The Candida rugosa lipase adsorbed onto titania as nano biocatalyst with improved
thermostability and reuse potential in aqueous and organic media
Author names and affiliations
Lidija T. Izrael Živkovića*, Ljiljana S. Živkovićb, Vladimir P. Beškoskic, Kristina R. Gopčevića,
Bojan M. Jokićd, Dragoslav S. Radosavljeviće, Ivanka M. Karadžića
a University of Belgrade, Faculty of Medicine, Institute of Chemistry in Medicine, Visegradska
26, 11000 Belgrade, Serbia;
b University of Belgrade, The Vinča Institute of Nuclear Sciences, 11000 Belgrade, Serbia;
c University of Belgrade, Faculty of Chemistry, Studentski trg 12-16, 11000 Belgrade, Serbia
d University of Belgrade, Faculty of Technology and Metallurgy, Karnegijeva 4, 11001 Belgrade,
Serbia
e University of Belgrade, Faculty of Medicine, Center for Communication and IT
Lidija Izrael Živković and Ljiljana Živković contributed equally to this article.
Corresponding author
Lidija Izrael Živković,
Phone+381-11-69-1898-007
Email: lidija.izrael-zivkovic@mfub.bg.ac.rs and lidijajob@yahoo.com
Abstract
The immobilization of Candida rugosa lipase by adsorption was performed onto commercial
titania powder (Degussa P25). The change of titania particles surface was diagnosed by means of
FTIR and FESEM analysis, as well as by shift of zeta potential value towards that of lipase. A
detailed study of the effect of immobilization on enzyme kinetic, temperature stability, as well as
on potential for its reuse in aqueous organic media was undertaken. Immobilization of lipase
altered enzyme affinity toward substrates with different length of carbon chain in hydrolytic
reaction. The Vmax value decreased 2-8-fold, where major constraint was registered for the ester
containing the longest carbon chain. Thermostability of lipase improved more than 7-fold at 60
oC. Significant potential for reuse in water solutions was also found after immobilization. In
cyclohexane immobilized lipase catalyzed synthesis of amyl octanoate by ping-pong bi-bi
mechanism with inhibition by amyl alcohol. Obtained kinetic constants were Vmax=26.4
µmol/min, KAc=0.52 mol/l, KAl=0.2 mol/l and Ki,Al=0.644 mol/l. Esterification activity remained
60 % after 5 reuse cycles in cyclohexane indicating moderate reuse stability.
Keywords
Candida rugosa lipase, Degussa P25 titania, Immobilization, Kinetic parameters, Cyclohexane
1

1. Introduction
Enzyme catalyzed reactions in aqueous medium have been extensively exploited for a wide
range of applications in biotechnology, such as production of food, detergents, leather,
pharmaceuticals. In spite of a broad implementation of enzymes in different fields, some
constraints referred to their cost and process stability still exist. To overcome a limit related to
short catalytic lifetime of enzymes in process conditions, a spectrum of immobilization methods
have been extensively studied to increase stability and enhance reuse, offer easier separation,
making production economically viable [1]. Properties of a vast number of enzymes were
significantly improved when immobilized onto different supports [2]. The characteristics of
support are of paramount importance in determining the performance of the immobilized enzyme
system [3]. Frequently used supports are polymers and inorganic materials [4]. Apart from being
affordable, an ideal matrix must encompass characteristics like inertness, physical strength,
ability to increase enzyme stability and activity, reduce microbial contamination [5]. Lately,
nanoscale supports in combination with enzymes have emerged a new field of nanobiocatalysis
which achieved a great success in enzyme stabilization [6]. Actually, nanobiocatalytic systems,
compared with enzymes immobilized on non-nanostructured materials, have advantagies related
to improvement of enzyme stability, more efficient loading, prolonged lifetime and larger
number of reuse cycles [7].
Having a long history, enzyme reactions in water conditions implied a general attitude that the
enzymes can work only in water solutions, while in organic solvents they denature. Nowadays,
however is well known that in spite of enzyme instability in organic solvents, a significant
number of reactions in organic chemistry can be catalyzed by enzymes in non-water conditions
(to avoid by-products and to obtain desired product of high purity). Although the transformations
in reduced water conditions are relatively new challenge in enzymology [8], merits of this
concept are recognized. Possibility to shift thermodynamic equilibrium in favor of synthesis over
hydrolysis, which allows for highly specific organic synthesis, e.g. of enantioselective drugs [9],
is undoubtedly one of the most important advantages. Aside of that, there are several more merits
of catalysis in non-water media: increased solubility of non-polar substrates, such as e.g. lipase
substrates, insolubility of enzymes which allows their reuse and recovery [10], enzyme
stabilization [11], and elimination of microbial contamination in reaction mixtures [12].
Although enzymatic conversions in water restricted environments open a possibility to perform
complex organic synthesis, enzymes being proteins, generally easily lose their activity in such
conditions [13]. Lipases produced by microorganisms isolated from water reduced environment
and active in organic solvents are rare [14,15]. In that respect, it has became necessary to
develop strategies to improve their lifespan in the presence of organic solvents. The use of novel
nanomaterials for immobilization has been considered as promising route [16].
Lipases are an intriguing group of enzymes which catalyze the hydrolysis of carboxylic esters in
water and the reverse reaction of ester synthesis in organic solvents. In water solutions, lipases
transform water insoluble substrates. Possessing a mobile lid, which covers substrate binding
site, lipases structure is specifically adjusted to non-polar substrates. Interestingly, a molecular
dynamic study showed that an organic solvent promotes and stabilizes open lid structure of
lipases [17]. Enzyme conversions of hydrophobic substrates can be facilitated by addition of
non-polar organic solvents, however, loss of enzymatic activity promoted by solvent becomes
factor of limitation in such conditions. On the other side, to be active in non-water environments
appropriate for substrate solubilization, a certain amount of water is necessary for
conformational mobility of enzymes. Delicacy of experimental conditions to achieve a certain
2

lipase reaction demands a good balance of nature/properties and amount of organic solvent,
amount of water and stability and amount of lipase. It is expected that immobilization of
enzymes /lipases on nanostructured materials would improve their stability and protect its
necessary conformational mobility in transformations of water non-soluble substrates in organic
solvents.
Lipase form Candida rugosa (C. rugosa) is well established in water solutions and its
stabilization on several inorganic materials has been documented in literature, the findings of our
team included [18,19]. The current study focuses on the use of commercial titania, a biosafe
nanostructured material with excellent physico-chemical stability, as support for lipase
immobilization. Degussa P25 is widely applied model powder for various applications of TiO2.
Interestingly, only one study deals with immobilization of lipase onto Degussa titania [20].
Hereby, it was selected for its morphology and surface properties. In such a manner,
immobilization process was performed under the same electrostatic conditions as done for
SBA15, zirconia and alumina [18,19] enabling evaluation of support morphology impact on
enzyme percent adsorption. Effect of lipase immobilization on enzyme kinetic, temperature
stability, as well as on potential for its reuse in water solution is investigated. Aside of behavior
of nanobiocatalyst in water solution, in this study, potential of immobilized lipase to act in
organic solvent was evaluated too.
2. Experimental
2.1. Materials
Lipase from C. rugosa (lyophilized powder, Type VII, 746 U/mg), p-nitrophenyl palmitate (p-
NPP), p-nitrophenyl laurate (p-NPL), p-nitrophenyl caprylate (p-NPC) and p-nitrophenyl butirate
(p-NPB) were purchased from Sigma Chemical Co. (St. Louis, MO, USA). All other chemicals
were of analytical grade.
Support material, titania (TiO2) (Degussa P25), purchased from Degussa Chemicals (Hanau,
Germany) was used as received. It had the following characteristics: phase composition of 80 %
anatase and 20% rutile, primary particle size of 27 nm and specific surface area of 57.4 m2g-1
with a mesopore range 13-23 nm [21].
2.2. Lipase immobilization
Titania was prepared for immobilization as follows: suspensions containing 4 mg solid/ml in 10
mM Tris-HCl buffer pH 7.6 were de-agglomerated for 10 min by sonication. Lipase solution (2
mg/ml in the same buffer), was added to previously de-agglomerated support and immobilization
was carried out for 1 h at room temperature under mild shaking (100 rpm). Final concentration of
support was 2 mg/ml, final concentration of lipase was 1 mg/ml. Immobilized lipase was
precipitated by centrifugation at 10000 rpm for 10 min, using micro-centrifuge (Denver
Instruments, USA). After removing supernatant, immobilized enzyme was washed 2 times (in
order to remove excess of unbounded enzyme), dried for 1 h at room temperature and after that
used for an assay.
Kinetics of the adsorption process was studied for 180 min using 10 mM Tris-HCl buffer pH 7.6
and the fixed lipase/support ratio (w/w) 1/2.
The efficiency of immobilization was evaluated in term of enzyme coupling yields, ηenz,
calculated as follows:
ηenz(%) = P1/P0 x 100
3

Po is the initial concentration of the enzyme and P1 is the concentration of immobilized enzyme.
P1 was calculated as a difference between initial lipase concentration and concentration in
supernatant after immobilization.
The efficiency of immobilization was also evaluated in term of activity coupling yields ηact.
ηact (%) = SA2/SA1 x 100
SA2 is the specific activity of immobilized lipase and SA1 is the specific activity of free lipase
[22].
2.3. Methods for material characterization
2.3.1. Zeta potential determination
Zeta potential measurements were performed by Zetasizer Nano ZS (Malvern, UK). The change
of ζ-potential with pH was firstly recorded in NaCl (0.01 M) electrolyte to determine the
isoelectric point (IEP) of titania as support. Prior to titration, the powder dispersion (1 mg/1mL)
was equilibrated for 24 h under mild shaking at room temperature. The ζ-potential of lipase and
that of support (before and after enzyme adsorption) was also determined in Tris-HCl buffer,
pH7.6
2.3.2. Fourier transform infrared spectroscopy (FTIR)
FTIR was used to examine the support surfaces before and after immobilization of lipase. The
spectra were recorded using FTIR Nicolet 6700 (Thermo Scientific, USA) in transmission mode
between 400 and 4000 cm-1. The platinum-ATR (Attenuated Total Reflectance) sampling
module with diamond crystal was used.
2.3.3. Field emission scanning electron microscopy (FESEM)
Field emission scanning electron microscopy (FESEM), using a Tescan Mira3 XMU (Czech
Republic) at 20 kV was used to compare the morphological features of support particles before
and after immobilization of C. rugose lipase. Prior to FESEM analysis, the samples were coated
with Au alloy using a spatter coater.
2.3.4. Determination of organic content in commercial lipase preparation
The content of ash was determined according to the standard test method - ASTM E1755-01
[23].
2.3.5. Elemental analysis
The C, H, S, and N contents of the commercial Candida rugosa lipase (Sigma L-1754) were
determined by a Vario EL III CHNS/O Elemental Analyzer (Vario EL III, Elemental Analysis
System GmbH, Germany).
2.4. Characterization of immobilized enzyme in water solution
2.4.1. Determination of lipase activity
Activity of free lipase was measured spectrophotometrically by using an assay based on the
hydrolysis of p-nitrophenyl palmitate (p-NPP).The p-NPP solution was prepared as follows: 30
mg of p-NPP in 10 ml of 2-propanol was added to 90 ml of 0.05 M phosphate buffer (pH 8.0)
supplemented with 200 mg of Na-deoxycholate and 100 mg of gum arabic. The absorbance was
measured at 410 nm for the first 3 min of reaction at 25oC. One unit (1 U) is defined as that
4

quantity of enzyme which under test conditions liberates 1 mol of p-nitrophenol per min. The
reaction mixture was composed of 900 l of p-NPP solution and 100 l of lipase solution [8].
Activity of immobilized lipase was determined using 10 mg of immobilized preparation
supplemented with 2 ml of p-NPP solution. Reaction was carried out at 25oC for 3 min and it
was stopped by addition of 0.5 M sodium carbonate solution. Precipitate was removed by
centrifugation at 10000 rpm for 10 min. Supernatant was diluted 10-fold with deionized water
and activity was measured at 410 nm. Activity was calculated as U per g of support material.
2.4.2. Thermal stability
Reaction mixtures containing free or immobilized enzyme were incubated at 50 and 60 oC for
various periods of time (20 - 120 min) and quickly cooled. Enzymatic activity was measured
according to the standard protocol for free and immobilized enzyme with p-NPP as substrate.
Lipase activity without previous incubation was determined as 100%.
Half life (t1/2) of enzyme with kd as the decay constant was calculated as:
t1/2 = ln 2/kd
(1)
2.4.3. Determination of kinetic parameters
Michaelis –Menten kinetics was used to describe the dependence of enzyme activity on substrate
concentration for free and immobilized lipase. Vmax is the highest possible specific lipase activity
(U per mg of protein) and Km is the Michaelis constant determined from substrate concentration
that gives a specific activity of half of Vmax. The two kinetic parameters Vmax and Km were
calculated from experimental data using Lineweaver-Burk equation:
1/ v=1/Vmax + Km/Vmax x 1/S
(2)
The y-axis intercept is 1/vmax, and the slope is Km/vmax. [24]
The kinetic parameters of free and immobilized lipase were determined using solutions of p-NP
esters: p-NP palmitate (p-NPP), p-NP laurate (p-NPL), p-NP caprylate (p-NPC) , p-NP butyrate
(p-NPB) at following concentrations: 0.2, 0.4, 0.8, 1.2, 1.6, 2.0 mM. The lipase activity was
measured as described in section 2.4.1. Measurements were conducted in triplicate.
2.4.4. Reuse stability
After immobilisation of lipase, its potential for reuse was determined by the following procedure:
25 mg of immobilised enzyme packed in a filter paper bag was used for hydrolysis of p-NPP
solution in 5 ml phosphate buffer pH 8.0, for 30 min at room temperature, under mild stirring (90
rpm). After each batch reaction, the immobilised lipase was washed three times in order to
remove the product, p-NP, and dried for 1h (one cycle). Five cycles were performed during one
day, and the immobilised lipase was stored at 4 oC overnight. The lipase activity was measured
as described in section 2.4.1. Activity of the first cycle was determined as 100%. In order to
follow the loss of enzyme i.e., desorption process, after each of 12 reuses, the amount of proteins
was determined in the batch solution. Measurements were conducted in triplicate.
2.4.5. Protein concentration
The concentration of protein was determined by the Bradford`s method using bovine serum
albumin as a standard [25].
2.5. Characterization of immobilized enzyme in organic solvent
2.5.1. Determination of lipase activity
5

Solution of amyl alcohol, octanoic acid, and 0.1% of water in 5 ml cyclohexane were incubated
with 10 mg of immobilized lipase at 40 oC with mechanical stirring at 150 rpm on rotary shaker
(Kuhner, Switzerland). The rate of esterification was determine as the residual acid content by
titration with sodium hydroxide, with phenophtalein as an indicator and ethanol and diethyl ether
mixture as a quenching agent. The quantity of ester formed was calculated as being equivalent
to acid consumed [26]. This was confirmedby determination of ester concentration using gas
chromatography–mass spectrometry (GC-MS) performed with a GCMS (QP2010 Ultra,
Shimadzu, Kyoto, Japan). A Rtx®-1 (RESTEK, Crossbond® 100 % dimethyl polysiloxane, 30
m × 0.25 mm I.D., 0.25-μm film thickness) column was used, with Helium as the carrier gas.
Injector temperature was constant: 280 ºC. The temperature program used was: initial
temperature 60 ºC, then 4 ºC per min until 310 ºC, and isothermal at 310 ºC for 7.5 min. The GC-
MS data was collected and analyzed (automated mass spectral deconvolution and identification)
with GCMS Solution software (Shimadzu). Spectrum analysis was performed using NIST11 and
Wiley8 database libraries, and relative ratios of components were calculated from the
corresponding peak areas.
2.5.2. Determination of kinetic parameters in organic solvent
The kinetic parameters of immobilized lipase were determined in cyclohexane using solutions of
amyl alcohol and octanoic acid in a range of concentrations: 0.05 to 0.6 M for alcohol and 0.05
to 1 M for acid. The concentrations of alcohol and acid were varied one at a time keeping the
other constant. The reaction mixture volume was 5 ml with 10 mg of immobilized lipase. One
unit (1 U) is defined as that quantity of enzyme which under test conditions synthesizes 1 mol
of amyl-octanoate per min.
The experimentally obtained data were fitted with model for bisubstrate ping-pong bi-bi model
with alcohol inhibition using Matlab software [26]. The rate equation describing this model is
given by:
(3)
v =
where v is the initial reaction rate, Vmax is the maximum reaction rate, [Ac] and [Al] are the
concentrations of octanoic acid and amyl alcohol, KAl and KAc are Michaelis constants for amyl
alcohol and octanoic acid, and Ki,al is the amyl alcohol inhibition constant [26].
Kinetic constants (Vmax , KAl, KAc, Ki,al) were calculated using a non-linear regression fit of the 48
experimental points. Parameters were optimized using MatLab software. For the kinetic model
applied, goodness of fit, R2 and Root Mean Squared Error, was determined.
2.5.3. Synthesis of methyl esters in solvent free system
10 mg of immobilised enzyme was incubated in 5 mL of methanol with palmitic, lauric and
octanoic acid with concentration of 0.6 mol/L. The rate of methyl esters synthesis was determine
as the residual acid content by titration with sodium hydroxide, with phenophtalein as an
indicator. The quantity of ester formed was calculated as being equivalent to acid consumed
Synthesis of methyl caprilate was confirmed by GC-MS analysis as described (2.5.1).
2.5.4. Reuse stability
6

After immobilisation of lipase, its potential for reuse in organic solvent was determined by the
following procedure: 10 mg of immobilised enzyme was used for amyl-octanoate synthesis in 5
mL of cyclohexane. After each batch reaction, the solvent was decanted, immobilised lipase was
washed and dried overnight (one cycle). Six cycles were performed. The lipase activity was
measured as described (2.5.1.). Activity of the first cycle was determined as 100%. In order to
follow loss of enzyme i.e., desorption process, after each of 6 reuses, decanted cyclohexane was
evaporated, residues were dissolved in water and proteins content determined. All measurements
were conducted in triplicate.
3. Results and discussion
3.1. Conditions for lipase immobilization
Lipase from C. rugosa is a globular glycoprotein with molecular mass of 57 kDa, with 31 acidic
and 18 basic amino acids exposed on the surface,[18] its IEP is located at pH 4.65. Above this
pH, the lipase acquires negative charge. Protein and organic compound content of commercial
C. rugosa lipase were determined and it was found that the preparation comprised of 13 %
protein and 83 % organic matter. Result corroborates the literature data where the main organic
impurity in commercial lipase was lactose, which acted as water reservoir [27]. In spite of high
content of lactose in the preparation, it did not disturb the process of lipase adsorption.
In this study, titania Degussa P25 was selected as support material for its well defined
morphology: nanometer-sized solid particles of spherical shape. Moreover, its isoelectric point
value permitted the Tris-HCl buffer at pH 7.6 to be used for immobilization, with an aim to
perform the adsorption of lipase under the same (repulsive) electrostatic conditions (i.e. the same
surface charge of the interacting partners) as previously done for SBA15, zirconia and alumina
supports.
Zeta potential values were collected over the pH range 39, using NaCl as indifferent electrolyte
[28, 29]. The dependence presented in Figure 1, indicated the isoelectric point at pH 6.7 (at IEP
ζ-potential equals to zero), in good accordance with literature [29].
Fig. 1.
Being amphoteric, titania particles develop positive and negative charge below and above pH
6.7, respectively, due to dissociation of the surface hydroxyl groups. Lipase has an acidic IEP
(4.6) and is negatively charged above this pH [18]. Accordingly, the adsorption partners should
carry a negative surface charge in the pre-selected immobilization conditions. Indeed, negative ζ-
potentials were measured, namely: -14.3 mV for lipase and -12.2 mV for support. Immobilized
lipase shifted the ζ value of titania to -19.4 mV. The change in zeta potential ascertained
adsorption of lipase onto support, in accordance with previous findings [18, 19, 30] that ζ-
potential is useful tool for qualitative confirmation of adsorption.
3.2. Kinetic of adsorption process
Adsorption of proteins on solid surfaces is common but very complex phenomenon [31]. The
effect of immobilization time on the C. rugosa lipase adsorption onto titania surface was studied,
as shown in Fig. 2. The adsorption of protein onto inorganic supports is relatively fast process in
suitable conditions of stirring or mixing [32].
Fig. 2.
7

The adsorption of lipase proceeds in two kinetic regimes: fast one followed by slower kinetics.
Simple models can provide useful insight into adsorption process. Protein adsorption onto
surface can be divided in two classes: I-random sequential adsorption and ballistic deposition,
and II- diffusional model [20]. In this work the adsorption process of seems to follow random
sequential mode where the lipase aggregates sequentially occupy the support surface [33, 34]. In
aqueous media, aggregation of proteins is possible to occur at the hydrated oxide surface;
therefore, adsorption of the lipase aggregates onto TiO2 is more realistic scenario than adsorption
of isolated molecules [20].
Despite repulsive electrostatic conditions, very good result was achieved already after 1h:
adsorption plateau with 65.5 % adsorbed lipase. As longer incubation time (two or three hours)
did not significantly improve the immobilization efficiency, the chosen contact time was 60 min.
The obtained results of adsorption are summarized in Table 1.
Table 1.
Although this procedure enabled the coupling of a higher amount of enzyme, the loss in activity
was inevitable and the activity coupling yield was 21%. It seems to be the result of
conformational changes and movement restrictions of lipase and barrier formation after
adsorption. Determined specific activity of immobilized lipase was 64.7 U/mg of protein.
3.3. FTIR characterization
The adsorption of lipase onto titania was also analyzed by FTIR. Figure 3. presents the spectra of
titania before and after adsorption process and spectrum of lipase for comparison. In titania
spectrum (curve a), the peak at 400–700 cm−1 corresponds to Ti-O stretching and Ti-O-Ti
bridging stretching modes. The broad band at 3400 and the peak at 1650 cm−1 are assigned to the
surface-adsorbed water and OH- group [33]. The bands characteristic for functional groups of
lipase (curve b), i.e. at 1530 cm−1 (amine groups), at 1650 cm−1 (C-O stretching), together with a
sharp peak in the region 1200–900 cm−1 representing carbohydrate band (the lipase is
glycoprotein), are clearly visible [34]. After immobilization process, titania (curve c) exhibited
three new bands: at 1530, 1650 and in the region 1200–900 cm−1, which is a verification of
successful adsorption of lipase.
Fig. 3.
3.4. FESEM characterization
Adsorption of lipase was also followed by FESEM, comparing morphological features of bare
titania and titania with adsorbed lipase (Fig. 4.).
Typical microphotograph of P25 revealed aggregated powder, composed of nanometric (cca 30
nm) spherical particles (Fig. 4a.). After adsorption of lipase, the extent of particle aggregation
evidently increased (Fig. 4b.).
It is known that due to high surface/volume ratio, ultrafine powders tend to stick together
forming aggregates, or secondary particles. A pore volume, made up of gaps between the
particles, is created, which is often comparable in size and related in shape to the primary
particles [35]. Indeed, with a mesoporosity range 13-25 nm [36], Degussa P25 can perfectly
accommodate single lipase molecules (5 x 4.2 x 3.3 nm), or small aggregates of several
8

molecules. Lipase thus easily entered the internal voids, which resulted in formation of numerous
clusters, due to bonding occurring between enzyme and support particles (Fig. 4b).
Fig. 4.
As stated, 65.5 % adsorption occurred onto titania within 1 h. For the sake of comparison, the
percent adsorption determined for other materials used as supports for C. rugosa lipase in our
previous studies: SBA15, zirconia and alumina is summarized in Table 2 [18,19].
Table 2.
As seen, the greatest amount of bound lipase was registered onto SBA15, followed by titania,
and smaller ones using zirconia and alumina as support materials. Morphological features of
previously used supports are provided in supplementary material (Fig. A. 1), to facilitate visual
comparison.
SBA-15 exhibited fiber-like morphology, made up of peanut-shaped domains, organized in
wheat macrostructures (supplementary Fig. A.1.). Its internal mesoporosity (ca half of the total
surface area), based on ordered hexagonal channels with small openings (2-25 nm radius), was
suitable for lipase to assess.
Sub-micrometer macroporous zirconia had much smaller Sp value. Its irregular broken sphere
morphology, with undeveloped geometry afforded twice smaller amount of lipase.
Even smaller percent adsorption was registered in the case of alumina. Composed of irregular
sub-micrometric solid particles with smooth surfaces, quite unsuitable for lipase to adhere,
alumina provided just a moderate adsorption of lipase.
In summary, it can be concluded that geometry and surface texture of particles are of paramount
importance in adsorption process of lipase. Its influence overrules largely that of electrostatics.
Owing to its patchwork surface charge, (In silico data [18]) made up of randomly distributed
negative (Glu, Asp) and positive residues (Lys, Arg, Hys), the lipase always establishes
favorable localized electrostatic conditions, leading to a successful adsorption in overall either
repulsive or attractive conditions. Therefore, it is a morphology of support particles that
challenges the lipase to approach, establish mutual bonds and adhere.
3.5. Effect of immobilization on enzyme properties in water solution
3.5.1. Kinetic parameters
The kinetic behavior of free and immobilized lipase was investigated using p-NP esters with
different length of carbon chain. Although it is known that lipase catalytic action is much more
complex than described by the Michaelis-Menten mechanism, where it is assumed that the
enzyme and substrate are parts of the same phase, it is commonly used as simplified model
where the trend of modification of catalytic property can be compared.
Free lipase and lipase immobilized onto titania obeyed Michaelis-Menten kinetics on p-NP
esters. Two parameters, Km and Vmax, were calculated from experimental data using
Lineweaver-Burk equation [24] and they are presented in Table 3.
Table 3.
9

The affinity for the substrates (p-NP esters) of both forms of enzyme, free and immobilized,
depended on the carbon chain length of the acid in the ester hydrolysed.
Free lipase showed similar affinity to substrates containing butyric, caprylic and lauric acid, Km
≈ 0.24 mM, however for palmitic acid, Km was considerably higher (0.4 mM), meaning lower
affinity. The hydrolytic reactions catalyzed by free lipase were the most rapid when lauric acid
(C-12) ester was hydrolysed, Vmax was more than 1200 U/mg of protein. When the substrates
were palmitic, caprylic and butyric acid esters, the reaction was 3.1, 2.3 and 1.9 times slower
respectively.
After immobilization onto titania, the affinity of lipase toward p-NPB and p-NPC was markedly
lower: 8.5 and 6.9 times, respectively. Change of the affinity of immobilized lipase was
negligible toward p-NPL (Km decrease for less than 17%), but the affinity toward p-NPP
doubled.
After immobilization, the Vmax for hydrolytic reaction was influenced in the same manner for
all investigated substrates. Lowering of Vmax is considered to be a consequence of increased
rigidity of enzyme. Conformational constraint and steric hindrance is well known to decrease
lipase activity [37]. In particular, p-NPP (with larger particle dimensions) hydrolysis slowed 8
times after immobilization. Besides transport, which depends on particle size, the steric
hindrance is likely to represent major constraint for the ester containing an acid with the longest
carbon chain (C16). Rate of hydrolysis of esters containing acids with a shorter carbon chain (12,
8 and 4) was also lower (i.e. decreased 2-3.6 folds).
3.5.2. Thermal stability
One of advantages of enzyme immobilization is improvement in thermal stability. Therefore, the
stability of lipase immobilized onto titania was determined at 50 and 60 oC, Fig. 5.After 2 h of
incubation at 50 oC, the remaining activity of free lipase and lipase adsorbed onto titania was 31
and 64 %, respectively. In terms of half-life, t1/2 of free lipase was 55 min, while after
immobilization, t1/2 increased to 180 min. The thermostability of lipase was increased more than
3-fold after immobilization. After 1 h of incubation at 60 oC, the free lipase was inactive, while
the remaining activity of immobilized enzyme was close to 60%. Even after 2 h, the activity
remained 40%, or in terms of half-life, increased more than 7-fold.
A significant improvement in thermal stability of immobilized lipase seems to be result of
restrict movements of protein after adsorption, preventing conformational changes and
unfolding. Similar improvements in temperature stability of C. rugosa lipase were obtained after
its immobilization onto other inorganic supports [18, 19].
Fig. 5.
3.6. Properties of immobilized enzyme in organic solvent
3.6.1. Kinetic parameters in organic solvent
It is important that kinetic measurements can be used to predict the optimum kinetic behaviour of
a particular biocatalyst [38]. Based on those predictions, optimisation of biocatalytic reactions, as
well as process design to improve productivity and reduce the cost of various processes can be
performed [39].
Most of the kinetic studies of lipase catalyzed esterification reaction in organic solvent assume
ping-pong model with inhibition by alcohol [26, 40, 41]. In order to find kinetic model of amyl
caprylate synthesis, catalyzed with C. rugosa lipase immobilized onto titania, series of
10

experiments were performed at determined conditions. Values of the equation parameters in Eq.
(1) obtained after processing experimental data are given in Table 4.
The proposed model Eq. (1) was validated by fitting the model to the set of experimental data.
For kinetic ping-pong model with inhibition by alcohol l fitting, goodness of fit was R2 = 0.835,
Adjusted R2 = 0.819 and Root Mean Squared Error = 1.95. A good agreement for this kinetic
model was obtained.
Table 4.
Fig. 6. presents dependence of initial rate of amyl octanoate synthesis on concentrations of both
substrates. The increase of concentration of octanoic acid increases the rate of esterification
achieving the maximum rate of 26.36 µmol min-1 at 1 mol/L of acid and 0.3 mol/L of alcohol. On
the other hand, the increase of concentration of amyl alcohol confirmed hypothesis of substrate
inhibition as presented in Fig.6 b.
Fig. 6.
3.6.2. Synthesis of methyl esters in solvent free system
Fatty acid methyl esters were the first fatty acid esters to be introduced for use as biodiesel [42].
Biodiesel appears to be an attractive energy resource hence it is a renewable with several
favourable environmental properties. It contains no aromatic compounds and other chemical
substances which are harmful to the environment [43]. Considering the importance of biodiesel,
a possibility of synthesizing methyl esters of palmitic, lauric and octanoic acid in solvent free
system, using lipase immobilized onto titania, was tested. Synthesis of methyl octanoate was
confirmed by GCMS analysis and titrimetry, with low reaction yield of 9% while esters of
methanol with lauric and palmitic acid were barely detected. This result is in a agreement with
previously published observation in which higher yield of methyl esters was obtained with
heptanoic and octanoic acids [44].
3.7. Reuse stability
The reusability of immobilized enzyme is one of the most important advantages for application.
Adsorption, as an immobilization method, is usually considered as a method with poor reuse
potential, as the linkages established are usually weak and the enzyme could be easily desorbed.
Reuse stability of lipase immobilized onto titania in water solution and in organic solvent is
shown in Fig. 7. As seen, the remaining lipase activity in water was about 90% after nine reuses.
The activity decreased continuously from 9 to 20 reuse cycles; however, it remained ca. 40%.
Protein desorption process was followed in parallel for 12 reuses. Although protein desorption
was 40% after 4 uses lipase activity remained almost the same.
Easily desorbed proteins, according to Table 1. (specific activity of 64.7 U/mg of protein) were
probably protein impurities. If any amount of lipase was desorbed, those were enzyme molecules
positioned at the surface of aggregates (section 3.2.) [20]. In return, the former inner lipases
became exposed and active towards the substrate, resulting in almost unaffected enzyme activity.
Fig 7.
11

On the other side, immobilized enzyme in cyclohexane shows lower reusability. As presented in
Fig.7., the second application of biocatalyst in synthesis of amyl octanoate was as good as the
first one, but after the third and the fourth reuse cycles the activity decreased to 80% and 77%,
respectively. The synthetic activity of lipase remained 60% after 5 reuse cycles, but dropped to
10% after the following cycle. Desorption process was followed for 5 cycles but protein leaching
was not registered. Denaturation of lipase as a consequence of damaged water layer around
lipase molecule could result in decreased activity. Although reuse stability in organic solvent was
not as good as in water, presented results point to the potential for reuse of lipase after
immobilization in cyclohexane.
4. Conclusions
C rugosa lipase was immobilized onto titania powder (Degussa P25) as support in the Tris-HCl
buffer, pH 7.6. High percent adsorption was found (65.5%) owing to mesoporous structure of the
nanometric sized powder. Determined specific activity of immobilized lipase was 64.7 U/mg of
protein. After immobilization, lipase affinity decreased toward p-NPB and p-NPC, but increased
toward p-NPP. Vmax for hydrolytic reaction decreased from 2 to 8 fold. The highest reduction of
activity was toward the largest substrate p-NPP. A significant improvement in thermal stability
was achieved. Excellent reuse stability in water solution was revealed.
Lipase immobilised onto titania was stable and active in organic solvent and could be used for
synthesis of esters of octanoic acid in organic solvents, and methyl esters in solvent free system.
Synthesis of amyl octanoate in cyclohexane was well described with ping-pong bi-bi mechanism
with inhibition by amyl alcohol. Reuse stability in cyclohexane was confirmed.
Based on the findings of current and our earlier studies, the morphology of powder used as a
support was ascertained as more important adsorption parameter than electrostatics.
Acknowledgements
This research was financed by the Ministry of Education, Science and Technological
Development, Republic of Serbia (Projects Nos. III 43004 and III 45012). The authors thank
professor Dejan Bezbradica for useful suggestions regarding enzyme kinetic in organic solvent
and assistant professor Sonja Šuvakov for valuable contribution.
References
[1] R.A. Sheldon, S. Van Pelt, Enzyme immobilisation in biocatalysis: why, what and how,
Chem. Soc. Rev. 42 (2013) 6223-6235.
[2] R. Ahmad, M. Sardar, Enzyme Immobilization: an overview on nanoparticles as
immobilization matrix, Biochem. Anal. Biochem. 4 (2015) doi:10.4172/2161-1009.1000178.
[3] B.M. Brena, F. Batista-Viera, Immobilization of Enzymes and Cells in J.M. Guisan (Ed)
Metods in biotechnology, Humana press Inc. 2006. pp. 15-30.
[4] S. Datta, L.R. Christena, Y.R.S. Rajaram, Enzyme immobilization: an overview on
techniques and support materials, Biotech. 3 (2013) 1–9.
[5] B.D. Singh, Biotechnology expanding horizons, second ed., Kalyani Publishers New Delhi
India. 2009.
12

[6] M. Kyoungseon, Y. Je Yoo, Recent progress in nanobiocatalysis for enzyme immobilization
and its application, Biotechnol. Bioproc. E. 19 (2014) 553-567.
[7] K. Jungbae, J.W. Grate, P. Wang, Nanobiocatalysis and its potential applications, Trends
Biotechnol. 26 (2008) 639- 646.
[8] I. Karadzic, A. Masui, L. Izrael-Zivkovic, N. Fujiwara, Purification and characterization of
an alkaline lipase from Pseudomonas aeruginosa isolated from putrid mineral cutting oil as
metal working fluid, J. Biosc. Bioeng. 102 (2006) 82-89.
[9] A. Baiyi, F. Hailin., Z. Wu, L. Zheng, L. Wang, Z. Wang, G. Chen, Ultrasound-assisted
enantioselective esterification of ibuprofen catalyzed by a flower-like nanobioreactor, Molecules
21 (2016) 565 doi:10.3390/molecules21050565
[10] A. Zaks, A. Klibanov, Enzyme-catalyzed processes in organic solvents, Proc Natl. Acad.
Sci. USA. 82 (1985) 3192–3196.
[11] S. Torres, G.R. Castro, Non-aqueous biocatalysis in homogenous solvent systems, Food
Technol. Biotech. 42 (2004) 271-277.
[12] M. Gupta, I. Roy, Enzymes in organic media forms, functions and applications, Eur. J.
Biochem. 271 (2004) 2575–2583.
[13] A. Klibanov, Improving enzymes by using them in organic solvents, Nature 409 (2001)
241-246.
[14] S. Aliyu, A. Zahangir, Solvent tolerant lipases: a review, Process Biochem. 50 (2015) 86–
96.
[15] K. Lambit, P. Goswami, Isolation of a Pseudomonas lipase produced in pure hydrocarbon
substrate and its application in the synthesis of isoamyl acetate using membrane-immobilised
lipase, Enzyme Microb. Tech. 31 (2002) 727–735.
[16] V. Stepankova, S. Bidmanova, T. Koudelakova, Z. Prokop, R. Chaloupkova, J. Damborsky,
Strategies for stabilization of enzymes in organic solvents, ACS Catal.3 (2013) 2823–2836.
[17] S. Rehm, P. Trodler, J. Pleiss, Solvent-induced lid opening in lipases: A molecular
dynamics study, Protein Sci.19 (2010) 2122—2130.
[18] L. Izrael Živković, Lj. Živković, B. Babić, M. Kokunešoski, B. Jokić, I. Karadžić
Immobilisation of Candida rugosa lipase by adsorption onto biosafe meso/macroporous silica
and zirconia, Biochem. Eng. J. 93 (2015) 73-83.
[19] L. Izrael Živković, Lj. Živković, B. Jokić, A. Savić, I. Karadžić, Adsorption of Candida
rugosa lipase onto alumina: effect of surface charge, J. Serb. Chem. Soc. 80 (2015) 1113-1125.
[20] M.L. Foresti, G. Valle, R. Bonetto, FTIR, SEM and fractal dimension characterization of
lipase B from Candida antarctica immobilized onto titania at selected conditions, Appl. Surf.
Sci. 256 (2010) 1624-1635.
[21] H. Liu, X. Sun, C. Yin, C. Hu, Removal of phosphate by mesoporous ZrO2, J. Hazard.
Mater. 151 (2008) 616–622.
[22]. Z. Knezevic, N. Milosavic, D. Bezbradica, Z. Jakovljevic, R. Prodanovic, Immobilisation
of lipase from Candida rugosa on Eupergit C supports by covalent attachment, Biochem. Eng. J.
30 (2006) 269-278.
[23] ASTM E1755-01., 2007, ASTM E1755-01, Standard test method for ash in biomass
American Society for Testing and Materials (ASTM), USA (2007).
[24] D. Purch, Contemporary enzyme kinetics and mechanism, Academic Press, London and N.
York, 2009.
[25] M.M. Bradford, A rapid and sensitive method for the quantitation of microgram quantities
of protein utilizing the principle of protein-dye binding, Anal. Biochem. 72 (1976) 248-254.
13

[26] D. Bezbradica, D. Mijin, S. Siler-Marinkovic, Z. Knezevic, The Candida rugosa catalyzed
synthesis of amyl isobutirate in organic solvent and solvent-free system: A kinetic study, J. Mol.
Catal. B-Enzym. 38 (2006) 11-16.
[27] J.M. Sanchez-Montero, V. Hamon, D. Thomas, M. D. Legoy, Modulation of lipase
hydrolysis and synthesis reactions using carbohydrates, Biochim. Biophys. Acta 1078 (1991)
345-350.
[28] K. Suttiponparnit, J. Jiang, M. Sahu1, S. Suvachittanont, T. Charinpanitkul, P. Biswas, Role
of surface area, primary particle size, and crystal phase on titanium dioxide nanoparticle
dispersion properties, Nanoscale Res. Lett. 6 (2011) 27.
[29] M. Kosmulski, Chemical properties of material surfaces, Marcel Dekker Inc, New York,
Basel, 2001.
[30] N. Schultz, G. Metreveli, M. Franzreb, F.H. Frimmel, C. Syldatk, Zeta potential
measurement as a diagnostic tool in enzyme immobilisation, Colloid. Surface. B 66 (2008) 39-
44.
[31] K. Nakanishi, T. Sakiyama, K. Imamura, Review on the adsorption of proteins, a common
but very complicated phenomenon, J. Biosci. Bioeng. 91 (2001) 233-244.
[32] K. Rezwan, L.P. Meier, M. Reywan, J. Voros, M. Textor, L.J. Gauckler, Bovine serum
albumin adsorption onto colloidal Al2O3 particles: a new model based on zeta potential and UV-
Vis measurements, Langmuir 20 (2004) 10055-10061.
[33] G. Wang, L. Xu, J. Zhang, T.Yin, D. Han, Enhanced photocatalytic activity of TiO2
powders (P25) via calcination treatment, Int. J. Photoenergy 2012 (2012) Article ID
265760,doi:10.1155/2012/265760.
[34] A. Natalello, D. Ami, S. Brocca, M. Lotti, S.M. Doglia, Secondary structure,
conformational stability and glycosylation of a recombinant Candida rugosa lipase studied by
Fourier-transform infrared spectroscopy, Biochem. J. 385 (2005) 511–517.
[35] S.J. Gregg, K.S.W. Sing, Adsorption, Surface Area and Porosity, Academic Press, London
and N. York, 1967.
[36] K.J.A. Raj, B. Viswanathan, Effect of surface area, pore volume and particle size of P25
titania on the phase transformation of anatase to rutile, Indian Journal of Chemistry 48
(2009)1378-1382.
[37] T.D. Nalder, S. Marshall, F. Pfeffer, C. Barrow, Characterisation of lipase fatty acid
selectivity using novel omega-3 pNP-acyl esters, J. Funct. Foods 6 (2014) 259-269.
[38] N.N. Ulusu, Evolution of Enzyme Kinetic Mechanisms, J. Mol. Evol. 80 (2015) 251-257.
[39] A. Bornadel, C.O. Akerman, P. Adlercreutz, R. Hatti-Kaul, N. Borg, Kinetic modeling of
lipase-catalyzed esterification reaction between oleic acid and trimethylolpropane: a simplified
model for multi-substrate multi-product ping-pong mechanisms, Biotechnol. Prog. 29 (2013)
1422–1429.
[40] P. Pires-Cabral, M. Fonseca, S. Ferreira-Dias, Synthesis of etyl butyrate in organic media
catalyzed by Candida rugosa lipase immobilized in polyurethane foams: A kinetic study,
Biochem. Eng. J. 43 (2009) 327-332.
[41] G.D. Yadav, P.S. Lathi, Kinetics and mechanism of synthesis of butyl isobutyrate over
immobilized lipase, Biochem. Eng. J. 16 (2003) 245-252.
[42] M. Firdaus, M. Yusoff, X. Xu, Z.Guo, Comparison of fatty acid methyl and ethyl esters as
biodiesel base stock: a review on processing and production requirements, J. Am. Oil Chem.
Soc. 91 (2014) 525–531.
14

[43] G.H. Huang, F. Chen, D. Wei, X. Wu Zhang, G. Chen, Biodiesel production by microalgal
biotechnology, Appl. Energ. 87 (2010) 38–46.
[44] F. Kartal, M. Janssen, F. Hollmann, R. Sheldon, Improved esterification activity of
Candida rugosa lipase in organic solvent by immobilization as cross-linked enzyme aggregates
(CLEAs), J. Mol. Catal. B-Enzym. 71 (2011) 85-89.
15

Fig 1
Fig 2
16

Fig. 3.
17

Fig. 4a
Fig. 4b
18

Fig 5a
Fig 5b
19

Fig 6.a
Fig 6.b
20

Fig 7
21

Table 1.
Efficiency of immobilization in terms of enzyme coupling yields, ηenz and activity coupling
yields ηact
Crude lipase Enzyme ηenz (%)
Free lipase
specific
activity
(U/mg of
protein )
Imobilised
ηact(%)
loading
(mg/g
loading
(mg
lipase specific
activity (U/mg
of protein )
support)
protein/g
support)
500
65
65.5
308
64,7
21
Table 2.
Efficiency of immobilization (ηenz and ηact) of C. rugosa lipase on different supports after 1 h
Support material
SBA 15 [18]
Titania
Zirconia [18]
Alumina [19]
aspecific surface area
ηenz (%)
80
65.5
42
Spa (m2 g-1) ηact
641
57.4
14
29
21
18
24
32
7
Table 3.
Kinetic constants of C. rugosa lipase before and after immobilization determined by hydrolysis
of p-NP esters
Free lipase
Immobilized lipase
Supstrate
Vmax (U/mg) Km (mM)
Vmax (U/mg) Km (mM)
p-NPP (C16)
p-NPL (C12)
p-NPC (C8)
p-NPB (C4)
410.6
1279
557
0.405
0.243
0.237
0.247
51
0.208
0.202
1.644
2.012
354
271
238
683
Table 4.
Values of kinetic constants from ping-pong bi-bi model with alcohol inhibition
Parameter
Value
26.36
0.200
0.522
0.644
Vmax (µmol min-1g-1)
KAl (moldm−3 )
KAc (moldm−3 )
Ki,Al (moldm−3 )
22
