A FACILE ONE POT SYNTHESIS OF PYRANO[2,3-
c]PYRAZOLE DERIVATIVES UNDER MICROWAVE
IRRADIATION
Jian-Feng Zhou a , Shu-Jiang Tu b , Hui-Qin Zhu a & San-Jun Zhi a
a Department of Chemistry, Huaiyin Normal College, Huaian, 223001, P.R. China
b Department of Chemistry, Xuzhou Normal University, Xuzhou, 221009, P.R. China
Published online: 16 Aug 2006.
To cite this article: Jian-Feng Zhou , Shu-Jiang Tu , Hui-Qin Zhu & San-Jun Zhi (2002) A FACILE ONE POT SYNTHESIS OF
PYRANO[2,3-c]PYRAZOLE DERIVATIVES UNDER MICROWAVE IRRADIATION, Synthetic Communications: An International Journal
for Rapid Communication of Synthetic Organic Chemistry, 32:21, 3363-3366, DOI: 10.1081/SCC-120014044
To link to this article: http://dx.doi.org/10.1081/SCC-120014044
PLEASE SCROLL DOWN FOR ARTICLE
Taylor & Francis makes every effort to ensure the accuracy of all the information (the “Content”) contained
in the publications on our platform. However, Taylor & Francis, our agents, and our licensors make no
representations or warranties whatsoever as to the accuracy, completeness, or suitability for any purpose of the
Content. Any opinions and views expressed in this publication are the opinions and views of the authors, and
are not the views of or endorsed by Taylor & Francis. The accuracy of the Content should not be relied upon and
should be independently verified with primary sources of information. Taylor and Francis shall not be liable for
any losses, actions, claims, proceedings, demands, costs, expenses, damages, and other liabilities whatsoever
or howsoever caused arising directly or indirectly in connection with, in relation to or arising out of the use of
the Content.
This article may be used for research, teaching, and private study purposes. Any substantial or systematic
reproduction, redistribution, reselling, loan, sub-licensing, systematic supply, or distribution in any
form to anyone is expressly forbidden. Terms & Conditions of access and use can be found at http://
www.tandfonline.com/page/terms-and-conditions

MARCEL DEKKER, INC. • 270 MADISON AVENUE • NEW YORK, NY 10016
©2002 Marcel Dekker, Inc. All rights reserved. This material may not be used or reproduced in any form without the express written permission of Marcel Dekker, Inc.
SYNTHETIC COMMUNICATIONS
Vol. 32, No. 21, pp. 3363–3366, 2002
A FACILE ONE POT SYNTHESIS OF
PYRANO[2,3-c]PYRAZOLE DERIVATIVES
UNDER MICROWAVE IRRADIATION
1,
2
Shu-JiangTu, Hui-Qin Zhu,1
*
Jian-FengZhou,
and San-Jun Zhi1
1Department of Chemistry, Huaiyin Normal College,
Huaian 223001, P.R. China
2Department of Chemistry, Xuzhou Normal University,
Xuzhou, 221009, P.R. China
ABSTRACT
A series of substituted pyrano[2,3-c]pyrazole derivatives were
synthesized by the one pot reaction of aromatic aldehydes,
malononitrile and 3-methyl-1-phenyl-2-pyrazolin-5-one under
microwave irradiation in good yields.
Polyfunctionalized 4H-pyrans are a common structural unit in a
number of natural products,[1] 4H-pyrans ring can be transformed to pyridine
systems related to pharmacologically important calcium antagonists of the
DHP type.[2–4] Substituted pyrazoles and condensed pyrazoles are important
*Corresponding author. E-mail: jfzhou@xinhuanet.com
3363
DOI: 10.1081/SCC-120014044
Copyright & 2002 by Marcel Dekker, Inc.
0039-7911 (Print); 1532-2432 (Online)
www.dekker.com

MARCEL DEKKER, INC. • 270 MADISON AVENUE • NEW YORK, NY 10016
©2002 Marcel Dekker, Inc. All rights reserved. This material may not be used or reproduced in any form without the express written permission of Marcel Dekker, Inc.
3364
ZHOU ET AL.
as pharmaceuticals[5,6] and biodegradable agrochemicals.[7,8] However, the
synthesis of variety of substituted condensed pyrano[2,3-c]pyrazole deriva-
tives were carried out by traditional heating with long time.[9,10]
Recently, the rate enhancement and wide applicability of microwave
heating organic synthesis has been reviewed.[11,12] In our laboratory, we have
researchered a facile synthesis of arylidenecyclo-alka[b]2-amino-4-aryl-3-
cyano-4H-pyrans by the one pot reaction of malononitrile with 2,4-bisaryli-
denecyclopentanone or 2,6-bisarylidenecyclohexanone using piperidine as
catalyst under microwave irradiation.[13] In this paper, we would like to report
the synthesis of substituted condensed pyrano[2,3-c]pyrazole derivatives by
the one pot reaction of aromatic aldehydes, malononitrile and 3-methyl-1-
phenyl-2-pyrazolin-5-one under microwave irradiation. The reactions were
generally finished in 2–8 min with good yields and easy work-up (Table 1).
The synthetic route is shown as following (Sch. 1):
All of title compounds were characterized on the base of spectral data
and elemental analysis. Also the product of 4d were further confirmed by
MS spectra.
Table 1. The Reaction Times and Yields of Compounds 4a–f
Reaction
Time (min)
Compounds
Ar
Yield (%)*
4a
4b
4c
4d
4e
4f
C6H5
4-ClC6H4
4-BrC6H4
4-O2NC6H4
3-O2NC6H4
4-CH3OC6H4
8
5
5
3
3
2
61
91
80
75
73
66
*Yields of the isolated products.
Scheme 1.

MARCEL DEKKER, INC. • 270 MADISON AVENUE • NEW YORK, NY 10016
©2002 Marcel Dekker, Inc. All rights reserved. This material may not be used or reproduced in any form without the express written permission of Marcel Dekker, Inc.
PYRANO[2,3-c]PYRAZOLE DERIVATIVES
EXPERIMENTAL
3365
Melting points were determined in open capillaries and uncorrected.
1
IR spectra were recorded on a Nicolet FT-IR 5DX instrument. H NMR
were measured on a Bruker 300 MHz spectrometer in CDCl3 with TMS as
internal standard. MS spectra were recorded on a VGZAB-HS (FAB).
Elemental analyzer were determined using Perkin-Elmer 240 C elemental
analyzer. The reactions were carried out with a modified commercial micro-
wave oven (Sanle WP650D 650 w) under atmospheric pressure.
General Procedure for Pyrano[2,3-c]pyrazole Derivatives
Into an Erlenmeyer flask (25 mL) equipped with reflux condenser were
introduced the aromatic aldehyde 1 (1 mmol), malononitrile 2 (1 mmol),
3-methyl-2-phenyl-2-pyrazolin-5-one 3 (1 mmol), dry ethanol (3 mL), and
piperidine (0.05 mL). After irradiation with microwaves for 2–8 min
(monitored by TLC), the reaction mixture was cooled. The precipitate
was collected by suction filtration and washed with cold ethanol. The crude
product was recrystallized from ethanol to give a pure sample. Specific
details on each product are as follows:
4a: White solid, m.p. 168–170ꢀC (167–168ꢀC).[10] 1H NMR (CD3Cl) ꢀ:
1.94 (s, 3H, CH3), 4.69 (s, 1H, 4-H), 4.74 (br, s, 2H, NH2), 7.75–7.31
(m, 10H, ArH). IR (KBr): 3450, 3320, 2200, 1660, 1590 cmꢁ1. Anal. calcd.
for C20H16N4O (%): C, 60.98; H, 4.88; N, 17.07. Found: C, 60.70; H, 4.84;
N, 16.95.
4b: White solid, m.p. 174–175ꢀC (186–187ꢀC).[10] 1H NMR (CD3Cl)
ꢀ: 1.95 (s, 3H, CH3), 4.68 (s, 1H, 4-H), 4.75 (br, s, 2H, NH2), 7.78–7.33
(m, 9H, ArH). IR (KBr): 3420, 3360, 2200, 1680, 1600 cmꢁ1. Anal. calcd. for
C20H15ClN4O (%): C, 55.17; H, 4.14; N, 15.45. Found: C, 54.95; H, 4.10;
N, 15.35.
4c: White solid, m.p. 183–184ꢀC (184–185ꢀC).[10] 1H NMR (CD3Cl)
ꢀ: 1.94 (s, 3H, CH3), 4.70 (s, 1H, 4-H), 4.78 (br, s, 2H, NH2), 7.71–7.30
(m, 9H, ArH). IR (KBr): 3420, 3360, 2200, 1680, 1600 cmꢁ1. Anal. calcd. for
C20H15BrN4O (%): C, 58.68; H, 3.67; N, 13.69. Found: C, 58.45; H, 3.61;
N, 15.23.
4d: White solid, m.p. 194–196ꢀC. H NMR (CD3Cl) ꢀ: 1.93 (s, 3H,
1
CH3), 4.77 (s, 1H, 4-H), 4.84 (br, s, 2H, NH2), 8.20–7.35 (m, 9H, ArH).
IR (KBr): 3420, 3330, 2200, 1680, 1600 cmꢁ1. Ms m/e: 373 (m þ 1). Anal.
calcd. for C20H15N5O3 (%): C, 64.34; H, 4.02; N, 18.77. Found: C, 64.02;
H, 3.95; N, 18.66.

MARCEL DEKKER, INC. • 270 MADISON AVENUE • NEW YORK, NY 10016
©2002 Marcel Dekker, Inc. All rights reserved. This material may not be used or reproduced in any form without the express written permission of Marcel Dekker, Inc.
3366
ZHOU ET AL.
4e: White solid, m.p. 188–190ꢀC (178–179ꢀC).[10] 1H NMR (CD3Cl)
ꢀ: 1.93 (s, 3H, CH3), 4.76 (s, 1H, 4-H), 4.88 (br, s, 2H, NH2), 8.20–7.34
(m, 9H, ArH). IR (KBr): 3420, 3330, 2200, 1680, 1600 cmꢁ1. Anal. calcd. for
C20H15N5O3 (%): C, 64.34; H, 4.02; N, 18.77. Found: C, 64.01; H, 3.95;
N, 18.64.
4f: White solid, m.p. 170–172ꢀC (177–178ꢀC).[10] 1H NMR (CD3Cl)
ꢀ: 1.92 (s, 3H, CH3), 4.68 (s, 1H, 4-H), 4.76 (br, s, 2H, NH2), 7.63–7.28
(m, 9H, ArH). IR (KBr): 3450, 3320, 2200, 1660, 1600 cmꢁ1. Anal. calcd. for
C20H18N4O2 (%): C, 70.39; H, 5.03; N, 18.87. Found: C, 70.02; H, 4.99;
N, 18.62.
REFERENCES
1. Hatakeyama, S.; Ochi, N.; Numata, H.; Takano, S. J. Chem. Soc.,
Chem. Communication 1988, 1202.
2. Ciller, J.A.; Martin, N.; Seoane, C.; Soto, J. J. Chem. Soc., Perkin
Trans. (1) 1985, 2581.
3. Marugan, M. M.; Martin, N.; Seoane, C.; Soto, J. Liebigs, Ann. Chem.
1989, 145.
4. Gonzalez, R.; Martin, N.; Seoane, C.; Macro, J.L.; Albert, A.;
Cano, F.H. Tetrahedron Lett. 1992, 33, 3809.
5. Novinson, T.; Miller, J.P.; Scholten, M.; Robins, R.K.; Simon, L.N.;
O’Brien, D.E.; Meyer, R.B. J. Med. Chem. 1975, 18, 460.
6. Senga, K.; Novinson, T.; Springer, R.H.; Rao, R.P.; O’Brien, D.E.;
Wilson, R.K. J. Med. Chem. 1975, 18, 312.
7. Wellinga, K.; Grosscurt, A.C.; Van, H.R.J. Agric. Food Chem. 1977,
25, 987.
8. Grosscurt, A.C.; Van, H.R.; Wellinga, K. Agric. Food Chem. 1979,
27, 406.
9. Monamed, Y.A.; Zahran, M.A.; Ali, M.M.; El-Agrody, A.M.; El-Said,
U.H. J. Chem. Res.(s), 1995, 22.
10. Sharanina, L.D.; Promonenkov, V.K.; Marshtupa, V.P.; Pashchenko,
A.V.; Puzanova, Y.A.; Klyuev, N.A.; Gusev, L.F.; Gnatnina, A.P.
Khim. Geterotsikl. Soedin 1982, 801.
11. Caddick, S. Tetrahedron 1995, 51, 10403.
12. Galema, S.A. Chem. Soc. Rev. 1997, 26, 233.
13. Zhou, J.-F.; Tu, S.-J.; Feng, J.-C. J. Chem. Res. (s) 2001, 268.
Received in Japan June 1, 2001
