Pd-Mediated synthesis of
7H-benzo[3,4]azepino[1,2-a]indole-6-carboxylic acid derivatives
from indole-containing Baylis–Hillman adducts
Hyun Seung Lee a, Sung Hwan Kim a, Taek Hyeon Kim b, Jae Nyoung Kim a,*
a Department of Chemistry and Institute of Basic Science, Chonnam National University, Gwangju 500-757, Republic of Korea
b Department of Applied Chemistry and Center for Functional Nano Fine Chemicals, College of Engineering, Chonnam National University,
Gwangju 500-757, Republic of Korea
Received 4 December 2007; revised 10 January 2008; accepted 11 January 2008
Available online 15 January 2008
Abstract
We synthesized novel tetracyclic fused indole derivatives via the intramolecular Heck reaction of indole-containing Baylis–Hillman
adducts in good to moderate yields.
Ó 2008 Elsevier Ltd. All rights reserved.
Keywords: Baylis–Hillman adducts; Benzoazepino[1,2-a]indole; Heck reaction; Palladium
Due to the abundance of medium-sized heterocyclic
compounds in many natural products, drugs, and preclini-
cal leads, syntheses of these compounds by intramolecular
Heck type reaction have received much attention.1 Palla-
dium-mediated direct aryl–aryl bond-forming protocols
have also been studied extensively in this respect.2 Among
the approaches of aryl–aryl bond-forming reactions, the
use of indole moiety as one of the aryl group received
special interest due to the biological importance of indole
moiety-containing heterocyclic compounds.1c,2a,b,3
Although palladium-mediated synthesis of medium-
sized heterocyclic compounds has been investigated,1 stud-
ies involving the Baylis–Hillman adducts have not been
reported much.4,5 Lamaty and co-workers reported the
synthesis of benzazepines starting from the aza-Baylis–Hill-
man adducts.4a,b Vasudevan and co-workers examined the
cyclization of sulfonamide derivatives of Baylis–Hillman
adducts and prepared seven-membered heterocyclic
compounds.4c Very recently, we reported the synthesis of
pentacyclic benzoazepino[2,1-a]isoindole compounds via
consecutive carbopalladation using enamides of Baylis–
Hillman adducts.5
During the continuous studies we reasoned that indole-
containing Baylis–Hillman adducts could be used efficiently
for the synthesis of poly-fused heterocyclic compounds
including benzo[3,4]azepino[1,2-a]indoles6 by applying
intramolecular palladium-catalyzed arylation. Poly-fused
heterocyclic compounds having indole moiety were known
to possess many interesting biological activities6–8 including
hepatitis C virus (HCV) NS5B polymerase inhibitory activ-
ity,6 thus we decided to examine the intramolecular Heck
reaction with indole-containing Baylis–Hillman adducts as
shown in Scheme 1.
Required starting materials 3a–g were synthesized by the
reaction of Baylis–Hillman acetates 14d and indole deriva-
tives 2 (KOH, DMF, 0 °C)9 in 45–95% yields. In all cases,
E-forms of 3a–g were formed as the majors and we sepa-
rated them easily from the minor Z-isomers (5–10%).4,5
We examined the optimum reaction conditions for the
intramolecular palladium-catalyzed arylation with com-
pound 3a, and the results are summarized in Table 1.
Although all the conditions examined afforded desired
product 4a in variable yields (24–65%), the conditions
*
Corresponding author. Tel.: +82 62 530 3381; fax: +82 62 530 3389.
E-mail address: kimjn@chonnam.ac.kr (J. N. Kim).
0040-4039/$ - see front matter Ó 2008 Elsevier Ltd. All rights reserved.
doi:10.1016/j.tetlet.2008.01.058

1774
H. S. Lee et al. / Tetrahedron Letters 49 (2008) 1773–1776
EWG
OAc
Br
N
EWG
R2
4a-e
R3
1a: EWG = COOMe
1b: EWG = COOEt
EWG
KOH, DMF
R3
+
Br
N
0 oC
R2
R3
R1
3a-g
R2
R1
N
H
EWG
N
2a: R1 = H, R2 = H, R3 = H
2b: R1 = H, R2 = Me, R3 = H
2c: R1 = H, R2 = H, R3 = OMe
2d: R1 = H, R2 = CH2COOEt, R3 = H
2e: R1 = Me, R2 = H, R3 = H
2f: R1 = Me, R2 = Me, R3 = H
R1
R2
4f, 4g
Scheme 1.
Table 1
Optimization of the reaction conditions for the synthesis of 4a
Entry
Conditions
Time (h)
4aa (%)
3aa (%)
1
2
3
4
5
6
a
Pd(OAc)2 (10 mol %), TBAB (1.0 equiv), K2CO3 (2.0 equiv), DMF, 100 °C
Pd(OAc)2 (10 mol %), PPh3 (20 mol %), K2CO3 (2.0 equiv), DMF, 100 °C
Pd(OAc)2 (10 mol %), TBAB (1.0 equiv), KOAc (2.0 equiv), DMF, 100 °C
Pd(OAc)2 (10 mol %), TBAB (1.0 equiv), K2CO3 (2.0 equiv), CH3CN, reflux
Pd(OAc)2 (10 mol %), TBAB (1.0 equiv), NaHCO3 (2.0 equiv), DMF, 100 °C
Pd(OAc)2 (10 mol %), PPh3 (20 mol %), Et3N (2.0 equiv), DMF, 100 °C
1
1
1
1
8
65
61
58
54
45
24
0
0
0
8
5
18
32
Isolated yield.
Table 2
Pd-mediated cyclizations of indole moiety-containing Baylis–Hillman adducts
Entry
Substratea (%)
Time (min)
60
Productb (%)
COOMe
COOMe
1
Br
N
N
3a (73)
4a (65)
COOEt
COOEt
N
2
60
N
N
Br
Br
3b (50)
4b (82)
COOMe
COOMe
N
3
30
3c (51)
4c (66)

H. S. Lee et al. / Tetrahedron Letters 49 (2008) 1773–1776
1775
Table 2 (continued)
Entry
Substratea (%)
COOMe
Time (min)
Productb (%)
COOMe
4
120
OMe
Br
N
N
3d (95)
4d (69)
OMe
COOMe
COOMe
N
Br
N
5
6
30
3e (60)
4e (78)
COOEt
EtOOC
COOMe
N
COOMe
N
60
Br
Br
3f (45)
3g (62)
4f (53)
COOMe
N
COOMe
N
7
300
4g (60)
a
Conditions: 1 (1.2 equiv), 2 (1.0 equiv), KOH (1.2 equiv), DMF, 0 °C, 30 min to 4 h. The stereochemistry of 3a–g was confirmed as E by their chemical
shifts of vinyl protons (d = 7.83–7.98 ppm).
b
Conditions: 3 (1.0 equiv), Pd(OAc)2 (10 mol %), TBAB (1.0 equiv), K2CO3 (2.0 equiv), DMF, 100 °C, 30 min to 5 h.
using Pd(OAc)2/TBAB (tetrabutylammonium bromide)/
K2CO3 in DMF (entry 1) was the best (65%). Under the
optimized conditions we examined the reactions of 3b–g
and the results are summarized in Table 2.10 For the indole
derivatives 3a–e, the reactions produced seven-membered
benzoazepino[1,2-a]indole derivatives 4a–e in good yields
(65–82%). However, 2-methyl group in compounds 3f
and 3g rendered the formation of seven-membered ring
impossible, and aryl–aryl bond-formation occurred to form
the eight-membered compounds 4f and 4g in moderate
yields (53–60%).10 The extreme selectivity between seven-
and eight-membered ring-formation could be used for
further elaboration of this strategy.
