The smallest cucurbituril analogue with high affinity for Ag+
Yufan Wua, Lixi Xua, Yenan Shena, Yang Wanga, Lei Zoua, Qiaochun Wang*a, Xiaoqing Jianga,
Jiansen Liua, He Tian*a
Received 00th January 20xx,
Accepted 00th January 20xx
DOI: 10.1039/x0xx00000x
www.rsc.org/
A new host Me8TD[4] was prepared for the first time from
propanediurea-formaldehyde condensation in the presence of
CaCl2 as template and it is the smallest cucurbituril analogues
reported so far. Thermodynamic quantities (logK, ∆H, and ∆S
values) measurements of the interactions of Me8TD[4] with a
series of cations by isothermal titration calorimetry indicated that
Me8TD[4] binds selectively towards Ag+ with a high binding
constant K~1.3×106M-1.
Cucurbit[n]uril (CB[n]) are cyclic oligomers that consist of
n glycoluril units doubly linked by 2n methylene bridges.[1-4]
These hosts display remarkable affinity towards positively
charged species for their polar uredio carbonyl groups on both
portals and the hydrophobic cavities.[5] The interaction of
CB[n] with various metal ions established the CB[n]-based
coordination chemistry as an increasingly important area in
Figure.1 The formation of Me8TD[4] and its single crystal structure in the absence
(a, b) and presence (c) of calcium (H2O are omitted for clarity. Hydrogen: gray,
Carbon: black, nitrogen: blue, oxygen: red, Calcium: purple).
CB[n] chemistry.[6 ] Novel poly-dimensional CB[n]-metal ions
coordination polymers exhibit important application potentials
in areas such as ionic/molecular transport[8], heterogeneous
catalysis[9] and gas absorption/separation[10]. It is easy to
understand that CB[n] are of various portal sizes and
consequently bind selectively towards metal ions[11]. For
example, Me10CB[5], the smallest analogue, shows a high
selectivity for Pb2+.[12] It is obvious that the smaller n value
would result in smaller portal size, and thus might lead to
selectivity towards special ions. Interestingly, the repeated
,
7
of
9,9-Dimethyl-2,4,6,8-tetraazabicyclo[3.3.1]nonane-3,7-
dione (Me2TD in Scheme 1) with formaldehyde (Sindelar’s
group[17] reported independently the same macrocycle nearly
at the same time, and named it as Me10prCB[5]). It is
interesting that only Me10TD[5] was separated during our
previous preparation, unlike CB[5] would form during common
CB[6] synthesis[2b], which led us to think about the possibility
of synthesizing a smaller homologue. Herein we report a new
member of cucurbituril analogue, Me8TD[4] (Figure 1), which
is of smaller cavity than ever and binds selectively to Ag+, and
the value of n in cucurbit family is reduced to 4 for the first
time.
]
number n that a cucurbituril (or an analogue)[13,14 possesses
has not been lower than 5, mainly due to the high strain
energy upon the cyclization of glycoluril with aldehyde (a
calculated value of 23.03 Kal/mol for CB[4][15]).
We[16] have firstly reported the preparation of a CB[5]-like
macrocycle Me10TD[5] using the acid-catalyzed condensation
Numerous attempts for synthesizing Me8TD[4] had been
carried out under template-free conditions (e.g., verifying the
reaction temperature, acid types and concentrations, and
equivalents of formaldehyde), Me10TD[5] had always been the
sole product obtained and no Me8TD[4] was found. Then we
turned to the template-directed synthesis. The use of
templates in the synthesis and purification of cucurbiturils is
an interesting part of cucurbituril chemistry. For example, p-
xylylenediammonium template was used to originate glycoluril
This journal is © The Royal Society of Chemistry 20xx
J. Name., 2013, 00, 1-3 | 1
Please do not adjust margins

Please do not adjust margins
ChemComm
Page 2 of 5
View Article Online
DOI: 10.1039/C7CC01729D
COMMUNICATION
Journal Name
Table 1 Cavity dimensions of Me8TD[4] and CB[5]
Portal diameter
(Å) (a) [a]
Cavity width (Å)
Height (Å) (h) [a]
(b) [a]
Me8TD[4]•2Ca2+
Me8TD[4]
CB[5]
1.2
1.5
2.4
3.4
8.6
8.8
9.1
3.4
4.4
[a] The values quoted for a, b, and h take into account the van der Waals radii of the
relevant atoms.
Table 2 The solubility and thermostability of Me8TD[4]
SH2O [mM]
48.5
SCH3OH [mM]
11.3
SDMSO [mM]
2.5
Stability[℃]
560
Me8TD[4]•2Ca2+
＜0.1
Me8TD[4]
4.5
1.8
495
Figure 2. The 1H NMR spectra (400 MHz, 25 °C, D2O) of a) Me8TD[4] and b)
Me10TD[5], all in the presence of CaCl2.
Table 3 Log K, ∆G (kJ·mol-1), ∆H (kJ·mol-1), and T∆S (kJ·mol-1) values for interactions of
Me8TD[4] with metal ions determined calorimetrically at 25.0 °C in deionized water.
hexamer and the preparation of monofunctionalized CB[6][18]
,
and the addition of K+ produced a high proportion of CB[5],
which gave a convenient method for isolating CB[5][19]
.
Ionic
radius
cation
Log K
anion
∆G
∆H
T∆S
Positive results were thus expected to be achieved
during the Me8TD[4] forming reaction by using suitable
templates, for their structural similarities to cucurbituril. It was
indeed surprising when calcium chloride was added to the
Li+
Na+
K+
0.59Å
a
Cl-
Cl-
Cl-
0.97Å
1.33Å
1.15Å
1.67Å
0.72Å
0.75Å
0.73Å
0.75Å
0.99Å
1.13Å
1.35Å
1.19Å
3.54±0.05
-17.2±0.8
-18.8±0.1
-43.0±0.2
-4.8±0.8
-1.6±0.1
-62.5±0.2
12.4
17.2
-19.5
3.38±0.05
1
reaction of Me2TD with formaldehyde. The H NMR spectra of
Ag+
6.11±0.03
NO3
-
the precipitated solid (Figure 2a) shows four groups of proton
resonances with 1 : 1 : 1 : 3 intensity, indicating a typical
symmetrical CB[n] analogue. The chemical shifts of the two
ethylene protons move from 6.26 & 4.19ppm to 6.44 &
4.11ppm, respectively, when compared with Me10TD[5]+CaCl2,
possibly indicating the formation of a new homologue. Further
MALDI-TOF measurement (Fig. S4) gave the expected result—
an intense peak at m/z= 855.3736, which corresponds to the
Cs+
a
Cl-
Cl-
Cl-
Cl-
Cl-
Cl-
Cl-
Cl-
Mg2+
Co2+
Cu2+
Zn2+
Ca2+
Sr2+
Ba2+
Pb2+
a
a
a
a
4.85±0.04
4.66±0.04
4.88±0.03
4.79±0.04
-27.7±0.2
-25.7±0.2
-34.7±0.4
-27.4±0.2
-21.0±0.2
-19.3±0.2
-27.5±0.4
-11.3±0.2
6.7
6.4
[M+Na]+ (calcd. 855.3739) of Me8TD[4]
.
The X-ray
crystallography (Figure 1) demonstrated the tetrameric
structure of four Me2TD units doubly bridged by 8 methylene
linkers.
7.2
-
16.1
NO3
The products of Me8TD[4] at this stage was the complex
with CaCl2 in a ratio of 1:2, which was confirmed by X-ray
crystallography (Fig. S19) and Atomic Absorption Spectroscopy
(Fig. S20). The calcium ion was finally removed from Me8TD[4]
after several unsuccessful attempts (for example, column
chromatography on ion-exchange resin and repetitive
a No measurable heat during the isothermal titration calorimetry experiments.
CB[5] (a=2.4Å, b=4.4Å, and h=9.1Å). The cavity volume of the
Me8TD[4] is accordingly estimated as 38 Å3, making it the
smallest cucurbituril-like cavity size so far to the best of our
knowledge. It should be noted that the portal size of Me8TD[4]
decreases by 0.3Å and the height decreases by 0.2Å when
binds with calcium cation.
recrystallization
from
dilute
HCl),
using
ethylenediaminetetraacetic acid (EDTA, a calcium chelator)
and (CH3)4N+OH- (the yield of Me8TD[4].2Ca2+ was 5%, and the
final yield of Me8TD[4] was 2%, see supporting information).
The Ca2+-free Me8TD[4] was also characterized by single-
crystal X-ray diffraction, as can be seen in Figure 1. The
structural dimensions of Me8TD[4] and its calcium complex
obtained from the crystallographic computations are listed in
Table 1. The cavity dimensions a, b and h of Me8TD[4] are
greatly reduced to 1.2 Å, 3.4Å and 8.6Å respectively, which are
significantly smaller than those of the smallest cucurbit family
The solubility of Me8TD[4] in common solvents at room
temperature was also determined by 1H NMR spectroscopy
with an internal standard[13a] (see Supporting Information), as
illustrated in Table 2. It can be seen that Me8TD[4] shows
somewhat solubility in water and methanol (4.5mM and
1.8mM, respectively) and almost no solubility in DMSO. In
comparison , the Ca2+-complexed Me8TD[4] show remarkable
increased solubility in these solvents
―48.5mM in water,
11.3mM in methanol and 2.5mM in DMSO.
2 | J. Name., 2012, 00, 1-3
This journal is © The Royal Society of Chemistry 20xx
Please do not adjust margins

Please do not adjust margins
ChemComm
Page 3 of 5
View Article Online
DOI: 10.1039/C7CC01729D
Journal Name
Thermal gravimetric analysis (TGA) of Me8TD[4] was
COMMUNICATION
This work was financially supported by the Science Fund
carried out in nitrogen atmosphere to 600
℃
thermal stability. We did not detect mass loss related to the (21572063, 21372076), and the Program of Introducing Talents
to evaluate their for Creative Research Groups (21421004), NSFC/China
decomposition of Me8TD[4] or its calcium complex up to 490 of Discipline to Universities (B16017).
℃ (Table 2 & Fig. S5), indicating that the macrocycle possesses
excellent thermal stability which is comparable with
[20]
Notes and references
cucurbiturils (exceed 370
℃
)
.
The relatively good solubility of free Me8TD[4] allows us
to investigate the host-guest chemistry of Me8TD[4] with
metal ions in neutral water. Log K, ∆G, ∆H, and T∆S values for
the interactions of the metal ions with Me8TD[4] in H2O are
listed in table 3. Those metal ions with small
radius―Li+(0.59Å), Mg2+(0.72Å), Co2+(0.75Å), Cu2+(0.73Å) and
Zn2+(0.75Å)[5b]―show no measurable heat during the titration
1
W. A. Freeman, W. L. Mock and N. Y. Shih, J. Am. Chem. Soc.
1981, 103, 7367.
a) A. I. Day, A. P. Arnold and R. J. Blanch (Unisearch Limited,
2
Australia),
PCT
Int.
Appl.
2000,
WO2000
–
2000AU41220000505, 112 (Priority: AU 99 – 232 19990507);
b) J. Kim, I. S. Jung, S. Y. Kim, E. Lee, J. K. Kang, S. Sakamoto,
K. Yamaguchi and K. Kim, J. Am. Chem. Soc. 2000, 122, 540.
A. I. Day, R. J. Blanch, A. P. Arnold, S. Lorenzo, G. R. Lewis and
I. Dance, Angew. Chem. 2002, 114, 285-287; Angew. Chem.
Int. Ed. 2002, 41, 275.
X.-J. Cheng, L.-L. Liang, K. Chen, N.-N. Ji, X. Xiao, J.-X. Zhang,
Y.-Q. Zhang, S.-F. Xue, Q.-J. Zhu, X.-L. Ni and Z. Tao, Angew.
Chem. 2013, 125, 7393-7396; Angew. Chem. Int. Ed. 2013,
52, 7252.
a) S. J. Barrow, S. Kasera, M. J. Rowland, J. del Barrio and O.
A. Scherman, Chem. Rev. 2015, 115, 12320; b) X.-L. Ni, X.
Xiao, H. Cong, L.-L. Liang, K. Cheng, X.-J. Cheng, N.-N. Ji, Q.-J.
Zhu, S.-F. Xue and Z. Tao, Chem. Soc. Rev. 2013, 42, 9480; c)
X.-L. Ni, X. Xiao, H. Cong, Q.-J. Zhu, S.-F. Xue and Z. Tao, Acc.
Chem. Res. 2014, 47, 1386; c) H.-Y. Zhang, Q.-C. Wang, X. Ma
and H. Tian, Org. Lett., 2009, 11, 3234; d) X. Ma and H. Tian,
Acc. Chem. Res. 2014, 47, 1971; e) A. E. Kaifer, W. Li and S. Yi,
Isr. J. Chem. 2011, 51, 496; f) V. Sindelar, S. Silvi, S. E. Parker,
3
4
(see Supporting Information), suggesting
none or tiny
complexation with Me8TD[4], and Cs+, which is of tremendous
radius(1.67Å), also shows no complexation. By contrast, those
metal ions, whether they are one monovalent or bivalent, with
moderate ionic radius―Na+ (0.97Å), Ca2+ (0.99Å), Sr2+(1.13Å),
Ag+(1.15Å), Pb2+ (1.19Å), K+(1.33Å) and Ba2+ (1.35Å)―display
considerable affinities with Me8TD[4]. For those monovalent
ions, it seems that there has an optimal radius during the
combination, because Ag+ has the maximum K value of
5
1.3
×
106M-1, Na+ (smaller radius than Ag+ with smaller
103M-1) and K+ (bigger radius with smaller K 103M-1)
2.4
K~
3.5
×
~
×
come second, while Li+ (smallest radius) and Cs+ (biggest radius)
rate final (no combinations). While for those bivalent ions, no
optimal ionic radius can be found because the ions whose
radius ranging from 0.99Å to 1.35Å are of similar K values
D. Sobransingh and A. E. Kaifer, Adv. Funct. Mater. 2007, 17
,
694 g) S. Liu, A. D. Shukla, S. Gadde, B. D. Wagner, A. E.
Kaifer and L. Isaacs, Angew. Chem. 2008, 120, 2697; Angew.
Chem. Int. Ed. 2008, 47, 2657.
O. A. Gerasko, M. N. Sokolov and V. P. Fedin, Pure Appl.
Chem., 2004, 76, 1633.
H. Cong, Q. J. Zhu, S. F. Xue, Z. Tao and G. Wei, Chin. Sci.
Bull., 2010, 55, 3633.
S. D. Choudhury, J. Mohanty, H. Pal and A. C. Bhasikuttan, J.
Am. Chem. Soc., 2010, 132, 1395.
(Ca2+
Pb2+
~
6.2
7.1
×
104,
Sr2+
~
4.7×
104,
Ba2+
~
7.6×
104,
and
6
7
8
9
~
×
104M-1, respectively). Nevertheless, the none-
combination to Me8TD[4] of the bivalent ions (Mg2+, Co2+, Cu2+
and Zn2+) with small radius is the same situation as that of the
monovalent ion. It should be pointed out that Me8TD[4] bind
selectively to Ag+ with
a
K
value of more than
M. Cao, J. Lin, H. Yang and R. Cao, Chem. Commun., 2010, 46
5088.
,
two orders of magnitude larger than other ions.
The isothermal titration calorimetry results also indicate
that Ag+, Pb2+ and Ba2+ form 1:1 complexes, while the other
cations form 2:1 ones with Me8TD[4]. These phenomenons
should be attributed to the fact that the two cucurbituril
portals, on one hand, could bind respectively with two ions to
form a capsule-like molecule; and on the other hand, could
10 X. Feng, K. Chen, Y.-Q. Zhang, S.-F. Xue, Q.-J. Zhu, Z. Tao and
A. I. Day, CrystEngComm, 2011, 13, 5049.
11 Buschmann, H.-J.; Jansen, K.; Meshke, C. and Schollmeyer, E.
J. Solution Chem. 1998, 27, 135.
12 X. X. Zhang, K. E. Krakowiak, G. Xue, J. S. Bradshaw, and R. M.
Izatt, Ind. Eng. Chem. Res. 2000, 39, 3516.
13 a) J.-Z. Zhao, H. J. Kim, J. Oh, S. Y. Kim, J. W. Lee, S.
Sakamoto, K. Yamaguchi and K. Kim, Angew. Chem. 2001,
113, 4363; Angew. Chem., Int. Ed. 2001, 40, 4233; b) F. Wu,
L.-H. Wu, X. Xiao, Y.-Q. Zhang, S.-F. Xue, Z. Tao and A. I. Day,
J. Org. Chem. 2012, 77, 606; c) A. Flinn, G. C. Hough, J. F.
Stoddart and D. J. Williams, Angew. Chem. 1992, 104, 1550;
Angew. Chem. Int. Ed. 1992, 31, 1475; d) L. Gilberg, S. A.
binds to one ion end to end, generating
a linear
supramolecular polymer. These two binding behaviors have
report[21]
been
confirmed
in
Tao’s
,
where
pentacyclopentanocucurbit[5]uril binds 1:2 with Ca2+ and Sr2+,
and 1:1 with Ba2+.
In conclusion, we have synthesized a new cucurbituril-like
macrocycle, Me8TD[4], by acid-catalyzed condensation of
dimethylpropanediurea and formaldehyde in the presence of
CaCl2 template. Me8TD[4] is the smallest cucurbituril
analogues reported so far with four repeated bi-uredio units,
having smaller portal diameter, cavity width, and lower height
when compared with other cucurbituril species, and exhibits
excellent thermal stability. It should be emphasized that
Me8TD[4] shows an outstanding binding selectivity toward
silver ion over a series of other metal ions.
Khan, M. Enderesova and V. Sindelar, Org. Lett. 2014, 16
,
2446; e) V. Lewin, J. Rivollier, H. K. ilova, P. Berthault, J. P.
Dognon and M. P. Heck G. Huber, Eur. J. Org. Chem. 2013,
18, 3857.
14 a) J. Lagona, P. Mukhopadhyay, S. Chakrabarti and L. Isaacs,
Angew. Chem. 2005, 117, 4922; Angew. Chem. Int. Ed. 2005,
44, 4844; b) K. Kim, N. Selvapalam, Y. H. Ko, K. M. Park, D.
Kim and J. Kim, Chem. Soc. Rev. 2007, 36, 267; c) L. Isaacs,
Chem. Commun. 2009, 619; d) E. Masson, X. Ling, R. Joseph,
L. Kyeremeh-Mensah, X. Lu, RSC Adv. 2012, 2, 1213. d) M. M.
Ayhan, H. Karoui, M. Hardy, A. Rockenbauer, L. Charles, R.
This journal is © The Royal Society of Chemistry 20xx
J. Name., 2013, 00, 1-3 | 3
Please do not adjust margins

Please do not adjust margins
ChemComm
Page 4 of 5
View Article Online
DOI: 10.1039/C7CC01729D
COMMUNICATION
Journal Name
Rosas, K. Udachin, P. Tordo, D. Bardelang and O. Ouari, J.
Am. Chem. Soc. 2015, 137, 10238.
15 J. W. LEE, S. Samal, N. Selvapalam, H-J Kim and K. Kim, Acc.
Chem. Res. 2003, 36, 621.
16 X. Jiang, X. Yao, X. Huang, Q. Wang H. Tian, Chem. Commun.
2015, 51, 2890.
17 L. Ustrnul, P. Kulhanek, T. Lizal, V. Sindelar, Org. Lett. 2015,
17, 1022.
18 D. Lucas, T. Minami, G. Iannuzzi, L. Cao, J. B. Wittenberg, P.
Anzenbacher Jr. and L. Isaacs, J. Am. Chem. Soc. 2011, 133
17966;
,
19 A. I. Day, R. J. Blanch, A. Coe and A. P. Arnold, J. Incl. Phen.
Macro. Chem. 2002, 43, 247.
20 P. Germain, J. M. Letoffe, M. P. Merlin and H.-J. Buschmann,
Thermochim. Acta, 1998, 315, 87.
21 Y.-F. Hu, K. Chen, R.-L. Lin, W.-Q. Sun, J. Zhu, J.-X. Liu, S.-F.
Xue, Q.J. Zhu and Z. Tao, RSC Advances, 2012, 2, 5663.
4 | J. Name., 2012, 00, 1-3
This journal is © The Royal Society of Chemistry 20xx
Please do not adjust margins

Page 5 of 5
ChemComm
View Article Online
DOI: 10.1039/C7CC01729D
A smallest cucurbituril analogue with four repeated bi-uredio units was firstly
synthesized and it binds selectively towards Ag+.
