Sequential Paired Electrosynthesis of a Diaryl Ether Derivative
Using an Electrochemical Microreactor
Tsuneo Kashiwagi,1 Toshio Fuchigami,1 Tsuyoshi Saito,3 Shigeru Nishiyama,2 and Mahito Atobe*1,4
1Department of Electronic Chemistry, Tokyo Institute of Technology,
4259 Nagatsuta-cho, Midori-ku, Yokohama, Kanagawa 226-8502
2Department of Chemistry, Faculty of Science Technology, Keio University,
3-14-1 Hiyoshi, Kohoku-ku, Yokohama, Kanagawa 223-8522
3International Institute for Integrative Sleep Medicine, Tsukuba University, Tennodai, Tsukuba, Ibaraki 305-8557
4Department of Environment and System Sciences, Yokohama National University,
79-7 Tokiwadai, Hodogaya-ku, Yokohama, Kanagawa 240-8501
(E-mail: atobe@ynu.ac.jp)
A paired electrosynthetic conversion of a phenol to a diaryl
ether derivative by using an electrochemical microreactor has
been demonstrated. Sequential anodic C-O coupling reaction of
phenol 1 to dienone aryl ether 2 and following reduction of 2
took place to give diaryl ether derivative 3 selectively by simply
passing an electrolytic solution through the electrochemical
microreactor.
sequence could be performed in a manner of paired electrolysis,
the process could become more sustainable. With this consid-
eration in mind, herein we wish to demonstrate a paired
electrosynthesis of diaryl ether.
To meet this challenge, an efficient sequential oxidation of
phenol and the following reduction must be achieved in one
electrolytic cell. However, in general, efficient sequential
oxidation (or reduction) and the following reduction (or
oxidation) of a single starting material has been difficult7
because the distance between the anode and cathode is
centimeter order when the reaction is carried out in a conven-
tional batch-type reactor. In other words, electrochemically
generated intermediates need specific time to diffuse from
the electrode surface to the counter electrode surface, so that
complete conversion of the intermediates is difficult with the
theoretically required amount of electricity. This reduces the
efficiency of the electrolysis as well as utility of the synthetic
process.
In order to solve this problem, an electrochemical micro-
reactor8 was employed in this study. The short distance between
the electrodes in the microreactor enable fast molecular diffusion
from anode to cathode, offering ideal circumstances for the
desired paired electrolysis (Figure 1).
At first, the effect of anode material on the desired reaction
was examined because the total yield (yield of 2 + 3) depends
on the anodic oxidation step. On the other hand, a Zn plate was
commonly employed as a cathode material in the reduction of
2 avoiding hydrogen evolution. According to the linear sweep
voltammograms, both graphite and glassy carbon electrodes
show clear anodic peaks. In contrast, an anodic peak was not
observed in this potential region when Pt electrode was used
although the current was greater than that recorded by other
electrode materials (Figure 2). Subsequently, preparative elec-
Diaryl ethers are important structural motifs that form the
central building block in a large number of naturally occurring
compounds and pharmaceutical agents. For instance, com-
brestatin,1 aspercyclide,2 and vancomycin3 contain a diaryl
ether moiety and show interesting biological activities. The
Williamson ether synthesis is the most classical and reliable
method to construct ethers. However, diaryl ethers cannot be
synthesized by just mixing a metal phenoxide and aryl halide.
Therefore, transition-metal-catalyzed or -mediated reaction4
between phenol and aryl halide has been the most widely used
method. On the other hand, synthetic methods without need for
metal reagents, especially oxidative C-O coupling, have been
reported recently.3
One of the authors (S. Nishiyama) has developed elec-
trochemical construction of diaryl ethers and applied this
protocol to total synthesis of natural products.5 In this reaction,
anodic one electron oxidation of phenol takes place to give
a dimeric product (dienone aryl ether) and then, reduction of
dienone aryl ether with zinc yields desired diaryl ether
derivatives. If natural products containing a diaryl ether structure
become a lead compound in drug discovery, the use of oxidants
difficult to handle on a large reaction scale or expensive
transition-metal reagents should be avoided. In contrast, since
electrochemical reaction is driven by electric potential, it has
cost advantages over other methods and the reaction is easily
controlled by switching the electrical power supply on and off.
In this regard, electrochemical methods would be ideal for diaryl
ether synthesis.
cathode
+2e, +H+
-CH3O-
O
O
O
flow
O
O
O
O
methanol
solution
Cl
O
In electrochemical reactions, the working electrodes have
received much attention because the desired reaction takes place
on its surface. In contrast, the reaction taking place on the
counter electrode has often been neglected. On the other hand,
electrolytic systems that utilize both the reactions at the anode
and cathode are known as “paired electrolysis.”6 If the reduction
of dienone aryl ether with zinc in the diaryl ether synthesis
could be altered by cathodic reduction, and the entire reaction
Cl
O
O
Cl
O
2
Cl
Cl
O
-2e, -2H+
-Cl-,
+CH3O-
Cl
O
OH
Cl
OH
O
Cl
anode
Figure 1. Schematic representation of electrochemical con-
version of dichlorophenol to diaryl ether in methanol solution
using an electrochemical microreactor.
Chem. Lett. 2014, 43, 799–801 | doi:10.1246/cl.140046
© 2014 The Chemical Society of Japan | 799
