bridging of phenolic oxygen atoms of the calixarene by polyoxyethylene
chains. The first member of this family was reported by Alfieri et al. as early as 1983.1 As calixcrowns
possess well preorganized structures and more rigid binding sites in comparison with calixarenes and
crown ethers, they exhibited superior recognition ability toward alkali metal cations. For example, the
Na+/K+ selectivity attainable with crown ethers has been saturated at the 102 order; with calixarenes
the selectivity can reach 103.1, but it is 105.3 for diethoxycalix[4]crown-4 in a partial cone conformation.2
Therefore, much attention has been paid to more sophisticated molecules: calixa-bis-crowns. All possible
types of calix[4]-bis-crowns have been synthesized,3–9 and their recognition properties toward Cs+, K+
etc. have been studied.10–14 Two types of calix[8]-bis-crowns have also been reported.15,16 However, no
paper concerning the synthesis of calix[6]-bis-crowns has appeared to date. Even for calix[6]crowns, only
1,4-p-tert-butylcalix[6]crown-5 and 1,4-calixa[6]crown-517 as well as 1,3-p-tert-butylcalix[6]crown-318
have been synthesized.
In this paper, we wish to report the synthesis of the first calix[6]-bis-crowns: p-tert-butylcalix[6]-1,4-
2,5-bis-crown-4 2a and p-tert-butylcalix[6]-1,4-crown-4-2,5-benzocrown-4 2b as well as their extraction
abilities toward some cations. The synthetic route is depicted in Scheme 1.
Reacting p-tert-butylcalix[6]arenes with triethylene glycol ditosylates or 1,2-bistosyloxyethoxybenzene
in the presence of 9 equiv. of K2CO3 in toluene for 36 h under a nitrogen atmosphere, gave 1,4-p-tert-
butylcalix[6]crown-4 1a and 1,4-p-tert-butylcalix[6]benzocrown-4 1b.19 To the DMF solution of 1, NaH
was added at room temperature, followed by 1.2 equiv. of triethylene glycol ditosylate with stirring at
70°C for 7 h. The excess of NaH was quenched by addition of a minimal quantity of methanol (caution!).
Distilling off the solvent, the residue was treated with HCl (10%, v/v) and then extracted with ethyl
∗
Corresponding author.
0040-4039/00/$ - see front matter © 2000 Elsevier Science Ltd. All rights reserved.
PII: S0040-4039(99)02332-1
tetl 16260

1572
Scheme 1. Reagents and conditions: (i) K2CO3, toluene, reflux, 36 h; (ii) NaH/DMF, 70°C, 7 h
