FIG. 2. Appearance of 125 nm thick surface alumina layer produced on a
CVDD substrate with a 50 nm thick Cr interlayer.
FIG. 4. Auger depth profile through an ϳ120 nm alumina film deposited on
a 50 nm Cr interlayer on a CVDD substrate. For reference, thicknesses
where known, are indicated along with sputter time on the abscissa.
Films for TEM studies were produced on a freshly cleaved
͑100͒ surface of NaCl under conditions identical to those
used for deposition on CVDD, so that the films could be
easily separated from the substrate for TEM observations.
The film was then characterized by transmission electron mi-
croscopy ͑TEM͒, energy dispersive x-ray spectroscopy
͑EDS͒, scanning electron microscopy ͑SEM͒, and Auger
electron spectroscopy ͑AES͒.
Al2O3 standard,5 confirming that the film is alumina. Spectra
collected after sputtering to different depths of the film were
found to be identical, suggesting that a uniform layer of alu-
mina was present on the CVDD samples studied here.
Figure 4 shows an Auger depth profile through the alu-
mina and Cr films deposited on CVDD. The Al/O ratio is
observed to be relatively constant until about 100 nm from
the surface ͑sputter time of ϳ5 min͒, in agreement with the
TEM results, which showed the layer to be ␥-Al2O3. Signifi-
cant interdiffusion is observed to have occurred between Cr
and Al/O. Furthermore, Cr and C from the underlying
CVDD are observed to have interdiffused, and appear to
have reacted as well. The prominent O signal near the Cr/C
interface is presumed to be due to the diffusion of O ad-
sorbed on the CVDD surface into the Cr layer. The interdif-
fusion zones between Al2O3 and Cr and between Cr and C
result in strong chemical bonding between Al2O3, Cr, and the
CVDD layers, and is responsible for the excellent adhesion
of the Al2O3 film to the substrate.
Figure 1 shows a bright field TEM image of the alumina
film deposited on a Cr interlayer and the corresponding se-
lected area diffraction pattern ͑SADP͒ is shown as an inset. It
is observed that the film is nanocrystalline, with the crystal-
lite size ranging from 3 to 10 nm. The sharp, somewhat
spotty, rings in the SADP correspond exactly to reflections
from ␥-Al2O3 and confirm that the film is largely
crystalline,4 with negligible amorphous component. The na-
ture of the alumina films was further confirmed by EDS and
AES studies. Figure 2 shows a SEM image of the surface of
the alumina film produced on CVDD ͑deposited on silicon͒
using the above technique. It is observed that some of the
surface crystallites have grown to about 0.2–0.3 m due to
rapid surface diffusion during the postdeposition heat treat-
ment, although the underlying layer was nanocrystalline
͑Fig. 1͒. Figure 3, which is an Auger electron spectrum from
the surface of the film, clearly shows two peaks, one corre-
sponding to oxygen at 504 eV, and the other corresponding
to aluminum at 1384 eV. The detailed structure of the Al
peaks in Fig. 3 was found to be identical to that from a pure
Thus, the above surface treatment yields a very thin,
ultrafine grained, adherent alumina surface layer on CVDD
substrate. Since the surface layer is alumina, which is widely
used as a substrate material for electronic packaging, the
CVDD substrate, treated as above, is easily metallizable by a
number of thin and thin film techniques, using existing tech-
nology.
This work was supported by a grant from the Naval
Surface Warfare Center, Crane Division, with K. G. Beasley
as contract monitor. The authors also wish to express their
gratitude to Dr. J. Sosniak of Naval Air Warfare Center,
Aircraft Division, Indianapolis, for supplying the CVDD
substrates.
1 D. J. Pickrell, P. J. Santini, and F. M. Kimock, Proceedings of the Inter-
national Symposium on Microelectronics ͑The Microelectronics Society,
1993͒, Vol. 2105, p. 405.
2 C. D. Iacovangelo and E. C. Jerabek, Proceedings of the International
Symposium on Microelectronics, 1993 ͑The Microelectronics Society,
1993͒, Vol. 2105, p. 132.
3 C. D. Iacovangelo, P. J. DiConza, E. C. Jerabek, and K. P. Zarnoch,
Mater. Res. Soc. Symp. Proc. 337, 401 ͑1994͒.
FIG. 3. Auger electron spectrum from the surface of the film deposited on
CVDD with a Cr interlayer, clearly showing two peaks—one corresponding
to oxygen at 504 eV, and the other corresponding to aluminum at 1384 eV.
Details of the Al peak are consistent with the Al peak from a pure Al2O3
standard ͑Ref. 5͒ and is distinct from the peak from unreacted aluminum.
4 JCPDS Powder Diffraction File, Card No. 10-425.
5 L. E. Davis, N. C. MacDonald, P. W. Palmberg, G. E. Riach, and R. E.
Weber, Handbook of Auger Electron Spectroscopy ͑Physical Electronics,
1976͒.
2952 Appl. Phys. Lett., Vol. 68, No. 21, 20 May 1996 E. S. K. Menon and I. Dutta
