The use of new metallophthalocyanines carrying peripherally
4-methyl-N-(3-morpholinopropyl)benzenesulfonamide moieties
for the sensitive fluorimetric determination of banned food dye
Sudan II in red chili peppers
b
a
a
a
a
Halit Kantekin a, , Beytullah Ertem , Nurten Aslan , Halise Yalazan , Ümmühan Ocak , Ender Çekirge ,
⇑
Abidin Gümrükçüog˘lu a, Volkan Çakır c, Miraç Ocak a
a Department of Chemistry, Karadeniz Technical University, 61080 Trabzon, Turkey
b Vocational School of Health Services, Karadeniz Technical University, 61080 Trabzon, Turkey
c Department of Property Protection and Security, Emergency and Disaster Management Program, Espiye Vocational School, Giresun University, Giresun 28600, Turkey
h i g h l i g h t s
g r a p h i c a l a b s t r a c t
ꢀ
ꢀ
ꢀ
ꢀ
The synthetic procedures and
spectrofluorimetric studies of new
MPcs described.
The new procedure suggests
detecting the banned food colorant
Sudan II dye.
The new simpler, cheaper, and faster
fluorimetric method was described
instead of HPLC.
MPcs were used for the first time as
spectrofluorimetric agents to detect
Sudan II dye.
a r t i c l e i n f o
a b s t r a c t
The structural elucidation and syntheses methods of new peripherally tetra-substituted MPcs [CuII (6),
CoII (7), MnCIIII (8), and NiII (9) phthalocyanines] carrying 4-methyl-N-(3-morpholinopropyl)benzenesul
fonamide moieties were reported in the present study. The corroboration of the prepared compounds (3,
5, and 6 to 9) was made by LC–TOF/MS, UV–Vis, Fourier Infrared, 1H NMR, 13C NMR, and MALDI–TOF mass
spectral data. Herein, we submit a new procedure that uses metallophthalocyanine complexes for the
first time as spectrofluorimetric agents to detect and determine health-threatening food additive,
Sudan II dye, with a new simpler, cheaper, and faster spectrofluorimetric method instead of time-
consuming and expensive HPLC processes. Furthermore, the sensitivities of the proposed methods are
good enough to determine the amount of dye at a concentration of 0.1 mg/L. The methods have LOD val-
ues between 0.035 and 0.050 mg/L. The linear ranges are found to be between 0 and 8.3 mg/L. The pre-
cision of the methods is determined to be between 1.1 and 2.4 as % RSD. Therefore, this study would make
a good contribution to the food industry and phthalocyanine chemistry by detecting and determining the
hazardous food colorant Sudan II with metal phthalocyanines.
Article history:
Received 17 July 2020
Received in revised form 7 November 2020
Accepted 10 November 2020
Available online xxxx
Keywords:
Morpholine
Phthalonitrile
Cobalt phthalocyanine
Sudan II
Fluorimetric definition procedure
Food colorant
Ó 2020 Elsevier B.V. All rights reserved.
⇑
Corresponding author at: Department of Chemistry, Karadeniz Technical University, 61080 Trabzon, Turkey.
E-mail address: halit@ktu.edu.tr (H. Kantekin).
https://doi.org/10.1016/j.saa.2020.119222
1386-1425/Ó 2020 Elsevier B.V. All rights reserved.
Please cite this article as: H. Kantekin, B. Ertem, N. Aslan et al., The use of new metallophthalocyanines carrying peripherally 4-methyl-N-(3-morpholino-
propyl)benzenesulfonamide moieties for the sensitive fluorimetric determination of banned food dye Sudan II in red chili peppers, Spectrochimica Acta
Part A: Molecular and Biomolecular Spectroscopy, https://doi.org/10.1016/j.saa.2020.119222

H. Kantekin, B. Ertem, N. Aslan et al.
Spectrochimica Acta Part A: Molecular and Biomolecular Spectroscopy xxx (xxxx) xxx
these methods [52,53]. These methods applied to determine Sudan
II in chili powder samples are based on the fluorescence properties
of the polyethyleneimine-capped silver [53] and copper [52] nan-
oclusters. Previous studies have shown the use of MPc complexes
with suitable functional groups as fluorescent reagents for the
determination of metal ions in food samples [54]. In the present
study, the usability of MPc complexes showing fluorescent prop-
erty in the determination of Sudan II dyes from the banned food
dyes was investigated.
As can be seen from the research in the literature, there are
many published papers associated with medicinal and pharmaceu-
tical applications of morpholine-based heterocycles. However, to
the best of our knowledge, no report has been found so far con-
cerning the morpholine-based phthalocyanine agent that is eligi-
ble, simple, and economical for the detection and determination
of Sudan II dye. In line with this purpose, we designed and synthe-
sized the new metallic phthalocyanines [CuII (6), CoII (7), MnCIIII
(8), and NiII (9)]. After the confirmation of the structures of these
newly synthesized metallated Pc complexes, we studied banned
food dye Sudan II in red chili peppers for the sensitive fluorimetric
determination procedure to determine a new simpler, cheaper, and
faster spectrofluorimetric strategy as compared to time-consuming
and expensive HPLC methods. By looking at analytical data of the
spectrofluorimetric measurements, it is elicited that the new cop-
per(II) phthalocyanine (6), cobalt(II) phthalocyanine (7), man-
1. Introduction
Phthalocyanines (Pcs) and their metal inserted congeners, met-
allophthalocyanines (MPcs), are one of the most important classes
of chromophores and aromatic macrocycles. From their discovery
by Braun and Tcherniac in 1907 [1,2] up to now, miscellaneous
researches and studies have been conducted to make use of varied
advantages of phthalocyanine compounds in science and technol-
ogy. There is a large volume of published studies describing their
spectacular photochemical, optical, redox, electronic and color fea-
tures [3–8] together with their high thermal and chemical stability
[9], both Pcs and MPcs have been using widely as electronic mate-
rials [10,11], dyes [12], optical materials [13], photosensitizer
agents [14–16], liquid crystal displays (LCDs) [17], semiconductors
[18], solar cells [19], in photodynamic therapy applications
[14–16,20], fluorescence ‘‘off-on-off” sensors [21] as well as cata-
lysts [22,23] and nonlinear optics [24]. To play a remarkable role
and obtain targeted molecules or materials for the above-
mentioned applications of phthalocyanines, their adjustable prop-
erties are tuned by the incorporation of many sorts of substituents
at different binding positions of Pc ring (i.e., peripheral, non-
peripheral or axial) and changing the central metal ions and as well
as designing different types of Pc molecules such as ball-type,
double-decker and so on.
As being a marvelous pharmacophore [25,26] and important
building blocks in medicinal chemistry, morpholine nucleus, and
its assorted derivatives has been of tremendous significance and
made use of as capping component and primary skeleton to
develop new drugs [27–29] owing to their diverse biological and
pharmacological activities with the inclusion of local anesthetic,
selective inhibitor of protein kinase C, neuroprotective, anti-
malarial, antidepressant, appetite suppressant, antitumor, anal-
gesic, antifungal, anti-tuberculosis, anticancer, antiplatelet, anti-
parasitic, HIV-protease inhibitors, anti-inflammatory, hypocholes-
terolemic and hypolipidemic activities as well [30–34]. Nowadays,
so many drugs containing morpholine backbone or its various
derivatives have been approved by the FDA (U.S. Food & Drug
Administration) and they are in use for the treatment of aforesaid
diseases [35]. In addition to pharmaceutical and medicinal applica-
tions, morpholine derivatives are also utilized including in air con-
ditioners, in water boiling systems as an anticorrosive agent, in the
textile industry, in the production of waxes, in catalysts as a chem-
ical intermediate and as well as in book paper preservation appli-
cations [36,37]. Of the great significance and potential, morpholine
units bearing compounds have been of particular attention,
numerous studies have been carried out and published comprising
morpholine scaffold fused phthalocyanines [38–41].
ganese(III)
chloride
phthalocyanine
(8),
and
nickel(II)
phthalocyanine (9) compounds are the new simpler, cheaper, and
faster spectrofluorimetric agents for detection and determination
of a banned azo-dye Sudan II in red pepper samples. In our time,
specifically during of Covid–19 pandemic, people pay much more
attention more than ever regarding the health, healthy life and
healthy food and nutrition. To that end, the present study attempts
to contribute as a simpler, cheaper, and faster detection and deter-
mination of banned or health-threatening food additives such as
azo-dye Sudan II by using metallic phthalocyanine complexes for
the first time.
2. Experimental
2.1. Materials, instrumentation, and method
The materials, instrumentation, Sudan II determination method,
and some of the figures were given as Supplementary information.
2.2. Syntheses
Sudan dyes, which are azo dyes, are known to have the poten-
tial for toxic properties. For example, Li et al. showed by spectro-
scopic methods that Sudan II and Sudan IV bind effectively with
the catalase enzyme, which is effective in protecting the cell from
oxidative stress [42]. It has been reported in another study that
these dyes affect the physiological activity of bovine hemoglobin
[43].
Sudan dyes generally have been detected and determined by
chromatographic methods [44]. These methods are often time-
consuming and require the use of expensive devices such as
HPLC-MS-MS [45,46]. For the determination of these dyes, some
electrochemical methods, and enzyme-linked immunosorbent
assay (ELISA) have also been proposed [47–49]. The intrinsic selec-
tion and high sensitivity of fluorescence methods provide generally
an overall advantage in analytical assays. However, the number of
recommended fluorescence methods for the determination of
Sudan dyes is also very few [50–53], and there are only several rec-
ommended fluorescence methods for determining Sudan II among
2.2.1. 4-Methyl-N-(3-morpholinopropyl)benzenesulfonamide (3)
Under
a dry nitrogen atmosphere, a two-necked round-
bottomed 100 mL flask was charged with 3-morpholinopropan-
1-amine (1) (2.50 g, 17.34 mmol, 1 eq.) and dry pyridine (2 mL)
and then degassed several times on a vacuum line. At –5 °C, a solu-
tion of p-toluenesulfonyl chloride (2) (3.34 g, 17.51 mmol, 1.01 eq.
in 4 mL dry pyridine) was added dropwise in 1 h to the reaction
mixture. As the addition of p-toluenesulfonyl chloride solution
was over, it was stirred at –5 °C for 4 h and the stirring was then
continued at room temperature overnight. During the addition of
p-toluenesulfonyl chloride solution, the color change was observed
at the beginning from pale yellow to dark orange and finally to
reddish-brownish color. Later, the reaction mixture was poured
into 300 g of crushed ice and stirred at room temperature for
3 h. The pH of the aqueous media was monitored and adjusted
approximately to pH = 7.00. Thereafter, aqueous media was
extracted with 4x30 mL of chloroform and the collected organic
phase was dried over anhydrous MgSO4. By the evaporation of
2

H. Kantekin, B. Ertem, N. Aslan et al.
Spectrochimica Acta Part A: Molecular and Biomolecular Spectroscopy xxx (xxxx) xxx
chloroform from the collected extract, the compound (3) obtained,
and the ultimate purification of the product was performed on a
microcolumn charged with silica gel with chloroform:ethanol
(50 mL:5 mL) solvent mixture to give as the yellow oily product.
Yield: 3.38 g (65.4%). FT–IR: tmax (cmÀ1) = 3272 (N–H), 3068 (C–
H aromatic), 2962–2914–2850 (CH3), 1596 (C = C), 1494, 1445,
1318 (Tosyl group, S = O asymmetric), 1275, 1155 (Tosyl group,
S = O symmetric), 1116, 1092 (N–H), 988, 922, 862, 817, 747,
706 and 659 (C–S). 1H NMR (ppm, CDCl3): d = 7.75–7.73 (d, 2H,
Tosyl, Ar–H), 7.32–7.30 (d, 2H, Tosyl, Ar–H), 7.00 (broad, 1H, N–
H), 3.73–3.71 (t, 4H, H2C–O–CH2), 3.08–3.05 (t, 2H, –CH2–CH2–N–
H), 2.43–2.40 (m, 7H, H2C–N–CH2 and Tosyl, –CH3), 1.68–1.62 (m,
4H, –N–CH2–CH2–CH2–CH2–N–H). 13C NMR (ppm, CDCl3):
were subsequently added into the solution and the sealed tube
was purged with dry nitrogen gas for several times to remove dis-
solved oxygen. At 160 °C, the reaction mixture was then refluxed
for 18 h. After cooling to room temperature, the reaction mixture
was precipitated by the addition of 10 mL ethanol. The resulting
precipitate was filtered off, washed with distilled water and ethyl
alcohol separately, and following that, the crude product was dried
in vacuo. The crude products were purified by column chromatog-
raphy on neutral alumina with chloroform:ethanol (50 mL:1.5 mL)
for 6 and 7; chloroform:ethanol (50 mL:3 mL) for 8 and 9. The col-
lected organic phase was evaporated to dryness and finally dried
under vacuum to give the corresponding metallic phthalocyanines
(6–9). Figure S1 illustrates the synthetic pathway for compounds
3, 5, and 6 to 9.
d
= 143.19, 137.12, 135.98, 129.65, 126.99, 126.42, 124.82,
66.88–61.46 (H2C–O–CH2), 58.44–58.22–53.53 (H2C–N–CH2),
43.86–42.94 (–CH2–CH2–N–H), 30.58–30.31–23.90 (–N–CH2–
CH2–CH2–N–H), 21.53 (Tosyl, –CH3). LC–TOF/MS m/z: Calculated:
298.40, Found: 299.147 [M + H]+.
2.2.3.1. Copper(II) phthalocyanine (6). Color: Blue. Yield: 50.00 mg
(22.0%), m.p. > 300 °C. FT–IR: tmax (cmÀ1) = 3062 (C–H aromatic),
2918–2850 (CH3), 1597 (C=C), 1495, 1448, 1326 (Tosyl group,
S=O asymmetric), 1157 (Tosyl group, S=O symmetric), 1116, 918,
862, 815, 749, 708 and 660 (C–S). UV–Vis (chloroform), kmax, nm
2.2.2. N-(3,4-dicyanophenyl)-4-methyl-N-(3-morpholinopropyl)
benzenesulfonamide (5)
(loge): 681 (5.01), 614 (4.35) and 343 (4.75). MALDI–TOF–MS
m/z: Calculated: 1761.61, Found: 1761.69 [M]+.
A two-necked round-bottomed 100 mL flask was charged with
4-methyl-N-(3-morpholinopropyl)benzenesulfonamide (3) (1.00 g,
3.35 mmol, 1 eq.), 4-nitrophtalonitrile (4) (0.58 g, 3.35 mmol, 1 eq.)
and dry acetonitrile (15 mL). Following the vigorously stirring at
reflux temperature (approximately at 85 °C), anhydrous K2CO3
(1.84 g, 13.40 mmol, 4 eq.) was added to the solution by portion-
wise over 1 h and the reaction mixture was degassed under the
nitrogen stream on a vacuum line. Under the N2(g) blanket, the
reaction mixture was continued to reflux for 6 days and monitored
by Thin Layer Chromatography technique (TLC) with chloroform as
a mobile phase on silica gel plates with UV indicator. The residue
was dissolved in 125 mL of chloroform and extracted with (4x25
mL) distilled water, after cooling to room temperature. The organic
phase was then dried over MgSO4, filtered off and chloroform was
removed by evaporation. The crude product was purified by chro-
matographic separation from unreacted reagents and byproducts
2.2.3.2. Cobalt(II) phthalocyanine (7). Color: Blue. Yield: 85.00 mg
(38.8%), m.p. > 300 °C. FT–IR: tmax (cmÀ1) = 3059 (C–H aromatic),
2953–2927–2854 (CH3), 1598 (C=C), 1494, 1448, 1324 (Tosyl
group, S=O asymmetric), 1288, 1155 (Tosyl group, S=O symmetric),
1116, 970, 918, 862, 815, 707 and 660 (C–S). UV–Vis (chloroform),
kmax, nm (loge): 672 (4.99), 607 (4.44) and 329 (4.91). MALDI–TOF–
MS m/z: Calculated: 1757.01, Bulunan: 1758.49 [M+H]+.
2.2.3.3. Manganese(III) chloride phthalocyanine (8). Color: Green.
Yield: 100.00 mg (44.9%), m.p. > 300 °C. FT–IR: tmax (cmÀ1) = 303
3–(C–H aromatic), 2951–2919–2850 (CH3), 1599 (C=C), 1494,
1447, 1326 (Tosyl group, S=O asymmetric), 1156 (Tosyl group,
S=O symmetric), 1116, 973, 862, 815, 707 and 659 (C–S). UV–Vis
(chloroform), kmax, nm (loge): 732 (5.08), 670 (4.68), 521 (4.55)
on
a
silica gel charged column with chloroform:ethanol
and 315 (5.57). MALDI–TOF–MS m/z: Calculated: 1788.45, Found:
(50 mL:7.5 mL) to give the phthalonitrile derivative (5) as a light
brown viscous oily product. Yield: 0.79 g (55.6%). FT–IR: tmax
(cmÀ1) = 3075–3042 (C–H aromatic), 2921–2851 (CH3), 2234
(CꢁN), 1596 (C = C), 1569, 1488, 1457, 1349 (Tosyl group, S = O
asymmetric), 1291, 1252, 1162 (Tosyl group, S = O symmetric),
1115, 940, 850, 815, 750, 706, 674 and 660 (C–S). 1H NMR (ppm,
CDCl3): d = 7.78–7.72 (m, 1H, Ar–H), 7.58–7.55 (m, 1H, Tosyl, Ar–
H), 7.44–7.42 (m, 1H, Ar–H), 7.32–7.29 (m, 4H, Ar–H and Tosyl,
Ar–H), 3.73–3.61 (m, 6H, H2C–O–CH2 and –CH2–N–), 2.45–2.32
(m, 9H, H2C–N–CH2 and Tosyl, –CH3), 1.67–1.60 (m, 2H, –N–CH2–
CH2–CH2–N–). 13C NMR (ppm, CDCl3): d = 144.93, 144.41, 143.24,
137.10, 134.26, 133.91, 132.01, 131.56, 130.09, 129.68, 127.41,
127.19, 127.00, 124.84, 116.77–114.90–114.70 (CꢁN) , 113.73,
66.90–66.88–66.04–65.18–63.34 (H2C–O–CH2), 58.47–58.26–
1754.84 [M–CI + H]+.
2.2.3.4. Nickel(II) phthalocyanine (9). Color: Dark green. Yield:
40.00 mg (18.3%), m.p. > 300 °C. FT–IR: tmax (cmÀ1) = 3064 (C–H
aromatic), 2924–2852 (CH3), 1611 (C=C), 1532, 1487, 1445, 1346
(Tosyl group, S=O asymmetric), 1261, 1159 (Tosyl group, S=O sym-
metric), 976, 862, 814, 750, 709 and 661 (C–S). 1H NMR (ppm,
CDCl3): d = 8.00–7.85 (br, 4H, Ar–H), 7.68–7.66 (br, 4H, Ar–H),
7.59–7.39 (m, 20H, Ar–H), 3.71 (br, 24H, H2C–O–CH2 and –CH2–
N–), 2.42–2.19 (br, 36H, H2C–N–CH2 and Tosyl, –CH3), 1.64–1.52
(br, 8H, –N–CH2–CH2–CH2–N–). UV–Vis (chloroform), kmax, nm
(loge): 701 (5.08), 638 (4.60) and 314 (5.00). MALDI–TOF–MS m/
z: Calculated: 1756.75, Found: 1744.26 [M-12H]+.
55.22–54.27–53.62–53.55
(H2C–N–CH2),
47.81–43.92–42.99
(–CH2–CH2–N–), 25.43–24.93–23.88–23.20–22.72 (–N–CH2–CH2–
CH2–N–), 21.66–21.55 (Tosyl, –CH3). LC–TOF/MS m/z: Calculated:
424.52, Found: 425.17 [M + H]+.
3. Results and discussion
3.1. Synthesis and characterization
2.2.3. The syntheses of CuII (6), CoII (7), MnCIIII (8) and NiII (9)
phthalocyanines
The synthetic procedures including the purification methods,
the verification of the chemical structures of new peripherally
N-(3,4-dicyanophenyl)-4-methyl-N-(3-morpholinopropyl)ben
zenesulfonamide (5) (0.212 g, 0.5 mmol, 2 eq.) was dissolved in
6 mL of dry pentan-1-ol under a stream of N2(g) in a Schlenk tube.
Later, anhydrous metal salts [CuCl2, 33.9 mg, 0.25 mmol, 1 eq. for
6; CoCl2, 32.5 mg, 0.25 mmol, 1 eq. for 7; MnCl2, 31.5 mg,
0.25 mmol, 1 eq. for 8 and NiCl2, 32.4 mg, 0.25 mmol, 1 eq. for 9]
along with 6 drops of 1,8-diazabicyclo[5.4.0]undec-7-ene (DBU)
4-methyl-N-(3-morpholinopropyl)benzenesulfonamide
compo-
nents fused copper(II) phthalocyanine (6), cobalt(II) phthalocya-
nine (7), manganese(III) chloride phthalocyanine (8), and nickel
(II) phthalocyanine (9) complexes and the detection and fluori-
metric determination of a health-threatening food colorant Sudan
II dye was explained in this work. We outlined a cheaper, faster,
simpler, and sensitive spectrofluorimetric method for the
3

H. Kantekin, B. Ertem, N. Aslan et al.
Spectrochimica Acta Part A: Molecular and Biomolecular Spectroscopy xxx (xxxx) xxx
detection and determination of Sudan II dye to overcome the time
consuming, tiring, and expensive HPLC methods. To put it another
way, the copper(II) phthalocyanine (6), cobalt(II) phthalocyanine
(7), manganese(III) chloride phthalocyanine (8), and nickel(II)
phthalocyanine (9) compounds were utilized for the first time
for the detection and determination of banned food dye Sudan
II in red chili peppers. The FT–IR, LC–TOF/MS (for the new com-
pounds 3 and 5), 1H NMR (for the new compounds 3, 5 and 9),
13C NMR (for the new compounds 3 and 5), UV–Vis (for the
new MPcs 6 to 9), and MALDI–TOF (for the new MPcs 6 to 9)
spectral methods were utilized to confirm the chemical structures
of newly synthesized compounds (3, 5, 6 to 9). Based on the
above-mentioned spectroscopic results, the new compounds (3,
5, 6 to 9) were agreeing well with the suggested structures in
Figure S1.
The peripherally 4-methyl-N-(3-morpholinopropyl)benzenesul
fonamide substituents fused CuPc (6), CoPc (7), MnCIPc (8), and
NiPc (9) was synthesized from N-(3,4-dicyanophenyl)-4-methyl-
N-(3-morpholinopropyl)benzenesulfonamide (5) and the related
anhydrous metal salts in the presence of 1,8-diazabicyclo[5.4.0]u
ndec-7-ene and dry pentan-1-ol under nitrogen gas stream. The
purification procedures were made by chromatographic separation
on neutral alumina with chloroform:ethanol (50 mL:1.5 mL) for 6
and 7; chloroform:ethanol (50 mL:3 mL) for 8 and 9. After success-
ful syntheses of the above-mentioned complexes [CuII (6), CoII (7),
MnCIIII (8), and NiII (9) phthalocyanines], two important spectro-
scopic alterations were recognized in the 13C NMR and infrared
spectra of the complexes as expected. These two spectral changes
were the evanescence of the CꢁN functionalities of the dicyano
compound (5) both in the 13C NMR (d = 116.77–114.90–114.70 pp
4-Methyl-N-(3-morpholinopropyl)benzenesulfonamide (3) was
obtained by the synthesis reaction of 3-morpholinopropan-
1-amine (1) and p-toluenesulfonyl chloride (2) at –5 °C in dry
pyridine by the customizing of the published work [55]. The purifi-
cation process of the phthalonitrile derivative (5) was carried out
by chromatographic separation on a silica gel charged column with
chloroform:ethanol (50 mL:5 mL). The 1H NMR signal correspond-
ing to the NH2 group in (1) evanesced and a new broad signal
belonging to the N–H proton at d = 7.00 ppm was observed in
the 1H NMR spectrum of tosylated compound (3). The aromatic
ring protons were resonated at d = 7.75–7.73 (d, 2H, Tosyl, Ar–H)
and 7.32–7.30 ppm (d, 2H, Tosyl, Ar–H) (Figure S2). Other 1H
NMR signals were detected at d = 3.73–3.71 (t, 4H, H2C–O–CH2),
3.08–3.05 (t, 2H, –CH2–CH2–N–H), 2.43–2.40 (m, 7H, H2C–N–CH2
and Tosyl, –CH3) and 1.68–1.62 ppm (m, 4H, –N–CH2–CH2–CH2–
CH2–N–H). The characteristic aromatic carbon atoms signals in
13C NMR of (3) were observed at d = 143.19, 137.12, 135.98,
129.65, 126.99, 126.42, 124.82 ppm. The other resonances in 13C
NMR of (3) were resonated at d = 66.88–61.46 (H2C–O–CH2),
58.44–58.22–53.53 (H2C–N–CH2), 43.86–42.94 (–CH2–CH2–N–H),
30.58–30.31–23.90 (–N–CH2–CH2–CH2–N–H), 21.53 (Tosyl, –CH3)
(Figure S3). The evanesce of the NH2 group of (1) and the arising
new stretching vibrations associated with the N–H (stretching
and bending) and the tosyl groups (asymmetric and symmetric)
m) and infrared (t
max = 2234 cmÀ1) spectra. The mass spectral data
were acquired by MALDI–TOF technique by using the 2,5-
dihydroxybenzoic acid (DHB) as the MALDI matrix for all complexes
(6–9). The parent molecular ion peaks of the new MPcs [CuII (6)
(Figure S7), CoII (7) (Figure S8), MnCIIII (8) and NiII (9)] were mea-
sured at m/z
= 1761.69, 1758.49, 1754.84, and 1744.26,
respectively.
Coupled with the above-mentioned spectral data, one of the
best substantial proofs regarding the successful preparation of
the CuII (6), CoII (7), MnCIIII (8), and NiII (9) phthalocyanine com-
pounds was obtained from the ground state electronic absorption
spectra. The distinctive Soret (B–) and Q– bands were seen in chlo-
roform at room temperature at 1.0 Â 10À5 M concentration. The
significant Q– and Soret bands appeared at kmax = 681 (log
e
= 5.01),
614 (4.35) and 343 nm (log
e
= 4.75) for (6); 672 (4.99), 607 (4.44)
and 329 nm (4.91) for (7); 732 (5.08), 670 (4.68), 521 (4.55) and
315 nm (5.57) for (8); 701 (5.08), 638 (4.60) and 314 nm (5.00)
for (9), respectively (Fig. 1). Based on the absorption spectra in
the ultraviolet–visible spectrum of the MPc compounds (6–9), all
new complexes exhibited a specific absorption spectrum related
to non-aggregated substituted and unsubstituted MPc species with
D4h symmetry that is consistent with other phthalocyanine metal
complexes reported in the literature [14,16,22].
of compound (3) at tmax
=
3272–1092 cmÀ1 and 1318–
3.2. Spectrofluorimetric determination studies
1155 cmÀ1 respectively in the FT–IR spectrum of (3) was one of
the best indications that the tosylation reaction was succeeded.
Mass spectral data for compound (3) was measured by the
LC–TOF/MS device and the molecular ion peak was observed at
m/z = 299.147.
The toxic properties of Sudan dyes [42,43] make their determi-
nation by cheap, fast, and simple determination methods impor-
tant. In this study, primarily the fluorescence properties of MPc
complexes prepared for the development of new determination
methods having mentioned properties based on fluorescence mea-
surement were determined. Consequently, it has been shown that
the new MPc complexes can be used as fluorescent reagents for the
sensitive determination of Sudan II (Fig. 2) in red pepper.
Fig. 3 shows the fluorescence spectra of the MPc complexes in
ethanol. As seen from Fig. 3, the fluorescence characteristics of
CoPc (7) and CuPc (6) complexes with emission maximums at
approximately 360 and 415 nm are similar. MnCIPc (8) complex
spectrum is similar to those of the CoPc (7) and CuPc (6) com-
plexes. However, while the fluorescence intensity increased at all
wavelengths, the emission peak at 360 nm shifted to a blue of
about 10 nm. The NiPc (9) complex showed a small emission peak
at 360 nm while showing a flat emission band between 375 and
495 nm.
The dicyano compound (5), N-(3,4-dicyanophenyl)-4-methyl-
N-(3-morpholinopropyl)benzenesulfonamide, was prepared as a
light brown viscous oily product by the substitution reaction of
compound (3) with 4-nitrophtalonitrile (4), anhydrous K2CO3 and
dry CH3CN at 85 °C for 6 days under the nitrogen. The purification
process of the phthalonitrile derivative (5) was carried out by chro-
matographic separation on a silica gel charged column with chlo-
roform:ethanol (50 mL:7.5 mL). In the 1H NMR spectrum of
precursor compound (3), the N–H proton signal at d = 7.00 ppm
vanished in the case of compound (5) (Figure S4). The CꢁN signals
in the 13C NMR spectrum of phthalonitrile derivative (5) were res-
onated at d = 116.77–114.90–114.70 ppm (Figure S5). The other
proton and 13C NMR resonance peaks were nearly the same with
precursor tosylated compound (3) except some little chemical
shifts. In the case of compound (5), a new vibration of the CꢁN
The effect of Sudan II on the emission spectrum of the CuPc (6),
CoPc (7), MnCIPc (8), and CuPc (6) complexes was examined. The
results show that Sudan II caused an increase in fluorescence
intensity of the metal complexes at all wavelengths. The fluores-
cence enhancement results from the hiding of the intramolecular
photoinduced electron transfer (PET) from morpholine donors to
MPc moiety providing a moderate fluorescence intensity by the
functional group was seen at t
max = 2234 cmÀ1 while the vibration
of the N–H group (stretching and bending) at tmax = 3272–1092 c
mÀ1 was evanesced as expected. Molecular ion peak was observed
at m/z = 425.17 in the mass spectrum of compound (5) (Figure S6).
All obtained spectral data were agreeing well with the dicyano
compound (5).
4

H. Kantekin, B. Ertem, N. Aslan et al.
Spectrochimica Acta Part A: Molecular and Biomolecular Spectroscopy xxx (xxxx) xxx
Fig. 1. The UV–Vis spectrum of new metallophthalocyanine compounds (6–9) in chloroform at room temperature (Concentration: 1.0 Â 10-5 M).
(9) phthalocyanine compounds. As a representative result related
to the change of the fluorescence spectra was given for the CoPc
(7) complex in Fig. 4. The 356 nm band observed in the fluores-
cence spectrum of the CoPc (7) complex can be explained by the
emission
[57]. The band around 425 nm is related to the bridging nitrogen
of the Pc ring and is caused by the
⁄ ? n transitions that con-
p⁄ ?
p, which is related to the Soret (B) band in PCs
p
tribute to the Soret band [58,59]. With the increasing Sudan II con-
centration in the fluorescence spectrum of the CoPc (7) complex,
the increase in emission intensity around 425 nm is very small
compared to the increase at 356 nm (Fig. 4). That the band at
425 nm gradually disappears can be explained by the decrease in
the g* ? n transition due to the interaction of the Sudan II molecule
with the donor groups at the peripheral positions in the CoPc (7)
complex. On the other hand, a significant increase in the fluores-
cence spectrum of the CoPc (7) complex at 356 nm was observed
with increasing the Sudan II dye concentration. Moreover, this
increase has been found to be linearly related to the Sudan II con-
centration (Fig. 4, inset). Thus, analytical method development
studies were carried out at 356 nm. Nearly similar changes were
obtained with the other metal complexes. Suitable calibration
graphs were formed from the fluorescence increase about
Fig. 2. The structure of Sudan II azo-dye.
effect of Sudan II [56]. This increase was highly effective at approx-
imately 360 nm and it was determined that there was a regular
relationship between the increasing Sudan II concentration and
the fluorescence intensity of the CuII (6), CoII (7), MnCIIII (8) and NiII
Fig. 3. The fluorescence spectra of the MPc complexes (6–9) in ethanol. The excitation wavelength is 320 nm. Concentration: 1.0 Â 10-5 M.
5

H. Kantekin, B. Ertem, N. Aslan et al.
Spectrochimica Acta Part A: Molecular and Biomolecular Spectroscopy xxx (xxxx) xxx
Fig. 4. The fluorescence enhancement of the CoPc (7) complex with increasing Sudan II concentration. The concentration range: 0–8,3 mg/L. Inset: The increase of
fluorescence intensity at 356 nm with increasing Sudan II concentration.
360 nm for the fluorimetric determination of Sudan II. A represen-
tative calibration graph is given in Fig. 4 inset.
as RSD % is between 2.4 and 1.1. The LOD values and linear ranges
of the proposed methods are comparable to those of the fluorimet-
ric methods recommended for the determination of Sudan II in the
literature [53,54]. So, the analytical studies showed that the pro-
posed methods can be applied for the determination of banned
dye Sudan II in red pepper samples.
The proposed methods do not require laborious pre-treatment
or extractions steps before the determination. It is sufficient to
use only an external calibration graph to determine Sudan II.
Therefore, the proposed methods are rapid and not complicated.
It was determined that all MPc complexes (6–9) can be used in
the fluorimetric determination of Sudan II. The proposed methods
base on the use of a simple external calibration graph. Measure-
ment conditions and calibration data of the proposed methods
are given in Table 1. It can be seen from Table 1 that high determi-
nation coefficients (R2) are obtained for copper(II) phthalocyanine
(6), cobalt(II) phthalocyanine (7), manganese(III) chloride phthalo-
cyanine (8), and nickel(II) (9) phthalocyanine complexes.
Table 2 gives the analytical performance data of the method
under the optimized conditions for all MPc complexes (6–9). For
these methods, the LOD and LOQ are defined as 3Sb/m and 10Sb/
m, respectively. Therefore, LOQ is about 3.3 times of LOD. The stan-
dard deviation of fluorescence intensity of 11 blank solutions and
slope of calibration equation have been indicated as s and m,
respectively. As can be seen from Table 2, the high recovery per-
centages (R%) were obtained for the Sudan II spiked samples
(1.0 mg/L). The precision of the results is given for intra-day and
inter-day measurements as percent relative standard deviation
(RSD %). The number of repeated measurements in these studies
is 3. Table 2 shows that the uncertainty in the measurement results
4. Conclusion
In this paper, we declared the synthesis and structural verifica-
tion of new peripherally tetra-substituted phthalocyanine deriva-
tives
benzenesulfonamide moieties. The confirmation of the chemical
structures of studied compounds was made via Fourier Infrared,
1H NMR, 13C NMR, LC–TOF/MS, UV–Vis, and MALDI–TOF mass
spectral data. Simple and economical detection and determination
of a banned azo-dye Sudan II using especially to increase red color
fused
4-methyl-N-(3-morpholinopropyl)
Table 1
Measurement conditions and calibration data of the proposed fluorimetric methods for Sudan II determination.
MPc
Excitation wavelength (nm)
Measurement wavelength (nm)
Calibration equation
The determination coefficient (R2)
CuPc (6)
CoPc (7)
MnCIPc (8)
NiPc (9)
320
320
320
320
356
356
356
356
y = 216596x + 53693
y = 278365x + 138157
y = 271201x + 594419
y = 270323x + 499260
0.9981
0.9969
0.9891
0.9927
Table 2
Analytical performance data of the proposed methods for Sudan II determination with the MPc complexes.
MPc
Linear range (mg/L)
LOD (mg/L)
LOQ (mg/L)
Added (mg/L)
R % RSD % (Intra-day precision, N = 3)
R % RSD % (Inter-day precision, N = 3)
CuPc (6)
CoPc (7)
MnCIPc (8)
NiPc (9)
0–2.9
0–8.3
0–6.0
0–5.5
0.050
0.035
0.050
0.045
0.149
0.106
0.149
0.136
1.0
1.0
1.0
1.0
101.7 2.1
102.3 2.4
100.4 2.4
103.0 2.0
100.7 1.1
101.1 1.6
101.0 2.1
100.8 1.4
6

H. Kantekin, B. Ertem, N. Aslan et al.
Spectrochimica Acta Part A: Molecular and Biomolecular Spectroscopy xxx (xxxx) xxx
[11] B. Ertem, G. Sarkı, H. Yalazan, Z. Bıyıklıog˘lu, H. Kantekin, The synthesis and
electrochemical characterization of new metallophthalocyanines containing
4-aminoantipyrine moieties on peripherally positions, Inorg. Chim. Acta. 462
(2017) 123–129, https://doi.org/10.1016/j.ica.2017.03.021.
[12] B. Brozek-Pluska, M. Orlikowski, H. Abramczyk, Spectroscopy and Raman
imaging studies of phthalocyanines in human breast tissues, in: Handbook of
Porphyrin Science: with Applications to Chemistry, Physics, Materials Science,
Engineering, Biology and Medicine, (2016) pp. 1–49.
in spices is still a critical problem in many countries of the world.
Time-consuming and expensive HPLC methods are generally rec-
ommended for the determination of Sudan II for this purpose. In
the present study, it is suggested that new MPc complexes can
be used for the determination by simpler, cheaper, and faster spec-
trofluorimetric methods. Moreover, the sensitivity of the proposed
method is good enough to determine the amount of dye at a con-
centration of 0.1 mg/L. That is to say, we offer a new procedure for
those who are interested in food chemistry and industry to detect
and determine the hazardous food colorant Sudan II dye.
[13] G. Kumar, J. Thomas, N. Unnikrishnan, V. Nampoori, C. Vallabhan, Optical
absorption and emission spectral studies of phthalocyanine molecules in DMF,
J. Porphyr. Phthalocyanines
5 (2001) 456–459, https://doi.org/10.1002/
jpp.339.
[14] H. Kantekin, H. Yalazan, N. Kahriman, B. Ertem, V. Serdarog˘lu, M. Pisßkin, M.
Durmußs, New peripherally and non-peripherally tetra-substituted metal-free,
magnesium(II) and zinc(II) phthalocyanine derivatives fused chalcone units:
design, synthesis, spectroscopic characterization, photochemistry and
photophysics, J. Photochem. Photobiol. A Chem. 361 (2018) 1–11, https://
doi.org/10.1016/j.jphotochem.2018.04.034.
[15] Y. Zhang, J.F. Lovell, Recent applications of phthalocyanines and
naphthalocyanine for imaging and therapy, WIREs Nanomed. Nanobiotechnol.
Nanomed. Nanobiotechnol. 9 (2017), https://doi.org/10.1002/wnan.1420 e1420.
[16] B. Ertem, H. Yalazan, Ö. Güngör, G. Sarkı, M. Durmußs, E.T. Saka, H. Kantekin,
Synthesis, structural characterization, and investigation on photophysical and
photochemical features of new metallophthalocyanines, J. Lumin. 204 (2018)
464–471, https://doi.org/10.1016/j.jlumin.2018.08.043.
CRediT authorship contribution statement
Halit Kantekin: Supervision, Funding acquisition, Methodol-
ogy, Resources. Beytullah Ertem: Writing - original draft. Nurten
Aslan: Investigation. Halise Yalazan: Investigation. Ümmühan
Ocak: Methodology, Investigation. Ender Çekirge:
.
Abidin
˘
Gümrükçüoglu:
. Volkan Çakır: Methodology. Miraç Ocak:
Methodology, Investigation.
[17] J. Choi, S.H. Kim, W. Lee, C. Yoon, J.P. Kim, Synthesis and characterization of
thermally stable dyes with improved optical properties for dye-based LCD
color filters, New J. Chem. 36 (2012) 812–818, https://doi.org/10.1039/
C2NJ20938A.
Declaration of Competing Interest
[18] A. Datyner, M.T. Pailthorpe, A study of dyestuff aggregation. II. The influence of
temperature on the aggregation of some anionic dyestuffs, J. Colloid Interface
Sci. 76 (1980) 557–562, https://doi.org/10.1016/0021-9797(80)90395-1.
[19] Y. Wang, X. Liu, H. Shan, Q. Chen, T. Liu, X. Sun, D. Ma, Z. Zhang, J. Xu, Z.-X. Xu,
Tetra-alkyl-substituted copper (II) phthalocyanines as dopant-free hole-
transport layers for planar perovskite solar cells with enhanced open circuit
voltage and stability, Dyes Pigm. 139 (2017) 619–626, https://doi.org/10.1016/
j.dyepig.2016.12.067.
The authors declare that they have no known competing finan-
cial interests or personal relationships that could have appeared
to influence the work reported in this paper.
Acknowledgments
[20] T. Goslinski, T. Osmalek, K. Konopka, M. Wierzchowski, P. Fita, J. Mielcarek,
Photophysical properties and photocytotoxicity of novel phthalocyanines –
potentially useful for their application in photodynamic therapy, Polyhedron
30 (2011) 1538–1546, https://doi.org/10.1016/j.poly.2011.03.003.
[21] O.J. Achadu, T. Nyokong, Graphene quantum dots anchored onto
mercaptopyridine-substituted zinc phthalocyanine-Au@Ag nanoparticle
hybrid: Application as fluorescence ‘‘off-on-off” sensor for Hg2+ and biothiols,
Dyes Pigm. 145 (2017) 189–201, https://doi.org/10.1016/j.dyepig.2017.06.002.
[22] H. Kantekin, E.T. Saka, B. Ertem, M.N. Mısır, H. Yalazan, G. Sarkı, New
The authors thank Karadeniz Technical University Scientific
Research Projects Coordination Unit (Project Number: FHD-2018-
7866) for the financial support for this work.
Appendix A. Supplementary material
peripherally
tetra-[trans-3,7-dimethyl-2,6-octadien-1-ol]
substituted
Supplementary data to this article can be found online at
https://doi.org/10.1016/j.saa.2020.119222.
metallophthalocyanines: synthesis, characterization and catalytic activity
studies on the oxidation of phenolic compounds, J. Coord. Chem. 71 (1)
(2018) 164–182, https://doi.org/10.1080/00958972.2018.1423560.
[23] Y. Jiang, Y. Lu, X. Lv, D. Han, Q. Zhang, L. Niu, W. Chen, Enhanced catalytic
performance of Pt-free iron phthalocyanine by graphene support for efficient
oxygen reduction reaction, ACS Catal. 3 (2013) 1263–1271, https://doi.org/
10.1021/cs4001927.
References
[1] A. Braun, J. Tcherniac, Über die Produkte der Einwirkung von Acetanhydrid auf
Phthalamid, Ber. Dtsch. Chem. Ges. 40 (1907) 2709–2714, https://doi.org/
10.1002/cber.190704002202.
[2] F.H. Moser, A.L. Thomas, Phthalocyanine Compounds, American Chemical
Society Monograph Series, Reinhold Publishing Corporation, New York, 1963.
[3] K. Kadish, R. Guilard, K. Smith, Application of Phthalocyanine, first ed.,
Academic Press, San Diego, CA, 2003.
[4] J.-J. Guo, S.-R. Wang, X.-G. Li, M.-Y. Yuan, The synthesis, photophysical and
thermal properties of novel 7-hydroxy-4-methylcoumarin tetrasubstituted
metallophthalocyanines with axial chloride ligand, Dyes Pigm. 93 (2012)
1463–1470, https://doi.org/10.1016/j.dyepig.2011.10.006.
[5] J.-J. Guo, S.-R. Wang, X.-G. Li, F. Zhang, Y. Xiao, C. Teng, T. Synthesis,
Characterisation, photophysical and thermal properties, and photovoltaic
[24] David
O.
Oluwole,
Tebello
Nyokong,
Optical
nonlinearity
of
pentadecylphenoxyl substituted sandwich-type metallophthalocyanines in
the presence of Ag–CdSeTe/ZnTeSe nanocrystals: Effects of conjugation and
central metals, Dyes Pigm. 151 (2018) 254–262. https://doi.org/10.1016/j.
dyepig.2018.01.009.
[25] M. Taha, S.A.A. Shah, M. Afifi, M. Zulkeflee, S. Sultan, A. Wadood, F. Rahim, N.H.
Ismail, Morpholine hydrazone scaffold: synthesis, anticancer activity and
docking studies, Chin. Chem. Lett. 28 (2017) 607–611, https://doi.org/10.1016/
j.cclet.2016.10.020.
[26] M. Andrs, J. Korabecny, D. Jun, Z. Hodny, J. Bartek, K. Kuca, Phosphatidylinositol
3-kinase (PI3K) and phosphatidylinositol 3-kinase-related kinase (PIKK)
inhibitors: importance of the morpholine ring, J. Med. Chem. 58 (1) (2015)
41–71, https://doi.org/10.1021/jm501026z.
[27] J.A. War, S.K. Srivastava, S.D. Srivastava, Design, synthesis and DNA-binding
study of some novel morpholine linked thiazolidinone derivatives,
Spectrochim. Acta A Mol. Biomol. Spectrosc. 173 (2017) 270–278, https://
doi.org/10.1016/j.saa.2016.07.054.
[28] M. Al-Ghorbani, B.A. Bushra, S. Mamatha, S.A. Khanum, Piperazine and
morpholine: synthetic preview and pharmaceutical applications, Res. J.
performance
of
7-coumarinoxy-4-methyltetrasubstituted
metallophthalocyanines, Aust. J. Chem. 68 (7) (2015) 1025–1034, https://doi.
org/10.1071/CH14502.
[6] F. Zhang, S. Wang, X. Li, Y. Xiao, Recent progress of perovskite solar cells, Curr.
Nanosci.
12
(2)
(2016)
137–156,
https://doi.org/10.2174/
1573413711666150523002002.
[7] F. Zhang, S.-R. Wang, X.-G. Li, Y. Xiao, J.-J. Guo, The effect of coadsorbent and
solvent on the photovoltaic performance of 2,9,16,23-Tetrakis(7-coumarinoxy-
4-methyl)-phthalocyaninatocopper-sensitized solar cells, J. Mol. Struct 1107
(2016) 329–336, https://doi.org/10.1016/j.molstruc.2015.11.074.
[8] F. Zhang, S. Wang, Y. Xiao, X. Li, Improvement in photovoltaic performance of
perovskite solar cells by interface modification and co-sensitization with novel
Pharm. Technol.
360X.2015.00100.6.
8
(2015) 611–628, https://doi.org/10.5958/0974-
[29] P. Panneerselvam, R.R. Nair, G. Vijayalakshmi, E.H. Subramanian, S.K. Sridhar,
Synthesis of Schiff bases of 4-(4-aminophenyl)-morpholine as potential
antimicrobial agents, Eur. J. Med. Chem. 40 (2005) 225–229, https://doi.org/
10.1016/j.ejmech.2004.09.003.
[30] P. Panneerselvam, R.V. Pradeepchandran, S.K. Sreedhar, Synthesis,
characterization and biological activities of novel 2- methyl-quinazolin-4
(3H)-ones, Indian J. Pharm. Sci. 65 (3) (2003) 268–273.
[31] G.R. Brown, A.J. Foubister, D. Stribling, Synthesis and resolution of 3-
substituted morpholine appetite suppressants and chiral synthesis via o-
arylhomoserines, J. Chem. Soc. Perkin Trans. 1 (1987) 547–551, https://doi.org/
10.1039/P19870000547.
asymmetry
7-coumarinoxy-4-methyltetrasubstituted
metallophthalocyanines, Synth. Met. 220 (2016) 187–193, https://doi.org/
10.1016/j.synthmet.2016.06.003.
[9] C.E. Dent, R.P. Linstead, Phthalocyanines. Part IV. Copper phthalocyanines, J.
Chem. Soc. (1934) 1027–1031, https://doi.org/10.1039/JR9340001027.
[10] E. Ermißs, Y. Çimen, F. Dumludag˘, A.R. Özkaya, B. Salih, Ö. Bekarog˘lu,
Electrochemical and electrical properties of novel mono and ball-type
phthalocyanines, Polyhedron 49 (2013) 129–137, https://doi.org/10.1016/j.
poly.2012.09.048.
7

H. Kantekin, B. Ertem, N. Aslan et al.
Spectrochimica Acta Part A: Molecular and Biomolecular Spectroscopy xxx (xxxx) xxx
[32] A.H. El-masry, H.H. Fahmy, S.H.A. Abdelwahed, Synthesis and antimicrobial
activity of some new benzimidazole derivatives, Molecules 5 (12) (2000)
1429–1438, https://doi.org/10.3390/51201429.
[33] V. Duhalde, B. Lahillie, F. Camou, S. Pédeboscq, J.P. Pometan, Proper use of
antibiotics: a prospective study on the use of linezolid in a French university
hospital, Pathol. Biol. 55 (10) (2007) 478–481, https://doi.org/10.1016/
j.patbio.2007.07.018.
[34] C. Marireau, M. Guilloton, F. Kartst, In vivo effects of fenpropimorph on the
yeast Saccharomyces cerevisiae and determination of the molecular basis of
the antifungal property, Antimicrob Agents Chemother. 34 (6) (1990) 989–
993, https://doi.org/10.1128/AAC.34.6.989.
[35] A.V. Shcherbatiuk, O.S. Shyshlyk, D.V. Yarmoliuk, O.V. Shishkin, S.V. Shishkina,
V.S. Starova, O.A. Zaporozhets, S. Zozulya, R. Moriev, O. Kravchuk, Synthesis of
2- and 3-trifluoromethylmorpholines: useful building blocks for drug
discovery, Tetrahedron 69 (2013) 3796–3804, https://doi.org/10.1016/j.
tet.2013.03.067.
[36] H. Enzmann, H. Zerban, A. Kopp-Schneider, E. Löser, P. Bannasch, Effects of low
doses of N-nitrosomorpholine on the development of early stages of
hepatocarcinogenesis, Carcinogenesis 16 (1995) 1513–1518, https://doi.org/
10.1093/carcin/16.7.1513.
[37] R.J. Lewis Sr., Danger Prop. Ind. Mater. Rep. 15 (1995) 270–297.
[38] B. Barut, Ü. Demirbaßs, A. Özel, H. Kantekin, Novel water soluble morpholine
substituted Zn(II) phthalocyanine: synthesis, characterization, DNA/BSA
[46] C. Schummer, J. Sassel, P. Bonenberger, G. Moris, Low-level detections of Sudan
I, II, III and IV in spices and chili- containing foodstuffs using UPLC-ESI-MS/MS,
J. Agric. Food Chem. 61 (2013) 2284–2289, https://doi.org/10.1021/jf400602a.
[47] D. Meiju, H. Xiaogang, Z. Zihao, W. Shouguo, Determination of Sudan I in hot
chili powder by using an activated glassy carbon electrode, Food Chem. 105
(2007) 883–888, https://doi.org/10.1016/j.foodchem.2006.12.039.
[48] Y. Wang, D. Wei, H. Yang, Y. Yang, W. Xing, Y. Li, A. Deng, Development of a
highly sensitive and specific monoclonal antibody-based enzyme-linked
immunosorbent assay (ELISA) for detection of Sudan
I in food samples,
Talanta 77 (2009) 1783–1789, https://doi.org/10.1016/j.talanta.2008.10.016.
[49] E.A. Zvereva, B.Ts. Zaichik, S.A. Eremin, A.V. Zherdev, B.B. Dzantiev, Enzyme
immunoassay for detection of Sudan I dye and its application to the control of
foodstuffs, J. Anal. Chem. 71 (2016) 944–948, https://doi.org/10.1134/
S1061934816090185.
[50] C.V. Di Anibal, M.S. Rodriguez, L. Albertengo, Synchronous fluorescence and
multivariate classification analysis as a screening tool for determining Sudan I
dye in culinary spices, Food Control 56 (2015) 18–23, https://doi.org/10.1016/
j.foodcont.2015.03.010.
[51] M. Wu, L. Sun, K. Miao, Y. Wu, L.-J. Fan, Detection of Sudan dyes based on
inner-filter effect with reusable conjugated polymer fibrous membranes, ACS
Appl. Mater. Interfaces 10 (2018) 8287–8295, https://doi.org/10.1021/
acsami.8b00164.
[52] Y. Ling, J.X. Li, F. Qu, N.B. Li, H.Q. Luo, Rapid fluorescence assay for Sudan dyes
usingpolyethyleneimine-coated copper nanoclusters, Microchim. Acta 181
(2014) 1069–1075, https://doi.org/10.1007/s00604-014-1214-9.
[53] N.Y. Chen, H.F. Li, Z.F. Gao, F. Qu, N.B. Li, H.Q. Luo, Utilizing polyethyleneimine-
capped silver nanoclusters as a new fluorescence probe for Sudan I-IV sensing
in ethanol based on fluorescence resonance energy transfer, Sens. Actuators B
Chem. 193 (2014) 730–736, https://doi.org/10.1016/j.snb.2013.12.020.
binding, DNA photocleavage and topoisomerase
Macromol. 105 (2017) 499–508,
ijbiomac.2017.07.072.
I
inhibition, Int. J. Biol.
https://doi.org/10.1016/j.
[39] A.K. Burat, A. Koca, J.P. Lewtak, D.T. Gryko, Preparation, electrochemistry and
optical properties of unsymmetrical phthalocyanines bearing morpholine and
tert-butylphenoxy substituents, Synth. Met. 161 (2011) 1537–1545, https://
doi.org/10.1016/j.synthmet.2011.05.010.
[54] Y. Çag˘lar, E.T. Saka, H. Alp, H. Kantekin, Ü. Ocak, M. Ocak,
A
simple
[40] S. Çolak, M. Durmußs, S.Z. Yıldız, Tetrakis{2-[N-((3-morpholino)
propyl)carbamate]oxyethyl} zinc(II) phthalocyanine and its water soluble
derivatives: Synthesis, photophysical, photochemical and protein binding
properties, J. Photochem. Photobiol. A Chem. 325 (2016) 125–134, https://doi.
org/10.1016/j.jphotochem.2016.04.006.
spectrofluorimetric method based on quenching of
phthalocyanine complex to determine iron (III), J. Fluoresc. 26 (2016) 1381–
a
nickel(II)-
1389, https://doi.org/10.1007/s10895-016-1829-9.
_
[55] M. Koçak, A.I. Okur, Ö. Bekarog˘lu, Novel two-fold-macrocycle-substituted
phthalocyanines, J. Chem. Soc. Dalton Trans. (1994) 323–326, https://doi.org/
10.1039/DT9940000323.
[56] X.-F. Zhang, J. Wang, Morpholine-phthalocyanine (donor-acceptor) construct:
Photoinduced intramolecular electron transfer and triplet formation from its
charge separation state, J. Phys. Chem. A 115 (2011) 8597–8603, https://doi.
org/10.1021/jp202997e.
[57] A.K. Pal, S. Varghese, D.B. Cordes, A.M.Z. Slawin, I.D.W. Samuel, E. Zysman-
Colman, Near-infrared fluorescence of silicon phthalocyanine carboxylate
esters, Sci. Rep. 7 (2017) 12282, https://doi.org/10.1038/s41598-017-12374-8.
[58] A.E.H. Machado, M.D. Franc, V. Velani, G.A. Magnino, H.M.M. Velani, F.S.
Freitas, P.S. Muller Jr., C. Sattler, M. Schmucker, Characterization and
evaluation of the efficiency of TiO2/zinc phthalocyanine nanocomposites as
photocatalysts for wastewater treatment using solar irradiation, Int. J.
Photoenergy (2008), https://doi.org/10.1155/2008/482373 482373.
[59] G. Ricciardi, A. Rosa, E.J. Baerends, Ground and excited states of zinc
phthalocyanine studied by density functional methods, J. Phys. Chem. A 105
(2001) 5242–5254, https://doi.org/10.1021/jp0042361.
[41] J. Dlugaszewska, W. Szczolko, T. Koczorowski, P. Skupin-Mrugalska, A. Teubert,
K. Konopka, M. Kucinska, M. Murias, N. Düzgünesß, J. Mielcarek, T. Goslinski,
Antimicrobial and anticancer photodynamic activity of
a phthalocyanine
photosensitizer with N-methyl morpholiniumethoxy substituents in non-
peripheral positions, J. Inorg. Biochem. 172 (2017) 67–79, https://doi.org/
10.1016/j.jinorgbio.2017.04.009.
[42] T. Li, M. Hao, J. Pan, W. Zong, R. Liu, Comparison of the toxicity of the dyes
Sudan II and Sudan I V to catalase, J. Biochem. Mol. Toxicol. (2017), https://doi.
org/10.1002/jbt.21943 e21943.
[43] H. Sun, Q. Xia, R. Liu, Comparison of the binding of the dyes Sudan II and Sudan
IV to bovine hemoglobin, J. Lumin. 148 (148) (2014) 143–150, https://doi.org/
10.1016/j.jlumin.2013.12.012.
[44] H.-W. Sun, F.-C. Wang, L.-F. Ai, Determination of banned 10 azo-dyes in hot
chili products by gel permeation chromatography–liquid chromatography-
electrospray ionization tandem mass spectrometry, J. Chromatography A 1164
(2007) 120–128, https://doi.org/10.1016/j.chroma.2007.06.075.
_
[45] A.B. Karatasß, I.E. Tokat, A. Arıkan Asan, Determination of some azo dyes in red
pepper flakes by LC-MS/MS, J. Food Feed Sci. Technol. 21 (2018) 26–39.
8
