Allosteric Effects in Polynuclear Triple-Stranded Ferric
Complexes
Sylvie Blanc,† Pnina Yakirevitch,‡ Emmanuelle Leize,§ Michel Meyer,
Jacqueline Libman,‡,| Alain Van Dorsselaer,§ Anne-Marie Albrecht-Gary,† and
Abraham Shanzer*,‡
Contribution from the Laboratoire de Physico-Chimie Bioinorganique, CNRS URA 405, ECPM,
1 rue Blaise Pascal, 67000 Strasbourg, France, Department of Organic Chemistry,
Weizmann Institute of Science, RehoVot 76100, Israe¨l, and Laboratoire de Spectrome´trie de
Masse Bio-Organique, CNRS URA 31, Faculte´ de Chimie, 1 rue Blaise Pascal,
67000 Strasbourg, France
ReceiVed July 17, 1996. ReVised Manuscript ReceiVed December 5, 1996X
Abstract: The synthesis and iron(III) coordination properties of three tripodal ligands (L1, L2, and L3) possessing
hydroxamate coordination cavities are examined by various methods (ESMS, UV-vis, CD). The ligands rely on a
trisamine as anchor, which is extended by an alternating sequence of variable spacers and hydroxamates as ion
binding groups. This modular strategy of design is adopted for the compounds’ preparation and enables modifications
of each structural element independently. The coordination properties of these iron binding molecules and particularly
the presence of allosteric effects are examined by classical spectrophotometric titrations in combination with
electrospray mass spectrometric measurements (ESMS). A good match between these two methods is observed, as
both indicate the formation of three species in thermodynamic equilibrium: mononuclear, binuclear, and trinuclear
ferric complexes. The respective stability constants are determined at p[H] ) 6.5 ( 0.1 in methanol, and the
corresponding distribution curves clearly illustrate the variations from ligand to ligand. These findings demonstrate
that subtle structural changes have a pronounced effect on these compounds’ coordination properties. Moreover,
among the binders studied representatives of opposite cooperative behavior is identified. The observed dependence
of the ligands’ coordination properties on their structural features are rationalized.
Introduction
helicates are much more abundant. Ru¨ttimann et al.8 reported
a dinuclear helicoidal complex with copper(I) and benzimida-
zole-pyridine. Lehn and co-workers synthesized double-
stranded (oligobipyridine)silver(I)9 and -copper(I)10 helicates
including up to five copper(I) ions.11-13 Dietrich-Buchecker
and Sauvage14 used a double helicoidal copper(I) complex with
two oligophenanthroline ligands as a precursor for the synthesis
of the first molecular knots. Potts et al.15 studied the occurrence
of interactions in double-stranded dicuprous helicates derived
from terpyridines. A stable trinuclear double helicoidal copper-
(II) complex of quinquepyridine was structurally characterized.16
Constable et al.17-20 used the oligobipyridine motif to form
homobinuclear helicoidal complexes with second- and third-
Allostery and cooperativity are interrelated phenomena that
play a major role in biological systems.1-3 They regulate the
activity of enzymes and the recognition properties of receptors,4
and occur when occupation of a given binding site changes the
complexation characteristics of the other binding site either by
improving or by reducing its binding efficiency.5 It occurred
to us that triple-stranded ligands could serve as ideal models
for the study of allosteric properties in helicoidal complexes
since they may be designed to possess distinct coordination sites
at predetermined positions.
A large variety of helicates have been described that differ
in their topology, the number of their ligands and of their guest
ions, and the nature of the metals and their properties. When
homopolynuclear helicates are classified according to the
number of ligands that are wrapped around the metal centers,
the first example consists of a single-stranded helicoidal complex
that possesses two ruthenium(II) ions.6,7 Double-stranded
(6) Thummel, R. P.; Herry, C.; Williamson, D.; Lefoulon, F. J. Am.
Chem. Soc. 1988, 110, 7894-7896.
(7) Cathey, L. J.; Constable, E. C.; Hannon, M. J.; Tocher, D. A.; Ward,
M. D. J. Chem. Soc., Chem. Commun. 1990, 621-622.
(8) Ru¨ttiman, S.; Piguet, C.; Bernardinelli, G.; Bocquet, B.; Williams,
A. F. J. Am. Chem. Soc. 1992, 114, 4230-4237.
(9) Garrett, T. M.; Koert, U.; Lehn, J. M. J. Phys. Org. Chem. 1992, 5,
529-532.
* To whom correspondence should be addressed.
(10) Pfeil, A.; Lehn, J. M. J. Chem. Soc., Chem. Commun. 1992, 838-
839.
† CNRS URA 405.
‡ Weizmann Institute of Science.
(11) Lehn, J. M.; Rigault, A.; Siegel, J.; Harrowfield, J.; Chevrier, B.;
Moras, D. Proc. Natl. Acad. Sci. U.S.A. 1987, 84, 2565-2569.
(12) Zarges, W.; Hall, J.; Lehn, J. M.; Bolm, C. HelV. Chim. Acta 1991,
74, 1843-1851.
§ CNRS URA 31.
Present address: Department of Chemistry, University of California,
Berkeley.
| Deceased March 1997.
(13) Schoentjes, B.; Lehn, J. M. HelV. Chim. Acta 1995, 78, 1-12.
(14) Dietrich-Buchecker, C. O.; Sauvage, J. P. Angew. Chem., Int. Ed.
Engl. 1989, 28, 189-192.
X Abstract published in AdVance ACS Abstracts, April 15, 1997.
(1) Lehn, J. M. Supramolecular Chemistry: Concepts and PerspectiVes;
VCH: Weinheim, 1995.
(15) Potts, K. T.; Keshavarz-K, M.; Tham, F. S.; Abrun˜a, H. D.; Arana,
C. R. Inorg. Chem. 1993, 32, 4450-4456.
(2) Koshland, D. E.; Neet, K. E. Annu. ReV. Biochem. 1968, 37, 359-
410.
(16) Baker, A. T.; Graig, D. C.; Dong, G. Inorg. Chem. 1996, 35, 1091-
1092.
(3) Hammes, G. G.; Wu, C. W. Annu. ReV. Biophys. Bioeng. 1974, 3,
1-33.
(17) Constable, E. C.; Ward, M. D. J. Am. Chem. Soc. 1990, 112, 1256-
1258.
(18) Constable, E. C.; Ward, M. D.; Tocher, D. A. J. Chem. Soc., Dalton
Trans. 1991, 1675-1683.
(4) Monod, J.; Changeux, J. P.; Jacob, F. J. Mol. Biol. 1963, 6, 306-
329.
(5) Perlmutter-Hayman, B. Acc. Chem. Res. 1986, 19, 90-96.
S0002-7863(96)02472-9 CCC: $14.00 © 1997 American Chemical Society

Allosteric Effects in Triple-Stranded Ferric Complexes
J. Am. Chem. Soc., Vol. 119, No. 21, 1997 4935
row transition metal elements (Cu(II), Fe(II), Pd(II), Ru(II),
Cd(II), Ni(II), Mn(II)). Recently, a synthetic analog of a
biscatecholate siderophore produced by the nitrogen-fixing
bacterium Azotobacter Vinelandii was shown to form a double
helical dioxomolybdenum(VI) complex.21 The diferric complex
formed at neutral pH with rhodotorulic acid, a ketopiperazine
bridged dihydroxamic siderophore, was the first characterized
triple helicate.22,23 The propeller-like arrangement of bidentate
chelating subunits in an octahedral environment has inspired
the design of various self-assembling systems forming triple
helicates. Several rhodotorulic acid mimics have been synthe-
sized by using 1,2-hydroxypyridinone,24 catechol,25,26 or tere-
phthalamide27 binding groups which favor hard metal cations
like iron(III) or gallium(III). Examples of multifunctional
strands incorporating soft donor atoms have also been
reported.28-33 This approach has been extended to ions of higher
coordination numbers (i.e., 9) and tridentate chelating subunits
by Piguet et al.,34-37 who synthesized a rich variety of
trihelicates with the aim to develop stable luminescent lanthanide
complexes that could serve as light converters.
The helicoidal systems described above illustrate the rich
variety of these structures and their possible applications for
the generation of functional, supramolecular assemblies, mostly
generated from single-stranded, symmetric ligands. However,
attachment of ligands to a tripodal anchor opens the possibility
to predetermine the coordinating binding cavities and to
drastically reduce the number of possible complexed species,
particularly when using nonsymmetric ligands. This approach
is synthetically more demanding, because it necessitates covalent
linkage of the ligating chains to a common anchor. Yet, the
use of tripodal, asymmetric ligands enables full physicochemical
characterization of these ligands’ coordination properties,
particularly the unambiguous characterization of each of the
ligands’ ion binding cavity, the preparation of site-directed,
heteronuclear complexes, and the generation of assemblies with
anisotropic properties. Motivated by these considerations, we
initiated a program aimed at the synthesis of chiral, triple-
Figure 1. Chemical formulas of the tripodal hydroxamate ligands: (a)
L1, m ) 0, R2 ) H; (b) L2, m ) 1, R1 ) i-Bu, R2 ) H; L3, m ) 1, R1
) i-Bu, R2 ) CONEt2.
stranded metal complexes and prepared the first homonuclear
representative back in 1987,38 and the related heteronuclear
derivatives thereafter.39
We describe here the synthesis, structural characteristics, and
coordination properties of a family of three triple-stranded,
polytopic ligands (Figure 1). These binders all possess hy-
droxamate binding cavities and bridges of the same length
between the coordination sites (Figure 1), yet they differ in the
spacers between the anchor and the closer hydroxamate group
(m ) 0 in L1, m ) 1 in L2 and L3) and in the substituents
attached to the spacers between the two hydroxamate functions
(R2 ) H in L1 and L2, R2 ) CONEt2 in L3). The consequences
of these subtle structural changes on the binders’ coordination
properties and particularly the presence of allosteric effects are
examined, by applying classical spectrophotometric titrations
in combination with electrospray mass spectrometric measure-
ments (ESMS).40-55 The combination of these two comple-
