Appl. Phys. Lett., Vol. 80, No. 6, 11 February 2002
Cho et al.
1053
FIG. 2. Dependence of the dielectric constant and flatband voltage shift as a
function of O2 /Ar flow rate ratios.
FIG. 3. Leakage current density as a function of equivalent oxide thickness.
As-deposited ZrO2 films at (O2 /Ar)у1 showed lower leakage levels than
SiO2 films of equivalent oxide thickness. Inset shows the leakage current
density as a function of applied voltage.
(O2 /Ar)ϭ0.5 and 91 Å at (O2 /Ar)ϭ1, 2, and 4. The theo-
retical C–V curve shown for comparison with the experi-
mental curve at (O2 /Ar)ϭ1 was calculated from the exact
charge theory11 using the known oxide thickness of 91 Å, a
dielectric constant of 16, and a dopant concentration of 8
ϫ1015 cmϪ3 in Si. The work function difference of
Ϫ0.94 eV between the Al electrode and the p-type Si was
also taken into account. Theoretical curves at other O2 /Ar
ratios were almost identical to that at (O2 /Ar)ϭ1 except for
the different levels of C/CAcc in the inversion regime
(CInv /CAcc). At (O2 /Ar)ϭ0.5, where the plasma is hydro-
carbon rich, the experimental and theoretical CInv /CAcc val-
ues differed only 5%. However, at (O2 /Ar)у1, where the
plasma is oxygen rich, the experimental values of CInv /CAcc
were always higher than the theoretical calculations by
ϳ70%. This indicates the presence of a lower-dielectric-
constant interfacial layer between ZrO2 and Si, decreasing
the overall dielectric constant.11,12
To identify this interfacial layer, we analyzed the as-
deposited films by high-resolution transmission electron mi-
croscopy ͑HRTEM͒. We confirmed the presence of an amor-
phous interfacial layer of ϳ2 nm between ZrO2 and Si. This
layer could be either silicon oxide (SiOx) ͑Refs. 13 and 14͒
or zirconium silicate (ZrSixOy) ͑Ref. 4͒ according to ZrO2
deposition studies using similar process conditions in the lit-
erature. In either case, the diffusion of excess oxygen
through ZrO2 is necessary for interfacial layer
formation.4,13,14 We reported in our previous study10 that
oxygen became excessive at O2 /Arу1 and its concentration
increased with increasing O2 /Ar, which could lead to the
formation of the observed interfacial layer. Moreover, taking
into account the physical thicknesses of the interfacial layer
and the ZrO2 layer measured by HRTEM, and ZrO2 dielec-
tric constant ranging from 20 to 25,3,15 we calculated a cor-
responding dielectric constant of the interfacial layer to be
5–7, which would explain the higher CInv /CAcc measure-
ments discussed above.
method.16 The decrease in Dit with increasing (O2 /Ar) is
also likely resulting from the formation of a superior inter-
face of either SiOx or ZrSixOy .3
Figure 2 shows that the dielectric constant of the depos-
ited ZrO2 increases from 13 at (O2 /Ar)ϭ0.5 to 16 at
(O2 /Ar)ϭ1, then decreases gradually to 14 at (O2 /Ar)ϭ4.
The lowest dielectric constant at (O2 /Ar)ϭ0.5 is related to
the highest hydrocarbon content in the film.17 We reported
earlier10 that a significant amount of hydrocarbon fragments
from ZTB ligands can be incorporated into the ZrO2 films
under oxygen-deficient conditions, and a linear correlation
was found between the x-ray photoelectron spectroscopy-
determined carbon composition in ZrO2 and the optical
emission spectroscopy ͑OES͒ intensity ratio of C2 ͑516.52
nm͒ to O ͑777.42 nm͒, which increases with decreasing
(O2 /Ar). The compositional depth profile by Auger electron
spectroscopy ͑AES͒ also showed the highest C/O atomic ra-
tio in the film at (O2 /Ar)ϭ0.5.
Figure 2 also shows the flatband ͑FB͒ voltage shifts,
⌬VFB (ϭVFBϪMS), where VFB is the flatband voltage and
is the Al–Si work-function difference. It is noteworthy
MS
that ⌬VFB scales linearly with increasing (O2 /Ar) at
O2 /Arу1. However, the thicker film deposited at (O2 /Ar)
ϭ0.5 shows a significant deviation (Ϫ520 mV). This indi-
cates that the film deposited at (O2 /Ar)ϭ0.5 is abundant in
positive oxide-trapped charge (Qox) and fixed charge (Qf),
but the net charge decreases and eventually becomes nega-
tive as the (O2 /Ar) ratios increase. The density of fixed
charges, Qf /q, at (O2 /Ar)ϭ2 is estimated to be at most
2.1ϫ1011 cmϪ2, assuming the ⌬VFB contributed solely by
Qf .
The inset in Fig. 3 shows the leakage current density (J)
versus bias voltage (Vb) characteristics from the PECVD
films at different (O2 /Ar) ratios. The leakage current density
at positive gate bias distinctly decreases with the increasing
(O2 /Ar) ratio. The log(J) showed a linear dependence on
V1b/2 at all O2 /Ar ratios, consistent with the Schottky emis-
sion mechanism,18 where the charge conduction is dominated
The slopes of the C–V curves gradually increase with
the increasing (O2 /Ar) ratio, indicating the decrease in the
interfacial trap density, Dit . We estimated the Dit to be
ϳ1012 cmϪ2 eVϪ1 for films deposited at (O2 /Ar)ϭ0.5 and
ϳ1011 cmϪ2 eVϪ1 those at (O2 /Ar)у1 by Terman’s
by the interface between ZrO2 and Si substrate. As indicated
