The use of umbelliferone in the synthesis of new heterocyclic compounds

Article abstract of DOI:10.3390/molecules16086833

New coumarin derivatives, namely 7-[(5-amino-1,3,4-thiadiazol-2-yl)methoxy] - 2H-chromen-2-one (4), 5-[(2-oxo-2H-chromen-7-yloxy)methyl]-1,3,4-thiadiazol- 2(3H)- one (5), 2-[2-(2-oxo-2H-chromen-7-yloxy)acetyl]-N- phenylhydrazinecarbothioamide (7), 7-[(5-(phenylamino)-1,3,4-thiadiazol-2-yl) methoxy]-2H-chromen-2-one (8) and 7-[(5- mercapto-4-phenyl-4H-1,2,4-triazol-3- yl)methoxy]-2H-chromen-2-one (9) were prepared starting from the natural compound umbelliferone (1). The newly synthesized compounds were characterized by elemental analysis and spectral studies (IR, 1H-NMR and 13C-NMR).

Full text of DOI:10.3390/molecules16086833

Molecules 2011, 16, 6833-6843; doi:10.3390/molecules16086833
OPEN ACCESS
molecules
ISSN 1420-3049
www.mdpi.com/journal/molecules
Article
The Use of Umbelliferone in the Synthesis of
New Heterocyclic Compounds
Ahmed A. Al-Amiery 1,2,*, Ahmed Y. Musa 1, Abdul Amir H. Kadhum 1 and
Abu Bakar Mohamad 1
1
Department of Chemical and Processing Engineering, Faculty of Engineering and Built
Environment, University of Kebangsaan Malaysia, Bangi, Selangor 43600, Malaysia
2
Biotechnology Division, Applied Science Department, University of Technology,
Baghdad 10066, Iraq
* Author to whom the correspondence should be addressed; E-Mail: dr.ahmed@eng.ukm.my or
dr.ahmed1975@gmail.com.
Received: 11 July 2011; in revised form: 22 July 2011 / Accepted: 1 August 2011 /
Published: 10 August 2011
Abstract: New coumarin derivatives, namely 7-[(5-amino-1,3,4-thiadiazol-2-yl)methoxy]-
2H-chromen-2-one (4), 5-[(2-oxo-2H-chromen-7-yloxy)methyl]-1,3,4-thiadiazol-2(3H)-
one (5), 2-[2-(2-oxo-2H-chromen-7-yloxy)acetyl]-N-phenylhydrazinecarbothioamide (7),
7-[(5-(phenylamino)-1,3,4-thiadiazol-2-yl)methoxy]-2H-chromen-2-one (8) and 7-[(5-
mercapto-4-phenyl-4H-1,2,4-triazol-3-yl)methoxy]-2H-chromen-2-one (9) were prepared
starting from the natural compound umbelliferone (1). The newly synthesized compounds
were characterized by elemental analysis and spectral studies (IR, 1H-NMR and
13C-NMR).
Keywords: coumarin; ethyl bromoacetate; phosphorous oxychloride; 1,3,4-thiadiazole;
thiosemicarbazide; umbelliferone
1. Introduction
Lactones constitute a large and diverse group of biologically active plant chemicals that have been
identified in several plant families [1-3]. Coumarin and its derivatives represent one of the most active
classes of compounds, possessing a wide spectrum of biological activity [4-7]. Many of these
compounds have proved to be active as antibacterial [8,9], antifungal [10], anti-inflammatory [11],

6834
Molecules 2011, 16
anticoagulant [12], anti-HIV [13] and antitumor [14] agents. Coumarins also have superior thermal
stability and outstanding optical properties, including an extended spectral response, high quantum
yields and superior photostability. Optical applications of these compounds, such as laser dyes,
nonlinear optical chromophores, fluorescent whiteners, fluorescent probes, polymer science, optical
recording and solar energy collectors, have been widely investigated [15-19]. The chemistry of
thiosemicarbazones has received considerable attention because of their variable bonding modes,
promising biological implications, structural diversity, and ion-sensing ability [20-22]. Thiazolidinones
substituted in the 2-position, its derivatives and analogues exhibit unusually high in vitro activity
against Mycobacterium tuberculosis [23-25]. In the current study we aimed to synthesize some new
coumarins derived from umbelliferone (7-hydroxycoumarin) and thiazoles, with predictable biological
activities. The chemical structures of the synthesized compounds were proven by IR, NMR spectra and
elemental analysis data.
2. Results and Discussion
2.1. Chemistry
For the synthesis of new umbelliferone derivatives, the reaction sequences outlined in Schemes 1
and 2 were followed. We started from umbelliferone (1) which is commercially available or,
alternatively, readily accessible through a Pechmann and Perkin condensation [26]. Synthesis of ethyl
2-(2-oxo-2H-chromen-7-yloxy) acetate (2) was brought about by refluxing ethyl bromoacetate with
umbelliferone in the presence of anhydrous K2CO3 in dry acetone. Reaction of compound 2 with
sodium hydroxide yield compound 2-(2-oxo-2H-chromen-7-yloxy)acetic acid (3) that was cyclized
with thiosemicarbazide in the presence of phosphorous oxychloride to yield 7-[(5-amino-1,3,4-
thiadiazol-2-yl)methoxy]-2H-chromen-2-one (4) that was converted into compound 5 by adding
sodium nitrate and hydrochloric acid.
Scheme 1. Synthesis of compounds 2–5.

6835
Molecules 2011, 16
Scheme 2. Synthesis of compounds 6–9.
N
O
O
O
S
N
NH
9
Compound 2
NaOH
N2H4
NH2
NH
S
NH
H2SO4
NH
PhNCS
S
NHNH
O
O
O
O
O
O
O
O
O
N
N
O
O
8
7
6
The addition of hydrazine to compound 2 yield compound 6 that was converted to compound 7 by
addition of phenyl isothiocyanate. The cyclization of compound 7 by sulphuric acid yielded compound
8, while reaction with sodium hydroxide produced compound 9.
In the IR spectrum of ethyl 2-(2-oxo-2H-chromen-7-yloxy)acetate (2) the lactone carbonyl
stretching frequency was observed at 1759 cm−1, whereas the ester carbonyl stretching appeared at
1717 cm−1, and a C-H aliphatic stretching frequency appeared at 2987 cm−1 that was not seen in the IR
spectrum of the starting material umbelliferone, in addition of the disappearance of the hydroxyl
1
group. In the H-NMR spectrum of compound 2, a 3H triplet was observed at 3.126 ppm due to the
ester CH3 protons and a quartet at 3.81 ppm due to the ester CH2 protons. The isolated CH2 protons
were observed downfield as a singlet (2H) at 4.770 ppm and triplet (2H) at 5.260, 5.239 and 5.27. The
coumarin alkene C-H appeared at 5.416 ppm. The protons of the aromatic ring were observed as
quartet (7.472, 7.457, 7.413, 7.216 ppm for C6-H), quintet (7.565 7.543, 7.537, 7.525, 7.519 ppm for
C5-H) and doublet, 7.895 ppm, 7.871 ppm for C8-H. The 13C-NMR spectrum analysis for compound 2,
1
combined with the information from H-NMR experiments, can be considered enough to guide future
synthetic work.
In the IR spectrum of 2-(2-oxo-2H-chromen-7-yloxy)acetic acid (3) the lactone carbonyl stretching
frequency was observed at 1755 cm−1, whereas the carboxylic acid carbonyl stretching appeared at
1
1724 cm−1, and the hydroxyl group appeared as a broad band at 2975–3170 cm−1. In the H-NMR
spectrum, the CH2 protons were observed downfield as a singlet (2H) at 4.83 ppm, and triplet (2H) at
5.311, 5.3 and 5.28. The C-H (alkene) of coumarin appeared at 5.418 ppm. The protons of the aromatic
ring were observed as quartet (7.47, 7.455, 7.411, 7.207 ppm for C6-H), triplet (7.555 7.531, 7.527
ppm for C5-H) and doublet (7.90 ppm, 7.876 ppm) for C8-H. The 13C-NMR spectrum analysis for
compound 3, combined with the information from 1H-NMR experiments, can be considered enough to
prove the structure of compound 3.
The IR spectrum is good evidence for formation of compound 4. The absence of a hydroxyl group
at 2975–3170 cm−1, and appearance of a new band at 3302 and 3343 cm−1, and a lactone carbonyl

6836
Molecules 2011, 16
1
stretching frequency at 1749 cm−1 were observed. In the H-NMR spectrum, a singlet (thiadiazole-
NH2) at 4.94 ppm and the C-H (alkene) of the coumarin appeared at 5.76 ppm and 5.891. The protons
13
of the aromatic ring were observed as multiplet (7.51–7.28). In the C-NMR, 163.5 and 176.4 were
new and due to the heterocyclic ring carbons.
The IR spectrum of compound 5 showed a carbonyl group at 1713 cm−1, in addition to an amino
1
group at 3297 cm−1. In the H-NMR; the coumarin C-H (alkene) protons appeared at 5.81 ppm
(singlet) and 6.43 ppm (singlet) and the singlet (NH) at 5.31 ppm. In the 13C-NMR the thiadiazole ring
carbonyl carbon atom appears at very low field (171.2).
Hydrazinolysis of compound 2 with hydrazine hydrate afforded 2-(2-oxo-2H-chromen-7-
yloxy)acetohydrazide (6) in good yield. The IR spectra of compound 6 showed absorption bands in the
3351.3, 3287.1 cm−1 region (hydrazide NH-NH2), 1689.2 cm−1 (amide-C=O carbonyl stretching), and
1761.5 cm−1 (lactone-C=O carbonyl stretching). The 1H-NMR spectrum exhibited a singlet due to the
–CO-NH-NH2 proton at δ 7.93 ppm. For compound 7, the IR spectrum has the following characteristic
absorption bands: νN-H (3367.6, 3301.2, 3278.9 cm−1); νC=O (1763 lactone; 1692.7 amide carbonyl
cm−1), νC=S (1258.5 cm−1). In the IR spectrum of compound 8, no absorption band at 1692.7 cm−1 was
detected, indicating the absence of the amide carbonyl group, which is evidence for the conversion of
compound 7 to compound 8. Also, in the IR spectrum of the new heterocyclic compound 8 a stretching
band characteristic of the C=N group from the thiadiazole nucleus appeared at 1620.6 cm−1. Although
two types of tautomers, thione or thiole, could be expected from the cyclization of compound 7, under
basic conditions, only the thione type compound 9 was observed. The existence of the thione form
predominantly in the solid state is demonstrated by the presence of two absorption bands at 1257 cm−1
and 3389.3 cm−1 belonging to the νC=S and νNH groups, respectively, and by absence of νSH. In the
13C-NMR spectra of new heterocyclic compounds 8 and 9 the absence of the signals for the ester
carbonyl and the absence of a thiocarbonyl carbon in compound 8, confirmed that cyclization of
compound 7 took place. In compound 9 the signal at 168.4 ppm indicated that in solution this
compound exists predominantly in the thione tautomeric form (Scheme 3).
Scheme 3. Tautomerization of thione.
2.2. Computational Studies
2.2.1. Atomic Charges and Stabilities
The theoretical studies for compound 5 revealed that the atomic charges have been affected by the
presence of the ring substituent. The minimized geometry is shown in Figure 1, where the calculated
atomic charges for the compound are also indicated. It can be seen from Figure 1 that the highest
atomic charge is at [O(6) −0.272)] the next charge value is at [O(19) −0.265]. These results clearly
indicated that these two atoms are the most reactive sites toward the reactions and bonding with the

6837
Molecules 2011, 16
metals. The calculated bond and twist angles (supplementary file) and 3d-geometrical structure,
indicated that this molecule is not planar.
Figure 1. 3d-geometrical structure for compound 5.
The minimized geometry for the compound 8 is shown in Figure 2. The calculated atomic charges
for the compound are shown in the figure too. The results showed that the highest atomic charge is at
[O(6) −0.272)] and the next charge value is at [O(19) −0.265]. These results showed clearly that these
two atoms are the most reactive sites toward the reactions and bonding with the metals. The
determined bond angles, twist angles and 3d-geometrical structure, indicate that this molecule is not
planar and the C(2)-C(3) stereochemistry is (Z).
Figure 2. 3d-geometrical structure for the compound 8.
2.2.2. Density Function Theory (DFT)
DFT calculations were performed for compounds 5 and 8. Optimized molecular structures of the
most stable forms are shown in Figure 3. Their calculated energies and relative energies are presented
in Table 1. Molecular orbital calculations provide a detailed description of orbitals including spatial
characteristics, nodal patterns and individual atom contributions. The contour plots of the frontier
orbitals for the ground state of 5 and 8 are shown in Figure 4, including the Highest Occupied

6838
Molecules 2011, 16
Molecular Orbital (HOMO) and the Lowest Unoccupied Molecular Orbital (LUMO). It is interesting
to see that both orbitals are substantially distributed over the conjugation plane. It can be seen from the
Figure 4 that the HOMO orbitals are located on the substituted molecule while LUMO orbitals
resemble those obtained for the unsubstituted molecule and therefore the substitution has an influence
on the electron donation ability, but only a small impact on electron acceptance ability [27]. The
orbital energy levels of HOMO and LUMO of compounds 5 and 8 are listed in Table 2. It can be seen
that the energy gaps between HOMO and LUMO is about 0.11 and 0.008 H.a. for the compounds 5
and 8, respectively. The lower value in the HOMO and LUMO energy gap explain the eventual charge
transfer interaction taking place within the molecules. The dipole moments of compounds 5 and 8,
were also calculated and listed in Table 3. The dipole moment for compounds 5 is oriented inwards,
while the dipole moment for compounds 8, is oriented outwards.
Figure 3. Optimized molecular structures of 5 and 8 by DFT.
Figure 4. HOMO orbitals of 5 and 8.
Figure 5. LUMO orbitals of 5 and 8.
Table 1. Total Energy, relative energies and heat of formation (H.a.) for 5 and 8.
Total
Sum of atomic
energies
Binding
energy
−5.061
−7.135
Kinetic Electrostatic
energy
5
8
−120.394
−145.743
−1265.697
−1474.474
−11.406
−11.317
2.934
−0.569

6839
Molecules 2011, 16
Table 2. HOMO and LUMO energies of 5 and 8.
HOMO (H. a) LUMO (H. a) ∆E
5
8
−0.207
−0.190
−0.097
−0.092
−0.11
−0.098
Table 3. The dipole moments (Debye) of 5 and 8.
x-component
−0.11
y-component z-component magnitude
5
8
2.694
4.254
0.019
0.627
2.697
4.748
2.016
3. Experimental
3.1. General
The chemicals used for the synthesis were supplied by Sigma-Aldrich. Purity of the compounds
was checked on thin layer chromatography (TLC) plates (Silicagel G) using the solvent systems
benzene-ethyl acetate-methanol (40:30:30, v/v/v) and toluene-acetone (75:25, v/v). The spots were
located under UV light (254 and 365 nm). The IR spectra were obtained on a Thermo Scientific,
Nicolet 6700 FT-IR spectrometer (without KBr or CsI pellets). The 1H-NMR spectra were obtained on
a Jeol jnm-ECP400 FT-NMR system. Elemental microanalysis was carried out using a model
5500-Carlo Erba C.H.N elemental analyzer instrument. A Gallenkamp M.F.B.600.010 F melting point
apparatus was used to measure the melting points of all the prepared compounds.
3.2. Synthesis
Ethyl 2-(2-oxo-2H-chromen-7-yloxy)acetate (2). A suspension of 7- hydroxycoumarin (6.17 mmol) in
acetone (30 mL) was refluxed with ethyl bromoacetate (9.15 mmol) and K2CO3 (4.69 g, 33.91 mmol)
for 12 h. After cooling, the mixture was evaporated to dryness and the residue was partitioned between
CHCl3 (50 mL) and water (50 mL). The organic phase was dried (Na2SO4), filtered and evaporated to
1
dryness. The residue was recrystallized from acetone, yield 82%, m.p. 112.5 °C; H-NMR (CDCl3): δ
3.126 (t, 3H, CH3), δ 3.81 (m, 2H, CH2), δ 4.77 (s, 2H) and δ 5.260, δ 5.239, δ 5.270 (s, 2H, CH2), δ
13
5.416 (s, 1H, –C=C-H), δ 7.472, δ 7.457, δ 7.413, δ 7.216 (q, 1H, aromatic); C-NMR (DMSO-d6):
22.3, 58.9, 65.1, 103.8, 108, 108.9, 110.1, 123.7, 154.6, 157.1, 160.8, 161.2, 166.5; IR: 2987 cm−1
(C-H, aliphatic), 1759 cm−1 (C=O, lactone), 1717 cm−1 (C=O, ester); Anal. Calcd. for C13H12O5: C
62.90%, H 4.87%. Found: C 61.81% H 4.01%.
2-(2-Oxo-2H-chromen-7-yloxy)acetic acid 3. A solution of the compound 2 (2.7 mmol) and 5%
sodium hydroxide (2.16 mL) in ethanol (15 mL) was stirred under reflux for 2 h. After removal of the
solvent, the residue was dissolved in water and acidified with HCl 6 M. The white solid collected by
filtration was washed with cool water, dried and recrystallized from ethanol, yield 92%, m.p. 210.5 °C;
1H-NMR (CDCl3): δ 4.83 (s, 2H) and δ 5.311, δ 5.300, δ 5.280 (s, 2H, CH2), δ 5.418 (s, 1H, –C=C-H),
δ 7.470, δ 7.455, δ 7.411, δ 7.207 (q, 1H, C6-H aromatic ring), δ 7.555, δ 7.531, δ 7.527 (t, 1H) for
C6-H aromatic ring, δ 7.90, δ 7.876 (s, 1H, C8-H aromatic ring ); 13C-NMR (DMSO-d6): 105.2, 110.3,

6840
Molecules 2011, 16
112.9, 113.9, 124.1, 153.9, 156.3, 161.2, 161.9, 167.1; IR: 3170-2975 cm−1 (hydroxyl), 1755 cm−1
(C=O, lactone), 1724 cm−1 (C=O, carboxylate); Anal. Calcd. for C11H8O5: C 60.00%, H 3.66%. Found:
C 58.40% H 2.94%.
7-[(5-Amino-1,3,4-thiadiazol-2-yl)methoxy]-2H-chromen-2-one (4). Phosphorus oxychloride (20 mL)
was added to compound 3 (0.05 mol) and the mixture was stirred for 1 h. at room temperature.
Thiosemicarbazide (4.56 gm, 0.05 mol) was added and the mixture was heated under reflux for 5 h. On
cooling, the mixture was poured on to ice. After 4 h. the mixture was stirred for 15 min. to decompose
the excess phosphorus oxychloride, then heated under reflux for 30 min, cooling, the mixture was
neutralized by 5% potassium hydroxide, the precipitate was filtered, washed with water, dried and
1
recrystallized from ethanol, yield 51%, m.p. 105 °C; H-NMR (CDCl3): δ 4.94 (s, 1H, NH2), δ 5.760,
5.891 (s, 1H, –C=C-H), δ 7.510–7.283 (m, 1H, C-H aromatic ring); 13C-NMR (DMSO-d6): 101.9,
1
111.0, 113.1, 114.1, 128.1, 149.5, 156.3, 160.8, 161.2, 163.5, 168.3, 176.4; IR: 3302 and 3343 cm−
1
(N-H, amine), 1747 cm− (C=O, lactone); Anal. Calcd. for C12H9N3O3S: C 52.36%, H 3.30%, N
15.26%. Found: C 50.49% H 2.76%, N 16.20%.
5-[(2-Oxo-2H-chromen-7-yloxy)methyl]-1,3,4-thiadiazol-2(3H)-one (5). 10% Aqueous sodium nitrite
solution (10 mL) was added dropwise with continuous stirring over a period of 20 min to an cooled
(ice-bath) suspension of compound 4 (0.01 mol) and hydrochloric acid (5 mL) in cold water (20 mL).
The temperature was then allowed to rise to room temperature and the mixture was heated to boiling
for 10 min, cooled and allowed to stand overnight. The separated crude product was filtered, washed
1
with water, dried and recrystallized from ethanol, yield 47%, m.p. 133 °C; H-NMR (CDCl3): δ 5.31
13
(s, 1H, NH), δ 5.810, 6.430 (s, 1H, –C=C-H), δ 7.811–7.299 (m, 1H, C-H aromatic ring); C-NMR
(DMSO-d6): 103.2, 115.1, 117.5, 117.9, 123.2, 155.3, 155.9, 156.4, 160.8, 161.1, 166.2, 171.2; IR:
1
1
3397 cm− (N-H, amine), 1713 cm− (C=O, lactone); Anal. Calcd. for C12H8N2O4S: C 52.17%, H
2.29%, N 10.14%. Found: C 50.34% H 3.01%, N 9.51%.
2-(2-Oxo-2H-chromen-7-yloxy)acetohydrazide (6). A solution of compound 2 (10 mmol) in ethanol
(25 mL) was refluxed with hydrazine hydrate (25 mmol) for 4 h. After concentrating the reaction
mixture a solid mass separated out and was recrystallized from ethanol, yield 75%, m.p. 234.5 °C;
1H-NMR (CDCl3): δ 7.93 (-CO-NHNH2), δ 4.61 (s, 2H) and δ 5.251, δ 5.222, δ 5.214 (s, 2H, CH2), δ
1
5.716 (s, 1H, –C=C-H), δ 7.61–7.110 (s, 1H, aromatic ring); IR: 3351.3 and 3287.1 cm− (N-H,
1
1
hydrazide), 1761.5 cm− (C=O, lactone), 1689.2 cm− (C=O, amide); Anal. Calcd. for C11H10N2O4: C
56.40%, H 4.38%, N 11.96%. Found: C 54.44%, H 4.04%, N 10.79%.
2-[2-(2-Oxo-2H-chromen-7-yloxy)acetyl]-N-phenylhydrazinecarbothioamide (7).
A
mixture of
hydrazide 6 (2 mmol) and phenyl isothiocyanate (2 mmol) in ethanol (15 mL) was refluxed for 12 h.
The reaction mixture was cooled and the separated product was filtered off, dried and recrystallized
1
from ethanol, yield 61%, m.p. 199 °C; IR: 3367.6, 3301.2 and 3278.9 cm− (N-H, hydrazone),
1
1
1
1763 cm− (C=O, lactone), 1692.7 cm− (C=O, amide), 1258.5 cm− (C=S); Anal. Calcd. for
C18H15N3O4S: C 58.53%, H 4.09%, N 11.38%. Found: C 56.49%, H 3.78%, N 10.22%.

6841
Molecules 2011, 16
7-[(5-(Phenylamino)-1,3,4-thiadiazol-2-yl)methoxy]-2H-chromen-2-one (8). A mixture of compound 7
(0.15 mmol) and concentrated H2SO4 (5 mL) was stirred in ice path for 5 h and then, at room
temperature, for another 5 h. The reaction mixture was neutralized with a diluted solution of
ammonium hydroxide, in ice bath. The precipitated was filtered off, washed with water, dried and
1
1
recrystallized from ethanol, yield 57%, m.p. 244 °C; IR: 3291 cm− (N-H), 1762.8 cm− (C=O,
1
13
lactone), 1620.6 cm− (C=N); C-NMR (DMSO-d6): 100.3, 107.2, 111.9, 114.2, 122.0, 125.4, 126.2,
126.8, 129.2, 129.7, 141.6, 156.2, 156.9, 157.3, 158.1, 160.5, 169.3; Anal. Calcd. for C18H13N3O3S: C
61.53%, H 3.73%, N 11.96%. Found: C 61.01%, H 3.11%, N 11.32%.
7-[(4-Phenyl-5-thioxo-4,5-dihydro-1H-1,2,4-triazol-3-yl)methoxy]-2H-chromen-2-one (9). Compound
7 (0.5 mmol) was added to 8% NaOH solution (4 mL) and the reaction mixture was heated under
reflux for 4 hours. After cooling, the solution was acidified with a diluted solution of HCl. The crude
product was precipitated, filtered off and washed with water. The solid thus separated was dried and
1
1
recrystallized from chloroform, yield 44%, m.p. 251 °C; IR: 3389.3 cm− (N-H), 1767.7 cm− (C=O,
1
1
13
lactone), 1618.1 cm− (C=N), 1257 cm− (C=S); C-NMR (DMSO-d6): 99.6, 109.8, 112.3, 114.1,
122.3, 127.1, 129.3, 129.8, 130.1, 130.9, 134.4, 154.0, 155.8, 156.5, 157.2, 163.6, 168.4; Anal. Calcd.
for C18H13N3O3S: C 61.53%, H 3.73%, N 11.96%. Found: C 61.01%, H 3.11%, N 11.32%.
3.3. DFT
The molecular drawings of the nine thio compounds were plotted using Visualization Materials
Studio 5.5. All quantum chemical calculations were performed using Density Functional Theory
(DFT) as implemented in the Materials Studio 5.5 software. DMol3 model was employed to obtain
quantum chemical parameters and to optimize the molecules’ geometry. These calculations employed
an ab initio, generalized gradient approximation (GGA) with the Lee-Yang-Parr correlation functional
(BLYP) functional and Double Numerical d-functions (DND) basis set. This approach is shown to
yield favorable geometries for a wide variety of systems. The following quantum chemical indices
were calculated: the energy of the highest occupied molecular orbital (HOMO), the energy of the
lowest unoccupied molecular orbital (LUMO) and dipole moment.
4. Conclusions
In this study, the compounds 2–9 were synthesized, and characterized using various spectroscopic
methods and elemental analysis. The synthesized compounds were studied theoretically and the atomic
charges, heat of formation and stereochemistry were estimated, and it was found that compounds 5 and
8 are not planar.
References
1. Mirjalili, M.; Moyano, E.; Bonfill, M.; Cusido, M.; Palazón, J. Steroidal Lactones from Withania
somnifera, an Ancient Plant for Novel Medicine. Molecules 2009, 14, 2373-2393.
2. Li, J.; Zhou, B. Biological Actions of Artemisinin: Insights from Medicinal Chemistry Studies.
Molecules 2010, 15, 1378-1397.

6842
Molecules 2011, 16
3. Al-Amiery, A.A.; Mohammed, A.; Ibrahim, H.; Abbas, A. Study the biological activities
of tribulus terrestris extracts. World Acad. Sci. Eng. Technol. 2009, 57, 433-435.
4. El-Agrody, A.; Abd El-Latif, M.; El-Hady, N.; Fakery1, A.; Bedair, A. Heteroaromatization with
4-ydroxycoumarin Part II: Synthesis of Some New Pyrano[2,3-d]pyrimidines, [1,2,4]triazolo[1,5-
c]pyrimidines and Pyrimido[1,6-b] [1,2,4]triazine Derivatives. Molecules 2001, 6, 519-527.
5. Rositca, D.; Nikolova, G.N.; Vayssilov, R.; Bojilova, R. Stereoselective [2 + 2]
Photodimerization of 3-Substituted 2-Alkoxy-2-oxo-2H-1,2-benzoxaphosphorines. Molecules
2002, 7, 420-432.
6. Flašík, R.; Stankovičová, H.; Gáplovský, A.; Donovalová, J. Synthesis and Study of Novel
Coumarin Derivatives Potentially Utilizable as Memory Media. Molecules 2009, 14, 4838-4848.
7. Sergiy, K.; Bylov, I.; Sytnik, K.; Chernykh, V.; Bilokin, Y. A New Pathway to 3-Hetaryl-2-oxo-
2H-chromenes: On the Proposed Mechanisms for the Reaction of 3-Carbamoyl-2-
iminochromenes with Dinucleophiles. Molecules 2000, 5, 1146-1165.
8. Jianwei, H.; Yong, X.; Jingwei, Z.; Shizheng, Z. l-Proline catalyzed condensation–cyclization
tandem process: Facile and effective synthesis of 3-polyfluoroalkanesulfonyl coumarin.
J. Fluorine Chem. 2011, 132, 409-413.
9. Musicki, B.; Periers, P.; Laurin, D.; Ferroud, Y.; Bendetti, S.; Lachaud, F.; Chatreaux, J.;
Haesslein, L.; Iltis, A.; Pierre, C.; Khider, J.; Tessot, N.; Airault, P.; Bonnefoy, A.; Vicat, P.;
Klich, M. Bioorg. Med. Chem. Lett. 2000, 10, 1695-1699.
10. Bistra, S.; Voislava, J.; Boris, S.; Nikolova, P.; Goran, S.; Bozhna, M.; Emil, P. Experimental and
theoretical investigation of the structure and nucleophilic properties of 4-aminocoumarin.
ARKIVOC 2010, x, 62-76.
11. Garazd, M.M.; Muzychka, O.V.; Voyk, A.I.; Nagorichna, I.V.; Ogorodniichuk, A.S. Synthesis
and antioxidant activity of 3-substituted 5,7-dihydroxy-4-methylcoumarins. Chem. Nat. Compd.
2007, 43, 19-23.
12. Edmont, V.; Jochen, M. Pechmann Reaction Promoted by Boron Trifluoride Dihydrate.
Molecules 2005, 10, 762–76.
13. Kotali, A.; Lafazanis, I.; Harris, P. ChemInform Abstract: Synthesis of 6,7-Diacylcoumarins via
the Transformation of a Hydroxy into a Carbonyl Group. Synth. Commun. 2008, 38, 3996-4006.
14. Nofal, Z.M.; El-Zahar, M.; Abd El-Karim, S. Novel coumarin derivatives with expected
biological activity. Molecules 2000, 5, 99-113.
15. Lin, S.; Kuo, P.; Yang, D. Design and Synthesis of a Coumarin-based Acidichromic Colorant.
Molecules 2007, 12, 1316-1324.
16. Verdía, P.; Santamarta, F.; Tojo, E. Knoevenagel Reaction in [MMIm][MSOS]: Synthesis of
Coumarins. Molecules 2011, 16, 4379-4388.
17. Mukhatar, S.; Mujeebur, R.V.P.; Ansari, W.H.; Lemiere, G.; De Groot, A.; Dommisse, R.
Bifunctional Derivative of p,p’-Dichlorochalcone. Part II. Synthesis of a Novel Compound
2-[2-Carboxymethylthio-2-(4-chlorophenyl)ethyl]-2-(4-chlorophenyl)-4-thiazolidinone. Molecules
1999, 4, 232-237.
18. Milan, C.; Maja, M.; Tomislav, B.; Nela, D.; Valentina, R. Design and Synthesis of Some
Thiazolidin-4-ones Based on(7-Hydroxy-2-oxo-2H-chromen-4-yl) Acetic Acid. Molecules 2009,
14, 2501-2513.

6843
Molecules 2011, 16
19. Butsch, W.L.; Stewart, J.D. Administration of dicoumarin compounds for prophylaxis of post
operative thrombosis and embolism. Arch. Surg. 1942, 45, 551-553.
20. Casas, J.S.; García-Tasende, M.S.; Sordo, J. Corrigendum to Main group metal complexes of
semicarbazones and thiosemicarbazones. A structural review. Coordin. Chem. Rev. 2000, 209,
197-261.
21. Mishra, D.; Naskar, S.; Michael, G.; Kumar, S. Synthesis, spectroscopic and redox properties of
some ruthenium(II) thiosemicarbazone complexes Structural description of four of these
complexes. Chattopadhyay 2006, 359, 585-592.
22. Al-Amiery, A.A.; Al-Majedy, K.; Abdulreazak H.; Abood, H. Synthesis, Characterization,
Theoretical Crystal Structure and Antibacterial activities of some transition metal complexes of
the thiosemicarbazone (Z)-2-(pyrrolidin-2-ylidene)hydrazinecarbothioamide. Bioinorg. Chem.
Appl. 2011, 2011, Article ID 483101, 6 pages.
23. Hintz, K.K.; Ren, J. Tetramethyl pyrazine elicits disparate responses in cardiac contraction and
intracellular Ca2+ transients in isolated adult rat ventricularmyocytes. Vascul. Pharmacol. 2003,
40, 213-217.
24. Cacic, M.; Trkovnik, M.; Cacic, F.; Has-Schon, E. Synthesis and Antimicrobial Activity of Some
Derivatives of (7-Hydroxy-2-oxo-2H-chromen-4-yl)-acetic Acid Hydrazide. Molecules 2006, 11,
134-147.
25. Ezabadi, I.R.; Camoutsis, C.; Zoumpoulakis, P.; Geronikaki, A.; Soković, M.; Glamocilija, J.;
Cirić, A. Sulfonamide-1,2,4-triazole derivatives as antifungal and antibacterial agents: Synthesis,
biological evaluation, lipophilicity, and conformational studies. Bioorg. Med. Chem. 2008,
16, 1150.
26. Kadhum, A.H.; Mohamad, A.; Al-Amiery, A.A. Anti-microbial and anti-oxidant activities of new
metal complexes derived from 3-aminocoumarin. Molecules 2011, in press.
27. Musa, A.Y.; Kadhum, A.A.H.; Mohamad, A.B.; Rahoma, A.A.B.; Mesmari, H. Electrochemical
and quantum chemical calculations on 4,4-dimethyloxazolidine-2-thione as inhibitor for mild
steel corrosion in hydrochloric acid. J. Mol. Struct. 2010, 969, 233-237.
Sample Availability: Samples of the compounds 1–9 are available from the authors.
© 2011 by the authors; licensee MDPI, Basel, Switzerland. This article is an open access article
distributed under the terms and conditions of the Creative Commons Attribution license
(http://creativecommons.org/licenses/by/3.0/).
