Simple preparation of amorphous infinite coordination polymer nanoparticles and solid
state transformation to ZnO nanoparticles
Maryam Mohammadikish, Fatemeh Molla
PII:
S0022-3697(18)33173-1
https://doi.org/10.1016/j.jpcs.2019.02.003
PCS 8901
DOI:
Reference:
To appear in: Journal of Physics and Chemistry of Solids
Received Date: 18 November 2018
Revised Date: 2 January 2019
Accepted Date: 1 February 2019
Please cite this article as: M. Mohammadikish, F. Molla, Simple preparation of amorphous infinite
coordination polymer nanoparticles and solid state transformation to ZnO nanoparticles, Journal of
Physics and Chemistry of Solids (2019), doi: https://doi.org/10.1016/j.jpcs.2019.02.003.
This is a PDF file of an unedited manuscript that has been accepted for publication. As a service to
our customers we are providing this early version of the manuscript. The manuscript will undergo
copyediting, typesetting, and review of the resulting proof before it is published in its final form. Please
note that during the production process errors may be discovered which could affect the content, and all
legal disclaimers that apply to the journal pertain.

ACCEPTED MANUSCRIPT
Simple preparation of amorphous infinite coordination polymer nanoparticles and solid state
transformation to ZnO nanoparticles
Maryam Mohammadikish*and Fatemeh Molla
Faculty of Chemistry, Kharazmi University, Tehran, Iran
E-mail: mohammadikish@khu.ac.ir
Abstract: A novel organic-inorganic hybrid materials comprised from infinite-chains of Zn(II) and bi-
carboxylic acid linker (4-Carboxy-1-{3-[(4-carboxy-phenylimino)-methyl]-4-hydroxy-benzyl}-
pyridinium chloride) was successfully formed by precipitation from the mixture of precursor solutions.
Thermogravimetric and elemental analyses, energy dispersive X-ray (EDX) and Fourier-transform
infrared (FT-IR) spectroscopies approved the existence of two well-defined coordinating sites (N,O and
COO sites) coordinated to zinc ions. Coordination of the linker N,O site to Zn2+ ion generated the
metalo-ligand units and further addition of Zn2+ ion resulted in the attachment of these units to each
other via carboxylic acid groups. Time-dependent SEM analysis demonstrated that the optimum time
for preparing the smallest particles is 5 min. Calcination of the prepared zinc based coordination
polymer achieved uniform ZnO nanoparticles with larger band gap in comparison with bulk counterpart.
Keywords: Band gap; Growth mechanism; Precipitation; Zinc coordination polymer; Zinc oxide
Introduction
Coordination polymers are a kind of organic-inorganic hybrid materials composed of metallic nodes
connected by repeating units of ligands extending in one, two or three dimensions and have attracted
great attentions [1-3]. Bailar reported the first series of procedures for constructing inorganic polymers
based on coordinative bonds [4]. While the researchers have been concerned in metal-organic
frameworks (MOFs), the first examples of nano- or microscale coordination polymer particles were
reported by Mirkin [5] and Wang [6]. Recent studies revealed great interest in two new types of
coordination polymers i.e. metal-organic frameworks (MOFs) and infinite coordination polymers (ICPs)
[7-10].
1

ACCEPTED MANUSCRIPT
In contrast to crystalline MOF, ICPs with amorphous nanostructures constructed from self-assembly of
metal ions and organic linkers [11-13]. By addition of nonpolar solvent to the mixture of metal ions
(Zn2+, Cu2+, Ni2+) and carboxylate functionalized binaphthyl bis-metallo-tridentate Schiff base (BMSB)
linker, micro/nanoparticles of ICPs was prepared [5]. Depending on the desired application, the ICPs
particles with specific physiochemical properties such as color, luminescence, and redox properties can
be achieved either by exchanging the metal ions and ligands or adjusting their interactions.
Recently, some researchers have developed the approaches to manufacture ICPs by using various
methods. Mirkin’s group reported the preparation of adjustable ICPs by using precipitation process [14-
16]. The preparation of micro-sized cubic ICPs via microwave-assisted solvothermal revealed by Masel
[17]. Lin’s group reported the formation of ICP nanorods via the water-in-oil microemulsion method
[18]. Oh and his coworkers developed the preparation method of ICPs with different morphologies and
sizes by utilizing solvothermal method [19-21]. ICPs particles have also been used as precursors for
producing metal oxides by Oh [19, 22, 23] and our groups [24-26].
In this paper, a new bi-carboxylic acid Schiff base linker was synthesized from p-aminobenzoic acid
and functionalized salicylaldehyde with iso-nicotinic acid. We describe a simple precipitation method to
fabricate zinc coordination polymer with bi-carboxylic acid Schiff base linker and used obtained ICP
for preparing ZnO by calcination.
Experimental Section
Materials and apparatus
Solvents and all other chemicals were obtained from Acros, Merck and Alfa-Aesar commercial sources
and used as received unless otherwise noted.
The CHN elemental analysis was done on a Perkin-Elmer 2400 SERIES II. Inductively coupled plasma-
optical emission spectroscopy (ICP-OES) was conducted on SPECTRO ARCOS FHE 12 ICP-OES
1
analyzer. H NMR spectra were recorded on a Bruker Avance 300 spectrometer. Fourier-transform
infrared spectra of solid samples (KBr pellets) were obtained on a Perkin-Elmer-RXI FT-IR
spectrometer. The elemental composition and surface morphology of the samples were studied using
2

ACCEPTED MANUSCRIPT
energy dispersive X-ray analysis (EDX) equipped with a high resolution MIRA3-TSCAN-XMU field
emission scanning electron microscope (FE-SEM). Atomic force microscopy (AFM) was carried out to
study the topology of the surface of coordination polymer using Ara-Research AFM full plus in the
non-contact mode and at ambient air. Thermogravimetric analysis (TGA) was conducted on TGA 1-
Mettler Toledo thermogravimeter in the temperature range from room temperature to 700°C at a heating
rate of 10°C min−1 in static air. XRD pattern was recorded on a Rigaku D-max CIII X-ray
diffractometer using Ni-filtered Cu Kα radiation. The electronic spectra were taken on a Cintra 101
spectrometer. The emission spectra were taken on a Jasco FP-6500 spectrofluorometer. The specific
surface area and pore size distribution were determined by the nitrogen adsorption method using
Belsorp-mini II instrument with 23 points for evaluation. Before performing the adsorption experiments
the sample was outgassed under vacuum at 150°C.
Synthesis of the ligand
All of the steps of the synthesis process are shown in Scheme 1. 5-(chloromethyl)-2-
hydroxybenzaldehyde (A) was prepared according previous report [26, 27].
4-Carboxy-1-(3-formyl-4-hydroxy-benzyl)-pyridinium chloride (B)
As a typical procedure, in a 100 mL round bottom flask, 9.23 g (75mmol) of isonicotinic acid in
methanol was added to the warm methanolic solution of 3 g NaOH. After 2h, the solution was exposed
to air to evaporate solvent. The precipitated white powder of sodium isonicotinate was collected and
washed with methanol (9.5 g; 87% yield).
5 g (35 mmol) of sodium isonicotinate was suspended in 25 mL of THF. A solution of 6 g (35 mmol) 5-
(chloromethyl)-2-hydroxybenzaldehyde (A) in 15 mL THF was added to this suspension and the
reaction mixture was refluxed for 48 h. The solvent was removed by filtration and the residue was
washed with THF several times. The product taken up in a small volume of distilled hot water (30 mL),
acidified with 6 M HCl and stirred for 30 min to achieve pH = 2. After concentrating the solution to
about a half volume in a hot water bath, the formed solid product was collected by filtration. To remove
the NaCl impurity, the white residue was treated with a small volume of methanol (20 mL), the mixture
3

ACCEPTED MANUSCRIPT
was filtered, and an excess volume of diethyl ether was added to the filtrate to precipitate the desired
compound. The product was collected and dried under vacuum (4 g; 38% yield) [28]. Elemental anal.
Calc. for C14H12NO4Cl.1.2H2O: C, 53.33; H, 4.60; N, 4.44. Found: C, 52.96; H, 4.30; N, 4.50. 1H NMR
(DMSO-d6): δ = 11.25 (s, 1H, OH10), 10.28 (s, 1H, CH9O), 9.34 (d, 2H, H1,4), 8.46 (d, 2H, H2,3), 7.91 (d,
1H, Haromatic), 7.73 (dd, 1H, Haromatic), 7.13 (d, 1H, Haromatic), 5.88 (s, 2H, C5H2Cl) ppm. FT-IR (KBr,
cm−1): 3198 (υO-H, H2O), 3059 (υC-H-aromatic), 2926(υC-H-aliphatic), 2865 (υC-H-aldehyde), 1711 (υC=O-acid), 1671
(υC=O-aldehyde), 1617, 1491 (υC=C).
Synthesis of Schiff base ligand, 4-Carboxy-1-{3-[(4-carboxy-phenylimino)-methyl]-4-hydroxy-
benzyl}-pyridinium chloride (L)
1.7 g (5.79 mmol) of 4-Carboxy-1-(3-formyl-4-hydroxy-benzyl)-pyridinium chloride (B) was dissolved
in 40 mL hot methanol, and 10 mL methanolic solution of p-aminobenzoic acid (0.794 g; 5.79 mmol)
was added to above solution slowly. Fine yellow crystal of the product was formed spontaneously and
the reaction mixture was stirred for 2h. After this time, the products were isolated, and subsequently
washed with methanol several times via centrifugation–redispersion cycles. Each successive supernatant
was decanted and replaced with fresh methanol. The product was collected and dried under vacuum (1.4
g; 59% yield). Elemental anal. Calc. for C21H17N2O5Cl: C, 61.10; H, 4.15; N, 6.79. Found: C, 61.49; H,
1
4.32; N, 6.43. H NMR (DMSO-d6): δ = 12.68 (s, 1H, OH10), 9.02 (d, 2H, H1,4), 8.92 (s, 1H, N=CH9),
8.20 (d, 2H, H2,3), 8.00 (d, 2H, H12,13), 7.85 (d, 1H, Haromatic), 7.60 (dd, 1H, Haromatic), 7.45 (dd, 2H,
H11,14), 7.05 (d, 1H, Haromatic), 5.78 (s, 2H, C5H2Cl) ppm. FT-IR (KBr, cm−1): 3381 (υO-H), 3121 (υC-H-
aromatic), 2926 (υC-H-aliphatic), 1708 (υC=O-acid), 1625 (υC=N).
Synthesis of Zn-ICP by precipitation method
A solution of Zn(OAc)2.2H2O (1.50 g; 6.83 mmol, 6 mL) in DMSO was added slowly to a 10 mL hot
DMSO solution of Schiff base ligand (L) (1.30 g, 3.15 mmol). Immediately, large amount of precipitate
was observed in the solution. The colloidal solution was further stirred and 4 mL taken from the
reaction mixture at various times (5, 10, 30, 60 min). The yellow precipitate was isolated by
centrifugation and washed with DMSO and ethanol several times (0.91 g; 48% yield). Elemental anal.
4

ACCEPTED MANUSCRIPT
Calc. for C23H17N2O7ClZn2.2H2O: C, 46.07; H, 2.86; N, 4.67; Zn, 21.81. Found: C, 46.42; H, 2.81; N,
4.96; Zn, 22.02. FT-IR (KBr, cm−1): 3427 (υO-H, H2O), 3051 (υC-H-aromatic), 2893 (υC-H-aliphatic), 1620 (υC=N),
1568 (υC=O-asymmetric), 1470 (υC=O-symmetric).
O
O
HO
HCl, (CH2O)n
HO
CH2Cl
5days, r.t.
A
9
O
8
6
4
3
2
H2N
COOH
Cl-
Sodium isonicotinate, THF, reflux, 48h
HCl 6M, pH = 2
A
C5H2 N+
COOH
H10
O
CH3OH, 2h, r.t.
1
7
B
4
1
3
2
5H2 Cl-
C
N+
COOH
8
2eq. Zn(OAc)2.2H2O
DMSO
14
11
13
12
6
9
N
7
HOOC
H10
O
L
H2 Cl-
C
N+
COO
Zn
n
N
OOC
O
Zn
O
O
C
Zn-ICP
H3C
Scheme 1. Illustrative preparation steps of the ligand preparation and proposed structure for Zn-ICP infinite
coordination polymer.
Results and Discussion
To fabricate Zn-ICP, the 4-Carboxy-1-{3-[(4-carboxy-phenylimino)-methyl]-4-hydroxy-benzyl}-
pyridinium chloride (L) containing carboxyl groups were designed to act as ligand for coordination of
the metal ion (Scheme 1). For this purpose, functionalized salicylaldehyde (B) was synthesized by
nucleophilic substitution of chloro group of 5-(chloromethyl)-2-hydroxybenzaldehyde (A) with sodium
isonicotinate followed by acidification of the mixture to protonate the carboxylate group. In the next
step, ligand (L) was prepared from 4-Carboxy-1-(3-formyl-4-hydroxy-benzyl)-pyridinium chloride (B)
and p-aminobenzoic acid by Schiff base condensation reaction. As shown in Scheme 1, the mixing of
DMSO solutions of prepared ligand (L) and Zn(OAc)2 at room temperature achieved the Zn-ICP as
light yellow precipitate.
5

ACCEPTED MANUSCRIPT
To study the chemical composition of obtained Zn-ICP, ICP-OES and CHN elemental analysis were
carried out which indicated the existence of two zinc ions per one ligand in each monomeric unit of Zn-
ICP and confirmed the proposed structure. One equivalent of Zn2+ions was coordinated by N,O site of
the ligand. Second equivalent of zinc cations acted as node to connect metal-organic building blocks
together through the carboxylate groups. The existence of one acetate anion is required in each unit for
the neutrality of prepared Zn-ICP.
The chemical composition of product was also explored by energy dispersive X-ray (EDX)
spectroscopy (Fig. 1). It can be deduced from EDX spectrum that the product is composed of C, N, O,
Cl and Zn elements. The 1.486 eV signal of Al is related to the coating material.
Fig. 1. EDX spectrum of Zn-ICP.
An important issue in the studying of ICP particles is that one should work with amorphous rather than
crystalline materials, so the single crystal X-ray analysis cannot be used to study the formation and the
exact structures of the obtained ICP particles [11]. XRD analysis of Zn-ICP (Fig. 2) indicated that it is
amorphous and no crystalline structure was formed during the preparation stages. It means that similar
to other examples of ICP particles achieved from the polymerization-precipitation approach [5, 13, 29],
this method do not favor slow crystallization which often produces the amorphous structures [11].
6

ACCEPTED MANUSCRIPT
80
60
40
20
0
10
30
50
70
Position (2-Theta)
Fig. 2. XRD pattern of the amorphous Zn-ICP.
Further evidence for the construction of Zn-ICP particles was provided by FT-IR spectroscopy.
Coordination of carboxylate groups to Zn2+ ions was verified by the observation of the shift in the
carboxyl stretching frequency from 1708 cm−1 to 1568 and 1470 cm−1. The C=N frequency shift from
1625 cm−1 in ligand to 1620 cm−1 in Zn-ICP also verified the coordination of N,O site to Zn2+ ions.
The thermal behavior and stability of the Zn-ICP was studied by thermogravimetric analysis
(TGA/DTA; Fig. 3). The TGA curve exhibited a slight weight loss from room temperature to 150 ºC
owing to the removing surface adsorbed water [30]. The ligand species started to decompose above 200
ºC and the framework collapsed until 450 ºC. From the relatively high temperature needed for this
decomposition, it can be found that the organic linker is strongly bonded to metal cation. Further weight
loss was not observed with heating of the sample to 700 ºC. The final residual weight is 25.47%
(calculated: 25.60%) attributed to the ZnO formation. TGA analysis clearly indicates the existence of
two water molecules and approves the molecular weight of the monomeric unit of the prepared Zn-ICP.
From the DTA curve it is obvious that the loss of water is endothermic. An intense exothermic
decomposition peak was observed for organic residue burning at about 380 °C.
7

ACCEPTED MANUSCRIPT
Fig. 3. TGA/DTA curves of Zn-ICP.
To provide better insight from the Zn-ICP morphology, FE-SEM analysis was employed (Fig. 4). The
prepared Zn-ICP particles have smooth surface with diameters of about 70 nm. Zn-ICP nanoparticles
formation process was further explored at various reaction times to find evidence for the possible
growth mechanism. Three clear evolution steps could be seen as exhibited in Fig. 4. At the primary
stages, an investigation of the intermediate product obtained after 5 min indicated that a large number of
sphere like nanoparticles are present (Fig. 4a), while the intermediate formed after 30 min comprised
from agglomerated nanoparticles (Fig. 4b). It is obvious that the nanoparticles have grown and attached
to each other. By increasing the reaction time to 60 min the more agglomerated particles was resulted
(Fig. 4c). However, the best time to achieve individual nanoparticles of Zn-ICP is 5 min.
From the time-dependent SEM analysis, proposed mechanism was deduced for the particle formation
process, which involves nucleation, aggregation and growth. At early stages of the reaction with high
concentrations of precursors, fine nanoparticles were produced from nucleation of product. However,
with proceeding the reaction, the concentration of precursor decreases and the growth process become
dominant and larger ICP particles with deviation from spherical shape were formed. The particle-
growth step involves both the coalescence of the nanosized seeds and agglomeration into larger
8

ACCEPTED MANUSCRIPT
particles structures along with the next adsorption of additional nanoparticles into the larger particle
cores.
Fig. 4. Representative FE-SEM images monitoring the formation of Zn-ICP at: a) 5 min, b) 30 min, c) 60 min,
and d) high resolution FE-SEM image of (c).
High resolution FE-SEM image (Fig. 4d) shows some porosity in the obtained Zn-ICP particles at 60
min. So, N2 adsorption/desorption analysis was used to study the porosity of prepared sample. Fig. 5
depicts the N2 adsorption/desorption isotherm of as-prepared Zn-ICP. As can be seen, the sample
represent type-II isotherm, indicating its nonporous nature. The BET surface area was calculated to be
9.5 m2/g. Despite some earlier reports about high porosity and good gas storage ability of ICPs [11, 15,
19, 31], the obtained micro/nano scale coordination polymers did not show well gas storage. Although
MOFs have good porosity for gas up-taking due to their well-defined porous framework, there is no any
framework or porosity in ICPs for gas up-taking [25].
9

ACCEPTED MANUSCRIPT
15
10
5
ADS
DES
0
0
0.2
0.4
0.6
0.8
1
p/p0
Fig. 5. Nitrogen adsorption/desorption isotherm of Zn-ICP nanoparticles prepared by precipitation method at 60
min
AFM was used in non-contact mode under ambient conditions to study the topography and roughness of
the Zn-ICP in three dimensions (Fig. 6). Crest and trough roughness of the surface was clearly seen in
the AFM image. The image confirmed spherical morphology and monodispersed nanoparticles with
height of about 77 nm.
10

ACCEPTED MANUSCRIPT
Fig. 6. AFM image of Zn-ICP nanoparticles.
Fig. 7 illustrates the absorption and emission spectra of the ligand and Zn-ICP nanoparticles. Evidently,
despite the similarity in the highest lying transition (π→π*) below 350 nm in absorption spectra,
prominent differences are seen around 350–500 nm, in which n→π* transition of ligand was
disappeared in Zn-ICP absorption spectrum and exhibits another absorption band at 442 nm owing to
MLCT transition. Upon excitation (at 380 nm and 440 nm for ligand and Zn-ICP, respectively), the
ligand showed an emission peak at 550 nm. After coordination of the ligand to Zn2+ ion, the intensity of
550 nm emission peak reduced indicating the involvement of nitrogen atom in the coordination to Zn2+
ion. This may be rationalized by incorporation of the Zn2+ ion in the structure of Zn-ICP and
decreasing the intensity of the n→π* transition.
11

ACCEPTED MANUSCRIPT
Fig. 7. UV/Vis (in DMSO) and fluorescence (in the solid state) spectra of ligand (λex = 380 nm) and Zn-ICP (λex
= 440 nm).
ICP like MOF counterpart and coordination complex could be good precursors for metal oxide
preparation [32-38]. Prepared Zn-ICP was calcined at 600 °C for 2 h for preparing ZnO nanoparticles.
During this process organic ligand was burn gradually and zinc oxide is final product. As show in Fig.
8a, the obtained XRD pattern of the ZnO nanoparticles is completely in compliance with the hexagonal
phase of bulk ZnO (JCPDS card no. 80-0075). Absence of any organic residue in FT-IR spectrum (Fig.
8b) confirmed the purity of the obtained ZnO nanoparticles. The FE-SEM analysis (Fig. 8c) illustrates
the size and morphology of ZnO nanoparticles. Fig. 8c shows monodispersed nanoparticles with 60 nm
average size slightly less than 70 nm in precursor (Zn-ICP) due to the role of organic linker.
The optical absorption spectrum of the obtained ZnO was shown in Fig. 8d. Tauc equation [39] shows
the absorption coefficient as a function of photon energy for allowed direct transitions:
(αhυ) = C (hυ – Eg)1/2
where α is absorption coefficient, h is Planck’s constant, υ is the frequency, C is a constant, and Eg is the
band gap energy. From the Tauc plot depicted in the inset of Fig. 8d, the Eg value was found to be 3.95
eV for ZnO. The larger optical band gap energy of ZnO nanoparticles in comparison with the bulk
counterpart (3.3 eV) [40] is due to the quantum confinement effect [41].
12

ACCEPTED MANUSCRIPT
Fig. 8. (a) XRD pattern, (b) FT-IR spectrum, (c) FE-SEM image, and (d) UV-Vis spectrum (the inset shows Tauc
plot) of ZnO product.
Conclusion
New bi-carboxylic acid functionalized Schiff base linker and corresponding zinc coordination polymer
were prepared and structurally characterized. Zn-ICP nanoparticles were obtained immediately after
mixing the precursor solutions of the ligand and Zn2+ ions. The initial formation of sphere like Zn-ICP
nanoparticles and the aggregation of initial seeds for the final formation of larger nanoparticles were
monitored via electron microscopy. The analysis of initial and final products illustrated that they had the
same chemical compositions and morphologies but different sizes. Morever, the best time for the
formation of individual nanoparticles of Zn-ICP is 5 min. Solid state transformation of Zn-ICP
produced pure ZnO nanoparticles with larger band gap relative to bulk counterpart.
Acknowledgements
13

ACCEPTED MANUSCRIPT
The authors gratefully acknowledge the financial support of Kharazmi University (GrantꢀNumber:ꢀ
12065).
References
[1] S.L. James, Metal-organic frameworks, Chemical Society Reviews, 32 (2003) 276-288.
[2] A.Y. Robin, K.M. Fromm, Coordination polymer networks with O-and N-donors: what they are,
why and how they are made, Coordination Chemistry Reviews, 250 (2006) 2127-2157.
[3] S.R. Batten, N.R. Champness, X.-M. Chen, J. Garcia-Martinez, S. Kitagawa, L. Öhrström, M.
O’Keeffe, M. Paik Suh, J. Reedijk, Terminology of metal–organic frameworks and coordination
polymers (IUPAC Recommendations 2013), Pure and Applied Chemistry, 85 (2013) 1715-1724.
[4] H.A. Goodwin, J.C. Bailar Jr, Coördination Compounds Derived from Polymeric Schiff's Bases1,
Journal of the American Chemical Society, 83 (1961) 2467-2471.
[5] C.A.M. Moonhyun Oh, Chemically tailorable colloidal particles from infinite coordination polymers,
Nature, 438 (2005) 651-654.
[6] S.D. Xuping Sun, Erkang Wang, Coordination-Induced Formation of Submicrometer-Scale,
Monodisperse, Spherical Colloids of Organic-Inorganic Hybrid Materials at Room Temperature
Journal of American Chemical Society, 127 (2005) 13102-13103.
[7] G. Férey, Hybrid porous solids: past, present, future, Chemical Society Reviews, 37 (2008) 191-214.
[8] J. Park, Q. Jiang, D. Feng, L. Mao, H.-C. Zhou, Size-controlled synthesis of porphyrinic metal–
organic framework and functionalization for targeted photodynamic therapy, J. Am. Chem. Soc,
138 (2016) 3518-3525.
[9] C. Gong, J. Zhang, X. Zeng, J. Xie, Highly effective synthesis of a cobalt (II) metal–organic
coordination polymer by using continuous flow chemistry, Dalton Transactions, 46 (2017) 25-28.
[10] M.L. Foo, R. Matsuda, S. Kitagawa, Functional hybrid porous coordination polymers, Chem.
Mater, 26 (2014) 310-322.
[11] D.K. Alexander M. Spokoyny, Abdelqader Sumrein, Chad A. Mirkin, Infinite coordination
polymer nano- and microparticle structures, Chemical Society Review, 38 (2009) 1218–1227
[12] C. He, D. Liu, W. Lin, Nanomedicine applications of hybrid nanomaterials built from metal–ligand
coordination bonds: nanoscale metal–organic frameworks and nanoscale coordination polymers,
Chem. Rev, 115 (2015) 11079-11108.
[13] G.S.A. You-Moon Jeon, Jungseok Heo, Mercouri G. Kanatzidis, Chad A. Mirki, Amorphous
Infinite Coordination Polymer Microparticles: A New Class of Selective Hydrogen Storage
Materials, Advanced Materals, 20 (2008) 2105–2110
[14] Y.-M. Jeon, J. Heo, C.A. Mirkin, Dynamic interconversion of amorphous microparticles and
crystalline rods in salen-based homochiral infinite coordination polymers, Journal of the
American Chemical Society, 129 (2007) 7480-7481.
[15] Y.M. Jeon, G.S. Armatas, D. Kim, M.G. Kanatzidis, C.A. Mirkin, Tröger's‐Base‐Derived
Infinite Co‐ordination Polymer Microparticles, small, 5 (2009) 46-50.
[16] C.M. Calabrese, T.J. Merkel, W.E. Briley, P.S. Randeria, S.P. Narayan, J.L. Rouge, D.A. Walker,
A.W. Scott, C.A. Mirkin, Biocompatible Infinite ‐ Coordination ‐ Polymer Nanoparticle –
Nucleic‐Acid Conjugates for Antisense Gene Regulation, Angewandte Chemie, 127 (2015)
486-490.
[17] Z. Ni, R.I. Masel, Rapid production of metal− organic frameworks via microwave-assisted
solvothermal synthesis, Journal of the American Chemical Society, 128 (2006) 12394-12395.
[18] K.M.L.T. William J. Rieter, Hongyu An, Weili Lin, Wenbin Lin, Nanoscale Metal-Organic
Frameworks as Potential Multimodal Contrast Enhancing Agents Journal of American Chemical
Society, 128 (2006) 9024-9025
14

ACCEPTED MANUSCRIPT
[19] S. Jung, W. Cho, H.J. Lee, M. Oh, Self‐Template‐Directed Formation of Coordination‐
Polymer Hexagonal Tubes and Rings, and their Calcination to ZnO Rings, Angewandte Chemie,
121 (2009) 1487-1490.
[20] W. Cho, H.J. Lee, M. Oh, Growth-controlled formation of porous coordination polymer particles,
Journal of the American Chemical Society, 130 (2008) 16943-16946.
[21] M.O. Soyoung Jung, Monitoring Shape Transformation from Nanowires to Nanocubes and Size-
Controlled Formation of Coordination Polymer Particles, Angewandte Chemie International
Edition, 47 (2008) 2049 –2051
[22] W. Cho, S. Park, M. Oh, Coordination polymer nanorods of Fe-MIL-88B and their utilization for
selective preparation of hematite and magnetite nanorods, Chemical Communications, 47 (2011)
4138-4140.
[23] S.-j. Park, W. Cho, M. Oh, Monitoring and analysis of the seed-directed growth of micro-sized
hexapod coordination polymers, CrystEngComm, 12 (2010) 1060-1064.
[24] M. Mohammadikish, A. Ahmadvand-Akradi, Facile synthesis of novel zinc-based infinite
coordination polymer nanoparticles, Inorganic Chemistry Communications, 78 (2017) 48-51.
[25] M. Mohammadikish, M. Talebi, Rapid production of acid-functionalized infinite coordination
polymer nanoparticles and their calcination to mineral metal oxide, Powder Technology, 313
(2017) 169-174.
[26] M. Mohammadikish, Z. Zafari, Coordination-induced formation of nanometer-scale infinite
coordination polymer at room temperature and conversion to CuO nanoparticles, Materials
Research Express, 5 (2018) 035053.
[27] M. Albrecht, M. Lutz, A.L. Spek, G. van Koten, Organoplatinum crystals for gas-triggered
switches, Nature, 406 (2000) 970-974.
[28] A. Dean, M.G. Ferlin, M. Cvijovic, P. Djurdjevic, F. Dotto, D. Badocco, P. Pastore, A. Venzo, V.B.
Di Marco, Evaluation of 1,2-dimethyl-3-hydroxy-4-pyridinecarboxylic acid and of other 3-
hydroxy-4-pyridinecarboxylic acid derivatives for possible application in iron and aluminium
chelation therapy, Polyhedron, 67 (2014) 520-528.
[29] D.M. Inhar Imaz, Clara Rodrguez-Blanco, Jose Manuel Perez-Falcon,-Javier Campo, Daniel
Ruiz-Molina, Valence-Tautomeric Metal–Organic Nanoparticles, Angewandte Chemie
International Edition, 47 (2008) 1857 –1860
[30] F. Ding, Y.G. Qi, Y. Xu, P.P. Yang, Y.H. Zhou, L.L. Zhu, Synthesis, Structures, and Luminescent
Properties of Two Four ‐ connected Polymers Based on 2, 2 ‐ Dimethylsuccinic Acid,
Zeitschrift für anorganische und allgemeine Chemie, 641 (2015) 1906-1910.
[31] H.J. Lee, W. Cho, S. Jung, M. Oh, Morphology‐Selective Formation and Morphology‐
Dependent Gas‐Adsorption Properties of Coordination Polymer Particles, Advanced Materials,
21 (2009) 674-677.
[32] M. Goudarzi, M. Mousavi-Kamazani, M. Salavati-Niasari, Zinc oxide nanoparticles: solvent-free
synthesis, characterization and application as heterogeneous nanocatalyst for photodegradation
of dye from aqueous phase, Journal of Materials Science: Materials in Electronics, 28 (2017)
8423-8428.
[33] F. Soofivand, M. Salavati-Niasari, F. Mohandes, Novel precursor-assisted synthesis and
characterization of zinc oxide nanoparticles/nanofibers, Materials Letters, 98 (2013) 55-58.
[34] A.K. Babaheydari, M. Salavati-Niasari, A. Khansari, Solvent-less synthesis of zinc oxide
nanostructures from Zn(salen) as precursor and their optical properties, Particuology, 10 (2012)
759-764.
[35] R. Wu, X. Qian, F. Yu, H. Liu, K. Zhou, J. Wei, Y. Huang, MOF-templated formation of porous
CuO hollow octahedra for lithium-ion battery anode materials, Journal of Materials Chemistry A,
1 (2013) 11126-11129.
[36] M. Salavati-Niasari, F. Davar, A. Khansari, Nanosphericals and nanobundles of ZnO: Synthesis
and characterization, Journal of Alloys and Compounds, 509 (2011) 61-65.
15

ACCEPTED MANUSCRIPT
[37] M.J. Soltanian Fard, P. Hayati, A. Firoozadeh, J. Janczak, Ultrasonic synthesis of two new zinc(II)
bipyridine coordination nano-particles polymers: New precursors for preparation of zinc(II)
oxide nano-particles, Ultrasonics Sonochemistry, 35 (2017) 502-513.
[38] M.J. Soltanian Fard, P. Hayati, A. Firoozadeh, J. Janczak, Sonochemical synthesis of two new
nano structure zinc(II) 1,10-phenanthroline coordination supramolecular compounds: New
precursors to produce nano-sized zinc(II) oxide, Ultrasonics Sonochemistry, 37 (2017) 286-297.
[39] J. Tauc, Optical properties and electronic structure of amorphous Ge and Si, Materials Research
Bulletin, 3 (1968) 37-46.
[40] V. Srikant, D.R. Clarke, On the optical band gap of zinc oxide, Journal of Applied Physics, 83
(1998) 5447-5451.
[41] M. Salavati-Niasari, F. Davar, M. Mazaheri, Preparation of ZnO nanoparticles from
[bis(acetylacetonato)zinc(II)]–oleylamine complex by thermal decomposition, Materials Letters,
62 (2008) 1890-1892.
16

ACCEPTED MANUSCRIPT
•
•
•
Step by step preparation of new bi-carboxylic acid linker.
Synthesis of new amorphous infinite coordination polymer.
Represent a reasonable mechanism for growth of crystals.
