Rotaxane-based molecular switch with fluorescence signaling

Article abstract of DOI:10.1016/S0040-4039(99)02094-8

A pseudorotaxane containing cucurbituril (as a molecular 'bead') threaded on fluorenyltriamine (as a 'string') behaves as a fluorescent, reversible molecular switch. The switching of the molecular bead from one site to the other site on the 'string' induc

Full text of DOI:10.1016/S0040-4039(99)02094-8

TETRAHEDRON
LETTERS
Pergamon
Tetrahedron Letters 41 (2000) 471–475
Rotaxane-based molecular switch with fluorescence signaling
Sung Im Jun,a Jae Wook Lee,a Shigeru Sakamoto,b Kentaro Yamaguchi b and Kimoon Kim a,∗
aNational Creative Research Initiative Center for Smart Supramolecules and Department of Chemistry,
Pohang University of Science and Technology, San 31 Hyojadong, Pohang 790-784, South Korea
bChemical Analysis Center, Chiba University, 1-33 Yayoicho, Inageku, Chiba 263-8522, Japan
Received 10 August 1999; revised 21 September 1999; accepted 2 November 1999
Abstract
A pseudorotaxane containing cucurbituril (as a molecular ‘bead’) threaded on fluorenyltriamine (as a ‘string’)
behaves as a fluorescent, reversible molecular switch. The switching of the molecular bead from one site to the
other site on the ‘string’ induced by pH change is easily detected by change in color and fluorescence. © 2000
Elsevier Science Ltd. All rights reserved.
Keywords: supramolecular chemistry; rotaxane; molecular switch; fluorescence.
We have been studying self-assembly of interlocked structures such as rotaxanes, polyrotaxanes and
molecular necklaces using cucurbituril (CB) as a molecular ‘bead’.1 In an effort to develop interlock-
ed structures with functions we became interested in rotaxane-based molecular switches. Molecular
switches that are controllable, reversible and readable at molecular level are an essential component of
molecular electronics.2 Several rotaxane-based molecular switches that involve mechanical movement of
a ‘ring’ component between two sites on a ‘string’ induced by external stimuli such as changes in pH
or electrical potentials, and light have been reported.3,4 Although fluorescence has been widely used as
one of the most sensitive detection means in sensors,2,5 no rotaxane-based molecular switch capable of
fluorescence signaling has been reported. Here we report a rotaxane-based molecular switch, that can be
turned on and off chemically with changes in fluorescence as well as color.
Mock reported a rotaxane-based molecular switch which consists of a CB ‘bead’ and a triamine ‘string’
PhNH(CH2)6NH(CH2)4NH2.4a When all the nitrogen atoms of the ‘string’ are protonated at low pH, the
‘bead’ resides at the protonated diaminohexane site, because CB forms a more stable complex with
diprotonated diaminohexane than with diprotonated diaminobutane. Upon deprotonation of the aniline
nitrogen (pKa=6.7), the ‘bead’ migrates to the diprotonated diaminobutane site because binding with
the monoprotonated diaminohexane is weaker. Based on this elegant work, we designed a fluorescent
molecular switch 1 (Fig. 1) which can signal the change in the ‘bead’ position by color and fluorescence
changes.
∗
Corresponding author. Tel: +82-562-279-2113; fax: +82-562-279-8129; e-mail: kkim@postech.ac.kr (K. Kim)
0040-4039/00/$ - see front matter © 2000 Elsevier Science Ltd. All rights reserved.
PII: S0040-4039(99)02094-8
tetl 16022

472
Fig. 1. Fluorescent, reversible rotaxane-based molecular switch 1
The synthesis of 1 is outlined in Scheme 1. Mono-protection of 1,6-hexanediol by benzyl bromide,
followed by oxidation affords 2. Reductive alkylation of 2-aminofluorene with 2 produces a secondary
amine. Protection of the amine group with TsCl, followed by deprotection of the benzyl group and
oxidation of alcohol affords 3. Coupling of 3 with mono-cbz-protected 1,4-diaminobutane followed
by deprotection gives the fluorenyltriamine ligand 4. The complex formation of 4 with cucurbituril
1
in water produces (pseudo)rotaxane 1.6 All the compounds have been characterized by H/13C NMR
spectroscopy, mass spectrometry and/or elemental analysis.
Scheme 1. Reagents and conditions: (i) BnBr, NaH, DMF, 6 h and then PCC, CH2Cl2; (ii) 2-amino-fluorene, Et3N, CH2Cl2, 12
h and then NaBH4, MeOH, 12 h, 62%; (iii) TsCl, Et3N, CH2Cl2, 12 h, 93%; (iv) H2, Pd/C (10%), EtOH, 12 h, 92%; (v) PCC,
CH2Cl2, 6 h, 95%; (vi) mono-cbz-1,4-diaminobutane, Et3N, CH2Cl2, 12 h and then NaBH4, MeOH, 12 h, 81%; (vii) 30% HBr
in AcOH, PhOH, 60°C, 74%; (viii) NaOH (aq.), CH2Cl2; (ix) concd HCl, MeOH, 87%; (x) cucurbituril, water, 95%
1
Fig. 2 compares H NMR spectra of 1 at pHs, 1.0, 4.4 and 8.0. Each peak has been assigned
unambiguously from 2D COSY spectra. The signals for the methylene groups located inside CB are
shifted to higher field due to the shielding effect of CB. These NMR spectra are consistent with
the interpretation that the CB bead resides at the (protonated) diaminohexane site at pH of 1.0, but
translocates to the (protonated) diaminobutane site at pH=8.0. At intermediate pH, we observe both
species, one with the bead at the diaminohexane site and one with the bead at the diaminobutane site,
in equilibrium. The shuttling of CB between the two sites is slow on the NMR time scale as separate
resonances are observed for each binding mode.
Most importantly, the switching of CB from one site to the other in 1 is easily detected by change
in color and fluorescence with high sensitivity. Fig. 3 displays changes in UV–visible and emission
spectra of 1 with the pH change.7 The intensity of the absorption band at 265 nm decreases while that

473
Fig. 2. 1H NMR (300 MHz) spectra of 1 at pHs, (a) 1.0, (b) 4.4 and (c) 8.0.
at 300 nm increases with an isosbestic point at 275 nm as the pH of the solution increases. The color of
the aqueous solution of 1 at pH 1.0 is yellow, which changes slowly with increasing pH and becomes
violet at pH 7.0. The solution of 1 at pH 1.0 is highly fluorescent with an emission maximum at 308
nm.7 The fluorescence intensity decreases with increasing pH due to the deprotonation of the aromatic
nitrogen. The fluorescence is almost completely quenched at pH 7.0. Such fluorescence quenching upon
deprotonation of nitrogen attached to a fluorophore is known to occur through a photo-induced electron
transfer mechanism.5 The pKa of the aromatic nitrogen in 1 estimated from these spectral changes is
5.7 which is in good agreement with the value obtained from the NMR data.7 Taken together, this data
suggests that the molecular bead resides predominantly at the (diprotonated) diaminohexane site at a pH
lower than the pKa, but translocates to (diprotonated) diaminobutane site when the pH of the solution
becomes higher than the pKa. Since the switching in 1 can be easily detected with a 10−7 M solution (by
fluorescence), the readability of the present molecular switch is 102–104 times better than other rotaxane-
based molecular switches.3,4
In summary, we have synthesized the first fluorescent, reversible molecular switch based on rotaxane.
The switching of the molecular bead from one site to the other site induced by pH change is easily
detected by changes in color and fluorescence with high sensitivity. We are currently investigating the
applications of this fluorescent molecular switch.

474
Fig. 3. (a) Absorption and (b) emission (with excitation at 260 nm) spectra of 1 in aqueous solution (concentration: 2.0×10−5
M in (a) and 2.0×10−7 M in (b) at pHs 1.0–8.0)
Acknowledgements
This work was supported by the Creative Research Initiative Program of the Korean Ministry of
Science and Technology. We thank Professor Jik Chin for reading the manuscript.
References
1. (a) Jeon, Y.-M.; Whang, D.; Kim, J.; Kim, K. Chem. Lett. 1996, 503; (b) Whang, D.; Jeon, Y.-M.; Heo, J.; Kim, K. J. Am.
Chem. Soc. 1996, 118, 11333; (c) Whang, D.; Kim, K. J. Am. Chem. Soc. 1997, 119, 451; (d) Whang, D.; Heo, J.; Kim, C.-A.;
Kim, K. J. Chem. Soc., Chem. Commun. 1997, 2361; (e) Whang, D.; Park, K.-M.; Heo, J.; Kim, K. J. Am. Chem. Soc. 1998,
120, 4899; (f) Roh, S.-G.; Park, K.-M.; Park, G.-J.; Sakamoto, S.; Yamaguchi, K.; Kim., K. Angew. Chem., Int. Ed. Engl.
1999, 38, 638.
2. (a) McCoy, C. Chem. Ind. 1994, 992; (b) Ward, M. D. Chem. Ind. 1997, 640; (c) Hadden, R. C.; Lamola, A. A. Proc. Natl.
Acad. Sci. USA 1985, 82, 1874.
3. Recent reviews: (a) Balzani, V.; Gomez-Lopez, M.; Stoddart, J. F. Acc. Chem. Res. 1998, 31, 405; (b) Chambron, J.-C.;
Sauvage, J.-P. Chem. Eur. J. 1998, 4, 1362.
4. (a) Mock, W. L.; Pierpont, J. Chem. Commun. 1990, 1509; (b) Bissell, R. A.; Cordova, E.; Kaifer, A. E.; Stoddart, J. F. Nature
1994, 369, 133; (c) Murakami, H.; Kawabuchi, A.; Kotoo, K.; Kunitake, M.; Nakashima, N. J. Am. Chem. Soc. 1997, 119,
7605; (d) Gavina, P.; Sauvage, J.-P. Tetrahedron Lett. 1997, 38, 3521; (e) Lane, A. S.; Leigh, D. A.; Murphy, A. J. Am. Chem.
Soc. 1997, 119, 11092.
5. (a) Fabbrizzi, L.; Poggi, A. Chem. Soc. Rev. 1995, 197; (b) Fluorescent Chemosensors of Ion and Molecule Recognition;
Czarnik, A. W., Ed.; ACS Symposium Series 538; American Chemical Society: Washington, DC, 1993.
6. Selected data for 1: 1H NMR (300 MHz, D2O, 25°C): δ 8.01 (d, 1H), 7.90 (m, 1H), 7.81 (d, 2H), 7.48 (d, 2H), 6.57 (br, 1H),
¯
5.72 (d, 6H), 5.76 (d, 12H), 5.48 (s, 12H), 4.33 (d, 6H), 4.21 (d, 6H), 4.0 (s, 2H), 3.51 (t, 2H), 3.27 (m, 2H), 3.13 (t, 2H), 2.98
(m, 2H), 1.95 (m, 4H), 0.83 (m, 2H), 0.60 (m, 6H); 13C NMR (75 MHz, D2O, 25°C): δ 157.10, 144.4, 143.9, 143.7, 141.9,
137.9, 135.6, 129.8, 128.2, 127.5, 126.5, 125.5, 120.5, 111.0, 70.8, 51.9, 50.7, 44.1, 37.3, 28.3, 26.3, 21.9; UV–vis (water):
λ
max=265, 292, 299 nm (pH=1.0), 300 nm (pH=7.0); fluorescence (excitation at 260 nm, water): λmax=308 nm; ESI-MS:
m/z=674.90 ([M+2H]2+ requires 674.94). Anal. calcd for C59H72N27O12·3PF6·9H2O: C, 36.37; H, 4.66; N, 19.41. Found: C,
36.28; H, 4.56; N, 19.62.

475
7. The UV–visible spectrum of the ‘string’ 4 and its pH dependence are similar to those of 1. However, the emission spectrum
of 4 is different from that of 1. The ‘string’ 4 shows two emission bands at 312 and 388 nm with almost equal intensity at
pH 1 whereas 1 shows only one emission band at 308 nm. As the pH of the solution increases, the intensities of the emission
bands of 4 decrease rapidly. While the emission at 312 nm is completely quenched at pH 7 or above, the intensity of the band
at 388 nm at pH 7 becomes about a half of that at pH 1 and does not change any further at higher pH. The pKa of the aromatic
nitrogen in 4 estimated from the absorption and emission spectral changes is 4.4. The presence of CB ‘bead’ on the ‘string’
increases the pKa of the aromatic nitrogen to 5.7, which is consistent with the observation made by Mock.4a
