sion of the Boc group into a silyl carbamate was achieved by
ful. Substrate 30 then was cleanly S-detritylated and O-Dpm-
using TBSOTf.[17] We found that TBS carbamate 24 could be
directly coupled to thiazole acid fragments 10 or 11 (see the
Supporting Information) by using HATU/HOAt and solid
NaHCO3, which apparently releases the amine from the TBS
carbamate slowly in situ. Coupling products could thereby be
obtained in good yields (39–71%). Interestingly we found
that silyl-protected threonine residues induced sensitivity to
E/Z isomerization of the enamine double bond under basic
conditions, while the N-acyl enamine had been rather inert in
building blocks featuring a tBu protecting group.[9] This
feature was more prominent with larger groups (TIPS >
TBS @ tBu). An excess of DBU at low temperature was
found to be optimal to cleanly achieve Fmoc cleavage (!7,
95%).
Closure of the B-ring assembly was then tested after Pd-
mediated deallylation[18] of ester 25 (Scheme 3). Coupling of
amine 27 to the resulting acid led to an amide that had to be
Tr- and Dpm-deprotected. Under acidic conditions, partial
cleavage of the indolyl ester and/or loss of the TBS groups
became apparent. However, TFA in anisole gave clean
conversion into an w-mercapto carboxylic acid that was
consecutively cyclized to thiolactone 28 in 66% yield. These
experiments validated the protecting-group strategy and set
the stage for completion of the synthesis. Notably, it was
found that the TBS group on the threonine residue was rather
labile toward acids and fluoride, therefore, the more stable
TIPS derivative was subsequently used instead.
deprotected by applying the conditions established earlier.
The annelated macrothiolactone B-ring was effectively
formed with PyAOP in THF (!31, 43%).
In order to install the terminal DHA residue, the primary
TIPS ether on scaffold 31 was selectively removed by using
aqueous HF. For the dehydration of the terminal serine
amide, a variety of conditions and reagents (e.g., TsCl/DMAP,
Tf2O, PPh3/CCl4, CuICl/EDCI) were tested to induce elimi-
nation. Concomitantly, dehydration of the terminal amide
(nitrile formation), Ts-deprotection, and/or 3-hydroxypyri-
dine refunctionalization were frequently observed. To our
delight, O-sulfonylation of the monodesilylated compound
could be selectively achieved by using MsCl and 2,6-lutidine.
Carefully monitored treatment with DBU then induced
elimination to generate the crucial DHA residue (!32, ca.
70%, 35% after preparative HPLC). Further desilylation was
then realized by using Et3N·3HF. The concluding cleavage of
the O-Ts group was then achieved by exposing compound 33
to a solution of HOBT in DMF in the presence of base.
Notably, the Ts group was removed cleanly without compro-
mising the thioester bond. Synthetic nosiheptide (1) was then
purified by employing preparative TLC (ca. 65%) followed
by preparative HPLC (36% yield over two steps).
Although mass spectrometry and optical rotation meas-
urements of the final product 1 indicated structural identity,
we found the NMR spectra of nosiheptide to be quite
dependent on solvent mixture, water content, and pH. To
exclude ambiguities, a comparison with original material was
pursued. The natural product was isolated for this purpose
from a commercial feeding additive containing nosiheptide
(“1% premix”) by following published procedures.[20] Com-
parison of HPLC, NMR, and LC–MS data for the synthetic
compound 1 with those for the synthesized material unequiv-
ocally confirmed structural identity (see the Supporting
Information).
Moreover, an initial activity evaluation in inhibition-zone
tests showed that the isolated and synthetic material similarly
inhibited the growth of Streptomyces coelicolor, with appar-
ent minimum inhibitory concentration (MIC) values of 0.3 mm
in each case (see the Supporting Information). This result
demonstrates that nosiheptide also displays potent antibacte-
rial activity against soil bacteria, very close relatives and
congeners of the producer S. actuosus. Surprisingly, O-
tosylation of the hydroxypyridine core is not tolerated, since
compound 33 did not display any appreciable antibacterial
activity. These results are currently being further investigated
with pathogenic bacteria.
Scheme 3. Completion of the fully equipped B-ring model. Reagents
and conditions: a) [Pd(PPh3)4] (20 mol%), PhSiH3 (8.6 equiv), THF,
08C, 20 min, 93%; b) PyBOP (2.1 equiv), EtNiPr2 (2.5 equiv), 27
(1.5 equiv), DMF, 08C!208C, 16 h, 77%; c) anisole/TFA/Et3SiH
(8:5:4), ꢀ258C!08C, 24 h; d) PyAOP (1.2 equiv), EtNiPr2 (2.2 equiv),
THF, 08C, 15 min, 208C, 1 h, 66%.
In conclusion, a viable total synthesis of the bicyclic
thiopeptide antibiotic nosiheptide was developed that enables
access to unique class e thiopeptide scaffolds. Key features
are an optimized macrocyclization precursor setup and an
advanced protecting-group strategy adapted to the specific
liabilities of the nosiheptide structure. Since this synthesis
allows the exchange of building blocks, we anticipate that
a deeper chemical biology profiling of this highly potent and
structurally surprising antibiotic by chemical synthesis will
now be possible.
Amine 7 had now to be coupled with acid 8 to obtain the
fully assembled linear precursor 29 (Scheme 4). During these
experiments, we found that the Ts protection of the hydroxy-
pyridine was partially cleaved when HOBt or HOAt were
used in excess. After screening coupling reagents, clean
conversion and an excellent coupling yield of 93% were
achieved by using PyDOP.[19] Pd-mediated Alloc and allyl
deprotection and consecutive macrocyclization of the A-ring
by using HATU under highly dilute conditions were success-
