Crystal structure of a π complex of AgBF4 with 2-allyl-5-phenyl-2H-tetrazole of the composition [Ag(C10H10N4)(BF4)]

Article abstract of DOI:10.1134/S0022476615010242

By the interaction of AgBF₄ with 2-allyl-5-phenyl-2H-tetrazole (2aphet) in the ethanol solution, a π complex of [Ag(2aphet)(BF₄)] is obtained which is studied using single crystal X-ray diffraction.

Full text of DOI:10.1134/S0022476615010242

Journal of Structural Chemistry. Vol. 56, No. 1, pp. 179-180, 2015.
Original Russian Text © 2015 Yu. I. Slyvka.
CRYSTAL STRUCTURE OF A π COMPLEX OF
AgBF WITH 2-ALLYL-5-PHENYL-2Н-TETRAZOLE
4
OF THE COMPOSITION [Ag(C H N )(BF )]
10 10 4 4
Yu. I. Slyvka
UDC 548.736:661
By the interaction of AgBF with 2-allyl-5-phenyl-2Н-tetrazole (2aphet) in the ethanol solution,
4
a π complex of [Ag(2aphet)(BF )] is obtained which is studied using single crystal X-ray diffraction.
4
DOI: 10.1134/S0022476615010242
Keywords: silver(I), π complex, tetrazole, crystal structure.
Coordination compounds of tetrazole derivatives have found a sufficiently wide application in the organic synthesis
as the precursors and catalysts for producing biologically active substances, corrosion inhibitors, luminophores, and as
efficient tools in crystal engineering of metal complexes [1]. Among the π coordinated compounds of d metals of Ib group
with allyl derivatives of tetrazoles only three crystalline π complexes of Ag(I) have been studied [2, 3], so in the continuation
+
of the investigation of the behavior of other substituted tetrazoles as compared with Ag , this work reports the results of the
synthesis and X-ray diffraction analysis of a new π complex of AgBF with 2-allyl-5-phenyl-2Н-tetrazole (2aphet) of the
4
composition [Ag(2aphet)BF ] (1).
4
Experimental. Synthesis. 5-Phenyltetrazole was obtained according to the known technique [4] from benzonitrile
and sodium azide. 5-Phenyltetrazole was alkylated with allyl chloride in the presence of an equivalent amount of NaHCO in
3
the ethanol solution resulting in a product of N-allyl-5-phenyltertrazole (aphet). Yield was 94 %.
The crystals of the [Ag(2aphet)BF ] compound (1) were synthesized by the interaction of silver(I) tetrafluoroborate
4
(formed in situ from Ag CO and HBF ) with 2-aphet in the ethanol solution. To the solution of 0.27 mmol (0.05 g) of
2 3 4
2-aphet in 0.7 ml of ethanol, at room temperature, 0.36 mmol (0.1 g) of freshly prepared Ag CO was added. The suspension
2 3
was acidified with concentrated HBF to pH ∼ 4, and a newly formed white, slightly rose suspension was left in the dark at
4
room temperature. In 52 h, on the surface of the precipitate from the solution, the colorless prismatic crystals of compound 1
formed.
Single crystal X-ray diffraction study. The array of the integrated reflection intensities for the crystals of
compound 1 was recorded on a single crystal Rigaku AFC7 diffractometer equipped with a coordinate Mercury CCD detector
(MoK radiation, graphite monochromator). The structure was solved and refined using the SHELXS-97 and SHELXL-97
α
software [5]. The details of the single crystal X-ray diffraction study and the main crystal structural data for 1 are as follows:
composition C H N AgBF , M = 380.9 g/mol, triclinic crystals, space group P1 , a = 6.3063(12) Å, b = 7.0074(12) Å,
10 10
4
4
3
c = 14.394(3) Å, α = 80.179(8)°, β = 88.241(7)°, γ = 78.732(6)°, V = 614.7(2) Å , Z = 2,
3
= 2.06 g/cm ,
ρ
calc
–1
μ(MoK ) = 1.683 mm , S = 1.077, R(F) = 0.0544 for 2389 reflections with I ≥ 2σ(I), R = 0.1475 for all 2534 independent
α
w
Franko National University of Lviv, Lviv, Ukraine; y_slyvka@franko.lviv.ua. Translated from Zhurnal Strukturnoi
Khimii, Vol. 56, No. 1, pp. 187-188, January-February, 2015. Original article submitted December 16, 2013.
0022-4766/15/5601-0179 © 2015 by Pleiades Publishing, Ltd.
179

Fig. 1. Fragment of the structure of {Ag(2aphet)BF } (1).
4 n
reflections. Three of four F atoms of the tetrafluoroborate anion are disordered over three sites. The positions of these F
atoms were refined in the isotropic approximation. Atomic coordinates and other parameters of compound 1 were deposited
with the Cambridge Structural Database (No. CCDC 976329) at the address of www.ccdc.cam.ac.uk/data_request/cif.
Results and discussion. In the structure of 1, the 2aphet molecule serves as a bridge-chelate π,σ-ligand and is
coordinated to the Ag(I) atom through the olefinic C=C bond of the allyl group and two N1 and N3 atoms of the tetrazole
n+
core (Fig. 1). Therefore, the linear organometallic cationic chains of the composition {Ag(2aphet)} are formed in the
n
structure. The phenyl ring in 2aphet is turned at 10.4° relative to the plane of the tetrazole core. A distorted trigonal-
bipyramidal environment of the silver atom consists of three mentioned active centers of 2aphet and two F atoms. The
i
i
ii
respective Ag–m (where m is the middle of the C=C bond, i = x–1, y, z), Ag–N1 , Ag–N3, Ag–F1 (іі = 1–x, 1–y, 1–z), and
Ag–F42 distances are 2.330(4) Å, 2.420(4) Å, 2.231(4) Å, 3.05(1) Å, and 2.53(1) Å respectively. As a whole, the topology of
compound 1 is similar to that of the previously studied π-complexes of Cu(І) with 2-allylbenzotriazole [6].
The author is grateful to Dr. Goreshnik (Jožef Stefan Institute, Liubljana, Slovenia) for measuring the crystals of
compound 1 on a diffractometer.
REFERENCES
1. P. N. Gaponik, S. V. Voitekhovich, and O. A. Ivashkevich, Russ. Chem. Rev., 75, 507 (2006).
2. Yu. Slyvka, O. Pavlyuk, N. Pokhodylo, et al., Acta Chim. Slov., 58, 134 (2011).
3. Yu. I. Slyvka, N. T. Pokhodylo, E. A. Goreshnik, and M. G. Mys′kiv, J. Struc. Chem., 55, No. 2, 368/369 (2014).
4. W. G. Finnegan, R. A. Henry, and R. Lofquist, J. Am. Chem. Soc., 80, 3908 (1958).
5. G. M. Sheldrick, SHELXS-97, SHELXL-97, Programs for the Solution and Refinement of Crystal Structures, University
of Göttingen, Germany (1997).
6. Yu. Slyvka, E. Goreshnik, A. Pavlyuk, and M. Myśkiv, Centr. Eur. J. Chem., 11, 1875 (2013).
180
