Communications
dehydroamination reaction with the formation of 1,4-dihy-
dropyridine and a silylated enol.
The postulated catalytic cycle of phenanthroline reduc-
tion starts with the displacement of a labile ligand L in [Cp(k2-
phen)RuL]+ (L = NCCH3, phenH2) by the silane to give the
silane s complex 11 (Scheme 3). This complex is probably too
sterically loaded to react with phenanthroline but can react
with water to furnish the hydride 10 and the protonated
The reaction of 2 with acid chlorides afforded the
corresponding amide and ClSiMe2Ph. In contrast, 2 did not
react with ethyl acetate even at elevated temperatures (up to
1008C) and in the presence of catalyst 1 (5 mol%). Com-
pound 2 did not react with aldimines, even when complex 1
was used as an activator. However, we found that 2 slowly
(50% conversion after 2 days, as determined by NMR
=
spectroscopy) hydrosilylated the aldimine PhN CHPh in
ether in the presence of ZnCl2 (1 equiv). No reaction between
=
2 and PhN CHPh or between 2 and ZnCl2 was observed; nor
=
did HSiMe2Ph react with PhN CHPh in the presence of
ZnCl2 under these conditions. We believe that ZnCl2 effec-
tively plays the same role in this reaction as a phosphoric acid
in the reduction of imines by 1,4-dihydropyridines;[19] that is, it
promotes the formation of
a cyclic transition state
(Scheme 2). The requirement of very high temperatures
(150–2008C) for previously reported ZnCl2-mediated hydro-
silylation reactions further supports this hypothesis.[4a,20]
À
Scheme 3. Catalytic hydrogenation of phenanthroline. An=PF6
.
silanol [PhMe2SiOH2]+, which is then deprotonated by
phenanthroline to give [H-phen]+. Hydride transfer from 10
to the 4-position of [H-phen]+ affords the two-hydrogen-
atom-reduced phenanthroline, which coordinates to ruthe-
nium to give a latent form of the catalyst, the observed
complex 8.
In summary, we have discovered unprecedented catalytic
activity and 1,4-selectivity in the hydrosilylation of pyridines
by complex 1 and the catalytic reduction of phenanthroline by
HSiMe2Ph in the presence of the complex [Cp(H3CCN)Ru-
(k2-phen)]+ (7).
=
Scheme 2. Synchronized reaction of 2, PhN CHPh, and ZnCl2.
Although quinoline underwent hydrosilylation (Table 1,
entry 8), its chelating analogue, phenanthroline, poisoned the
catalyst by forming the very stable complex [Cp(iPr3P)Ru(k2-
phen)]+ (6). To free up a reaction site in the catalyst, we
attempted the hydrosilylation of phenanthroline in the
presence of [CpRu(NCCH3)3]+, which contains three poten-
tially labile ligands. However, only very low conversion was
observed. Accidentally, we discovered that adventitious water
triggers a different catalytic process: in the presence of water,
the compound [Cp(NCCH3)Ru(k2-phen)]+ (7) formed in situ
catalyzed the reduction of phenanthroline by excess HSi-
Me2Ph to 1,4-dihydrophenanthroline. An analogous process
occurred in the presence of an alcohol as the proton source.
The reaction was accompanied by intensive evolution of
dihydrogen as a result of concomitant silane hydrolysis
(alcoholysis). However, independent experiments showed
that no hydrogenation of phenanthroline by gaseous hydro-
gen occurred under these conditions in the absence of the
silane.
Monitoring of the course of phenanthroline reduction by
NMR spectroscopy revealed that the complex [Cp(k2-phen)-
Ru(k1-phenH2)]+ (8) with a partially reduced phenanthroline
ligand was the predominant ruthenium species in the reaction
mixture. At the end of reduction, 8 was slowly converted into
the hydride-bridged dimer [{Cp(k2-phen)Ru}2(m-H)]+ (9).
Although complex 9 itself is not an active catalyst, its
formation provides some evidence for the intermediacy of a
neutral ruthenium hydride, [Cp(phen)RuH] (10). Unfortu-
nately, numerous attempts to prepare compound 10 from the
precursor 7 have been unsuccessful so far. In all cases, the
complex 9 was observed as the major product.
Experimental Section
For general reaction conditions, see the Supporting Information.
Synthesis of 2: [CpRu(PiPr3)(CH3CN)2]PF6 (0.20 g, 3 mol%) was
added to a solution of pyridine (1.00 mL, 12.3 mmol) and HSiMe2Ph
(2.00 mL, 13.0 mmol) in CH2Cl2 (20 mL), and the resulting mixture
was stirred for 6 h at ambient temperature. The removal of all
volatiles under vacuum and distillation of the resulting oil under
reduced pressure then gave 2 (1.97 g, 74%) as a yellow oil. 1H NMR
(300 MHz, CDCl3): d = 7.58–7.52 (m, 2H, Ph), 7.42–7.32 (m, 3H, Ph),
=
5.89 (d, JH,H = 8.3 Hz, 2H, NCH CH), 4.45 (dt, JH,H = 8.3, 3.2 Hz, 2H,
=
NCH CHCH2), 2.95 (m, 2H, CH2), 0.42 ppm (s, 6H, SiMe);
13C NMR (75.5 MHz, CDCl3): d = 136.5, 133.8, 129.8, 128.7, 128.1,
1
100.1, 22.5, À2.4 ppm; H–29Si HSQC (CDCl3): d = 1.1 ppm.
Dehydrosilylation of
2
with benzonitrile: [CpRu(PiPr3)-
(CH3CN)2]PF6 (0.002 g, 2 mol%) was added to a solution of 2
(30 mL, 0.14 mmol) and PhCN (14 mL, 0.14 mmol) in [D6]acetone
(0.6 mL), and the resulting mixture was stirred at ambient temper-
=
ature. After 24 h, 40% conversion of 2 into PhCH NSiMe2Ph and
pyridine was observed. Conversion was complete after 18 days at
ambient temperature.
Exchange reaction of
2 with DSiMe2Ph: [CpRu(PiPr3)-
(CH3CN)2]BAF (0.005 g, 5 mol%) was added to a solution of 2
(20 mL, 0.09 mmol) and DSiMe2Ph (14.3 mL, 0.09 mmol) in CH2Cl2
(0.6 mL), and the resulting mixture was stirred at ambient temper-
ature. After 24 h, 25% deuteration of the 4-position of 2 was
1386
