Synthesis, characterization, and reactivity of copper complexes supported by the TPMEN ligand framework

Article abstract of DOI:10.1016/j.ica.2017.09.041

Two new Cu(II) complexes supported by nitrogen-rich ligands have been synthesized and characterized by absorption spectroscopy, magnetic moment, and cyclic voltammetry. Complex 1 is supported by the ligand TPMEN (N,N,N′-tris(2-pyridylmethyl)-N′-methylethylenediamine) with two amine and three pyridyl nitrogen donors; while 2 is supported by the ligand TQMEN (N,N,N′-tris(2-quinolylmethyl)-N′-methylethylenediamine) where quinoline groups replace the pyridyl groups. Replacing the pyridyl moiety with quinoline has a marked effect on the Cu(II/I) reduction couple. The complexes are capable of reducing superoxide (O₂^[rad]?) to hydrogen peroxide (H₂O₂) in the presence of a proton donor. The reaction between potassium superoxide (KO₂) and the Cu-complexes was monitored via absorption spectroscopy, and further probed with electrospray ionization mass spectrometry (ESI-MS). Both 1 and 2 depicted evidence of ligand oxidation in mass-spectrometry.

Full text of DOI:10.1016/j.ica.2017.09.041

Accepted Manuscript
Research paper
Synthesis, Characterization, and Reactivity of Copper Complexes Supported by
the TPMEN Ligand Framework
Victoria G. Snider, Bruce J. Pella, Anusree Mukherjee
PII:
S0020-1693(17)31031-9
http://dx.doi.org/10.1016/j.ica.2017.09.041
ICA 17900
DOI:
Reference:
Inorganica Chimica Acta
To appear in:
Received Date:
Revised Date:
Accepted Date:
30 June 2017
15 September 2017
15 September 2017
Please cite this article as: V.G. Snider, B.J. Pella, A. Mukherjee, Synthesis, Characterization, and Reactivity of
Copper Complexes Supported by the TPMEN Ligand Framework, Inorganica Chimica Acta (2017), doi: http://
dx.doi.org/10.1016/j.ica.2017.09.041
This is a PDF file of an unedited manuscript that has been accepted for publication. As a service to our customers
we are providing this early version of the manuscript. The manuscript will undergo copyediting, typesetting, and
review of the resulting proof before it is published in its final form. Please note that during the production process
errors may be discovered which could affect the content, and all legal disclaimers that apply to the journal pertain.

Synthesis, Characterization, and Reactivity of
Copper Complexes Supported by the TPMEN
Ligand Framework
Victoria G. Snider, Bruce J. Pella, Anusree Mukherjee*,
Department of Chemistry, University of Alabama in Huntsville, 301 Sparkman Dr NW,
Huntsville, AL 35899
KEYWORDS: Copper coordination chemistry, oxidation reactions, complex characterization,
quinoline, pentadentate
ABSTRACT
Two new Cu(II) complexes supported by nitrogen-rich ligands have been synthesized,
and characterized by absorption spectroscopy, magnetic moment, and cyclic voltammetry.
Complex 1 is supported by the ligand TPMEN (N,N,N’-tris(2-pyridylmethyl)-N’-
methylethylenediamine) with two amine and three pyridyl nitrogen donors; while 2 is supported
by the ligand TQMEN (N,N,N’-tris(2-quinolylmethyl)-N’-methylethylenediamine) where
quinoline groups replace the pyridyl groups. Replacing the pyridyl moiety with quinoline has a
marked effect on the Cu(II/I) reduction couple. The complexes are capable of reducing
•-
superoxide (O2 ) to hydrogen peroxide (H2O2) in the presence of a proton donor. The reaction
between potassium superoxide (KO2) and the Cu-complexes was monitored via absorption
spectroscopy, and further probed with electrospray ionization mass spectrometry (ESI-MS). Both
1 and 2 depicted evidence of ligand oxidation in mass-spectrometry.
1

INTRODUCTION
Transition metal complexes supported by pentadentate polypyridyl ligands have been
widely studied in literature because of their diverse applications in synthetic and bioinorganic
chemistry.1-8 In particular, Cu-complexes supported by pentadentate N5 ligands have
applications in substrate oxidation,9 water oxidation catalysts,2,10,11 modeling enzyme activity,12
and cleavage of plasmid DNA.13 Very recently, a Cu-complex supported by the pentadentate N5
bztpen (N-benzyl-N,N’,N” –tris(pyridine-2ylmethyl)ethylenediamine) ligand was reported.10 The
ligand architecture played a crucial role in the complex reactivity as it was observed that
modifying bztpen with more benzyl moieties increased its oxygen-evolving capabilities.11
Another ligand of the N5 ligand family, the N4Py ligand (N,N-bis(2-pyridylmethyl)-N-bis(2-
pyridyl)methylamine) and its bulkier analogue in which two pyridine rings of the ligand were
replaced by quinoline groups (2PyN2Q) supported Cu-complexes showed a difference in
substrate binding modes and changes in reduction potential.14 Thus, it can be stated that ligand
electronics and bulk of the ligand have a strong effect on the properties of the supported metal
complex.4,14,15
Studying properties and reactivity of pentadentate mononuclear Cu(II)-complexes is
biologically relevant as it mimics the oxidized state of the active site of CuZnSOD. The CuZn
superoxide dismutase (CuZnSOD) enzyme is an excellent model system for Cu-O2 chemistry as
•-
the enzyme controls the dismutation of superoxide (O2 ) to hydrogen peroxide (H2O2) and
molecular oxygen (O2).16 Human SOD1 is a homodimeric protein with each subunit holding one
copper and one zinc binding site. In the reduced form, Cu(I) is ligated by His46, His48, and
His120 in a nearly trigonal planar geometry while the zinc is coordinated nearby with His63,
2

His71, His80, and Asp83. Upon oxidation to Cu(II), His63 bridges the Cu(II) ion to the zinc ion
while a water molecule also binds to the copper resulting in a five-coordinate copper with
distorted square pyramidal geometry.16 Several model complexes have been synthesized to
mimic the spectroscopic, structural, and catalytic properties of CuZnSOD. The dismutation
activity of these model complexes were correlated to the flexibility of the geometric
transformations at the copper center during the Cu(II)/Cu(I) redox process during catalysis.17-20
Structural models of the enzyme were synthesized with hetero and homo dinuclear
imidazolate-bridging complexes and they exhibited excellent SOD activity.20,21 In the enzyme,
CuZnSOD, the metal center that participates in red-ox processes is the Cu-center. As a result,
attempts were made to design functional mimics of the enzyme with mononuclear copper
complexes.17,22-25 However, in these functional mimics reactivity showed strong dependence on
coordination geometry around the metal center. The tetradentate complex [Cu(PuPy)](ClO4)2
with square planar geometry showed moderate SOD activity26, while the tetradentate complexes
[Cu(tpa)(H2O)](ClO4)2 and [Cu(tapa)Cl]ClO4 with trigonal bipyramidal geometry exhibited
relatively high SOD activity (Figure 1).23 The pentadentate complex [Cu(PMDT)(bipy)](ClO4)2
with distorted square pyramidal geometry has shown moderate SOD activity (Figure 1).25 While
there is a large body of work devoted to CuZnSOD mimics,17,22,23,27-31 the study of pentadentate
nitrogen-rich ligands as support for CuZnSOD models has not been thoroughly explored.
3

Figure 1. Structures of N-polydentate Cu-complexes that have shown SOD activity: (top
[Cu(PuPY)]2+ (PuPY =1,8-Bis(2-pyridyl)-2,7-diazaoctadiene-1,7),
left)
(top right)
[Cu(PMDT)(bipy)]2+ (PMDT = N,N,N’,N”,N”-pentamethyldiethylenetriamine, bipy = 2,2’-
bipyridine), (bottom left) [Cu(tpa)Cl]+ (tpa = tris(2-pyridylmethyl)amine), and (bottom left)
[Cu(tapa)Cl]+ (tapa = tris(6-amino-2-pyridylmethyl)amine).
This paper reports the synthesis and characterization of two novel Cu-complexes
supported by neutral N5 ligands, [Cu(TPMEN)(ClO4)2] and [Cu(TQMEN)(ClO4)2] (Figure 2). It
was noticed that substituting quinoline-N donors for pyridine-N donors affects the redox
potential of the ligated metal as noted in the literature.32 The reactivity of [Cu(TPMEN)(ClO4)2]
and [Cu(TQMEN)(ClO4)2], hereafter referred to as 1 and 2 respectively, were investigated
towards potassium superoxide at ambient temperatures.
4

Figure 2. Proposed structures of [Cu(TPMEN)(ClO4)2] (1) and [Cu(TQMEN)(ClO4)2] (2).
EXPERIMENTAL METHODS
Materials N,N,N’-tris(2-pyridylmethyl)-N’-methylethylenediamine (TPMEN) and N,N,N’-
tris(2-quinolylmethyl)-N’-methylethylenediamine (TQMEN) were synthesized according to
reported procedures.33,34 Caution! Although no problems were encountered in the preparation of
the perchlorate salts, care should be taken when handling such potentially hazardous compounds.
The reagents and the solvents used in this study, except for the ligands and complexes, were
commercially available and obtained in the highest available purity from Sigma-Aldrich and
1
Fisher Scientific. H NMR experiments were performed in deuterated solvents purchased from
Cambridge Isotope Laboratory on a Varian Inova-500 MHz instrument at 25 °C. UV-visible
experiments were performed on an Agilent Cary 8454 UV-visible spectrometer in a quartz
cuvette with a 1 cm pathlength. Electrochemical measurements were carried out on a BASi-C3
Epsilon electrochemical instrument using a glassy carbon working electrode, a platinum wire
auxiliary electrode, and Ag/AgCl reference electrode. All cyclic voltammetric experiments were
performed under nitrogen atmosphere using tetrabutyammonium hexafluorophosphate (TBF-6,
5

0.1M) as the supporting electrolyte. Electrospray ionization mass spectrometry (ESI-MS)
experiments were performed on a Thermo Scientific LTQ Orbitrap XL Hybrid FT Mass
Spectrometer in positive ionization mode. ESI-MS measured with an ion transfer tube
temperature of 240 °C and a flow rate of 5 µL. Solid state magnetic susceptibility measurements
were performed at room temperature using a MSB Evan’s balance (model number MK I #7967;
Johnson Matthey; Wayne, PA). The appropriate diamagnetic corrections were applied using
Pascal’s constants.35 Elemental analyses were performed by Atlantic Microlab, Inc (Norcross,
GA).
Synthesis of N,N,N’-tris(2-pyridylmethyl)-N’-methylethylenediamine (TPMEN)
2-Picolyl chloride hydrochloride (3.0 g, 18.3 mmol) was dissolved in 10 N NaOH (30 mL)
aqueous solution. To this solution, N-methylethylenediamine (0.45 mL, 5.2 mmol) was added
dropwise with stirring. After stirring for 3 days at room temperature, the upper oil layer was
decanted and dissolved in dichloromethane (30 mL). The dichloromethane solution was washed
with an excess of water (80 mL) and dried using anhydrous MgSO4. After evaporation of
dichloromethane, the crude sample was purified using a silica column (CHCl3:CH3OH 10:1
(v/v)). A light brown oil was obtained with a 50% yield (0.90 g, 2.6 mmol). NMR δ (500 MHz,
CDCl3) 8.51 (m, 3H, -Py), 7.62 (m, 3H, -Py), 7.52, 7.37 (m, 3H, -Py), 7.13 (m, 3H, -Py), 3.85 (s,
4H, -N(-CH2-Py)2), 3.48 (s, 2H, -N-CH2-Py), 2.77 (d, 4H, N-CH2CH2-N), 2.20 (s, 3H, -CH3).
Synthesis of N,N,N’-tris(2-quinolylmethyl)-N’-methylethylenediamine (TQMEN)
2-(chloromethyl) quinoline hydrochloride (3.0 g, 14.01 mmol) was dissolved in 10 N NaOH (30
mL) aqueous solution. To this solution, N-methylethylenediamine (0.347 mL, 3.98 mmol) was
6

added dropwise with stirring. After 3 days at room temperature, the upper oil layer was decanted
and dissolved in dichloromethane (30 mL). The dichloromethane solution was washed with an
excess of water (80 mL) and dried using anhydrous MgSO4. After evaporation of
dichloromethane, the crude sample was purified using a silica column (CH2Cl2:CH3OH 10:1
(v/v)). Light yellow oil of the ligand was obtained with 67% yield (1.3 g, 2.7 mmol). 1H NMR δ
(500 MHz, CDCl3) 8.09 (m, 3H, -Qn), 8.01 (m, 3H, -Qn), 7.86 (m, 3H, -Qn), 7.80 (m, 3H, -Qn),
7.65 (m, 3H, - Qn), 7.55 (m, 3H, -Qn), 5.65-5.36 (d, 4H, N-CH2CH2-N), 4.28 (s, 3H, -CH3), 3.48
(s, 4H, -N(-CH2-Qn)2), 3.40 (S, 2H, -N-CH2-Qn). 13C NMR (500 MHz. CDCl3) 158.68, 150.41,
147.45, 137.57, 136.76, 130.15, 129.67, 129.20, 128.96, 127.83, 127.70, 127.62, 127.22, 126.44,
125.03, 121.23, 65.56, 61.28, 57.84, 48.93. ESI-MS m/z for [TQMEN + H]+: 498.27 (calculated),
498.25 (experimental, [L+H]+).
Complex Syntheses
Both 1 and 2 were prepared by reaction of [Cu(ClO4)2]•6H2O with TPMEN or TQMEN,
respectively, in a 1:1 mole ratio in methanol. Solutions were stirred at room temperature for 30
min before the precipitate was filtered. The precipitates were washed with cold water (1 mL) and
diethyl ether (1 mL) before being dried in vacuo.
[Cu(TPMEN)(ClO4)2] (1) Mixing methanol solutions of TPMEN (0.256 g, 0.737 mmol) and
[Cu(ClO4)2]•6H2O (0.274 g, 0.740 mmol) yielded a royal blue solid (0.274 g, 0.450 mmol, yield:
61%). ESI-MS m/z for [Cu(TPMEN)(ClO4)]+: 509.09 (calculated), 509.17 (experimental).
Elemental analysis calculated for [Cu(TPMEN)(ClO4)2]•2H2O: C, 38.57; H, 3.92; N, 10.70; Cl,
11.49%. Found: C, 39.05; H, 4.35; N, 10.84; Cl, 10.98%. UV-vis (λ (nm) [ε (M-1cm-1)] in MeCN
at 25 °C: 682 (279), 907 (130).
7

[Cu(TQMEN)(ClO4)2] (2) Mixing methanol solutions of TQMEN (0.225 g, 0.452 mmol) and
[Cu(ClO4)2]•6H2O (0.107 g, 0.451 mmol) yielded a mint green solid (0.239 g, 0.316 mmol,
yield: 70%). ESI-MS m/z for [Cu(TQMEN)]2+: 280.25 (calculated), 279.67 (experimental).
Elemental analysis calculated for [Cu(TQMEN)(ClO4)2]•2H2O•HCl: C, 47.68; H, 4.05; N, 7.72;
Cl, 12.27%. Found: C, 47.61; H, 4.36; N, 8.41; Cl, 12.77%. UV-vis (λ (nm) [ε (M-1cm-1)] in
MeCN at 25 °C: 745 (206).
Potassium superoxide reactivity
A solution of 1 (2 mM) in a dry solution of acetone/DMF (4:1 v/v) was allowed to react with one
equivalent KO2. The stock solution of KO2 (50 mM) was prepared in the same solvent system
using equimolar amounts of 18-crown-6 to solubilize KO2. The reaction mixture was stirred at
25 °C for 3.5 hours. The procedure was the same for 2, except the reaction was allowed to stir for
6 hours.
Demetallation of reaction products
Demetallation studies were carried out as previously reported.36 The reaction mixture was treated
with NH4OH (5 ml) and passed through an alumina column. The alumina column was washed
with methanol (50 ml) followed by dichloromethane (80 ml). The combined filtrate was washed
with water (3 x 20 ml). The organic phase was dried over Na2SO4 and concentrated in vacuo.
Quantification of liberated hydrogen peroxide (H2O2)
Amount of hydrogen peroxide was determined by iodometry as follows. To a solution of 1 (2
mM) in a dry solution of acetone/DMF (4:1 v/v) two equivalents of HClO4 were added followed
8

by the addition of one equivalent KO2 at room temperature (18-crown-6 was used to solubilize
KO2). After completion of the reaction, another two equivalents of HClO4 was added to stabilize
the liberated hydrogen peroxide. Then 1 mL of this final reaction mixture was diluted to 10 mL
-
and was treated with excess NaI. The amount of I3 liberated was quantified using UV-visible
spectroscopy (λmax= 361 nm, ε = 2.5 x 104 M-1 cm-1). The procedure is the same for 2.
RESULTS AND DISCUSSION
Synthesis and Characterization
The synthesis of the N5 ligands was accomplished following the published procedure
known for respective ligands.33,34 The Cu-complexes, [Cu(TPMEN)(ClO4)2] (1) and
[Cu(TQMEN)(ClO4)2] (2), were synthesized by adding one equivalent Cu(ClO4)2 • 6H2O to the
respective ligands in methanol. This is the first report of these complexes in literature. The
complexes were characterized by various analytical and spectroscopic techniques. Both 1 and 2
were soluble in polar solvents such as acetonitrile and acetone, but sparingly soluble in nonpolar
solvents. The optical spectra for the Cu-complexes in acetonitrile and methanol are shown in
Figure 3, while the optical parameters along with molar absorptivity in methanol, acetone, and
acetonitrile are summarized in Table 1. Both complexes exhibited a low intensity band between
600-800 nm. Complex 1 exhibited a broad peak at 682 nm in acetonitrile along with a shoulder
in the 908 nm region. The peak of 1 appeared in a similar position in methanol and acetone
(Table 1). Complex 2 had a peak at 745 nm in acetonitrile, which was shifted to a higher
wavelength in methanol and acetone. The red shift in the peak position of 2 compared to 1 is
similar to other known Cu-complexes where pyridyl groups in the ligand were replaced by
quinoline groups.14,37 The optical spectral data of complex 1 and 2 matched well with other
9

reported Cu-complexes supported by N5 ligands with distorted trigonal bipyramidal geometry.
14,38
Figure 3. Optical data of 1 (Blue solid line) and 2 (Red solid line) in acetonitrile (left) and
methanol (right). Data were collected at room temperature using a cuvette with 1 cm pathlength.
Table 1: Optical and magnetic parameters of the Cu(II) complexes.
Optical Parameters
Magnetic Parameters
λ (nm), [ε (M-1cm-1)]
Compound
µeff (B.M.)
χA (emu mol-1)
Methanol Acetonitrile Acetone
668
(144),
910 sh
1.11 x 10-3
682 (278), 676 (384),
907 sh
1.84
1
2
900 sh
800
772 (189),
441 sh, 471 1.82
sh
(292),
440 sh,
472 sh
745 (206)
9.97 x 10-4
The magnetic susceptibility of both complexes was measured in an Evans Balance at
room temperature. Complex 1 has a magnetic moment of 1.84 B.M, and 2 has a magnetic
moment of 1.82 B.M. These values lie within the expected range for a Cu(II) complex,39 as well
10

as being similar in value to other pentadentate mononuclear Cu(II) complexes.40 Based on the
electronic spectra of related complexes and magnetic susceptibility measurements, it can be
concluded that 1 and 2 exist as mono-nuclear complexes with distorted trigonal bipyramidal
geometry.10,38
The cyclic voltammogram (CV) of 1 exhibited a quasi-reversible redox peak
corresponding to the Cu(II)/Cu(I) couple at E1/2 = – 0.13 V (versus Ag/AgCl, ∆E = 90mV,
Figure 4), near that of similar Cu(II) complexes supported by pyridine N-donor ligands.10,11 The
peak current increased proportionally to the square root of the scan rate, as it was varied from
100 mV/s to 500 mV/s suggesting a diffusion-limited single electron transfer reaction. The CV
of 2 had a more positive reduction potential than 1 with a cathodic peak at + 0.55 V and an
anodic peak at – 0.15 V (versus Ag/AgCl, Figure S1). This trend of a more positive reduction of
Cu(II) supported by quinoline ligands compared to pyridine ligands had been noted in
literature.14,32,38 This electrochemical trend is likely due to the relative base strength of the
quinoline N donors versus pyridine N donors.32,41
11

Figure 4. Cyclic voltammogram of 1 in DMF under N2 with 0.1 M TBF-6 as the supporting
electrolyte.
Analysis of Superoxide Reduction
The reduction potential of 1 and 2 lie within the window for superoxide
disproportionation (-0.18 V and +0.91 V).42 Both complexes were investigated for superoxide
reduction capabilities. When 1 and 2 were subjected to react with superoxide in the presence of a
proton source, production of hydrogen peroxide was quantified via sodium iodide (NaI) assays.
-
The reaction of NaI with hydrogen peroxide produces I3 , which has a λmax of 361 nm, and can be
monitored with UV-visible spectroscopy (see Figures S2 and S3). Perchloric acid acts to stabilize
the hydrogen peroxide, thus to insure a more accurate assay. Both 1 and 2 produce hydrogen
peroxide with moderate yield (40% and 41 %, respectively). In the absence of Cu, the percent
yield of hydrogen is negligible (0.03 %). Thus, the Cu-complexes are key facilitators in the
reduction of superoxide to hydrogen peroxide, which is not surprising as it is known that Cu(II)-
superoxide model complexes are nucleophilic in nature and tend to form more stable cupric-
hydroperoxo intermediate if proton source is available. Furthermore, this hydroperoxo
intermediate can undergo various decay pathways, but in the presence of a proton source like
perchloric acid it can be further protonated to produce hydrogen peroxide. The moderate yield of
hydrogen peroxide production, however, suggests possible side reactions are also occurring. In
order to understand what other possible decay pathway may impede the hydrogen peroxide yield,
UV-visible spectroscopy was used to monitor the reaction between the Cu-complexes and KO2
in absence of a proton source.
12

Monitoring reactivity with potassium superoxide using optical spectroscopy
The reaction between both 1 and KO2/HClO4 produced no color change (Figure S4), 2
behaved similarly. However, in the absence of perchloric acid, the reaction with one equivalent
KO2 in dry acetone/DMF produced a color change for both 1 and 2. Both complexes reacted
rapidly with KO2 as evidenced by a swift color change from royal blue to emerald green for 1
and green to yellow for 2 (Figure 5). Optical spectra of 1 in dry acetone/DMF (4:1 v/v) showed
two characteristic features, a broad band in 600-700 nm and an intense peak at 330 nm. Upon the
addition of one equivalent KO2 to 1, the peak at 330 nm exhibited an immediate increase in
intensity along with slight shift to 340 nm. The band in the 600-700 nm decayed simultaneously.
The peak at 340 nm lost its intensity over time (3.5 hours). Similarly, 2 showed a peak at 340 nm
in the acetone/DMF solvent mixture along with a broad band in 800 nm. Upon addition of KO2
the band at 800 nm decreased its intensity but the peak at 340 nm slightly increased in intensity
(Figure 5, right panel). Over time, the peak at 340 nm decayed to generate an optical spectrum
with a shoulder at 420 nm. The final solution of each reaction was analyzed with electrospray
ionization mass spectrometry (ESI-MS). Evidence for ligand oxidation was observed in the ESI-
MS spectrum for 1, a peak emerged at 424 m/z (Figures S5-S6). Simulation of the peak at m/z
424 indicated oxidation of the ligand in one of the benzylic position (Figure S6). Removing the
Cu from the product solution afforded brown oil. Analysis of this brown oil with ESI-MS
showed two peaks at m/z 348 and 362 corresponding to TPMEN and oxidized TPMEN,
respectively (Figures S7-S8). When the final solution of 2 and KO2 was analyzed, a new peak at
m/z 574 was detected. The isotope pattern of this peak also closely matched with the simulated
data (Figures S9-S10). ESI-MS analysis of the product solution after removing Cu revealed a
peak at m/z 512 attributed to oxidized TQMEN (Figures S11-S12).
13

Figure 5. Optical changes of 1 and 2 with 1 equiv. KO2 in acetone/DMF (4:1) at RT using 1 cm
pathlength. Left panel showed the reaction of 1 and right panel showed reaction of 2. In both
cases: black is the starting material, red trace is generated upon immediate addition of KO2, and
blue line reflect the final spectrum.
Scheme 1. Possible pathways for superoxide reaction with Cu-complexes
CONCLUSION
This is the first report of the synthesis and reactivity of mononuclear Cu(II) complexes
[Cu(TPMEN)(ClO4)2] and [Cu(TQMEN)(ClO4)2]. The complexes were characterized using
spectroscopic and analytical techniques. The electrochemistry of the Cu-complexes was in
accord with previously reported complexes. Both 1 and 2 demonstrated the ability to reduce
superoxide to hydrogen peroxide as confirmed by sodium iodide assays. The reduction yields
were moderate for both Cu-complexes. This led to the investigation of possible side reactions
14

between the Cu-complexes and KO2 via UV-visible spectroscopy and ESI-MS. The evidence of
ligand oxidation by mass-spectrometry suggested that the reaction of 1 and 2 with superoxide
have multiple pathways to progress. In the presence of a proton source, superoxide can bind to
the Cu-center and get further reduced to cupric hydroperoxo intermediate. The protic medium
facilitates production of hydrogen peroxide from this intermediate (Scheme 1, pathway B).
However, in the absence of proton the Cu(II)-superoxide intermediate might abstract a proton
from the ligand and generate reactive intermediates species that further oxidize the ligand
(Scheme 1, pathway A). Reactivity of Cu-superoxide species is very different, in some examples
Cu-superoxide showed abstraction of H-atom from ligand,43 but in other case cupric-
hydroperoxo (Cu-hydroperoxo) seems to be the stronger oxidant.44 In literature, the absorption
region of 325-465 nm was associated before with Cu-hydroperoxo complexes supported by
polypyridyl ligands.45-47 Thus, the peak seen in the spectrum of 1 and 2 upon addition of KO2 at
~340 nm could be indicative of a Cu-hydroperoxo intermediate that oxidizes the ligand.45,46 At
this stage, the mechanism for both pathways remain unclear. Pathway B could happen via Fenton
chemistry involving a hydroxyl radical, or some other metal-based oxidant. Clearly, further work
is warranted to determine the intermediate and establish mechanism of the reaction between
these Cu-complexes and KO2. Current research in the group focuses in that direction.
15

AUTHOR INFORMATION
Corresponding Author
*Email: anusree.mukherjee@uah.edu
Notes
The authors declare no competing financial interest
Funding Sources
This work was funded by University of Alabama in Huntsville (start-up support, NFR Award
and IIDR-award to A.M.). We thank Prof. Chris Goldsmith and Dr. Cheryl Colquhoun of Auburn
University for helping us collect magnetic susceptibility data on these complexes at their facility.
REFERENCES
(1)
donating pentadentate ligand PY4Im. Inorg. Chem. 2010, 49, 11223-11230.
(2) Coggins, M. K.; Zhang, M.-T.; Chen, Z.; Song, N.; Meyer, T. J. Single-Site
Smith, J. M.; Long, J. R. First-row transition metal complexes of the strongly
Copper(II) Water Oxidation Electrocatalysis: Rate Enhancements with HPO42- as a Proton
Acceptor at pH 8. Angew. Chem., Int. Ed. 2014, 53, 12226-12230.
(3)
Wang, D.; Ray, K.; Collins, M. J.; Farquhar, E. R.; Frisch, J. R.; Gomez, L.;
Jackson, T. A.; Kerscher, M.; Waleska, A.; Comba, P.; Costas, M.; Que, L. Nonheme
oxoiron(IV) complexes of pentadentate N5 ligands: spectroscopy, electrochemistry, and
oxidative reactivity. Chem. Sci. 2013, 4, 282-291.
(4)
Sankaralingam, M.; Balamurugan, M.; Palaniandavar, M.; Vadivelu, P.; Suresh,
C. H. Nickel(II) complexes of pentadentate N5 ligands as catalysts for alkane hydroxylation by
using m-CPBA as oxidant: A combined experimental and computational study. Chem. - Eur. J.
2014, 20, 11346-11361.
(5)
Tamura, M.; Urano, Y.; Kikuchi, K.; Higuchi, T.; Hirobe, M.; Nagano, T.
Superoxide dismutase activity of iron(II)TPEN complex and its derivatives. Chem. Pharm. Bull.
2000, 48, 1514-1518.
(6) Groni, S.; Dorlet, P.; Blain, G.; Bourcier, S.; Guillot, R.; Anxolabehere-Mallart,
E. Reactivity of an Aminopyridine [LMnII]2+ Complex with H2O2. Detection of Intermediates
at Low Temperature. Inorg. Chem. 2008, 47, 3166-3172.
16

(7)
Kenkel, I.; Franke, A.; Duerr, M.; Zahl, A.; Duecker-Benfer, C.; Langer, J.;
Filipovic, M. R.; Yu, M.; Puchta, R.; Fiedler, S. R.; Shores, M. P.; Goldsmith, C. R.; Ivanovic-
Burmazovic, I. Switching between Inner- and Outer-Sphere PCET Mechanisms of Small-
Molecule Activation: Superoxide Dismutation and Oxygen/Superoxide Reduction Reactivity
Deriving from the Same Manganese Complex. J. Am. Chem. Soc. 2017, 139, 1472-1484.
(8)
Lakk-Bogath, D.; Csonka, R.; Speier, G.; Reglier, M.; Simaan, A. J.; Naubron, J.-
V.; Giorgi, M.; Lazar, K.; Kaizer, J. Formation, Characterization, and Reactivity of a Nonheme
Oxoiron(IV) Complex Derived from the Chiral Pentadentate Ligand asN4Py. Inorg. Chem. 2016,
55, 10090-10093.
(9)
Shircliff, A. D.; Wilson, K. R.; Cannon-Smith, D. J.; Jones, D. G.; Zhang, Z.;
Chen, Z.; Yin, G.; Prior, T. J.; Hubin, T. J. Synthesis, structural studies, and oxidation catalysis
of the manganese(II), iron(II), and copper(II) complexes of a 2-pyridylmethyl pendant armed
side-bridged cyclam. Inorg. Chem. Commun. 2015, 59, 71-75.
(10) Zhang, P.; Wang, M.; Yang, Y.; Yao, T.; Sun, L. A Molecular Copper Catalyst
for Electrochemical Water Reduction with a Large Hydrogen-Generation Rate Constant in
Aqueous Solution. Angew. Chem., Int. Ed. 2014, 53, 13803-13807.
(11) Shen, J.; Wang, M.; Zhang, P.; Jiang, J.; Sun, L. Electrocatalytic water oxidation
by copper(II) complexes containing a tetra- or pentadentate amine-pyridine ligand. Chem.
Commun. (Cambridge, U. K.) 2017, 53, 4374-4377.
(12) Mirica, L. M.; Ottenwaelder, X.; Stack, T. D. P. Structure and Spectroscopy of
Copper-Dioxygen Complexes. Chem. Rev. (Washington, DC, U. S.) 2004, 104, 1013-1045.
(13) Ida, S.; Iwamaru, K.; Fujita, M.; Okamoto, Y.; Kudo, Y.; Kurosaki, H.; Otsuka,
M. L-Histidyl-glycyl-glycyl-L-histidine. Amino-acid structuring of the bleomycin-type
pentadentate metal-binding environment capable of efficient double-strand cleavage of plasmid
DNA. Bioorg. Chem. 2015, 62, 8-14.
(14) Lo, W. K. C.; McAdam, C. J.; Blackman, A. G.; Crowley, J. D.; McMorran, D. A.
The pentadentate ligands 2PyN2Q and N4Py, and their Cu(II) and Zn(II) complexes: A
synthetic, spectroscopic and crystallographic structural study. Inorg. Chim. Acta 2015, 426, 183-
194.
(15) Cho, K.-B.; Kim, E. J.; Seo, M. S.; Shaik, S.; Nam, W. Correlating DFT
Calculated Energy Barriers to Experiments in Nonheme Octahedral FeIVO Species. Chem. -
Eur. J. 2012, 18, 10444-10453, S10444/10441-S10444/10440.
(16) Sheng, Y.; Abreu, I. A.; Cabelli, D. E.; Maroney, M. J.; Miller, A.-F.; Teixeira,
M.; Valentine, J. S. Superoxide dismutases and superoxide reductases. Chem. Rev. (Washington,
DC, U. S.) 2014, 114, 3854-3918.
(17) Patel, M.; Gandhi, D.; Parmar, P. Antibacterial, nuclease, and SOD-mimic
behaviors of copper(II) complexes of norfloxacin and phenanthrolines. J. Coord. Chem. 2011,
64, 1276-1288.
(18) Weser, U.; Schubotz, L. M.; Lengfelder, E. Imidazole-bridged copper complexes
as copper-zinc (Cu2Zn2)-superoxide dismutase models. J. Mol. Catal. 1981, 13, 249-261.
(19) Tabbi, G.; Driessen, W. L.; Reedijk, J.; Bonomo, R. P.; Veldman, N.; Spek, A. L.
High Superoxide Dismutase Activity of a Novel, Intramolecularly Imidazolato-Bridged
Asymmetric Dicopper(II) Species. Design, Synthesis, Structure, and Magnetism of Copper(II)
Complexes with a Mixed Pyrazole-Imidazole Donor Set. Inorg. Chem. 1997, 36, 1168-1175.
17

(20) Ohtsu, H.; Shimazaki, Y.; Odani, A.; Yamauchi, O.; Mori, W.; Itoh, S.;
Fukuzumi, S. Synthesis and Characterization of Imidazolate-Bridged Dinuclear Complexes as
Active Site Models of Cu,Zn-SOD. J. Am. Chem. Soc. 2000, 122, 5733-5741.
(21) Patel, R. N.; Singh, N.; Shukla, K. K.; Gundla, V. L. N.; Chauhan, U. K.
Synthesis, spectra and biomimetic properties of copper(II)-copper(II) and copper(II)-zinc(II)
binuclear complexes with CuN5 chromophores. Spectrochim. Acta, Part A 2005, 61A, 2603-
2610.
(22) Siddiqi, Z. A.; Sharma, P. K.; Shahid, M.; Khalid, M.; Kumar, S. Synthesis,
spectral characterizations and biological studies of transition metal mixed ligand complexes: X-
ray crystal structures of [Cu(oda)(Bipy)(H2O)]·4H2O and [VO(oda)(Bipy)]·2H2O. J. Mol.
Struct. 2011, 994, 295-301.
(23) Jitsukawa, K.; Harata, M.; Arii, H.; Sakurai, H.; Masuda, H. SOD activities of the
copper complexes with tripodal poly pyridylamine ligands having a hydrogen bonding site.
Inorg. Chim. Acta 2001, 324, 108-116.
(24) Casanova, J.; Alzuet, G.; Borras, J.; Lattore, J.; Sanau, M.; Garcia-Granda, S.
Coordination behavior of sulfathiazole. Crystal structure of [Cu(sulfathiazole)(py)3Cl]
superoxide dismutase activity. J. Inorg. Biochem. 1995, 60, 219-230.
(25) Patel, R. N.; Singh, N.; Shukla, K. K.; Chauhan, U. K.; Niclos-Gutierrez, J.;
Castineiras, A. Magnetic, spectroscopic, structural and biological properties of mixed-ligand
complexes of copper(II) with N,N,N',N'',N''-pentamethyldiethylenetriamine and polypyridine
ligands. Inorg. Chim. Acta 2004, 357, 2469-2476.
(26) Lange, J.; Elias, H.; Paulus, H.; Mueller, J.; Weser, U. Copper(II) and Copper(I)
Complexes with an Open-Chain N4 Schiff Base Ligand Modeling CuZn Superoxide Dismutase:
Structural and Spectroscopic Characterization and Kinetics of Electron Transfer. Inorg. Chem.
2000, 39, 3342-3349.
(27) Yan, F.; Yan, G.; Lv, S.; Shen, N.; Mu, Y.; Chen, T.; Gong, P.; Xu, Y.; Lv, L.;
Liu, J.; Shen, J.; Luo, G. A novel 65-mer peptide imitates the synergism of superoxide dismutase
and glutathione peroxidase. Int. J. Biochem. Cell Biol. 2011, 43, 1802-1811.
(28) Zhou, Y.-H.; Sun, D.-L.; Tao, J.; Chen, L.-Q.; Huang, Y.-F.; Li, Y.-K.; Cheng, Y.
Synthesis, crystal structure, and SOD-like activity of two copper(II) complexes with
hydroxymethyl pendants. J. Coord. Chem. 2014, 67, 2393-2404.
(29) Suksrichavalit, T.; Prachayasittikul, S.; Nantasenamat, C.; Isarankura-Na-
Ayudhya, C.; Prachayasittikul, V. Copper complexes of pyridine derivatives with superoxide
scavenging and antimicrobial activities. Eur. J. Med. Chem. 2009, 44, 3259-3265.
(30) Siddiqi, Z. A.; Khalid, M.; Shahid, M.; Kumar, S.; Sharma, P. K.; Siddique, A.;
Anjuli. H-bonded supramolecular assembly via proton transfer: Isolation, X-ray crystallographic
characterization and SOD mimic activity of [Cu(dipic)2]2[PA-H]4·5H2O. J. Mol. Struct. 2013,
1033, 98-103.
(31) Deters, D.; Weser, U. The analogous reaction of diSchiff base coordinated copper
and Cu2Zn2 superoxide dismutase with nitric oxide. BioMetals 1995, 8, 25-29.
(32) Wei, N.; Murthy, N. N.; Karlin, K. D. Chemistry of Pentacoordinate [LCuII-Cl]+
Complexes with Quinolyl Containing Tripodal Tetradentate Ligands L. Inorg. Chem. 1994, 33,
6093-6100.
(33) Zhang, L.; Tang, H.; Tang, J.; Shen, Y.; Meng, L.; Radosz, M.; Arulsamy, N.
Pentadentate Copper Halide Complexes Have Higher Catalytic Activity in Atom Transfer
18

Radical Polymerization of Methyl Acrylate Than Hexadentate Complexes. Macromolecules
(Washington, DC, U. S.) 2009, 42, 4531-4538.
(34) Snider, V. G.; Farquhar, E. R.; Allen, M.; Abu-Spetani, A.; Mukherjee, A. Design
and reactivity of Ni-complexes using pentadentate neutral-polypyridyl ligands: Possible mimics
of NiSOD. J. Inorg. Biochem. 2017, 175, 110-117.
(35) Bain, G. A.; Berry, J. F. Diamagnetic corrections and Pascal's constants. J. Chem.
Educ. 2008, 85, 532-536.
(36) Chaloner, L.; Khomutovskaya, A.; Thomas, F.; Ottenwaelder, X. Supramolecular
control of monooxygenase reactivity in a copper(II) cryptate. Dalton Trans. 2016, 45, 11109-
11119.
(37) Singh, N.; Niklas, J.; Poluektov, O.; Van Heuvelen, K. M.; Mukherjee, A.
Mononuclear Nickel (II) and Copper (II) Coordination Complexes Supported by Bispicen
Ligand Derivatives: Experimental and Computational Studies. Inorganica Chimica Acta 2017,
455, 221-230.
(38) McLachlan, G. A.; Fallon, G. D.; Martin, R. L.; Spiccia, L. Synthesis, Structure
and Properties of Five-Coordinate Copper(II) Complexes of Pentadentate Ligands with Pyridyl
Pendant Arms. Inorg. Chem. 1995, 34, 254-261.
(39) Kato, M.; Jonassen, H. B.; Fanning, J. C. Copper(II) complexes with subnormal
magnetic moments. Chem. Rev. 1964, 64, 99-128.
(40) Morin, T. J.; Bennett, B.; Lindeman, S. V.; Gardinier, J. R. First-Row Transition-
Metal Complexes of a New Pentadentate Ligand, α,α,α',α'-Tetra(pyrazolyl)lutidine. Inorg. Chem.
2008, 47, 7468-7470.
(41) Nelson, S. M.; Shepherd, T. M. Metal-to-ligand π-bonding in some nickel(II)
pseudo-halide complexes with heterocyclic aromatic amines. Inorg. Chem. 1965, 4, 813-817.
(42) Rao, P. S.; Hayon, E. Redox potentials of free radicals. IV. Superoxide and
hydroperoxy radicals . O2- and . HO2. J. Phys. Chem. 1975, 79, 397-402.
(43) Pirovano, P.; Magherusan, A. M.; McGlynn, C.; Ure, A.; Lynes, A.; McDonald,
A. R. Nucleophilic Reactivity of a Copper(II)-Superoxide Complex. Angew. Chem., Int. Ed.
2014, 53, 5946-5950.
(44) Tano, T.; Okubo, Y.; Kunishita, A.; Kubo, M.; Sugimoto, H.; Fujieda, N.; Ogura,
T.; Itoh, S. Redox Properties of a Mononuclear Copper(II)-Superoxide Complex. Inorg. Chem.
2013, 52, 10431-10437.
(45) Maiti, D.; Lucas, H. R.; Narducci Sarjeant, A. A.; Karlin, K. D. Aryl
Hydroxylation from a Mononuclear Copper-Hydroperoxo Species. J. Am. Chem. Soc. 2007, 129,
6998-6999.
(46) Maiti, D.; Narducci Sarjeant, A. A.; Karlin, K. D. Copper(II)-Hydroperoxo
Complex Induced Oxidative N-Dealkylation Chemistry. J. Am. Chem. Soc. 2007, 129, 6720-
6721.
(47) Elwell, C. E.; Gagnon, N. L.; Neisen, B. D.; Dhar, D.; Spaeth, A. D.; Yee, G. M.;
Tolman, W. B. Copper-Oxygen Complexes Revisited: Structures, Spectroscopy, and Reactivity.
Chem. Rev. (Washington, DC, U. S.) 2017, 117, 2059-2107.
19

Highlight:
•
Nitrogen-rich, pentadentate Cu(II) complexes were synthesized and characterized by absorption
spectroscopy, cyclic voltammetry, and magnetic moment.
•
•
Reactivity with potassium superoxide (KO2) was monitored with UV-Visible spectroscopy.
The Cu complexes were capable of reducing superoxide to hydrogen peroxide in the presence of
a proton donor.
20

21
