(entry 6) had a marked effect on the d.r. value of the reaction,
the ee value (6%) was unacceptable.
the natural anticancer agent (+)-trans-dihydrolycoricidine
(6).
From these results (Table 1, entries 1–6) we hypothesized
that to achieve high ee and d.r. values, the use of 13c in
conjunction with a bulky chiral cinchona base might be
required. We therefore investigated a series of combinations
of chiral secondary amines in the presence of a bulky basic
tertiary amine cocatalysts with stunning results. While neither
the prolinol catalyst 13c/13d nor the quinidine 16a or quinine
16b alone provided significant turnover, we were delighted to
find that dual catalysis provided 18a in 48–50% yield upon
isolation, and also now with high d.r. values (> 20:1) and
greater than 90% ee (entries 7 and 8). The absolute stereo-
chemistry of the product (see below) proved to be governed
only by 13c, with either enantiomer of the quinine increasing
the selectivity on the aldol reaction alone (d.r.). Switching to
the secondary amine antipode 13d yielded ent-18a (compare
entries 7 and 9) in similar yield and stereoselectivity as before.
Finally, the same process conducted on the methylenedioxy-
substituted cinnamaldehyde 11a, available in one step from
piperonal,[8] proved even more stereoselective and the desired
cyclohexane ent-17a (entry 10) was isolated in 56% yield and
with greater than 98% ee. The reaction also proved highly
effective on scale up (65% yield upon isolation), thus
providing reliable access to greater than 500 mg quantities
of the desired stereoisomer ent-17a (entry 11).
The absolute configuration of ent-17a was determined as
depicted in Scheme 3. The azido group was reduced and the
resulting cyclohexylamine protected in situ with DMDC as
the methoxycarbonylamino (Moc) derivative 19. Reduction
of the 4-oxo group to the C4 equatorial alcohol and
bis(benzoylation) of the resulting 2,4-diol with 4-bromoben-
zoylchloride gave the derivative 20. A single-crystal X-ray
diffraction analysis confirmed the relative and absolute
stereochemistry as depicted (Scheme 3). Thus it was defini-
tively shown that use of the (R)-(+)-stereoisomer of prolinol
silyl ether catalyst 13d provided the Michael/aldol cyclo-
adduct having the correct absolute configuration as found in
We finally turned our attention to completion of the
synthesis of 6, as outlined in Scheme 4. The adduct ent-17a,
obtained as described (Table 1, entry 11), was converted into
the methoxycarbamate 19 as before. Treatment with meth-
Scheme 4. Reagents and conditions: Yields of isolated products are
indicated. e) MsCl (1.30 equiv), DIPEA (3.0 equiv), CH2Cl2, 08C!RT,
10 h, 95%. f) LiHAl(OtBu)3 (3.0 equiv), THF, 08C!RT, 7 h, 85%.
g) mCPBA (2.0 equiv), NaHCO3 (2.0 equiv), CH2Cl2, RT, 24 h, 22a
59%, 22b 16%. h) NaOBz (0.06 equiv), H2O, 958C, 16 h, 93%.
i) Ac2O (6.0 equiv), py, RT, 16 h, 87%. j) Tf2O (5.0 equiv), DMAP
(3.0 equiv), CH2Cl2, 08C!RT, 16 h, 52%. k) K2CO3 (0.10 equiv),
MeOH/H2O (1:9), RT, 16 h, 92%. MsCl=methanesulfonyl chloride,
mCPBA=meta-chloroperbenzoic acid, Tf=trifluoromethanesulfonyl,
THF=tetrahydrofuran.
anesulfonyl chloride in the presence of Hꢁnigꢀs base effected
dehydration to give the cyclohexanone 21 in 95% yield.
Chemoselective reduction of the carbonyl group in 21 using
lithium tri-tert-butoxyaluminium hydride gave the equatorial
alcohol 9 (85%). Epoxidation of 9 was accomplished using
mCPBA, thus yielding a mixture of the b-epoxide 22a and a-
epoxide 22b in a 4:1 ratio.[9] The epoxides could be easily
separated on silica gel and were isolated in 59% (22a) and
16% (22b) yields and independently characterized. Stereo-
selective opening of the epoxides was achieved as expect-
ed,[2 m] through either axial attack at C2 (22a) or C3 (22b),
thus giving the same 2,3,4-triol 23 in 96% yield (from 22a).
The triol derivative was protected as the triacetate 24 without
incident, and 24 cyclized following the Banwell[10] modifica-
tion of the Bischler–Napieralski reaction to give 25 in 52%
yield and greater than 98% ee (see Table S1 in the Supporting
Information). Finally, removal of the acetate protecting
groups yielded natural 6 in 92% yield from 25. Overall, 6
was obtained in nine chemical steps from 12b and 11a, with
an overall yield of 12% and greater than 98% ee. While the
absolute configuration was determined as described in
Scheme 3, optical rotation and all other spectroscopic char-
acterization data for (+)-trans-dihydrolycoricidine (6) were in
accord with published values (see Tables S2 and S3 in the
Supporting Information).[4]
Scheme 3. Reagents and conditions: Yields of isolated products are
indicated.[11] a) 13d (10 mol%) and 16a (10 mol%), CH2Cl2, RT, 24 h,
65%. b) DMDC (3.0 equiv), H2, 10% Pd/C (0.075 equiv), 50 psi,
MeOH, RT, 16 h, 82%. c) Me4NHB(OAc)3 (4.0 equiv), acetonitrile/
AcOH (96:4), RT, 12 h, 77%. d) p-BrBzCl (3.0 equiv), DMAP
(0.10 equiv), py, 08C, 8 h, 71%. Bz=benzoyl, DMAP=4-dimethyl-
aminopyridine, DMDC=dimethyl dicarbonate.
