X. Qi et al.
Journal of Physics and Chemistry of Solids 151 (2021) 109903
(TC). In addition, UiO-66@BiOIO3-50 composite exhibits appreciable
oxidative removal performance for the gaseous Hg0. The potential re-
action mechanism of increased photocatalytic activity for UiO-66@-
BiOIO3-x composites was investigated by the active species trap
experiments.
2.4. Photocatalytic decomposition of organic pollutants
The decomposition of RhB and TC, at 20 mg/L each with a 300 W
xenon arc lamp (Perfect Light Co., PLS-SXE 300, wavelength range
320–800 nm) irradiation was examined to estimate the photocatalytic
property of the samples. Generally, 100 mg photocatalyst was dispersed
into a 100 mL solution containing one of the pollutants. The solution was
stirred for 0.5h under dark to achieve an adsorption–desorption equi-
librium between the reagents prior to the irradiation. Next, a few mil-
lilitres of suspension were extracted and filtered at regular intervals.
Then the solution was analysed to record the concentration by a
spectrophotometer.
2. Experimental
2.1. Synthesis of UiO-66
UiO-66 was synthesized by solvothermal method in the light of the
previous report method with slightly modification [27]. Briefly, ZrCl4
(0.233 g, 1 mmol) and 1, 4-benzenedicarboxylic acid (0.245 g, 1 mmol)
were dissolved in 60 ml DMF solution. The obtained mixture was then
put into an autoclave and performed the solvothermal reaction at 120 ◦C
for 24 h. The obtained powders were filtered and washed with water and
absolute ethanol several times. Finally, the samples were then dried at
80 ◦C for 12 h in air. In order to eliminate occluded DMF molecules
completely, the obtained white products were immersed into the
methanol solution and shook in constant temperature shaker for 1h.
Then the products were filtered, washed and dried according to the
above procedure.
2.5. Photocatalytic oxidative removal of Hg0
The oxidized removal of gaseous Hg0 was chosen to further assess-
ment the activity of the obtained samples at the laboratory system
described in our previous studies [28]. The mercury was generated from
the mercury permeation tube which was immersed into a water bath at
55 ◦C to guarantee an invariable Hg0 permeation rate. The entrance
mercury concentration was kept about 55
μ
g/m3. The concentration of
Hg0 was measured by an on-line mercury analyzer (RA-915 M, Lumex
Ltd., Russia). The device was mainly consisted of three parts: gas system,
photocatalytic system and the online mercury analysis. The compressed
air was split into two streams and employed two mass flow meters
(CS200) to control the velocity of flow. The total velocity was kept at 1.2
L/min and one of the streams with 0.2 L/min run through the Hg0
permeation tube to carry Hg0 vapor to the system. Firstly, the Hg0
stream ran through the bypass. When the concentration of Hg0 reached
to a constant concentration for a certain time, the gas circuit was
changed to the photocatalytic reactor. At the same time, the LED light
was turned on. The photocatalytic test was implemented with the pho-
tocatalyst(50 mg) loaded on a quartz glass plate. Finally, the gas flowed
through the activated carbon system to adsorb the unreacted gaseous
Hg0 and then discharged. The Hg0 removal efficiency can be defined as
follows:
2.2. Synthesis of UiO-66@BiOIO3 composites
UiO-66@BiOIO3 composites with different mass ratio of UiO-66 to
BiOIO3 were fabricated via hydrothermal method. Briefly, 0.485g Bi
(NO3) ⋅5H2O was dissolved in 30 mL deionized water. In order to inhibit
the hydrolysis of bismuth nitrate, 1 ml 67% (w/w) HNO3 solution was
added to the solution. Then 0.12g UiO-66 powder was dispersed into the
above solution to form a homogeneous suspension under the condition
of magnetic stirring. Subsequently, 0.214g KIO3 was dissolved with 30
mL deionized water to another beaker. Then the KIO3 solution was
dropped into the above suspension. A certain amount of NaOH solution
was added to adjust the pH value of the solution. The pH value of the
solution was adjusted to ca.3.02 under the stirring condition. The
mixture was then loaded into a stainless-steel autoclave and heated at
160 ◦C for 16 h. And the following operations are the same as the syn-
thesis of UiO-66. The as-synthesised UiO-66@BiOIO3 composite was
denoted as UiO-66@BiOIO3-x (x = 30, where x refers to the mass ratio of
UiO-66 to BiOIO3 was 30%). Another UiO-66@BiOIO3-50 composite
was also prepared taking the similar process by changing the dosage of
the Bi (NO3) ⋅5H2O and KIO3. Pristine BiOIO3 was obtained via the same
procedure except not added UiO-66 power.
Where, Hg0inlet and Hgo0utlet indicate Hg0 concentration at the inlet and
outlet of the reactor,
μ
g/m3.
3. Results and discussion
3.1. characterizations of the as-prepared samples
2.3. Characterisation
The XRD patterns of the as-prepared samples are illustrated in Fig. 1.
The diffraction pattern of UiO-66 matches well with that reported lit-
eratures and no impurity peaks were observed [25,26]. The main
diffraction peaks at 7.36◦, 8.48◦, 12.04◦, 22.25◦ and 25.68◦ correspond
to the (111), (002), (022), (115) and (224) diffraction planes, respec-
tively. For BiOIO3, the characteristic diffraction peaks match exactly
with the orthorhombic structure of BiOIO3 (ICSD # 262019), indicating
that pure BiOIO3 sample was prepared. For the as-prepared UiO-66@-
BiOIO3-x composites, the main diffraction peaks of UiO-66 can be
detected evidently. In comparison with pristine UiO-66, the main peak
intensity of UiO-66 in UiO-66@BiOIO3-x composites decreased and no
extra peaks were checked, verifying that the UiO-66 maintains its
crystalline structure during the preparation process of the composites.
The diffraction peaks correspond to the (111), (022) and (224) facets of
UiO-66 in the composites. These results demonstrated that the UiO-66
particles have been successfully loaded on the surface of BiOIO3
nanosheets.
The crystal structure of the samples was measured by a diffractom-
eter with a Cu-Kα radiation (D8 ADVANCE, Bruker). The morphology
and microstructure of the samples was characterized by the field emis-
sion scanning electron microscopy (FE-SEM, SU-1500, Hitachi) and
transmission electron microscope (TEM, JEM-2010, Jeol) operated at
200 kV. The optical absorption property of the samples was recorded by
a UV–vis spectrophotometer (UV-2550, Shimadzu). BET specific surface
area was counted via N2 adsorption-desorption with a GeminiVII 2390
instrument. The photoluminescence (PL) spectra was measured using a
fluorescence spectrophotometer (RF-5301, Shimadzu). The spectra were
excited at 360 nm and photoluminescence spectra were recorded in the
range of 400–600 nm. Electron Spin-Resonance spectroscopy (ESR) was
measured by using a Bruker EPR A300-10/12 spectrometer at room
temperature with the signals of radicals trapped by 5,5-dimethyl-1-pyr-
roline nitrogen oxide (DMPO) for •Oꢀ2 and 2,2,6,6- tetramethylpiper-
idine nitrogen oxide (TEMPO) for h+. The data were collected with a
300W xenon lamp to simulate solar irradiation at selected time.
The morphology structure of the obtained samples was detected by
