Switchable dual binding mode molecular shuttle

Article abstract of DOI:10.1021/ol062284j

Protonation controls the location of a dual binding mode macrocycle in a [2]rotaxane. In the neutral form, amide-amide hydrogen bonds hold the macrocycle over a dipeptide residue; when the thread is protonated, polyether-ammonium cation interactions domin

Full text of DOI:10.1021/ol062284j

ORGANIC
LETTERS
2006
Vol. 8, No. 23
5377-5379
Switchable Dual Binding Mode
Molecular Shuttle
David A. Leigh* and Andrew R. Thomson
UniVersity of Edinburgh, School of Chemistry, The King’s Buildings,
West Mains Road, Edinburgh EH9 3JJ, U.K.
daVid.leigh@ed.ac.uk
Received September 16, 2006
ABSTRACT
Protonation controls the location of a dual binding mode macrocycle in a [2]rotaxane. In the neutral form, amide
−amide hydrogen bonds hold
the macrocycle over a dipeptide residue; when the thread is protonated, polyether
changes position.
−ammonium cation interactions dominate and the macrocycle
