Methanol-to-olefin conversion over H-MCM-22 catalyst

Article abstract of DOI:10.1016/j.molcata.2015.11.013

H-MCM-22 zeolites with different Si/Al ratios were hydrothermally synthesized, also the parent sample was dealuminated by ammonium hexafluorosilicate (AHFS). Then all of the samples were characterized and evaluated for the methanol-to-olefin (MTO) convers

Full text of DOI:10.1016/j.molcata.2015.11.013

Accepted Manuscript
Title: Methanol-to-olefin conversion over H-MCM-22 catalyst
Author: Lei Zhang Hui Wang Guangbo Liu Kun Gao Jinhu
Wu
PII:
S1381-1169(15)30153-9
DOI:
Reference:
http://dx.doi.org/doi:10.1016/j.molcata.2015.11.013
MOLCAA 9693
To appear in:
Journal of Molecular Catalysis A: Chemical
Received date:
Revised date:
Accepted date:
25-9-2015
11-11-2015
12-11-2015
Please cite this article as: Lei Zhang, Hui Wang, Guangbo Liu, Kun Gao, Jinhu
Wu, Methanol-to-olefin conversion over H-MCM-22 catalyst, Journal of Molecular
Catalysis A: Chemical http://dx.doi.org/10.1016/j.molcata.2015.11.013
This is a PDF file of an unedited manuscript that has been accepted for publication.
As a service to our customers we are providing this early version of the manuscript.
The manuscript will undergo copyediting, typesetting, and review of the resulting proof
before it is published in its final form. Please note that during the production process
errors may be discovered which could affect the content, and all legal disclaimers that
apply to the journal pertain.

Methanol-to-olefin conversion over H-MCM-22 catalyst
Lei Zhanga,b, Hui Wanga*, Guangbo Liua, Kun Gaoa, Jinhu Wua*
aKey Laboratory of Biofuels, Qingdao Institute of Bioenergy and Bioprocess Technology Chinese
Academy of Sciences, Qingdao, 266101, PR China
bUniversity of Chinese Academy of Sciences, Beijing 100049, PR China
* To whom correspondence should be addressed
Tel: +86-532-80662764, +86-532-80662761
Fax: +86-532-80662761
E-mail: huiwangsun@gmail.com, wujh@qibebt.ac.cn
1

Graphical abstract
The H-MCM-22 was dealuminated by ammonium hexafluorosilicate (AHFS), most of the
extraframework Al species were selectively removed, the selectivity of propylene and butylene
increased significantly and the coke deposition can be inhibited to some extent.
H-MCM-22(35.1D)
H-MCM-22(49.8)
H-MCM-22(35.1)
H-MCM-22(28.3)
H-MCM-22(10.8)
100 80 60 40 20
0
-20 -40 -60 -80 -100
ppm
2

Highlights
 The H-MCM-22 catalysts with different Si/Al ratios for MTO reaction were studied.
 The Si/Al ratio influences the acidic properties and the catalytic performance.
 Most of the extraframework Al species in the H-MCM-22 can be selectively removed by
ammonium hexafluorosilicate (AHFS).
 The dealuminated H-MCM-22 has higher selectivity of propylene and butylene and slow coke
deposition.
Abstract
H-MCM-22 zeolites with different Si/Al ratios were hydrothermally synthesized, also the parent
sample was dealuminated by ammonium hexafluorosilicate (AHFS). Then all of the samples were
characterized and evaluated for the methanol-to-olefin (MTO) conversion. The correlation of
structural and acidic properties of H-MCM-22 with catalytic performance was investigated. The
H-MCM-22 (Si/Al= 35.1) exhibits best catalytic stability in all the samples because of its suitable
acid site amount and distribution. As for the H-MCM-22 (Si/Al=35.1) after dealumination by AHFS,
most of the extra-framework Al species were selectively removed, the selectivity of light olefin was
enhanced further and the coke deposition seems to be inhibited.
Keywords: Methanol; Olefin; H-MCM-22; Catalyst
3

Light olefins, such as ethylene, propylene and butylene, are very important raw materials for the
production of polyolefins in modern chemical industry. At present, light olefins are mainly
manufactured by thermal cracking of naphtha, which requires high energy consumption with low
yield of light olefins. Furthermore, in view of the depletion of world oil reserves, it is urgent to
develop new routes to produce light olefins using non-oil feedstocks [1].During the past decades,
methanol-to-olefin (MTO) conversion, as an alternative route for the production of light olefins, has
attracted much attention, because methanol can be conveniently manufactured from any
carbon-containing resources such as coal, natural gas and biomass [2-3,4,5].In the process of MTO,
the dual-cycle mechanism was widely accepted, the initial step is the formation of dimethyl ether
(DME) through dehydration of methanol, and then reacts to produce light olefins. Meanwhile, light
olefins could further react to paraffins, aromatics via hydrogen transfer reaction [1].
A lot of acidic zeolites and zeotype materials have been used in the MTO reaction since its
discovery. The catalytic performances, such as activity, selectivity and stability, are largely dependent
on the structure and acidity of catalyst, reaction conditions, etc. Zeolite ZSM-5 and SAPO-34
molecular sieve are two valuable catalysts for the MTO conversion. H-SAPO-34 molecular sieve is
highly selective in formation of light olefins due to its moderate acidity and small pore entrances,
which has been commercially applied in MTO process [6]. Unfortunately, the catalytic life of
SAPO-34 is short due to rapid coke deposition on its surfaces [7], thus, it needs to be frequently
regenerated to recover the activity [8,9]. H-ZSM-5, with strong acidity and medium channel
dimensions, is more resistant to deactivation than H-SAPO-34 and used in MTP process, developed
by Lurgi, but its one-pass selectivity to propylene and propylene/ethylene (P/E) ratio are still needed
to improve [10,11,12]. Moreover, with the increasing gap between the global supply and demand of
propylene [13], selective production of propylene from methanol draws more and more attention.
Thus, it is necessary to explore new catalyst selectively converting methanol with high propylene
yield and P/E ratio.
MCM-22 zeolite possesses three independent pore systems, the first one is formed by large
cylindrical supercages (7.1Å×7.1Å×18.2Å) between layers, the second one is formed by sinusoidal
10 MR channels (4.1 × 5.1 Å) and the last one is located at the external surface, covered with 12 MR
pockets (7.1Å×7.1Å×7Å) [14,15]. Due to the peculiar pore structure, MCM-22 zeolite has been
applied in many catalytic processes and is considered to be a potential catalyst in MTO reaction. Min
4

et al. investigated the role of each pore system of H-MCM-22 in MTO reaction and pointed out that
acid sites located in the external 12-ring pockets were detrimental to the MTO selectivity and
stability. However, the MTO catalysis in both of the sinusoidal 10-MR channels and the cage-based
pore system are selective to propylene formation, therefore high selectivity to propylene could be
obtained [16]. Wang et al. used phosphorus modified H-MCM-22 for the MTH reaction and found
about 40% selectivity to propylene could be achieved at 100% methanol conversion over
H-MCM-22 loading with 3% phosphorus [17]. Wang et al. [8] studied the catalytic properties of
H-MCM-22 zeolites in the conversion of methanol to hydrocarbons (MTH). They found that the
catalytic performance of H-MCM-22 zeolites was greatly affected by the external surface acid sites
and the catalytic stability can be enhanced by selectively removing these acid sites with
dealumination. Lacarriere et al. suggested that during MTH reaction over H-MCM-22 zeolite, acid
sites located inside the supercages are quickly deactivated, and the acid sites located on the external
surface and within the sinusoidal micropores are mainly responsible for the MTH reaction [18].
Hence, it was expected that H-MCM-22 may perform well on MTO reaction with high selectivity to
propylene.
In this work, H-MCM-22 with a Si/Al ratio ranging from 10.8 to 49.8 were hydrothermally
synthesized, and the parent sample was also dealuminated by ammonium hexafluorosilicate (AHFS),
then they were characterized and tested in the MTO reaction. The correlation of structural and acidic
properties of H-MCM-22 with catalyst stability and product selectivity was investigated.
2. Experimental
2.1 Preparation of catalyst
MCM-22 samples with various Si/Al ratios were hydrothermally synthesized with silica
(Cab-O-Sil M5, Cabot Bluestar Co., Ltd.), sodium aluminate (Sinopharm Chemical Reagent Co.,
Ltd), hexamethyleneimine (HMI, 98 wt%, Jiangsu Fengyuan Bioengineering Co., Ltd.), NaOH (96
wt%, Sinopharm Chemical Reagent Co., Ltd.) and distilled water according to the procedures in Ref.
[19]. The synthetic gel was prepared with the molar composition of 0.3 NaOH : SiO2 : x Al2O3 : 0.5
HMI : 40 H2O, where x = 0.0333, 0.016, 0.0125 and 0.01. The resulting gel was dynamically
crystallized in a Teflon-lined stainless-steel autoclave with a rotation speed of 60 rpm at 150 oC for 7
5

o
d. Then the solid product was washed with distilled water, dried at 110 C overnight and calcined at
550 oC for 8 h. The Na-MCM-22 was converted to H-MCM-22 by refluxing twice with 1 M NH4NO3
o
o
solution at 80 C for 3 h, followed by drying at 110 C overnight and calcination at 550 oC for 4 h.
The obtained H-MCM-22 zeolites with different Si/Al ratios were designated as H-MCM-22(x), the
actual value of Si/Al ratio x of H-MCM-22(x) zeolites was determined by inductively coupled
plasma-atomic emission spectrometry (ICP-AES), as shown in Table 1.
The obtained H-MCM-22 (35.1) sample was treated with 0.1 M AHFS solution at 60 oC for 4 h
o
under reflux conditions. Then it was filtered, washed with distilled water, dried at 110 C overnight
and calcined at 550 oC for 4 h. The sample after dealumination was named as H-MCM-22(35.1D).
2.2 Catalyst characterization
Powder X-ray diffraction (XRD) analysis was carried out by using Bruker D8 Advance X-ray
diffractometer with Cu Kα radiation (λ = 1.5418 Å) and operated at 30 kV and 30 mA. Data were
recorded in the range of 2θ=5-50° with a step size of 0.02°.
The textural analyses were obtained by nitrogen adsorption/desorption method at -196 oC with a
Micromeritics ASAP2010 automatic analyzer. Before nitrogen adsorption, the samples were
o
evacuated at 300 C for 3 h in vacuum. The specific surface area was assessed by the
Brunauer-Emmett-Teller (BET) method. The micropore volume and the micropore surface area were
obtained from the t-plot method. The total pore volumes were based on the adsorbed amount at
P/P0=0.99.
The sample acidity was measured by temperature programmed desorption of ammonia
(NH3-TPD) on a Micromeritics Autochem II Chemisorption Analyzer. Sample of ca. 0.1 g was
pretreated at 550 oC in Ar flow (30 ml) for 1 h and then cooled down to 100 oC. After saturation with
5%NH3/Ar, the sample was purged with Ar flow (30 ml/min) at 100 °C for 2 h to remove the
o
physically absorbed ammonia. The NH3-TPD profile was obtained from 100 to 600 C with a
ramping rate of 10 oC/min.
The acidic properties of the samples were determined by Fourier transform infrared (FT-IR)
spectra of adsorbed pyridine on a Nicolet 6700 FT-IR spectrometer. Prior to the measurement, the
self-supporting wafers of the zeolite samples were pretreated under 10-2 Pa at 450 oC for 2 h and then
cooled down to room temperature, the IR spectra were recorded. After adsorption with pyridine
6

vapor for 1 h at room temperature and evacuation at 150 oC for 1h, the Py-IR spectra were recorded.
The Brønsted and Lewis acidities were calculated with the integrated areas of peaks at 1545 and
1450 cm-1 by following the procedures reported in Ref. [20,21].
Al MAS NMR spectra were recorded on a 600 MHz Bruker Avance III equipped with a 4mm
MAS probe at a spinning rate of 13 KHz. The 27Al chemical shift is referred to Al(NO3)3 solution.
2.3 Catalytic tests
The MTO reaction was carried out under atmosphere pressure in a fixed-bed stainless reactor
(i.d. 10mm). In all the experiments, 2.0 g of catalyst (40-60 mesh) was placed in the middle of the
o
reactor and activated in situ at 550 C for 3 h under N2 flow of 30 ml/min. Then methanol was
o
pumped to an evaporator with 160 C at a rate of 0.042 ml/min (1 h-1 WHSV) and then was
introduced to the reactor by the flowing N2. The MTO reaction was performed at 450 oC.
=
=
=
The reactor exit stream including the ethylene (C2 ), propylene (C3 ), butylenes (C4 ), paraffins
(C1-C4), C5+ hydrocarbons, and DME, was separated into gas, liquid hydrocarbons and reaction
water fractions using an ice-cooled condenser. The gas product was analyzed by an on-line GC
Agilent 7890A with a HP-PLOT capillary column and a flame ionization detector (FID). The oil
phase (liquid hydrocarbons) was analyzed by Agilent 7820A gas chromatogragh equipped with an
OV-101 column and an FID detector. The aqueous phase was analyzed by Agilent 7890A gas
chromatogragh equipped with a HP-INNOWAX column and an FID detector. The methanol
conversion and selectivities of the products were calculated on the carbon number basis. The
methanol conversion (CMeOH) was defined as the percentage of MeOH consumed during the MTO
reaction, and the DME was considered as unconverted methanol. The selectivity of each product was
calculated as the percentage to the amount (in mole) of MeOH converted to hydrocarbons. They
were calculated according to the following formula, respectively.
n MeOH -n MeOH -2n DME

in

out


CMeOH
=
out ×100%
n MeOH

in
X×n C H

y 
x
out
SCxHy
=
×100%
n MeOH -n MeOH -2n DME

in

out

out
7

3. Results and discussion
3.1 Catalyst characterization
Fig. 1 shows the XRD patterns of the parent H-MCM-22 samples with various Si/Al ratios and
the dealumination H-MCM-22 (35.1D). It can be seen that all the samples exhibit the typical MWW
structure characteristics as reported in Ref. [22]. It can be found that H-MCM-22 zeolites with
Si/Al=10.8, 28.3 and 35.1 display high intensities of the XRD patterns, showing high crystallinity.
However, with the Si/Al ratio further increasing to 49.8, the intensities of the XRD pattern exhibit a
pronounced reduction compared with other synthesized H-MCM-22 zeolites. The results are in good
coincidence with Ref. [8]. As for the H-MCM-22 dealuminated with AHFS, there is almost no effect
on the crystalline structure, which can be confirmed by the nitrogen physisorption results (Fig. 2 and
Table 1).
The acidic properties of H-MCM-22 samples are evaluated by NH3-TPD, as shown in Fig. 3,
and the quantitative analysis of NH3-TPD results is summarized in Table 2. For all H-MCM-22
o
o
samples, there are two distinct desorption peaks around 190 C and 360 C, corresponding to weak
acid sites and strong acid sites respectively [20,23]8. With the Si/Al ratios of 10.8-49.8 were
implemented, both of the peak area of weak and strong acid sites decreased, indicating the
continuous reduction of weak and strong acid sites on the H-MCM-22 surfaces. As for the
dealumination H-MCM-22 (35.1D) sample, the weak and strong acid sites decreased further, while
more weak acid sites were removed than strong ones by the AHFS treatment, as shown in Table 2.
Fig. 4 shows the Py-IR spectra of the H-MCM-22 with different Si/Al ratios. The bands at 1599
and 1445 cm-1 are associated with hydrogen-bonded pyridine and the band at 1440 cm-1 is ascribed to
the physically adsorbed pyridine [24,25]. The bands at 1490 cm-1 are characteristic of both Brønsted
and Lewis acid sites. The bands at 1450 and 1545 cm-1 are corresponding to Lewis acid sites and
Brønsted acid sites respectively. By changing the Si/Al ratio from 10.8 to 49.8, both of the bands of
1545 and 1450 cm-1 become weak, indicating less Lewis and Brønsted acid sites are generated, as
shown in Table 2. Although the AHFS treatment removed considerable amounts of Brønsted and
Lewis acid sites, and much more Brønsted than Lewis acid sites were removed.
Fig. 5 depicts the 27Al MAS NMR spectra of all the H-MCM-22 samples. Both tetrahedral (AlIV,
signals around 56 ppm) and octahedral (AlVI, signal at 0 ppm) Al species are present in all samples
8

and the amount of extra-framework Al species increased with the Al content in the sample [8].
Meanwhile, as for the dealumination H-MCM-22 (35.1D), the AlVI species at 0 ppm almost
disappears. This suggests that the dealumination treatment could remove most of the
extra-framework Al species. The broad signal around 56 ppm contains at least three components
centered at 50.5, 56.0 and 61.5 ppm, which are attributed to the Al species located at
crystallographically different T sites [8,26]. Obviously, the relative intensities of the three
components change with the Si/Al ratio increasing, this indicates that the Al distribution in the
framework depends on its content in the samples [8]. Interestingly, as for the dealumination
H-MCM-22 (35.1D), the relative intensity of the Al species at 50.5 ppm reduced, this suggests that
the AHFS treatment also can remove some framework Al species. Anyway, the AlF/AlEF ratio (Table
1) of dealuminated sample was increased significantly, compared to the parent one. This illustrates
that much more extra-framework than framework Al species were removed by the AHFS treatment.
3.2 Catalytic performance
The catalytic results of methanol conversion to olefins over H-MCM-22 with different Si/Al
ratios and the dealumination H-MCM-22 (35.1D) are shown in Fig. 6, and the data were collected
with time on stream at 450 oC and 1 h-1. Fig. 6 A shows the methanol conversion vs. time on stream
for the parent and the dealuminated H-MCM-22 samples during the MTO reaction. All the
H-MCM-22 samples, regardless of their Si/Al ratio, exhibit initial methanol conversions of nearly
100%. The catalyst stability is estimated by using the reaction time for complete methanol
conversion at a certain WHSV according to ref. [11,27,28,29,30,31,32,33], and the catalyst lifetime
is different from one another. As the Si/Al ratio increased from 10.8 to 35.1, the catalytic lifetime
increased from 23 to 48 h. However, with the Si/Al ratio further increasing to 49.8, the catalytic
lifetime dramatically decreased to 17 h, which may be due to the presence of lower amounts of acid
sites, especially for the amount of the Lewis acid sites in the sample (Table 2). However, as for the
dealumination H-MCM-22 (35.1D) sample, the lifetime was about 36 h, this may be ascribed to the
increase of Lewis acid sites, as shown in Table 1.
Another parameter related to the catalyst stability to deactivation is the conversion capacity that
is the amount of methanol converted per gram of catalyst during the catalyst lifetime [18]. Obviously,
9

the H-MCM-22 (35.1) has highest conversion capacity. Meanwhile the combination of higher
conversion capacity and the least acid sites results in the highest turnover frequency (TOF) over the
H-MCM-22 (35.1D) catalyst, as listed in Table 2.
As for the product selectivity over H-MCM-22 samples under investigation, the products
mainly contain light olefins (ethylene, propylene and butylene) and alkanes and some liquid products
(water and oil). The light olefins selectivities were shown in Fig. 6. The ethylene selectivity (Fig. 6 B)
decreased with increasing Si/Al ratio as a result of the decrease of the acid sites amount. While the
initial propylene and butylene selectivities increased during the lifetime (all the samples have the
similar methanol conversion of 100%) with the Si/Al ratio increasing from 10.8 to 49.8, and then the
H-MCM-22 (49.8) decreased quickly with the shortest lifetime, as shown in Fig. 6 C and D. As for
the dealumination H-MCM-22 (35.1D) sample, the propylene and butylene selectivities were
enhanced further with decreasing the selectivity of ethylene to some extent. Therefore, the P/E
=
=
(C3 /C2 ) ratio increased with the Si/Al ratio increasing with and without dealumination with AHFS,
as shown in Fig. 6 E. Also Fig. 6 F gives the CH4 selectivity, as suggested that it can be an indication
for the deposition of large amount of coke, because CH4 was considered to be generated by
methylation of the coke with methanol [9]. Interestingly, compared with the parent H-MCM-22
sample, the dealumination H-MCM-22 (35.1D) sample has more slow increase in the methane
selectivity. This suggested that the dealumination treatment can inhibit the coke deposition to some
extent.
Concerning the acidic properties of H-MCM-22 samples, it seems that the catalytic stability is
related to the amount of acid sites, some extent decrease of the acid sites is beneficial to prolong the
catalytic lifetime, however, when the amount of Lewis acid decreases too much, the catalytic
stability seems to be destroyed, as shown in Table 2. Meanwhile, with the Si/Al ratio increasing from
10.8 to 49.8, the propylene and butylene selectivities increased although the amounts of Brønsted
acid sites decreased. As for the dealumination H-MCM-22(35.1 D), the amounts of Brønsted acid
sites decreased further, with the amounts of the Lewis acid sites increased, the propylene and
butylene selectivities increased further with higher catalytic stability. Hence, it seems that the light
olefin selectivity is related to the amounts of the Brønsted acid sites, and the stability is related to the
amounts of Lewis acid sites.
10

4. Conclusions
A series of H-MCM-22 samples with Si/Al ratios from 10.8 to 49.8 were hydrothermally
synthesized, and also the H-MCM-22 (35.1) was dealuminated by AHFS. The amount of AlVI species
decreased with increasing Si/Al ratio in the sample, and the AlVI species in the dealuminated sample
almost disappears, showing that much more extra-framework Al species were removed by the AHFS
treatment. The MTO catalytic properties of H-MCM-22 are highly dependent on its acidic properties.
An increase in the Si/Al ratio leads to an increase of the propylene and butylene selectivities but a
decrease in ethylene selectivity. It seems that the catalytic stability is related to the amount of acid
sites especially the Lewis acid sites, too much or too less Lewis acid does not benefit to improve the
catalytic stability. The H-MCM-22 with Si/Al ratio of 35.1 exhibits much higher catalytic stability
than the other samples because of its suitable acid site amount and distribution. And the light olefin
selectivity seems to be related to the amounts of Brønsted acid sites, the less Brønsted acid sites and
the higher light olefin selectivity. The dealumination H-MCM-22 (35.1D) has the fewest Brønsted
acid sites, it has the highest light olefin selectivity.
Acknowledgments
The authors are grateful for financial support by the Chinese Academy of Sciences Research
Program (No. XDA07070301), the National Science Foundation of China (No. 21403264), the
Qingdao Institute of Bioenergy and Bioprocess Technology Director Innovation Foundation for
Young Scientists (Grant No. CASKLB201502) and the Applied Basic Research Programs of
Qingdao (Grant No. 14-2-4-53-jch).
11

References
[1] U. Olsbye, S. Svelle, K. P. Lillerud, Z. H. Wei, Y. Y. Chen, J. F. Li, J. G. Wang, W. B. Fan,
Chem. Soc. Rev. DOI: 10.1039/c5cs00304k.
[2] W. Dai, X. Wang, G. Wu, N. Guan, M. Hunger, L. Li, ACS Catal. 1 (2011) 292-299.
[3] C.D. Chang, Catal. Rev. Sci. Eng. 25 (1983) 1-118.
[4] U. Olsbye, S. Svelle, M. Bjorgen, P. Beato, T.V.W. Janssens, F. Joensen, S. Bordiga, K.P.
Lillerud, Angew. Chem. Int. Ed. 51 (2012) 5810-5831.
[5] M.A. Deimund, J.E. Schmidt, M.E. Davis, Top. Catal. 58 (2015) 416-423.
[6] J.Q. Chen, A. Bozzano, B. Glover, T. Fuglerud, S. Kvisle, Catal. Today 106 (2005) 103-107.
[7] G. Yang, Y. Wei, S. Xu, J. Chen, J. Li, Z. Li, J. Yu, R. Xu, J. Phys. Chem. C 117 (2013)
8214-8222.
[8] P. Wang, L. Huang, J. Li, M. Dong, J. Wang, T. Tatsumi, W. Fan, RSC Adv. 5 (2015)
28794-28802.
[9] P. Tian, Y. Wei, M. Ye, Z. Liu, ACS Catal. 5 (2015) 1922-1938.
[10] S. Hu, Y. Gong, Q. Xu, X. Liu, Q. Zhang, L. Zhang, T. Dou, Catal. Commun. 28 (2012) 95-99.
[11] C. Mei, P. Wen, Z. Liu, H. Liu, Y. Wang, W. Yang, Z. Xie, W. Hua, Z. Gao, J. Catal. 258 (2008)
243-249.
[12] S. Park, Y. Watanabe, Y. Nishita, T. Fukuoka, S. Inagaki, Y. Kubota, J. Catal. 319 (2014)
265-273.
[13] W. Xia, A. Takahashi, I. Nakamura, H. Shimada, T. Fujitani, J. Mol. Catal. A: Chem. 328 (2010)
114-118.
[14] M.E. Leonowicz, J.A. Lawton, S.L. Lawton, M.K. Rubin, Science 264 (1994) 1910-1913.
[15]S. Lawton, M.E. Leonowicz, R. Partridge, P. Chu, M.K. Rubin, Microporous Mesoporous Mater.
23 (1998) 109-117.
[16] H.-K. Min, M.B. Park, S.B. Hong, J. Catal. 271 (2010) 186-194.
[17] X. Wang, W. Dai, G. Wu, L. Li, N. Guan, M. Hunger, Microporous Mesoporous Mater. 151
(2012) 99-106.
[18] A. Lacarriere, F. Luck, D. Swierczynski, F. Fajula, V. Hulea, Appl. Catal. A Gen. 402 (2011)
208-217.
[19] A. Corma, C. Corell, J. Perezpariente, Zeolites 15 (1995) 2-8.
[20] X. Niu, J. Gao, Q. Miao, M. Dong, G. Wang, W. Fan, Z. Qin, J. Wang, Microporous
Mesoporous Mater. 197 (2014) 252-261.
[21] F.F. Madeira, K. Ben Tayeb, L. Pinard, H. Vezin, S. Maury, N. Cadran, Appl. Catal. A Gen. 443
12

(2012) 171-180.
[22] A. Corma, V. Martinez-Soria, E. Schnoeveld, J. Catal. 192 (2000) 163-173.
[23] X. Li, D. Han, H. Wang, G. Liu, B. Wang, Z. Li, J. Wu, Fuel 144 (2015) 9-14.
[24] L. Li, J. Ding, J.G. Jiang, Z. Zhu, P. Wu, Chin. J. Catal. 36 (2015) 820-828.
[25] P. Li, G. Liu, H. Wu, Y. Liu, J. g. Jiang, P. Wu, J. Phys. Chem. C 115 (2011) 3663-3670.
[26] E. Lippmaa, A. Samoson, M. Magi, J. Am. Chem. Soc. 108 (1986) 1730-1735.
[27] Z. Hu, H. Zhang, L. Wang, H. Zhang, Y. Zhang, H. Xu, W. Shen, Y. Tang, Catal. Sci. Technol. 4
(2014) 2891-2895.
[28] M. Milina, S. Mitchell, P. Crivelli, D. Cooke, J. Perez-Ramirez, Nat. Commun. 3922 (2014)
DOI: 10.1038/ncomms4922.
[29] M. Yoshioka, T.Yokoi, T. Tatsumi, ACS Catal. 5(2015) 4268-4275.
[30] L. Wu, V. Degirmenci, P. C.M.M. Magusin, N. J.H.G.M. Lousberg, E. J.M. Hensen, J. Catal.
298 (2013) 27-40.
[31] Q. Sun, N. Wang, D. Xi, M. Yang, J.H. Yu, Chem. Commun., 50 (2014) 6502-6505.
[32] M. Choi, K. Na, J. Kim, Y. Sakamoto, O. Terasaki, R. Ryoo, Nature 461 (2009) 246-249.
[33] R. Chal, C. Gerardin, M. Bulut, S. van Donk, Chemcatchem 3 (2011) 67-81.
13

(e)
(d)
(c)
(b)
(a)
10
20
30
40
50
2
Fig. 1 XRD patterns of (a) H-MCM-22(10.8), (b) H-MCM-22(28.3), (c) H-MCM-22(35.1), (d)
H-MCM-22(49.8) and (e) H-MCM-22(35.1D) samples.
14

50
e
d
c
b
a
0.0
0.2
0.4
0.6
0.8
1.0
P/P0
Fig. 2 Nitrogen adsorption-desorption isotherms of (a) H-MCM-22(10.8), (b) H-MCM-22(28.3), (c)
H-MCM-22(35.1), (d) H-MCM-22(49.8) and (e) H-MCM-22(35.1D) samples.
15

a
b
c
d
e
100
200
300
400
500
600
Temperature (oC)
Fig. 3 NH3-TPD spectra of (a) H-MCM-22(10.8), (b) H-MCM-22(28.3), (c) H-MCM-22(35.1), (d)
H-MCM-22(49.8) and (e) H-MCM-22(35.1D) samples.
1490
1599
1450
1445
1440
1620
1636
1545
a
b
c
d
e
1700 1650 1600 1550 1500 1450 1400
Wavenumber (cm-1)
Fig. 4 FTIR spectra of adsorbed pyridine of (a) H-MCM-22(10.8), (b) H-MCM-22(28.3), (c)
H-MCM-22(35.1), (d) H-MCM-22(49.8) and (e) H-MCM-22(35.1D) samples.
16

e
d
c
b
a
100 80 60 40 20
0
-20 -40 -60 -80 -100
ppm
Fig. 5 27Al MAS NMR spectra of (a) H-MCM-22(10.8), (b) H-MCM-22(28.3), (c) H-MCM-22
(35.1), (d) H-MCM-22 (49.8) and (e) HMCM-22 (35.1D) samples.
17

8
6
4
2
0
(A)
100
90
80
70
60
50
(B)
(a)
(a)
(b)
40
(b)
(c)
60
(e)
(c)
(d)
(d)
(e)
0
10
20
30
40
50
60
0
10
20
30
50
Time on stream (h)
Time on stream (h)
30
25
20
15
10
5
50
(C)
(D)
40
30
20
10
(e)
(d)
(d)
(c)
60
(b)
(a)
(e)
(c)
(b)
(a)
0
10
20
30
40
50
0
10
20
30
40
50
60
Time on stream (h)
Time on stream (h)
16
8
6
4
2
0
(a)
(E)
(c)
(F)
(e)
12
8
(d)
(b)
(c)
(b)
(d)
4
(e)
(a)
0
0
10
20
30
40
50
60
0
10
20
30
40
50
60
Time on stream (h)
Time on stream (h)
Fig. 6 Catalytic performance of methanol to olefins over (a) H-MCM-22(10.8), (b) H-MCM-22(28.3),
(c) H-MCM-22 (35.1), (d) H-MCM-22 (49.8) and (e) H-MCM-22 (35.1D) samples.
18

Table 1 Physical properties of different H-MCM-22 catalysts.
Pore volume (cm3g-1)
SBET
Sample
Si/Al
AlF/AlEF
(m2g-1)
Vmicro
0.19
0.20
0.20
0.11
0.20
Vmeso
0.36
0.49
0.34
0.40
0.24
H-MCM-22(10.8)
H-MCM-22(28.3)
H-MCM-22(35.1)
H-MCM-22(49.8)
H-MCM-22(35.1D)
10.8
28.3
35.1
49.8
96.0
573
597
590
350
553
84/22
87/15
85/4
55/9
426/6
Table 2 Acidic properties and the MTO lifetime parameters of different H-MCM-22 catalysts.
Acidity
by
Acidity by typeb
(µmol g-1)
Conversion
capacityc
(g g-1)
strengtha
(mmol g-1)
Lifetime
(h)
TOFd
(h-1)
Sample
Weak Strong Brønsted Lewis B/L
H-MCM-22(10.8)
H-MCM-22(28.3)
H-MCM-22(35.1)
H-MCM-22(49.8)
1.05
0.45
0.38
0.29
0.5
117.70
82.30
70.44
38.76
22.30
68.98 1.7
29.98 2.7
23.29 3.0
23
31
48
17
36
23
31
48
17
36
20
45
56
74
111
0.25
0.17
0.13
0.11
7.92
4.9
H-MCM-22(35.1D) 0.17
20.76 1.1
a Density of the acid sites, assorted according to the acidic strength, determined by NH3-TPD.
b Density of the acid sites, assorted according to the acidic type, determined by Py-IR.
c The amount (g) of methanol converted per gram of catalyst during the catalyst lifetime.
d TOF was calculated on the basis of total acid sites identified by NH3-TPD.
19
