was removed under vacuum; this step was performed twice. Purification
of the residue was performed by distillation (60 °C, 50 mbar), yielding a
colorless oil (2.3 g, 14.3 mmol, 39 %) corresponding at the desired
product which contains a trace amount of C–TMS. 1H NMR (400 MHz,
CDCl3): δ 3.73 (q, J = 7.1 Hz, 2H), 3.18 (d, J = 2.7 Hz, 1H), 3.04 (d, J =
2.6 Hz, 1 H), 1.28 (t, J = 7.1 Hz, 3 H), 0.21 (s, 9 H) ppm. 13C NMR (100
MHz, CDCl3): δ 160.9, 63.3, 60.1, 14.2, 0.0 (3C) ppm. These data are in
accordance with that previously described.[43]
stirred at room temperature for an additional 16 h, the mixture was
treated with HCl 1M (20 mL) and MeOH (10 mL), an extraction of the
aqueous phase was performed with Diethylether (50 mL). The organic
layer was washed with an ammonia solution (3x30 mL) and brine (1x30
mL), the solvent was removed under vacuum and the crude was
analyzed by 1H NMR (conversion: 80 %). Characteristic peaks:
Benzaldehyde: 1H NMR (400 MHz, CDCl3): δ 9.92 (s, 1 H) ppm. Product
B: 1H NMR (400 MHz, CDCl3): δ 6.15 (ddd, J = 9.6, 2.4 and 1.2 Hz, 1H),
Dienolate synthesis: N,N-Diisopropylamine (DIPA) (6.2 mL, 44.2 mmol,
1.20 equiv) and freshly distilled THF (70 mL) were added to a flame-dried
flask at 0 °C. Then, n-BuLi (27.6 mL, 44.2 mmol, 1.20 equiv, 1.6 M in
Et2O) was added dropwise over a period of 30 min. The pale yellow
solution obtained was stirred for an additional 15 min and then cooled at
−78 °C. Freshly distilled 1,3-dimethyl-3,4,5,6-tetrahydro-2(1H)-
pyrimidinone (DMPU) (6.0 mL, 44.2 mmol, 1.20 equiv) was added
dropwise to the reaction mixture, giving rise to a milky solution. After 30
min, freshly distilled ester was added (4.6 mL, 36.8 mmol, 1.00 equiv),
and the color turned yellow. The resulting mixture was stirred at the same
temperature for another hour. Thus, freshly distilled chlorotrimethylsilane
(TMSCl) (5.5 mL, 58.9 mmol, 1.60 equiv) was added dropwise over a
period of 10 min. The milky solution obtained was stirred for 30 min at
−78 °C and then allowed to reach room temperature. The formation of a
white suspension in an orange solution was observed. The suspension
was filtered through oven dried anhydrous Na2SO4, and the solvent was
removed under reduced pressure. The crude product obtained was
diluted with pentane (150 mL), filtered off, and the solvent was removed
under vacuum; this step was performed twice. The crude product so
obtained was diluted with pentane and washed with a saturated aqueous
solution of NaHCO3 and brine. The organic layer was dried over
anhydrous Na2SO4, and the solvent was removed under reduced
pressure. Purification of the residue was performed by distillation (100 °C,
0.7 mbar), yielding a colorless oil (5.7 g, 30.5 mmol, 83%) corresponding
to a mixture of the two inseparable Z/E isomers with a ratio of 8:2 in favor
of the Z isomer (1H NMR determination). Z isomer: 1H NMR (400 MHz,
CDCl3): δ 6.46−6.58 (m, J = 10.4 and 17.2 Hz, 1H), 4.80 (dd, J = 1.8 and
17.2 Hz, 1H), 4.58 (dd, J = 1.8 and 10.4 Hz, 1H), 4.43 (d, J = 10.4 Hz,
1H), 3.78 (q, J = 7.0 Hz, 2H), 1.28 (t, J = 7.0 Hz, 3H), 0.21 (s, 9H) ppm.
13C NMR (100 MHz, CDCl3): δ 157.6, 132.5, 106.4, 80.8, 63.3, 14.3, 0.3,
ppm. E isomer: 1H NMR (400 MHz, CDCl3) δ 6.46−6.58 (m, J = 10.4 and
17.2 Hz, 1H), 4.80 (dd, J = 1.8 and 17.2 Hz, 1H), 4.58 (dd, J = 1.8 and
10.4 Hz, 1H), 4.51 (d, J = 10.4 Hz, 1H), 3.89 (q, J = 7.0 Hz, 2H), 1.22 (t, J
= 7.0 Hz, 3H), 0.24 (s, 9H) ppm.13C NMR (100 MHz, CDCl3) δ 154.6,
132.1, 107.3, 88.4, 62.8, 14.8, −0.2 ppm. These data are in accordance
with that previously described.[23]
1
5.46 (dd, J = 11.0 and 4.9 Hz, 1H) ppm. Product C: H NMR (400 MHz,
CDCl3): δ 5.81 (dt, J = 15.7 and 1.6 Hz, 1H), 4.72 (dd, J = 7.7 and 5.2 Hz,
1H) ppm. These data are in accordance with that previously described.[38]
Competition between enolate and dienolate with benzaldehyde:
CuCl (74 mg, 0.74 mmol, 1.0 equiv.) and MeONa (40 mg, 0.74 mmol, 1.0
equiv.) were added in a flame dried round bottom flask, dissolved in
freshly distilled THF (60 mL), and stirred at 50 °C for 2 h. The light brown
suspension obtained was cooled at room temperature and cannulated in
a separately flame dried round bottom flask containing BINAP (463 mg,
0.74 mmol, 1.0 equiv.), 2x5 mL of freshly distilled THF were used to
rinsed the flask. After being stirred for 1 h at room temperature, freshly
distilled benzaldehyde (76 µL, 0.74 mmol, 1.0 equiv) was added, followed
by a freshly prepared mix of dienolate and enolate (1:1 (verified by 1H
NMR), 305 µL, 0.74 mmol of each, 1.0 equiv. of each). After being stirred
at room temperature for an additional 16 h, the mixture was treated with
HCl 1M (20 mL) and MeOH (10 mL), an extraction of the aqueous phase
was performed with Diethylether (50 mL). The organic layer was washed
with an ammonia solution (3x30 mL) and brine (1x30 mL), the solvent
was removed under vacuum and the crude was analyzed by 1H NMR
(conversion: 77 %). Characteristic peaks: Benzaldehyde: 1H NMR (400
MHz, CDCl3): δ 9.92 (s, 1 H) ppm. Product A: 1H NMR (400 MHz,
CDCl3): δ 5.02 (dd, J = 8.8 and 4.2 Hz, 1H) ppm. Product B: 1H NMR
(400 MHz, CDCl3): δ 6.15 (ddd, J = 9.6, 2.4 and 1.2 Hz, 1H), 5.46 (dd, J
= 11.0 and 4.9 Hz, 1H) ppm. Product C: 1H NMR (400 MHz, CDCl3): δ
5.81 (dt, J = 15.7 and 1.6 Hz, 1H), 4.72 (dd, J = 7.7 and 5.2 Hz, 1H) ppm.
These data are in accordance with that previously described.[38, 44]
Reaction with CuCl:
CuCl (74 mg, 0.74 mmol, 1.0 equiv.) and BINAP (463 mg, 0.74 mmol, 1.0
equiv.) were added in a flame dried round bottom flask, dissolved in
freshly distilled THF (60 mL). After being stirred for 2 h at room
temperature, freshly distilled benzaldehyde (76 µL, 0.74 mmol, 1.0 equiv)
was added, followed by freshly distilled dienolate (160 µL, 0.74 mmol, 1.0
equiv). After being stirred at room temperature for an additional 16 h, the
mixture was treated with HCl 1M (20 mL) and MeOH (10 mL), an
extraction of the aqueous phase was performed with Diethylether (50
mL). The organic layer was washed with an ammonia solution (3x30 mL)
and brine (1x30 mL), the solvent was removed under vacuum and the
crude was analyzed by 1H NMR (conversion: 0 %).
Reaction without ligand: CuCl (74 mg, 0.74 mmol, 1.0 equiv.) and
MeONa (40 mg, 0.74 mmol, 1.0 equiv.) were added in a flame dried
round bottom flask, dissolved in freshly distilled THF (60 mL). After being
stirred for 2 h at room temperature, freshly distilled benzaldehyde (76 µL,
0.74 mmol, 1.0 equiv) was added, followed by freshly distilled dienolate
(160 µL, 0.74 mmol, 1.0 equiv). After being stirred at room temperature
for an additional 16 h, the mixture was treated with HCl 1M (20 mL) and
MeOH (10 mL), an extraction of the aqueous phase was performed with
Diethylether (50 mL). The organic layer was washed with an ammonia
solution (3x30 mL) and brine (1x30 mL), the solvent was removed under
vacuum and the crude was analyzed by 1H NMR (conversion: 40 %).
Characteristic peaks: Benzaldehyde: 1H NMR (400 MHz, CDCl3): δ 9.92
(s, 1 H) ppm. Products D: Dia 1: 1H NMR (400 MHz, CDCl3): δ 5.90 (ddd,
J = 17.2, 10.3 and 8.5 Hz, 1H) ppm. Dia 2: 1H NMR (400 MHz, CDCl3): δ
5.62 (ddd, J = 17.2, 10.3 and 8.9 Hz, 1H) ppm. These data are in
accordance with that previously described.[38]
Reaction between enolate and benzaldehyde: CuCl (74 mg, 0.74
mmol, 1.0 equiv.) and MeONa (40 mg, 0.74 mmol, 1.0 equiv.) were
added in a flame dried round bottom flask, dissolved in freshly distilled
THF (60 mL), and stirred at 50 °C for 2 h. The light brown suspension
obtained was cooled at room temperature and cannulated in a separately
flame dried round bottom flask containing BINAP (463 mg, 0.74 mmol,
1.0 equiv.), 2x5 mL of freshly distilled THF were used to rinsed the flask.
After being stirred for
1 h at room temperature, freshly distilled
benzaldehyde (76 µL, 0.74 mmol, 1.0 equiv) was added, followed by
freshly distilled enolate (145 µL, 0.74 mmol, 1.0 equiv). After being stirred
at room temperature for an additional 16 h, the mixture was treated with
HCl 1M (20 mL) and MeOH (10 mL), an extraction of the aqueous phase
was performed with diethylether (50 mL). The organic layer was washed
with an ammonia solution (3x30 mL) and brine (1x30 mL), the solvent
was removed under vacuum and the crude was analyzed by 1H NMR
(conversion: 85 %). Characteristic peaks: Benzaldehyde: 1H NMR (400
MHz, CDCl3): δ 9.92 (s, 1 H) ppm. Product A: 1H NMR (400 MHz,
CDCl3): δ 5.02 (dd, J = 8.8 and 4.2 Hz, 1H) ppm. These data are in
accordance with that previously described.[44]
Reaction between dienolate and benzaldehyde: CuCl (74 mg, 0.74
mmol, 1.0 equiv.) and MeONa (40 mg, 0.74 mmol, 1.0 equiv.) were
added in a flame dried round bottom flask, dissolved in freshly distilled
THF (60 mL), and stirred at 50 °C for 2 h. The light brown suspension
obtained was cooled at room temperature and cannulated in a separately
flame dried round bottom flask containing BINAP (463 mg, 0.74 mmol,
1.0 equiv.), 2x5 mL of freshly distilled THF were used to rinsed the flask.
After being stirred for
1 h at room temperature, freshly distilled
benzaldehyde (76 µL, 0.74 mmol, 1.0 equiv) was added, followed by
freshly distilled dienolate (160 µL, 0.74 mmol, 1.0 equiv). After being
